Instruments and controls
Instrument panels 14-16
Warning lamps 1 7-32
Indicators
33

-42
Manual test

4
3
Setting buttons

4
4- 46
-

t
rip distance recorder
-
d

ashboard lighting dimmer / black panel
-

c
ustomisation of dials and screens
Adjusting headlamps
1

34
Door mirrors

1
00 -101
Electric windows

87
- 88
Dashboard fuses

2
88 -290
Opening the bonnet

2
42 Monochrome screen
4

7-50
Seat belt / front passenger airbag warning lamp display

1
58 -159, 163
Reversing camera

2
23
Manual gearbox
1

97
Automatic gearbox

1
98 -201
Parking brake

1
92
Electric parking brake

3
1-32, 193 -196
Rear view mirror

1
02
Courtesy lamps
1
42
Ventilation
1
03
Manual air conditioning
1

04-105
Digital air conditioning
1

06-109
Front Demisting / Defrosting

1
10
Demisting / Defrosting the rear screen
1

11
Audio system

3
77- 404
Setting the date / time

5
0
Touch screen tablet

5
1-54, 313 -376
Setting the date / time

5
5
Interior mood lighting
1 43
Ignition switch / Steering lock / Starting with the key

1
86 -188
Steering lock / Starting with the START/ STOP button

1
86, 189 -191
Over view

8
DS4_en_Chap00b_vue-ensemble_ed01-2016
Emergency call 150 -153
Assistance call 1 50 -153Fuel filler flap
2 27-230
DSC/ASR system 1 55 -156
Hazard warning lamps

1
49
Central locking

7
8 -79
Black panel (comfortable night-driving display)

4
6Lane departure warning system

2
09
Alarm volumetric monitoring

8
3 - 86
Electric child lock

1
81
Side switch panels
Central switch panels
Instruments and controls
Parking sensors 2 21-222
Stop & Start 2 06 -208
Blind spot sensors

2
10 -212
Over view

10
As a passenger, if you avoid connecting
your multimedia devices (film, music, video
game...), you will contribute towards limiting
the consumption of electrical energy, and so
of fuel.
Disconnect your portable devices before
leaving the vehicle.
Eco-driving
Eco-driving is a range of everyday practices that allow the motorist to optimise their fuel consumption and CO2 emissions.
Optimise the use of your
gearbox
With a manual gearbox, move off gently and
change up without waiting. During acceleration
change up early.
With an automatic gearbox, give preference
to automatic mode and avoid pressing the
accelerator pedal heavily or suddenly.
The gear efficiency indicator invites you to
engage the most suitable gear: as soon as the
indication is displayed in the instrument panel,
follow it straight away.
For vehicles fitted with an automatic gearbox,
this indicator appears only in manual mode.
Drive smoothly
Maintain a safe distance between vehicles,
use engine braking rather than the brake
pedal, and press the accelerator progressively.
These practices contribute towards a reduction
in fuel consumption and CO
2 emissions and
also help reduce the background traffic noise.
If your vehicle has cruise control, make use of
the system at speeds above 25 mph (40 km/h)
when the traffic is flowing well.
Control the use of your
electrical equipment
Before moving off, if the passenger compartment
is too warm, ventilate it by opening the windows
and air vents before using the air conditioning.
Above 30 mph (50 km/h), close the windows and
leave the air vents open.
Remember to make use of equipment
that can help keep the temperature in the
passenger compartment down (sunroof and
window
b

linds...).
Switch off the headlamps and front foglamps
when the ambient light level does not require
their use.
Avoid running the engine before moving off,
particularly in winter; your vehicle will warm up
much faster while driving.
Switch off the air conditioning, unless it has
automatic regulation, as soon as the desired
temperature is attained.
Switch off the demisting and defrosting
controls, if not automatic.
Switch off the heated seat as soon as possible.
Eco-driving

