CHRYSLER 200 2012 1.G Warranty Booklet
Manufacturer: CHRYSLER, Model Year: 2012, Model line: 200, Model: CHRYSLER 200 2012 1.GPages: 60, PDF Size: 2.1 MB
Page 21 of 60
Perform Maintenance At 91,000 km or 42 Months
❏Change the engine oil and oil filter.Under no circumstances should the oil change interval
exceed 13,000 km or 6 months whichever occurs first.*
❏Rotate tires, rotate at the first sign of irregular wear even if it occurs prior to this service.
* Oil changes that are prompted by the oil change indicator system prior to this schedule mainte-
nance interval can be recorded in the oil change log section.
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler Canada Retailer
CHRYSLER
RETAILERSTAMP
Perform Maintenance At 104,000 km or 48 Months
❏Change the engine oil and oil filter.Under no circumstances should the oil change interval
exceed 13,000 km or 6 months whichever occurs first.*
❏Rotate tires, rotate at the first sign of irregular wear even if it occurs prior to this service.
❏Inspect the brake linings; replace if necessary.
❏Adjust the parking brake on vehicles equipped with four-wheel disc brakes.
❏Replace the air conditioning filter. (if equipped)
❏Inspect the front suspension components, tie rod ends and boot seals; replace if necessary.
❏Replace the engine air filter.
❏Replace the spark plugs on 2.4L engines.
❏Change the automatic transmission fluid and filter if using your vehicle for any of the follow-
ing: police, taxi, fleet or frequent trailer towing.
* Oil changes that are prompted by the oil change indicator system prior to this schedule mainte-
nance interval can be recorded in the oil change log section.
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler Canada Retailer
CHRYSLER
RETAILERSTAMP
19
Page 22 of 60
Perform Maintenance At 117,000 km or 54 Months
❏Change the engine oil and oil filter.Under no circumstances should the oil change interval
exceed 13,000 km or 6 months whichever occurs first.*
❏Rotate tires, rotate at the first sign of irregular wear even if it occurs prior to this service.
❏Inspect the CV joints.
❏Inspect the exhaust system.
* Oil changes that are prompted by the oil change indicator system prior to this schedule mainte-
nance interval can be recorded in the oil change log section.
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler Canada Retailer
CHRYSLER
RETAILERSTAMP
Perform Maintenance At 130,000 km or 60 Months
❏Change the engine oil and oil filter.Under no circumstances should the oil change interval
exceed 13,000 km or 6 months whichever occurs first.*
❏Rotate tires, rotate at the first sign of irregular wear even if it occurs prior to this service.
❏Inspect the engine air filter if using your vehicle in dusty or off-road conditions; replace if nec-
essary.
❏Inspect the brake linings; replace if necessary.
❏Replace the air conditioning filter. (if equipped)
❏Inspect the front suspension components, tie rod ends and boot seals; replace if necessary.
❏Flush and replace the engine coolant at 60 months if not done at 169,000 km.
* Oil changes that are prompted by the oil change indicator system prior to this schedule mainte-
nance interval can be recorded in the oil change log section.
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler Canada Retailer
CHRYSLER
RETAILERSTAMP
20
Page 23 of 60
Perform Maintenance At 143,000 km or 66 Months
❏Change the engine oil and oil filter.Under no circumstances should the oil change interval
exceed 13,000 km or 6 months whichever occurs first.*
❏Rotate tires, rotate at the first sign of irregular wear even if it occurs prior to this service.
* Oil changes that are prompted by the oil change indicator system prior to this schedule mainte-
nance interval can be recorded in the oil change log section.
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler Canada Retailer
CHRYSLER
RETAILERSTAMP
Perform Maintenance At 156,000 km or 72 Months
❏Change the engine oil and oil filter.Under no circumstances should the oil change interval
exceed 13,000 km or 6 months whichever occurs first.*
❏Rotate tires, rotate at the first sign of irregular wear even if it occurs prior to this service.
❏Inspect the brake linings; replace if necessary.
❏Adjust the parking brake on vehicles equipped with four-wheel disc brakes.
❏Replace the air conditioning filter. (if equipped)
❏Inspect the CV joints.
❏Inspect the exhaust system.
❏Inspect the front suspension components, tie rod ends and boot seals; replace if necessary.
❏Replace the engine air filter.
❏Replace the spark plugs on 2.4L engines.
