2004 S2000 Online Reference Owner's Manual
Use these links (and links throughout this manual) to navigate through\
this reference.
For a printed owner's manual, click on authorized manuals or go to www.h\
elminc.com.
Contents
Owner's Identification Form
Introduction ........................................................................\
................................................................. i
A Few Words About Safet y........................................................................\
.........................................ii
Your Vehicle at a Glanc e........................................................................\
.............................................2
Driver and Passenger Safety ........................................................................\
......................................5
Proper use and care of your vehicle's seat belts, and Supplemental Restr\
aint System.
Instruments and Control s........................................................................\
........................................ .37
Instrume nt panel indicator and gauge, and how to use dashboard and steering colu\
mn controls.
Comfort and Convenience Features ........................................................................\
....................... .73
How to operate the climate control system, the audio system, and other c\
onvenience features.
Before Driving........................................................................\
........................................................... .99
What gasoline to use, how to break -in your new vehicle, and how to load luggage and other cargo.
Driving ........................................................................\
..................................................................... .111
The proper way to start the engine, shift the transmission, and park, pl\
us towing a trailer.
Maintenance........................................................................\
.............................................................119
The Maintenance Schedule shows you when you need to take you r vehicle to the dealer.
Taking Care of the Unexpecte d........................................................................\
..............................153
This section covers several problems motorists sometimes experience, an d how to handle them.
Technical Informatio n........................................................................\
.............................................177
ID numbers, dimensions, capacities, and technical information.
Warranty and Customer Relations (U.S. and Canada)................................................................191
A summary of the warranties covering your new Acura, and how to contact \
us.
Authorized Manu als (U.S. only)........................................................................\
..............................195
How to order manuals and other technical literature.
Index........................................................................\
........................................................................\
...... I
Service Information Summary
A summary of information you need when you pull up to the fuel pump.
Page 12 of 208
Your vehicle has a Supplemental
Restraint System (SRS) with frontal
airbags to help protect the heads and
chests of the driver and a passenger
during a moderate to severe frontal
collision (see page f or more
information on how your airbags
work).The most important things you need
to know about your airbags are:
They are designed to supplement
the seat belts. To do
their job, airbags must inf late with
tremendous f orce. So while
airbags help save lives, they can
cause minor injuries or more
serious or even fatal injuries if
occupants are not properly
restrained or sitting properly.
Always wear
your seat belt properly, and sit
upright and as f ar back f rom the
steering wheel while allowing f ull
control of the vehicle. A passenger
should move the seat as far back
f rom the dashboard as possible.
18
Your Vehicle’s Saf ety Features
Driver and Passenger Saf ety
Airbags
Airbags do not replace seat belts.
Airbags of f er no protection in sideimpact s, rear impact s, rollovers,or minor collisions. A irbags can pose hazards.
What you should do:
9
Page 13 of 208
The rest of this section gives more
detailed inf ormation about how you
can maximize your saf ety.
Remember however, that no saf ety
system can prevent all injures or
deaths that can occur in severe
crashes, even where seat belts are
properly worn and the airbags deploy.
The f ollowing pages provide
instructions on how to properly
protect the driver, adult passengers
and teenage children who are large
enough and mature enough to ride in
your Honda.
See page f or important guidelines
on how to properly protect small
children and larger children who ride
in your vehicle.Af ter everyone has entered the
vehicle, be sure the doors are closed
and locked.
Locking the doors also helps prevent
an outsider f rom unexpectedly
opening a door when you come to a
stop.
See page f or how to lock the
doors.
Adjust driver’s seat as far to the rear
as possible while allowing you to
maintain control of the vehicle. Have
a passenger adjust his or her seat as
far to the rear as possible.
If you sit too close to the steering
wheel or dashboard, you can be
seriously injured by an inf lating
airbag, or by striking the steering
wheel or dashboard.
Locking the doors reduces the
chance of someone being thrown out
of the vehicle during a crash, and it
helps prevent a passenger f rom
accidentally opening a door and
f alling out.
22 54
Protecting A dults and Teens
Driver and Passenger Saf ety
Close and L ock the DoorsA djust the Seats
1. 2.
