Page 187 of 457
INSTRUMENT CLUSTER DESCRIPTIONS
1. Voltage Light
This light monitors the electrical system voltage.
The light should turn on momentarily as the
engine is started. If the light stays on or turns on while
driving, it indicates a problem with the charging system.
Immediate service should be obtained.
2. Temperature Gauge
The temperature gauge shows engine coolant tempera-
ture. Any reading within the normal range indicates that
the engine cooling system is operating satisfactorily.
The gauge pointer will likely indicate a higher tempera-
ture when driving in hot weather, up mountain grades,
or when towing a trailer. It should not be allowed to
exceed the upper limits of the normal operating range.
CAUTION!
Driving with a hot engine cooling system could
damage your vehicle. If temperature gauge reads
ªHº, pull over in a safe area as soon as possible and
stop the vehicle. Idle the vehicle with the air condi-
tioner turned off until the pointer drops back into the
normal range. If the pointer remains on the ªHº, and
you hear continuous chimes, turn the engine off
immediately, and call for service.
UNDERSTANDING YOUR INSTRUMENT PANEL 187
4
Page 389 of 457
Cooling System
WARNING!
²When working near the radiator cooling fan, dis-
connect the fan motor lead or turn the ignition
switch to the OFF position. The fan is temperature
controlled and can start at any time the ignition
switch is in the ON position.
²You or others can be badly burned by hot coolant
or steam from your radiator. If you see or hear
steam coming from under the hood, don't open the
hood until the radiator has had time to cool. Never
try to open a cooling system pressure cap when the
radiator is hot.
Engine Coolant Checks
Check the engine coolant (antifreeze) protection every 12
months (before the onset of freezing weather, where
applicable). If coolant is dirty or rusty in appearance, the
system should be drained, flushed and refilled with fresh
coolant. Check the front of the A/C condenser for any
accumulation of bugs, leaves, etc. If dirty, clean by gently
spraying water from a garden hose vertically down the
face of the condenser.
Check the coolant recovery bottle tubing for brittle rub-
ber, cracking, tears, cuts and tightness of the connection
at the bottle and radiator. Inspect the entire system for
leaks.
With the engine at normal operating temperature (but
not running), check the cooling system pressure cap for
proper vacuum sealing by draining a small amount of
coolant from the radiator drain cock. If the cap is sealing
properly, the engine coolant (antifreeze) will begin to
MAINTAINING YOUR VEHICLE 389
7
Page 391 of 457
Adding Engine Coolant
Your vehicle has been built with an improved engine
coolant that allows extended maintenance intervals. This
coolant can be used up to 5 Years or 100,000 miles before
replacement. To prevent reducing this extended mainte-
nance period, it is important that you use the same
coolant throughout the life of your vehicle. Please review
these recommendations for using Hybrid Organic Addi-
tive Technology (HOAT) coolant.
When adding coolant, a minimum solution of 50% rec-
ommended Mopar Antifreeze/ Coolant 5 Year / 100,000
Mile Formula HOAT (Hybrid Organic Additive Technol-
ogy), or equivalent, in water should be used. Use higher
concentrations (not to exceed 70%) if temperatures below
234ÉF (237ÉC ) are anticipated.
Use only high purity water such as distilled or deionized
water when mixing the water/engine coolant solution.The use of lower quality water will reduce the amount of
corrosion protection in the engine cooling system.
Please note that it is the owner's responsibility to main-
tain the proper level of protection against freezing ac-
cording to the temperatures occurring in the area where
the vehicle is operated.
NOTE:Mixing coolant types will decrease the life of the
engine coolant and will require more frequent coolant
changes.
Cooling System Pressure Cap
The cap must be fully tightened to prevent loss of
coolant, and to insure that coolant will return to the
radiator from the coolant recovery bottle.
The cap should be inspected and cleaned if there is any
accumulation of foreign material on the sealing surfaces.
MAINTAINING YOUR VEHICLE 391
7
Page 392 of 457
WARNING!
²The warning words ªDO NOT OPEN HOTº on
the cooling system pressure cap are a safety pre-
caution. Never add coolant when the engine is
overheated. Do not loosen or remove the cap to
cool an overheated engine. Heat causes pressure to
build up in the cooling system. To prevent scald-
ing or injury, do not remove the pressure cap while
the system is hot or under pressure.
²Do not use a pressure cap other than the one
specified for your vehicle. Personal injury or en-
gine damage may result.
Disposal of Used Engine Coolant
Used ethylene glycol based engine coolant is a regulated
substance requiring proper disposal. Check with your
local authorities to determine the disposal rules for yourcommunity. To prevent ingestion by animals or children
do not store ethylene glycol based engine coolant in open
containers or allow it to remain in puddles on the
ground. If ingested by a child, contact a physician
immediately. Clean up any ground spills immediately.
