If the replacement fuse of the
same rating blows in a short time,
there is probably a serious
electrical problem in your vehicle.
Leave the blown fuse in that
circuit and have your vehicle
checked by a qualif ied technician.
If you cannot drive the vehicle
without f ixing the problem, and you
do not have a spare fuse, take a fuse
of the same rating or a lower rating
f rom one of the other circuits. Make
sureyoucandowithoutthatcircuit
temporarily (such as the accessory
power socket or radio).
If you replace the blown f use with a
spare f use that has a lower rating, it
might blow out again. This does not
indicate anything wrong. Replace the
f use with one of the correct rating as
soon as you can.
Look f or a blown wire inside the
f use. If it is blown, replace it with
oneof thesparefusesof thesame
rating or lower.
Your vehicle has spare fuses on
the back of the under-hood f use
box cover. If the radio f use is removed, the
audio system will disable itself . The
nexttimeyouturnontheradioyou
may see ‘‘ENTER CODE’’ in the
f requency display. Use the preset
buttons to enter the digit code (see
page ).
On vehicles with a navigation system,
touch the appropriate icon to enter
the code number (see page ).
6.
5. 218
218
Fuses
T aking Care of t he Unexpect ed
329
BLOWN
Replacing a f use with one that has a
higher rating greatly increases the
chances of damaging the electrical
system. If you do not have a
replacement f use with the proper rating
f or the circuit, install one with a lower
rating.
\f—\f—y
y
(,\fy\fy
2009 CR- V

Call Helm Inc. at 1-800-782-4356 (credit card orders only)
Go online at
T he publications shown below can be purchased f rom Helm
Incorporated. You can order by phone or online:
If you are interested in other years or models, contact Helm Inc.
at 1-800-782-4356.
Covers maintenance and recommended procedures f or
repair to engine and chassis components. It is written
f or the journeyman mechanic, but it is simple enough
f or most mechanically inclined owners to understand.
Complements the Service Manual by providing in-depth
troubleshooting inf ormation f or each electrical circuit
in your vehicle.
Describes the procedures involved in the replacement
of damaged body parts.
Authorized Manuals
Service Manual:
Electrical T roubleshooting Manual:
Body Repair Manual:
Purchasing Factory Authorized Manuals (U.S. only)
Authorized Manuals
353
Form Description
2007-2009 Honda CR-V Service Manual 2007-2009 Honda CR-V
Electrical Troubleshooting Manual
2007 Honda CR-V Body Repair Manual 2009 Honda CR-V Owner’s Manual 2009 Honda CR-V
Navigation System Owner’s Manual
2009 Honda CR-V Honda Service History 2009 Honda CR-V Quick Start Guide
Order Form for Previous Years-Indicate Year and Model Desired
Publication
Form Number 61SWA02
61SWA02EL
61SWA30
31SWA620
31SWA820
31SWAM20 31SWAQ20 HON-R
www. helminc. com