10
Page 21 of 208
Your airbag system includes:Two SRS (Supplemental Restraint
System) airbags. The driver’s
airbag is stored in the center of
the steering wheel; the passenger’s
airbag is stored in the dashboard.
Both are marked ‘‘SRS AIRBAG.’’
Automatic seat belt tensioners
(see page ).
Sensors that can detect a
moderate to severe frontal
collision.
A sophisticated electronic system
that continually monitors
inf ormation about the sensors, the
control unit, and the airbag
activators when the ignition is in
the ON (II) position. An indicator on the instrument
panel that alerts you to a possible
problem with your airbags (see
page ).
Emergency backup power in case
your vehicle’s electrical system is
disconnected in a crash.
If you ever have a moderate to
severe f rontal collision, sensors will
detect the vehicle’s rapid
deceleration. If the rate of
deceleration is high enough, the
control unit will instantly inf late the
drivers and passenger’s airbags.
16
20
Additional Inf ormation About Your Airbags
Driver and Passenger Saf ety
A irbag System Components
How Your A irbags Work
18
Page 27 of 208
µ
To remind you of the passenger’s
airbag hazards, your vehicle has
warninglabelsonthedashboardand
on the driver’s and passenger’s
visors. Please read and f ollow the
instructions on these labels.To remind you of the airbag hazards,
your vehicle has warning labels on
the driver’s and passenger’s visors.
Please read and follow the
instructions on these labels.
Protecting Children General Guidelines
Driver and Passenger Saf ety
U.S. Models
Canadian Models
24
Page 28 of 208
µ
Never hold a small child on your
lap. If you are not wearing a seat
belt in crash, you could be thrown
f orward and crush the child
against the dashboard. If you are
wearing a seat belt, the child can
be torn f rom your arms and be
seriously hurt or killed.
Never put a seat belt over yourself
and a child. During a crash, the
belt could press deep into the child
and cause serious or fatal injuries.
Never let two children use the
same seat belt. If they do, they
could be very seriously injured in a
crash.Lock both doors and the trunk
when your vehicle is not in use.
Children who play in vehicles can
accidentally get trapped inside the
trunk. Teach your children not to
play in or around vehicles. Know
how to operate the emergency
trunk opener and decide if your
children should be shown how to
use this f eature (see page ).Keep vehicle keys and remote
transmitters out of the reach of
children. Even very young
children learn how to unlock
vehicle doors, turn on the ignition,
and open the trunk, which can
lead to accidental injury or death.
Do not leave children alone in a
vehicle. Leaving children without
adult supervision is illegal in most
states and Canadian provinces,
and can be very hazardous. For
example, a small child lef t in a
vehicle on a hot day can die f rom
heatstroke. A child lef t alone with
the key in the ignition can
accidentally set the vehicle in
motion, possibly injuring
themselves or others.
55
Protecting Children General Guidelines
Driver and Passenger Saf ety
Additional Saf ety Precautions
25
Page 38 of 208
These labels are in the locations
shown. They warn you of potential
hazards that could cause serious
injury. Read these labels caref ully. If
a label comes of f or becomes hard to
read, contact your Honda dealer f or
a replacement.U.S. modelsCanadian models
U.S. models only
Saf ety L abels
Driver and Passenger Saf ety35
BATTERY
SUN VISOR
RADIATOR SRSSEAT BELT TENSIONER
DASHBOARD
Page 78 of 208
Push this lever up and down to
increase and decrease the f an speed.
The indicators next to the lever show
you the speed selected.
Turning this dial clockwise increases
the temperature of the airflow.
This button turns the air
conditioning on and of f . The
indicator in the button comes on
when the A/C is on.
This button controls the source of
the air going into the system. When
the indicator in this button is on, air
f rom the vehicle’s interior is sent
through the system again
(Recirculation mode). When the
indicator is of f , air is brought in f rom
outside the vehicle (Fresh Air mode).The outside air intakes f or the
heating and cooling system are at
the base of the windshield. Keep this
area clear of leaves and other debris.
ThesystemshouldbeleftinFresh
Air mode under almost all conditions.
