Page 21 of 356
19Familiarisation
Monitoring
On switching on, the dial needles go to the extent of their travel then return to 0.
A.With the ignition on, the bars indicate the
fuel remaining.
B.With the engine running, the associated
low level warning lamp should go off.
Instrument panel
1.
With the ignition on, the orange and redwarning lamps come on. 2.With the engine running, these warninglamps should go off.
If a warning lamp remains on, refer to the page concerned.
Warning lamps
31
C.
With the ignition on, the instrument panelscreen should indicate the oil level.
If the levels are not correct, top up the level which is low.
69, 4
3
Page 23 of 356
21Familiarisation
If this warning lamp comes on in
the instrument panel, automatic application / release is
deactivated. The parking brake must
be applied and released manually.
y
Before leaving the vehicle, check
that the the brake warning lamp and
the P warning lamp in the controllever A
are on fixed (not flashing).
103
If towing a trailer or caravan or if theslope might vary (transpor t by boat or lorry, recovery of the vehicle...) make a maximum application of the parking brake - by making a long pull on thecontrol lever A
- to immobilise thevehicle.
*
Dependin
g on country of sale.
Driving safely
Electric parking brake
Manual Application/Release
Manual application
of the parking brake is possible by pulling
the control lever A. With the ignition on, manual releaseof theparking brake is possible by pressing the brake pedal
and pulling
then releasing
the control lever A
.
On opening the driver's door with theengine running, if an audible signalis heard, apply the parking brake
manually. Do not leave a child alone in the vehicle with the ignition on; they might release the parking brake.
Automatic Application / Release *
Press the accelerator and release the clutch(manual gearbox), the parking brake is releasedautomatically and progressively as you moveoff. With the vehicle stationary, the parking brakeis applied automatically on switching off the
engine.
Page 26 of 356
Driving safely
Stop & Start
Going into engine STOP mode
122
The "ECO"warning lamp comes
on in the instrument panel and the
engine goes into standby; with the electronic gearboxsystem andspeeds below 5 mph (8 km/h), press the brakepedal or put the gear lever in position N.In cer tain circumstances, the STOP modemay not be available; the "ECO"
warning lamp flashes for a few seconds, then goes off.
Going into engine START mode
Deactivation / Reactivation
123
123
The system is automatically reactivated every time the engine is star ted withthe STA R T/STOP button.
Before refuelling or doing anything under the bonnet, you must switch off the ignition with the START/STOP button. Th
e "ECO"
warning lamp goes off
and the engine restar ts with theelectronic gearbox system:
- with the
gear lever in position A
or Mrelease the brake pedal,
- or with the gear lever in position N
andbrake pedal released, move the gear lever
to position Aor M ,
- or engage reverse.
In certain circumstances, STA R T m o d e m ay be
invoked automatically; the "ECO"warning lampflashes for a few seconds, then goes off. You can deactivate the s
ystem at any time bypressing the "ECO OFF"
button; the button's
warning lamp comes on.
Page 33 of 356
Monitoring
Indicator and warning lamps
When the engine is star ted, these same warning lamps should go off.
If they remain on, before moving off, refer to the information on the warning lamp concerned.
Associated warnings
The switching on of cer tain warning lamps may
be accompanied by an audible signal and a
messa
ge in the instrument panel screen.
The warning lamps may come on continuously (fixed) or flash.
Certain warning lamps may come on inone of two modes: fixed (continuous) or flashing.
Only by relating the type of illumination to the operation of the vehicle can itbe determined whether the situation is normal or a fault has occurred.
Refer to the tables on the following pages for more information. Visual indicators in
forming the driver that asystem is in operation, switched off or has a fault.
When the ignition is switched on
Certain warning lamps come on for afew seconds in the instrument panel and/or
instrument panel screen when the vehicle's
ignition is switched on.
Page 35 of 356
33Monitoring
Rear foglamps
fixed. The rear foglamps are switched on. Turn the ring on the stalk rear wards to switch off the
rear foglamps.