❏Replace the spark plugs on 3.6L engines.
❏Inspect the PCV valve; replace if necessary.
* Oil changes that are prompted by the oil change indicator system prior to this schedule mainte-
nance interval can be recorded in the oil change log section.
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler Canada Retailer
CHRYSLER
RETAILERSTAMP
21
Page 24 of 60
Perform Maintenance At 169,000 km or 78 Months
❏Change the engine oil and oil filter.Under no circumstances should the oil change interval
exceed 13,000 km or 6 months whichever occurs first.*
❏Rotate tires, rotate at the first sign of irregular wear even if it occurs prior to this service.
❏Flush and replace the engine coolant if not done at 60 months.
* Oil changes that are prompted by the oil change indicator system prior to this schedule mainte-
nance interval can be recorded in the oil change log section.
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler Canada Retailer
CHRYSLER
RETAILERSTAMP
Perform Maintenance At 182,000 km or 84 Months
❏Change the engine oil and oil filter.Under no circumstances should the oil change interval
exceed 13,000 km or 6 months whichever occurs first.*
❏Rotate tires, rotate at the first sign of irregular wear even if it occurs prior to this service.
❏Inspect the engine air filter if using your vehicle in dusty or off-road conditions; replace if nec-
essary.
❏Inspect the brake linings; replace if necessary.
❏Replace the air conditioning filter. (if equipped)
❏Inspect the front suspension components, tie rod ends and boot seals; replace if necessary.
* Oil changes that are prompted by the oil change indicator system prior to this schedule mainte-
nance interval can be recorded in the oil change log section.
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler Canada Retailer
CHRYSLER
RETAILERSTAMP
22
Page 25 of 60
Perform Maintenance At 195,000 km or 90 Months
❏Change the engine oil and oil filter.Under no circumstances should the oil change interval
exceed 13,000 km or 6 months whichever occurs first.*
❏Rotate tires, rotate at the first sign of irregular wear even if it occurs prior to this service.
❏Inspect the CV joints.
❏Inspect the exhaust system.
❏Change the automatic transmission fluid and filter.
❏Inspect the accessory drive belt; replace if necessary.
* Oil changes that are prompted by the oil change indicator system prior to this schedule mainte-
nance interval can be recorded in the oil change log section.
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler Canada Retailer
CHRYSLER
RETAILERSTAMP
Perform Maintenance At 208,000 km or 96 Months
❏Change the engine oil and oil filter.Under no circumstances should the oil change interval
exceed 13,000 km or 6 months whichever occurs first.*
❏Rotate tires, rotate at the first sign of irregular wear even if it occurs prior to this service.
❏Inspect the brake linings; replace if necessary.
❏Adjust the parking brake on vehicles equipped with four-wheel disc brakes.
❏Replace the air conditioning filter. (if equipped)
❏Inspect the front suspension components, tie rod ends and boot seals; replace if necessary.
❏Replace the engine air filter.
❏Replace the spark plugs on 2.4L engines.
* Oil changes that are prompted by the oil change indicator system prior to this schedule mainte-
nance interval can be recorded in the oil change log section.
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler Canada Retailer
CHRYSLER
RETAILERSTAMP
23
Page 26 of 60
Perform Maintenance At 221,000 km or
102 Months
❏Change the engine oil and oil filter.Under no circumstances should the oil change interval
exceed 13,000 km or 6 months whichever occurs first.*
❏Rotate tires, rotate at the first sign of irregular wear even if it occurs prior to this service.
* Oil changes that are prompted by the oil change indicator system prior to this schedule mainte-
nance interval can be recorded in the oil change log section.
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler Canada Retailer
CHRYSLER
RETAILERSTAMP
Perform Maintenance At 234,000 km or
108 Months
❏Change the engine oil and oil filter.Under no circumstances should the oil change interval
exceed 13,000 km or 6 months whichever occurs first.*
❏Rotate tires, rotate at the first sign of irregular wear even if it occurs prior to this service.
❏Inspect the engine air filter if using your vehicle in dusty or off-road conditions; replace if nec-
essary.
❏Inspect the brake linings; replace if necessary.
❏Replace the air conditioning filter. (if equipped)
❏Inspect the CV joints.
❏Inspect the exhaust system.
❏Inspect the front suspension components, tie rod ends and boot seals; replace if necessary.
