Page 24 of 72
1. POWERTRAIN PLANS*
Powertrain plans complement the factory powertrain warranty by provid-
ing enhanced roadside coverage and car rental allowance if your vehicle is
not drivable and must be kept overnight. Certain plans also provide
additional distance coverage.
Major components covered are:
• engine •transmission •front-wheel drive •rear-wheel drive •4-wheel
drive (4x4) •all-wheel drive vehicles
2. GOLDPLANS*
Each plan provides full mechanical repair protection to non-powertrain
(Gold) components. Certain plans also provide full mechanical protection
against powertrain component repairs beyond your vehicle’s Powertrain
Warranty coverage. Contracts are available with or without a deductible.
Major components covered are:
• steering •air conditioning •engine cooling and fuel •front suspension
• rear suspension •electrical •hydraulic brake components •anti-lock
brakes
* Maximum terms available on new vehicles registered in Canada only.
3. GOLDPLUSPLANS*
The most complete protection available for your new vehicle is a Gold
Plus Service Contract which combines the benefits of Gold component
coverage (see GoldPlans), plus, the most important vehicle maintenance
functions:
• Engine oil and oil filter changes
• Tire rotation every other service
• Peace of Mind motoring with Tire Road Hazard Protection which
provides full, or pro-rata, replacement of the original four tires, or
their repair
• Rental car allowance for same-day warranty repairs - your vehicle
need not be kept overnight before eligibility for the rental allow-
ance is met
26
OPTIONAL DAIMLERCHRYSLER CANADA SERVICE CONTRACTS
Page 33 of 72
❏Change the engine oil and engine oil filter.
❏ Rotate tires.
❏ Inspect the brake linings, replace if necessary.
❏ Inspect the CV joints.
❏ Inspect the exhaust system.
❏ Inspect the front suspension, tie rod ends and boot seals, replace if necessary.
❏ Replace the engine air cleaner filter.
❏ Inspect the transfer case fluid.
❏ Replace the top row of spark plugs on 4.7L engines. **
❏ Replace the spark plugs on 3.7L and 5.7L engines.
❏ Change the transfer case fluid if using your vehicle for any of the following:
police, taxi, fleet, off-road or frequent trailer towing.
❏ Change the manual transmission fluid if using your vehicle for any of the fol-
lowing: trailer towing, snowplowing, heavy loading, taxi, police, delivery ser-
vice (commercial service), off-road, desert operation or more then 50% of your
driving is at sustained high speeds during hot weather, above 32C°.
❏ Drain and refill automatic transmission fluid, change filter (3.7L engines).
❏ Drain and refill automatic transmission fluid and change main sump filter and
spin-on cooler return filter (4.7L/5.7L engines only).
❏ Replace accessory drive belt(s).
** Vehicles built with the 4.7L engine are equipped with sixteen spark plugs, one
set is located on the top of the engine under the coils and the second set is lo-
cated on the side of the engine. The spark plugs located under the coils are a stan-
dard plug and must be change every 50,000 kilometres. The spark plugs located
on the side of the engine are a premium plug and must be changed every
170,000 kilometres.
Perform Maintenance Every
200,000 km or 120 Months
Odometer Reading
Date
Repair Order No.
DAIMLERCHRYSLER
RETAILERSTAMP
Signature of authorized DaimlerChrysler Canada Retailer
................................................................................................
Page 34 of 72
Perform Maintenance Every
200,000 km or 120 Months
❏ Change the engine oil and engine oil filter.
❏ Rotate tires.
❏ Inspect the brake linings, replace if necessary.
❏ Inspect the CV joints.
❏ Inspect the exhaust system.
❏ Inspect the front suspension, tie rod ends and boot seals, replace if necessary.
❏ Replace the engine air cleaner filter.
❏ Inspect the transfer case fluid.
❏ Replace the top row of spark plugs on 4.7L engines. **
❏ Replace the spark plugs on 3.7L and 5.7L engines.
❏ Change the transfer case fluid if using your vehicle for any of the following: police, taxi, fleet, off-road
or frequent trailer towing.
❏ Change the manual transmission fluid if using your vehicle for any of the following: trailer towing,
snowplowing, heavy loading, taxi, police, delivery service (commercial service), off-road, desert
operation or more then 50% of your driving is at sustained high speeds during hot weather, above 32C°.
❏ Drain and refill automatic transmission fluid, change filter (3.7L engines).
❏ Drain and refill automatic transmission fluid and change main sump filter and spin-on cooler return filter
(4.7L/5.7L engines only).
❏ Replace accessory drive belt(s).
** Vehicles built with the 4.7L engine are equipped with sixteen spark plugs, one set is located on the top of the
engine under the coils and the second set is located on the side of the engine. The spark plugs located under the
coils are a standard plug and must be change every 50,000 kilometres. The spark plugs located on the side of the
engine are a premium plug and must be changed every 170,000 kilometres.
Perform Maintenance
Every
120 Months or
200,000 km
Odometer Reading
DateRetailer Copy
Remove and attach to Repair Order
................................................................................................