Warning / indicator lampStateCauseAction / Observations
Diesel engine pre-heating fixed. The STA R T/STOP
switch has been pressed (ignition on). Wait until the warning lamp goes off before star ting.
Once it goes off, star ting is immediate, on condition
that the brake pedal remains pressed for automatic or electronic gearboxes, or the clutch pedal is pressed
fully down for manual gearboxes.
The period of illumination of the warning lamp is
determined by the ambient conditions (up to about
thirty seconds in extreme conditions).
If the engine does not star t, switch the ignition off and
then on, wait until the warning lamp goes off again,
then start the engine.
Electric parking brake
fixed. The electric parking brake is applied. Release the electric parking brake to switch off the
warning lamp: with your foot on the brake pedal, pull
the electric parking brake control lever.
Obser ve the safety recommendations.
For more information on the electric parking brake,
refer to the corresponding section.
Deactivation of the automatic functions of the electric parkingbrake
fixed. The "automatic application" (on switching off the engine) and
"automatic release" functions aredeactivated or faulty.
Activate the function (according to country) via the
vehicle configuration menu or contact a CITROËN
dealer or a qualified workshop if automatic
application / release is not possible.
The parking brake can be released manually using the emergency release procedure.
For more information on the electric parking brake,
refer to the corresponding section.
Page 38 of 356
When the engine is running or the vehicle is being driven, illumination of one of the following warning lamps indicates a fault which requires action on
the par t of the driver.
Any fault resulting in the illumination of a warning lamp must be investigated further by reading the associated message in the instrument panel screen.
If you encounter any problems, contact a CITROËN dealer or a qualified workshop.
Warning / indicator lampStateCauseAction / Observations
STOPfixed, associated withanother warning lamp, accompanied by an audible signal and amessage in the screen. It is associated with a punctured
wheel, the brakin
g system, the power steering, the engine oil pressure,
the engine coolant temperature or a major electrical fault.Stop as soon as it is safe to do so as the en
gine may cut out.
Park, switch off the ignition and call a CITROËN
dealer or a qualified workshop.
Serviceon temporarily. A minor fault has occurred for which
there is no specific warning lamp. Identif
y the fault by reading the message shown in the screen, such as, for example:
- the closing of the doors, boot or bonnet,
- the engine oil level,
- the screenwash level,
- the remote control battery,
- the tyre pressures,
- saturation of the particle emission filter (Diesel).
- ...
For an
y other faults, contact a CITROËN dealer or a qualified workshop.
fixed. A major fault has occurred for which
there is no specific warning lamp. Identify the fault by reading the message shown on the screen and contact a CITROËN dealer or a yyg g
qualified workshop.
PEF: particle emissions filter,Diesel
fixed, associated
temporarily with a message on the risk of
blockage of the PEF.Thi
s indicates the start of saturation
of the par ticle emissions filter. As soon as traffic conditions allow, regenerate the
filter by driving at a speed of at least 35 mph (60 km/h)
until the ser vice warning lamp goes off.
fixed.This indicates the low level in theDiesel additive reservoir. Have the level topped up b
y a CITROËN dealer or
a qualified workshop as soon as possible.
Page 39 of 356
37
Monitoring
Warning / indicator lampStateCauseAction / Observations
Electric parking
brake
flashing.The electric parking brake is not
app
lied automatically.
The application/release is faulty. You must stop as soon as it is sa
fe to do so.
Park on
flat level ground, switch off the ignition and contact a CITROËN dealer or a qualified workshop.
Electric parking brake fault
fixed. The electric parking brake has a fault. Contact a CITROËN dealer or a qualified workshop
without delay.
The parking brake can be released manually.
For more information on the electric parking brake,
refer to the corresponding section.
Braking
fixed. The braking system fluid level has
dropped significantly. You must stop as soon as it is safe to do so.
Top up with brake fluid listed by CITROËN.
If the problem persists, have the system checked by aCITROËN dealer or a qualified workshop.
+
fixed, associated
with the ABS warnin
glamp. Th
e electronic brake force distribution(EBFD) system has a fault. You must stop as soon as it is safe to do so.
