CHRYSLER PACIFICA 2004 1.G Owners Manual
Manufacturer: CHRYSLER, Model Year: 2004, Model line: PACIFICA, Model: CHRYSLER PACIFICA 2004 1.GPages: 361, PDF Size: 5.21 MB
Page 1 of 361
TABLE OF CONTENTSSECTIONPAGE
1INTRODUCTION.............................................................3
2THINGS TO KNOW BEFORE STARTING YOUR VEHICLE..............................9
3UNDERSTANDING THE FEATURES OF YOUR VEHICLE..............................65
4UNDERSTANDING YOUR INSTRUMENT PANEL...................................133
5STARTING AND OPERATING.................................................195
6WHAT TO DO IN EMERGENCIES..............................................249
7MAINTAINING YOUR VEHICLE...............................................265
8MAINTENANCE SCHEDULES..................................................315
9IF YOU NEED CONSUMER ASSISTANCE.........................................335
10INDEX....................................................................345
1
2
3
4
5
6
7
8
9
10
Page 2 of 361
Page 3 of 361
INTRODUCTION
CONTENTS
mIntroduction........................... 4
mHow To Use This Manual.................. 4
mWarnings And Cautions................... 6mVehicle Identification Number............... 6
mVehicle Modifications / Alterations........... 7
1
Page 4 of 361
INTRODUCTION
This manual has been prepared with the assistance of
service and engineering specialists to acquaint you with
the operation and maintenance of your new vehicle. It is
supplemented by a Warranty Information Booklet and
various customer oriented documents. You are urged to
read these publications carefully. Following the instruc-
tions and recommendations in this manual will help
assure safe and enjoyable operation of your vehicle.
NOTE: After you read the manual, it should be stored
in the vehicle for convenient reference and remain with
the vehicle when sold, so that the new owner will be
aware of all safety warnings.
When it comes to service, remember that your dealer
knows your vehicle best, has the factory-trained techni-
cians and genuine Mopartparts, and is interested in
your satisfaction.WARNING!
Engine exhaust, some of its constituents, and certain
vehicle components contain or emit chemicals
known to the State of California to cause cancer and
birth defects or other reproductive harm. In addition,
certain fluids contained in vehicles and certain prod-
ucts of component wear contain or emit chemicals
known to the State of California to cause cancer and
birth defects or other reproductive harm.
HOW TO USE THIS MANUAL
Consult the table of contents to determine which section
contains the information you desire.
The detailed index, at the rear of this manual, contains a
complete listing of all subjects.
Consult the following table for a description of the
symbols that may be used on your vehicle or throughout
this owner's manual:
4 INTRODUCTION
Page 5 of 361
INTRODUCTION 5
1
Page 6 of 361
WARNINGS AND CAUTIONS
This manual containsWARNINGSagainst operating
procedures which could result in an accident or bodily
injury. It also containsCAUTIONSagainst procedures
which could result in damage to your vehicle. If you do
not read this entire manual you may miss important
information. Observe all Warnings and Cautions.
VEHICLE IDENTIFICATION NUMBER
The vehicle identification number (VIN) is found on the
left front corner of the instrument panel, visible from
outside of the vehicle through the windshield. This
number also appears on the Automobile Information
Disclosure Label affixed to a window on your vehicle.
Save this label for a convenient record of your vehicle
identification number and optional equipment.NOTE:It is illegal to remove the VIN plate.
6 INTRODUCTION
Page 7 of 361
VEHICLE MODIFICATIONS / ALTERATIONS
WARNING!
Any modifications or alterations to this vehicle
could seriously affect its roadworthiness and safety
and may lead to an accident resulting in serious
injury or death.
INTRODUCTION 7
1
Page 8 of 361
Page 9 of 361
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
CONTENTS
mA Word About Your Keys..................11
NIgnition Key Removal...................11
NKey-In-Ignition Reminder................12
mSentry Key............................12
NReplacement Keys......................14
NSentry Key Programming.................14
NGeneral Information....................15
mIlluminated Entry System..................15
mDoor Locks............................16NManual Door Locks.....................16
NPower Door Locks.....................17
NChild Protection Door Lock...............18
mRemote Keyless Entry.....................19
NTo Unlock The Doors And Liftgate..........20
NTo Lock The Doors And Liftgate............21
NUsing The Panic Alarm..................21
NGeneral Information....................23
NTransmitter Battery Service...............23
2
Page 10 of 361
mVehicle Theft Alarm......................24
mLiftgate...............................26
NPower Liftgate Ð If Equipped.............27
mWindows.............................30
NPower Windows.......................30
mOccupant Restraints......................31
NLap/Shoulder Belts.....................32
NLap/Shoulder Belt Untwisting Procedure.....38
NSeat Belt Pretensioners...................40
NEnhanced Driver Seat Belt Reminder System
(BeltAlertŸ)..........................40
NSeat Belts And Pregnant Women............41NSeat Belt Extender......................42
NDriver And Front Passenger Supplemental
Restraint System - Airbag................43
NSide Airbags Supplemental Restraint System
(SRS) Ð If Equipped....................50
NChild Restraint........................53
mEngine Break-In Recommendations...........61
mSafety Tips............................62
NExhaust Gas..........................62
NSafety Checks You Should Make Inside The
Vehicle..............................62
NPeriodic Safety Checks You Should Make
Outside The Vehicle....................63
10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