14
DS4_en_Chap01_instruments-de-bord_ed01-2016
Customisable colour instrument panel - Type 1
1. Rev counter (x 1 000 rpm or tr/min).
2. Gear efficiency indicator or gear lever
position and gear for an automatic
gearbox.
3.
A

nalogue speedometer (mph or km/h).
4.
C

ruise control or speed limiter setting.
5.
D

igital speedometer (mph or km/h).
6.
E

ngine oil level indicator*.
Dials and screens Control buttons
7. Service indicator (
miles or km) then,
t

otal mileage recorder.
T

hese two functions are displayed
successively on switching on the ignition.
L

ighting dimmer setting (when making an
adjustment).
8.
T

rip mileage recorder (miles or km).
9.
F

uel gauge and associated low fuel
warning lamp.
10.
R

ange (miles or km) for the fuel (a) or the
AdBlue additive and SCR system (b) .A. D
ial COLOUR: customisation of the
background colour of the dials.
B.
S

creen COLOUR: customisation of the
background colour of the screens.
C.
L

ighting dimmer (available in night mode).
D.
R

eset the service indicator or the trip
mileage recorder.
*

Depending on version.
01
Instruments

15
DS4_en_Chap01_instruments-de-bord_ed01-2016
1. Rev counter (x 1 000 rpm or tr/min).
2. Gear efficiency indicator or gear lever
position and gear for an automatic
gearbox.
3.
S

peedometer (mph or km/h).
4.
C

entral screen.
5.
F

uel gauge and associated low fuel level
warning lamp.
Dials and screens
6. Trip mileage recorder (miles or km).
7. S ervice spanner (if a service is due or
missed),
t

otal mileage recorder (miles or km).
Control buttons
Customisable colour instrument panel - Type 2
A. Dial COLOUR: customisation of the background colour of the dials.
B.
S

creen COLOUR: customisation of the
background colour of the screens.
C.
D

ashboard lighting dimmer (in night mode).
D.
S

tart a manual test (procedure for checking
the status of systems and display of vehicle
a l e r t s).
R

eset service indicator or trip mileage
recorder.
01
Instruments

16
DS4_en_Chap01_instruments-de-bord_ed01-2016
Type 2 instrument panel central screen and controls
1. Speed limiter or cruise control settings.
2. Engine oil level indicator*.
S

ervice indicator.
R

ange indicators (miles or km) related to
the AdBlue additive and the SCR system
(BlueHDi).
T

rip computer.
C

urrent audio source playing.
R

epeat of the navigation instruction.
R

epeat of the vehicle's speed. Press the button on the end of the wiper control
stalk to cycle through the different active
functions available (trip computer, current audio
source, navigation...).
Approaching the maximum engine speed, the
bars flash to indicate to you the need to change
up a gear.
Rev counter
* Depending on version.
Alert or information messages can also be
displayed temporarily. When switching the ignition on or off,
the speedometer needle and the bars
of the rev counter and fuel gauge carry
out a full sweep and then return to 0.
Display zones
Control
01
Instruments

17
DS4_en_Chap01_instruments-de-bord_ed01-2016
Visual indicators informing the driver that a system is in operation or is switched off (indicator lamp),
or has a fault (warning lamp).
Indicator and warning lamps
When the ignition is switched on
Certain warning lamps come on for a few
seconds when the vehicle's ignition is
switched on.
When the engine is started, these same
warning lamps should go off.
If they remain on, before moving off, refer to the
information on the warning lamp concerned.
Associated warnings
Certain warning lamps may come on in one of
two modes: fixed (continuous) or flashing.
Only by relating the type of illumination to the
operation of the vehicle can it be determined
whether the situation is normal or a fault has
occurred. In the event of a fault, the illumination
of the warning lamp may be accompanied by
an audible signal and/or a message.
Warning lamps
When the engine is running or the vehicle is
being driven, illumination of one of the following
warning lamps indicates a fault which requires
action on the part of the driver.
Any fault resulting in the illumination of a
warning lamp must be investigated further
using the associated message.
If you encounter any problems, contact a
CITROËN dealer or a qualified workshop.
Operation indicator lamps
If one of the following indicator lamps comes on
in the instrument panel and/or instrument panel
screen, this confirms that the corresponding
system has come into operation.
Deactivation indicator lamps
If one of the following indicator lamps comes
on, this confirms that the corresponding system
has been switched off intentionally.
This is may be accompanied by an audible
signal and the display of a message.
01
Instruments