Have it checked by a CITROËN dealer or a qualified
workshop.
Deactivation of the automatic functions of the electric parkingbrake
fixed. The "automatic application" (on switching off the engine) and
"automatic release" functions aredeactivated or faulty.
Activate the function (according to country) via the
vehicle configuration menu or contact a CITROËN
dealer or a qualified workshop if automatic
application / release is not possible.
The parking brake can be released manually using the
emergency release procedure.
For more information on the electric parking brake,
refer to the corresponding section.
Page 40 of 356
Warning / indicator lampStateCauseAction / Observations
Dynamic stability control(DSC/ASR)
flashing. The DSC/ASR regulation is
operating. The system optimises traction and improves the
directional stability of the vehicle.
fixed. Unless it has been deactivated(button pressed and its indicator lamp
on) the DSC/ASR system has a fault.Have it checked b
y a CITROËN or a qualified
workshop.
Engine autodiagnosis system
flashing.The engine management system hasa fault. Risk of destruction of the catalytic conver ter.
Have it checked by a CITROËN dealer or a qualified
workshop.
fixed. The emission control system hasa fault. The warning lamp should go off when the engine is started. If it does not go off, contact a CITROËN dealer or
qualified workshop without delay.
Low fuel levelfixed with the two last
bars flashing.When it first comes on there remainsapproximately 6 litres offfuelin thetank.You must re
fuel as soon as possible to avoid runningout of fuel.This warning lamp will come on every time the ignition
is switched on, until a sufficient addition of fuel is made.
Fuel tank capacit
y: approximately 60 litres.
Never continue to drive until you run out of fuel as
this could damage the emission control and injectionsystems.
Anti-lock
Braking System(ABS)
fixed. The anti-lock braking system has a
f
ault. The vehicle retains conventional brakin
g.
Drive carefull
y at reduced speed and contact a CITROËN dealer or a qualified workshop without
delay.
Page 41 of 356
39Monitoring
Warning / indicator lampStateCauseAction / Observations
Airbags
on temporarily. This lamp comes on for a fewseconds when you turn on the
ignition, then goes off. This lamp should
go off when the engine is started.
If it does not go off, contact a CITROËN dealer or a qualified workshop.
fixed. One of the airbag or seat belt pretensioner systems has a fault. Have it checked by a CITROËN dealer or a qualified
workshop.
Directionalheadlamps
flashing. The directional headlamps system has a fault. Have it checked by a CITROËN dealer or a qualified
workshop.
Seat belt(s)
not fastened / unfastened
fix
ed
or flashingaccompanied by an
audible signal.
A seat belt has not been fastened or
has been unfastened. Pull the strap then inser t the ton
gue in the buckle.
Page 43 of 356
Monitoring
Service indicator
More than 1 800 miles (3 000 km) remain before the next service is due
When the ignition is switched on, no ser vice information appears in the screen. S
ystem which informs the driver when the next ser vice is due, in accordance with themanufacturer's servicing schedule.
The point at which the ser vice is due is calculated from the last indicator zero reset. It is determined by two parameters:
- the distance travelled,
- the time elapsed since the last ser vice.
Between 600 miles (1 000 km)and 1 800 miles (3 000 km) remainbefore the next service is due
For 5 seconds after the ignition is switched on, the
spanner symbolising the ser vice operations comes
on. The distance recorder displa
y line indicates the
distance remaining before the next ser vice is due.
Example:1 700 miles (2 800 km) remain before
the next service is due.
For 5 seconds after the ignition is switched on,
the screen indicates:
5 seconds a
fter the ignition is switched on,the spanner goes off; the distance recorder fresumes its normal operation. The screen thenindicates the total and trip distances.
Less than 600 miles (1 000 km)remain before the next service is due
Example:
560 miles (900 km) remain before
the next service is due.
For 5 seconds after the ignition is switched on,
the screen indicates:
5 seconds after the i
gnition is switched on,
the distance recorder resumes its normal
operation. The spanner remains onto indicate
that a service must be carried out soon.
Illumination of the key is accompaniedby a message in the instrument panel screen.