Page 41 of 72
❏Change the engine oil and engine oil filter.
❏ Rotate tires.
❏ If using your vehicle for any of the following: Dusty or
off-road conditions. Inspect the engine air cleaner filter,
replace if necessary.
❏ Inspect the brake linings, replace if necessary.
❏ Inspect the CV joints.
❏ Inspect the exhaust system.
❏ Inspect the front suspension, tie rod ends and boot seals,
replace if necessary.
Perform Maintenance Every
160,000 km or 96 Months
Odometer Reading
Date
Repair Order No.
DAIMLERCHRYSLER
RETAILERSTAMP
Signature of authorized DaimlerChrysler Canada Retailer
................................................................................................
Page 42 of 72
Perform Maintenance Every
160,000 km or 96 Months
❏ Change the engine oil and engine oil filter.
❏ Rotate tires.
❏ If using your vehicle for any of the following: Dusty or off-road conditions. Inspect
the engine air cleaner filter, replace if necessary.
❏ Inspect the brake linings, replace if necessary.
❏ Inspect the CV joints.
❏ Inspect the exhaust system.
❏ Inspect the front suspension, tie rod ends and boot seals, replace if necessary.Perform Maintenance
Every
96 Months or
160,000 km
Odometer Reading
DateRetailer Copy
Remove and attach to Repair Order
................................................................................................
Page 49 of 72
❏Change the engine oil and engine oil filter.
❏ Rotate tires.
❏ If using your vehicle for any of the following: Dusty or
off-road conditions. Inspect the engine air cleaner filter,
replace if necessary.
❏ Inspect the brake linings, replace if necessary.
❏ Inspect the front & rear axle fluid, change if using your
vehicle for police, taxi, fleet, off-road or frequent trailer
towing.
❏ Inspect the CV joints.
❏ Inspect the exhaust system.
❏ Inspect the front suspension, tie rod ends and boot seals,
replace if necessary.
Perform Maintenance Every
120,000 km or 72 Months
Odometer Reading
Date
Repair Order No.
DAIMLERCHRYSLER
RETAILERSTAMP
Signature of authorized DaimlerChrysler Canada Retailer
................................................................................................
Page 50 of 72
Perform Maintenance Every
120,000 km or 72 Months
❏ Change the engine oil and engine oil filter.
❏ Rotate tires.
❏ If using your vehicle for any of the following: Dusty or off-road conditions. Inspect
the engine air cleaner filter, replace if necessary.
❏ Inspect the brake linings, replace if necessary.
❏ Inspect the front & rear axle fluid, change if using your vehicle for police, taxi,
fleet, off-road or frequent trailer towing.
❏ Inspect the CV joints.
❏ Inspect the exhaust system.
❏ Inspect the front suspension, tie rod ends and boot seals, replace if necessary.Perform Maintenance
Every
72 Months or
120,000 km
Odometer Reading
DateRetailer Copy
Remove and attach to Repair Order
................................................................................................
Page 57 of 72
❏Change the engine oil and engine oil filter.
❏ Rotate tires.
❏ If using your vehicle for any of the following: Dusty or
off-road conditions. Inspect the engine air cleaner filter,
replace if necessary.
❏ Inspect the brake linings, replace if necessary.
❏ Inspect the CV joints.
❏ Inspect the exhaust system.
❏ Inspect the front suspension, tie rod ends and boot seals,
replace if necessary.
Perform Maintenance Every
80,000 km or 48 Months
Odometer Reading
Date
Repair Order No.
DAIMLERCHRYSLER
RETAILERSTAMP
Signature of authorized DaimlerChrysler Canada Retailer
................................................................................................
Page 58 of 72
Perform Maintenance Every
80,000 km or 48 Months
❏ Change the engine oil and engine oil filter.
❏ Rotate tires.
❏ If using your vehicle for any of the following: Dusty or off-road conditions. Inspect
the engine air cleaner filter, replace if necessary.
❏ Inspect the brake linings, replace if necessary.
❏ Inspect the CV joints.
❏ Inspect the exhaust system.
❏ Inspect the front suspension, tie rod ends and boot seals, replace if necessary.Perform Maintenance
Every
48 Months or
80,000 km
Odometer Reading
DateRetailer Copy
Remove and attach to Repair Order
................................................................................................
Page 65 of 72
❏Change the engine oil and engine oil filter.
❏ Rotate tires.
❏ If using your vehicle for any of the following: Dusty or
off-road conditions. Inspect the engine air cleaner filter,
replace if necessary.
❏ Inspect the brake linings, replace if necessary.
❏ Inspect the CV joints.
❏ Inspect the exhaust system.
❏ Inspect the front suspension, tie rod ends and boot seals,
replace if necessary.
Perform Maintenance Every
40,000 km or 24 Months
Odometer Reading
Date
Repair Order No.
DAIMLERCHRYSLER
RETAILERSTAMP
Signature of authorized DaimlerChrysler Canada Retailer
................................................................................................