21
DS4_en_Chap01_instruments-de-bord_ed01-2016
Servicetemporarily,
accompanied by a
message. One or more minor faults for which
there is no specific warning lamp
have been detected. Identify the cause of the fault using the message
displayed in the screen.
You can deal with some problems yourself, such as a
door open or the start of saturation of the particle filter
(as soon as the traffic conditions allow, regenerate
the filter by driving at a speed of at least 40 mph
(60
km/h), until the warning lamp goes off).
For any other problems, such as a fault with the tyre
under inflation detection system, contact a CITROËN
dealer or a qualified workshop.
fixed, accompanied by
a message. One or more major faults for which
there is no specific warning lamp
have been detected. Identify the cause of the fault using the message
displayed in the screen; you must then contact a
CITROËN dealer or a qualified workshop.
fixed, associated with the
flashing and then fixed
display of the service
indicator spanner.The servicing interval has been
exceeded.
Only on BlueHDi Diesel versions.
Your vehicle must be serviced as soon as possible.
Warning
/indicator lampis on Cause Action/Observations
Engine self-
diagnosis systemflashing.
The engine management system has
a fault. Risk of destruction of the catalytic converter.
Have it checked by a CITROËN dealer or a qualified
workshop.
fixed. The emission control system has a
fault.
The warning lamp should go off when the engine is started.
If it does not go off, contact a CITROËN dealer or qualified
workshop without delay.
01
Instruments

26
DS4_en_Chap01_instruments-de-bord_ed01-2016
Warning/indicator lampis on Cause Action/Observations
Electric parking
brake fixed.
The electric parking brake is applied. Release the electric parking brake to switch off the
warning lamp: with your foot on the brake pedal, pull
the electric brake control.
Observe the safety recommendations.
For more information on the Electric parking brake ,
refer to the corresponding section.
Deactivation of
the automatic
functions of the
electric parking
brake fixed.
The "automatic application" (on
switching off the engine) and
"automatic release" functions are
deactivated or faulty. Activate the function (depending on the country of
sale) via the vehicle configuration menu or contact a
CITROËN dealer or a qualified workshop.
Passenger's
airbag system fixed in the seat belt
and passenger's front
airbag warning lamps
display. The control switch, located in the
glove box, has been placed in the
"ON"
position.
The passenger's front airbag is
activated. In this case, do not install a rear ward facing child seat
on this seat.
Move the control switch to the "OFF"
position to
deactivate the passenger's front airbag. In this case,
you can install a rear ward facing child seat, unless
there is a fault with the airbags (airbag warning
lamp
on).
Passenger's
airbag system fixed in the instrument
panel and/or seat belt
and front passenger's
airbag warning lamps
display. The control switch, located in the
glove box, is set to the OFF
position.
The passenger's front airbag is
deactivated. You can install a rear ward facing child seat, unless
there is a fault with the airbags (airbag warning
lamp
on).
Set the control to the "ON" position to activate the
passenger's front airbag. In this case, do not install a
rear ward facing child seat on this seat.
01
Instruments

31
DS4_en_Chap01_instruments-de-bord_ed01-2016
Electric parking brake
Warning lampsStatusCauses Actions / Observations
They are on and
accompanied by
the displaying of the
message "Parking
brake fault" .Manual release of the electric parking
brake is only available by pressing
the accelerator pedal and releasing
the electric parking brake lever.
The hill start assistance is not
available. The automatic functions and manual application are still available.
Contact a CITROËN dealer or a qualified workshop.
They are on and
accompanied by
the displaying of the
message "Parking
brake fault" .The automatic functions are
deactivated.
The hill start assistance is not
available.
The electric parking brake can only be used manually.
Contact a CITROËN dealer or aqualified workshop.
They are on and
accompanied by
the displaying of the
message "Parking
brake fault" .The automatic functions are
deactivated.
The hill start assistance is not
available.
To apply the electric parking brake:
-

i
mmobilise the vehicle and switch off the ignition.
-

p
ull the control for at least 5 seconds or until application is
complete.
-

s
witch on the ignition and check the switching on of the electric
parking brake warning lamps.
The application is slower than during normal operation.
To release the electric parking brake:
-

s
witch on the ignition.
-

p
ull the control and hold it for approximately 3 seconds then
release it.
If the braking warning lamp is flashing or if the warning lamps do not
come on with the ignition on, these procedures will not work.
Place the vehicle in a safe condition (on level ground, gear engaged)
and have it checked by a CITROËN dealer or a qualified workshop.
01
Instruments