* Oil changes that are prompted by the oil change indicator system prior to this schedule mainte-
nance interval can be recorded in the oil change log section.
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler Canada Retailer
CHRYSLER
RETAILERSTAMP
24
Page 27 of 60
Perform Maintenance At 247,000 km or
114 Months
❏Change the engine oil and oil filter.Under no circumstances should the oil change interval
exceed 13,000 km or 6 months whichever occurs first.*
❏Rotate tires, rotate at the first sign of irregular wear even if it occurs prior to this service.
* Oil changes that are prompted by the oil change indicator system prior to this schedule mainte-
nance interval can be recorded in the oil change log section.
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler Canada Retailer
CHRYSLER
RETAILERSTAMP
25
Page 28 of 60
OIL CHANGE LOG
SERVICE # 1
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler
Canada Retailer
SERVICE # 2
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler
Canada Retailer
SERVICE # 3
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler
Canada Retailer
SERVICE # 4
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler
Canada Retailer
SERVICE # 5
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler
Canada Retailer
SERVICE # 6
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler
Canada Retailer
SERVICE # 7
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler
Canada Retailer
SERVICE # 8
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler
Canada Retailer
SERVICE # 9
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler
Canada Retailer
SERVICE # 10
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler
Canada Retailer
SERVICE # 11
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler
Canada Retailer
SERVICE # 12
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler
Canada Retailer
Page 29 of 60
OIL CHANGE LOG
SERVICE # 13
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler
Canada Retailer
SERVICE # 14
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler
Canada Retailer
SERVICE # 15
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler
Canada Retailer
SERVICE # 16
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler
Canada Retailer
SERVICE # 17
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler
Canada Retailer
SERVICE # 18
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler
Canada Retailer
SERVICE # 19
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler
Canada Retailer
SERVICE # 20
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler
Canada Retailer
SERVICE # 21
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler
Canada Retailer
SERVICE # 22
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler
Canada Retailer
SERVICE # 23
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler
Canada Retailer
SERVICE # 24
Odometer Reading
Date
Repair Order No.
Signature of authorized Chrysler
Canada Retailer
Page 30 of 60
À NOS CLIENTS
Ce livret énumère les garanties limitées, les contrats de service optionnels et le calendrier des services
d’entretien qui protègent votre véhicule neuf. On y explique précisément ce qui est couvert, la durée
de chaque garantie et ce qu’il faut faire pour que lesdites garanties demeurent en vigueur. Veuillez lire
les garanties, ainsi que les détails et les renseignements utiles se trouvant dans ce livret.
VEUILLEZ CONSERVER CE LIVRET DANS LE VÉHICULE.
Dans ce livret, le terme « concessionnaire Chrysler » désigne tout concessionnaire autorisé qui vend
et fait l’entretien et la réparation des véhicules Chrysler, Jeep
MDou Dodge.
« Chrysler » et « Chrysler Canada » désignent Chrysler Canada Inc.
Les « pièces Chrysler » comprennent les pièces de marque Mopar
MDet AutoparMCconçues par
Chrysler Group LLC pour les véhicules Chrysler, Jeep
MDet Dodge.
Chrysler et Dodge sont des marques de commerce déposées de Chrysler Canada Inc., une filiale en
propriété exclusive de Chrysler Group LLC. Jeep est une marque de commerce déposée de Chrysler
Group LLC, utilisée sous licence par Chrysler Canada Inc. Mopar est une marque de commerce
déposée de Chrysler Group LLC. Autopar est une marque de commerce de Chrysler Canada Inc.
TABLE DES MATIÈRES
Énoncé de confidentialité....................................2
Renseignements sur les garanties................................3
Vos droits et responsabilités...................................3
Renseignements sur les garanties................................4
Garantie de base 3/60.......................................4
Garantie 5/100 du groupe motopropulseur...........................4
Garantie 5/100 du moteur diesel.................................5
Garantie 8/160 du système hybride..............................5
Garantie anticorrosion.......................................6
Garanties à l’égard du système antipollution . . .......................6
Exclusions des garanties......................................7
Services en vertu de la garantie.................................9
Autres points d’intérêt.......................................9
Service à la clientèle.......................................10
Programme d’arbitrage......................................11
Programme d’assistance routière 5/100...........................11
Contrats de service optionnels.................................14
Service d’entretien........................................17
1