Engine Coolant Level
The coolant bottle provides a quick visual method for
determining that the coolant level is adequate. With the
engine off and cold, the coolant level in the coolant
recovery bottle should be between the ranges indicated
on the bottle.
The radiator normally remains completely full, so there is
no need to remove the radiator cap unless checking for
coolant freeze point or replacing coolant. Advise your
service attendant of this. As long as the engine operating
temperature is satisfactory, the coolant bottle need only
be checked once a month.
392 MAINTAINING YOUR VEHICLE
Page 438 of 457
Adding Fuel........................... 329
Adding Washer Fluid..................142,387
Additives, Fuel......................... 327
Adjustable Pedals....................... 159
Air Conditioner Maintenance............... 383
Air Conditioning.....................251,256
Air Conditioning Controls................. 251
Air Conditioning Filter.................269,384
Air Conditioning Refrigerant............... 383
Air Conditioning System..........251,256,259,383
Air Conditioning System, Zone Control........ 252
Air Pressure, Tires....................... 304
Airbag................................ 50
Airbag Deployment....................... 62
Airbag Light...................54,55,64,79,197
Airbag Maintenance....................... 64
Airbag, Window (Side Curtain)............... 51
Alarm (Security Alarm).................... 18
Alignment and Balance.................... 311All Wheel Drive (AWD)................284,400
Alterations/Modifications, Vehicle............. 7
Antenna, Satellite Radio................... 248
Antifreeze (Engine Coolant)...........390,391,416
Disposal............................ 392
Anti-Lock Brake System (ABS)............153,288
Anti-Lock Warning Light.................. 188
Anti-Theft System........................ 18
Appearance Care........................ 401
Auto Down Power Windows................ 32
Auto Up Power Windows.................. 33
Automatic Dimming Mirror................. 86
Automatic Door Locks...................27,28
Automatic Headlights.................... 137
Automatic Oil Change Indicator..........192,202
Automatic Temperature Control (ATC)......... 259
Automatic Transaxle....................12,278
Adding Fluid......................... 418
Interlock System.....................15,280
438 INDEX
Page 444 of 457
Freeing A Stuck Vehicle................... 362
Fuel................................. 325
Adding............................. 329
Additives............................ 327
Clean Air............................ 326
Filler Cap (Gas Cap).................... 329
Gasoline............................ 325
Gauge.............................. 188
Hoses.............................. 397
Octane Rating......................325,417
Requirements......................325,416
Tank Capacity........................ 416
Fuel System Caution..................... 327
Fueling............................... 329
Fuses................................ 407
Garage Door Opener (HomeLinkt) ........... 146
Gas Cap (Fuel Filler Cap)............329,330,373
Gasoline, Clean Air...................... 326Gasoline (Fuel)......................... 325
Gasoline, Reformulated................... 326
Gauges
Coolant Temperature.................... 187
Fuel................................ 188
Odometer........................... 191
Speedometer......................... 188
Tachometer.......................... 191
Gearshift.............................. 281
General Information...............18,25,114,324
Glass Cleaning.......................... 405
Grocery Bag Retainer..................... 128
Gross Axle Weight Rating...............332,335
Gross Vehicle Weight Rating.............332,334
Hands-Free Phone (UConnectŸ).............. 89
Hazard
Driving Through Flowing, Rising, or Shallow
Standing Water........................ 292
444 INDEX
Page 453 of 457
System, Navigation...................... 244
Tachometer............................ 191
Temperature Control, Automatic (ATC)........ 259
Temperature Gauge, Engine Coolant.......187,351
Tether Anchor, Child Restraint.............71,74
Tie Down Hooks, Cargo................... 177
Tilt Steering Column..................... 143
Tire and Loading Information Placard......... 299
Tire Identification Number (TIN)............. 298
Tire Markings.......................... 294
Tire Safety Information.................... 294
Tires ............................80,303,434
Aging (Life of Tires).................... 309
Air Pressure.......................... 303
Alignment........................... 311
Chains.............................. 312
Changing............................ 352
Compact Spare........................ 307General Information.................... 303
High Speed.......................... 306
Inflation Pressures..................... 304
Jacking............................. 352
Life of Tires.......................... 309
Load Capacity.....................299,300
Pressure Monitor System (TPMS)........... 314
Quality Grading....................... 434
Radial.............................. 306
Replacement......................... 310
Rotation............................. 313
Safety...........................294,303
Sizes............................... 296
Snow Tires........................... 313
Spare Tire........................... 354
Spinning............................ 308
Tread Wear Indicators................... 309
Tongue Weight/Trailer Weight.............. 341
Towing............................... 334
INDEX 453