Keeping the system in Recirculation
mode, particularly with the A/C of f ,
can cause the windows to fog up.
Switch to Recirculation mode when
driving through dusty or smoky
conditions, then return to Fresh Air
mode.
This button turns the rear window
def ogger of f and on (see page ).
Use the mode control dial to select
the vents the air flows from. Some
air will f low f rom the dashboard
vents in all modes. Air flows from the vents on
both sides of the instrument panel,
andfromthedashboardventinfront
of the passenger.
Airf low is divided between
the vents in the dashboard and the
f loor vents.
Air flows from the center
vents in the dashboard above the
audio system, the vents on both
sides of the instrument panel, and
f rom the f loor vents. Select this
position when you drive with the
convertible top f olded.
Air f lows f rom the f loor
vents and the vents on both sides of
the instrument panel.
Airf low is divided between
the f loor vents and the def roster
vents at the base of the windshield,
and the vents on both sides of the
instrument panel.
50
Comf ort and Convenience Feat ures
Fan Control L ever
T emperature Control Dial
Air Conditioning (A/C) Button
Recirculation Button
Rear Window Def ogger Button
Mode Control Dial
Airf low Buttons
75
Page 80 of 208
To remove f og f rom the inside of the
windows:
When you switch to another mode
f rom , the A/C stays on.
Press the A/C button to turn it of f .Select . The system
automatically switches to Fresh
Air mode and turns on the A/C.
Select .
Set the f an and temperature
controls to the maximum level.
Air conditioning, as it cools, removes
moisture from the air. When used in
combination with the heater, it
makes the interior warm and dry.
Switch the f an on.
Turn on the air conditioning.
Select and Fresh Air mode.
Adjust the temperature control
dial to your pref erence.
This setting is suitable f or all driving
conditions whenever the outside
temperature is above 32°F (0°C). Set the f an to the desired speed.
Select . When you select
, the system automatically
switches to Fresh Air mode and
turns on the A/C.
Adjust the temperature control
dial so the airflow feels warm.
Select to help clear the
rear window. To clear the windows f aster, you can
close the dashboard corner vents
and the vents on both sides of the
instrument panel by rotating the
wheel below the vent. This will send
more warm air to the windshield
def roster vents. Once the windshield
is clear, select the Fresh Air mode to
avoid f ogging the windows.
For your saf ety, make sure you have
a clear view through all the windows
bef ore driving.
1.
2.
3.
4.
1.
2.
3.
4.1.
2.
3.
Vents, Heating, and A/C
Comf ort and Convenience Feat ures
T o Def og and Def rost
T o Remove Exterior Frost or Ice
From the Windows
To Dehumidif y the Interior
77
Page 96 of 208
Four controls f or the audio system
areontheleftsideof thedashboard
by the instrument panel. These let
you control basic f unctions without
distracting your attention f rom
driving.
Use the VOLUME lever to adjust the
volume. Push the lever up to
increase the volume and down to
decrease it. Hold the lever until the
volume reaches the desired level,
then release it.If you want to mute the sound
temporarily, push the MUTE button.
The indicator in the button will come
on to indicate the mute f unction is on.
Press the button again to cancel
MUTE.
The AUDIO CONTROL button
changes the mode. Pressing the
button repeatedly selects AM, FM1,
FM2, or CD (if a CD is loaded), XM1,
XM2 (if you have the optional
satellite radio f eature).
The CHANNEL button has two
f unctions, depending on whether you
are listening to the radio, or playing a
CD.
If you are listening to the radio, use
the CHANNEL button to change
stations. Each time you press this
button, the system advances to the
next preset station on the band you
are listening to. You will see the
number of the selected preset buttonin the audio system display.
If youareplayingaCD,thesystem
skips to the beginning of the next
track each time you push the
CHANNEL button.
These controls work only with the
f actory-installed audio system. They
will not f unction if you install any
other system.
Remote Audio Controls
Comf ort and Convenience Feat ures93
AUDIO CONTROL
BUTTON
CHANNEL
BUTTON
MUTE
BUTTON
VOLUME
LEVER
