recommended oil MERCEDES-BENZ R500 2006 W251 Owner's Manual
[x] Cancel search | Manufacturer: MERCEDES-BENZ, Model Year: 2006, Model line: R500, Model: MERCEDES-BENZ R500 2006 W251Pages: 561
Page 7 of 561
ContentsLoading .............................................. 279
Roof rack* .................................... 279
Loading instructions ..................... 280
Cargo tie-down rings .................... 281
Hooks ........................................... 282
Expanding cargo compartment .... 283
Cargo compartment cover blind* . 288
Partition net* ............................... 290
Useful features .................................. 294
Storage compartments................. 294
Parcel nets ................................... 298
Cup holders .................................. 299
Ashtrays* ..................................... 302
Cigarette lighter* ......................... 305
Power outlets ............................... 306
Rear center console* ................... 308
Telephone*................................... 310
Tele Aid* ...................................... 311
Garage door opener* ................... 320
Compass ...................................... 327
Floormats* ................................... 328
Infrared reflecting windshield* ..... 328
Operation......................................... 329
The first 1000 miles (1500 km) ......... 330
Driving instructions............................ 331
Drive sensibly – save fuel ............. 331
Drinking and driving ..................... 331
Pedals .......................................... 331
Power assistance ......................... 331
Brakes .......................................... 332
Driving off .................................... 333
Parking ......................................... 334
Tires ............................................. 334
Hydroplaning ................................ 335
Tire traction.................................. 335
Tire speed rating .......................... 336
Winter driving instructions ........... 337
Standing water ............................. 338
Passenger compartment .............. 338
Driving abroad.............................. 339
Control and operation of radio
transmitters ................................. 339
Catalytic converter ....................... 340
Emission control .......................... 340
Coolant temperature .................... 341At the gas station .............................. 342
Refueling ...................................... 342
Check regularly and before a
long trip ....................................... 343
Engine compartment ......................... 345
Hood ............................................ 345
Engine oil ..................................... 346
Transmission fluid level................ 350
Coolant level ................................ 351
Windshield / rear window washer
system and headlamp cleaning
system* ....................................... 352
Tires and wheels................................ 353
Important guidelines .................... 353
Tire care and maintenance........... 354
Direction of rotation..................... 356
Loading the vehicle ...................... 356
Recommended tire inflation
pressure ....................................... 363
Checking tire inflation pressure ... 365
Tire labeling ................................. 375
Load identification ....................... 380
DOT, Tire Identification Number
(TIN) ............................................. 380
Maximum tire load ....................... 382
Maximum tire inflation pressure .. 382
Page 356 of 561
355 Operation
Tires and wheels
Tread depth
Do not allow your tires to wear down too
far. Adhesion properties on wet roads are
sharply reduced at tread depths under 1/8in (3 mm).
Treadwear indicators (TWI) are required by
law. These indicators are located in six
places on the tread circumference and
become visible at a tread depth of approx-
imately
1/16
in (1.6 mm), at which point
the tire is considered worn and should be
replaced.
Recommended minimum tire tread depth:
Summer tires
1/8in (3 mm)
Winter tires
1/6in (4 mm)
1TWI (T
read W
ear I
ndicator)
The treadwear indicator appears as a solid
band across the tread.Storing tires
Cleaning tires
Warning!
G
Although the applicable federal motor safety
laws consider a tire to be worn when the
treadwear indicators (TWI) become visible at
approximately
1/16in (1.6 mm), we recom-
mend that you do not allow your tires
to wear down to that level. As tread depth
approaches
1/8in (3 mm), the adhesion
properties on a wet road are sharply re-
duced.
Depending upon the weather and/or road
surface (conditions), the tire traction varies
widely.
!Keep unmounted tires in a cool, dry
place with as little exposure to light as
possible. Protect tires from contact
with oil, grease and gasoline.!Never use a round nozzle to power
wash tires. The intense jet of water can
result in damage to the tire.
Always replace a damaged tire.
Page 396 of 561
395 Operation
Vehicle care
Vehicle care
Cleaning and care of the vehicle
While in operation, even while parked, your
vehicle is subjected to varying external in-
fluences which, if gone unchecked, can at-
tack the paintwork as well as the
underbody and cause lasting damage.Such damage is caused not only by ex-
treme and varying climatic conditions, but
also by:
Air pollution
Road salt
Tar
Gravel and stone chipping
To avoid paint damage, you should imme-
diately remove:
Grease and oil
Fuel
Coolant
Brake fluid
Bird droppings
Insects
Tree resins, etc.
Frequent washing reduces and / or elimi-
nates the aggressiveness and potency of
the above adverse influences.More frequent washings are necessary to
deal with unfavorable conditions:
near the ocean
in industrial areas (smoke, exhaust
emissions)
during winter operation
You should check your vehicle from time to
time for stone chipping or other damage.
Any damage should be repaired as soon as
possible to prevent corrosion.
In doing so, do not neglect the underbody
of the vehicle. A prerequisite for a thor-
ough check is a washing of the underbody
followed by a thorough inspection. Dam-
aged areas need to be re-undercoated.
Your vehicle has been treated at the facto-
ry with a wax-base rustproofing in the body
cavities which will last for the lifetime of
the vehicle. Post-production treatment is
neither necessary nor recommended by
Mercedes-Benz because of the possibility
of incompatibility between materials used
in the production process and others ap-
plied later.
Warning!
G
Many cleaning products can be hazardous.
Some are poisonous, others are flammable.
Always follow the instructions on the partic-
ular container. Always open your vehicle’s
doors or windows when cleaning the inside.
Never use fluids or solvents that are not de-
signed for cleaning your vehicle.
Always lock away cleaning products and
keep them out of reach of children.
Page 524 of 561
523 Technical data
Fuels, coolants, lubricants, etc.
Engine oils
Engine oils are specifically tested for their
suitability in our engines and durability for
our service intervals. Therefore, only use
approved engine oils and oil filters re-
quired for vehicles with Maintenance Sys-
tem (U.S. vehicles) or FSS (Canada
vehicles). For a listing of approved engine
oils and oil filters, refer to the Factory Ap-
proved Service Products pamphlet, or con-
tact an authorized Mercedes-Benz Light
Truck Center.
Engine oil additives
Do not blend oil additives with engine oil.
They may damage the engine.
Damage or malfunctions resulting from
blending oil additives are not covered by
the Mercedes-Benz Limited Warranty.Air conditioning refrigerant
R-134a (HFC) refrigerant and special PAG
lubricating oil are used in the air condition-
ing system.
Never use R-12 (CFC) or mineral-based lu-
bricating oil. Otherwise damage to the
system will occur.
Brake fluid
During vehicle operation, the boiling point
of the brake fluid is continuously reduced
through the absorption of moisture from
the atmosphere.
Only brake fluid approved by
Mercedes-Benz is recommended. Your
authorized Mercedes-Benz Light Truck
Center will provide you with additional in-
formation.
!Using engine oils and oil filters of
specification other than those express-
ly required for the Maintenance System
(U.S. vehicles) or FSS PLUS (Canada
vehicles), or changing of oil and oil filter
at change intervals longer than those
called for by the Maintenance System
(U.S. vehicles) or FSS PLUS (Canada
vehicles) will result in engine damage
not covered by the Mercedes-Benz
Limited Warranty.
Please follow Maintenance System
(U.S. vehicles) or FSS PLUS (Canada
vehicles) recommendations for sched-
uled oil changes. Failure to do so could
result in engine damage not covered by
the Mercedes-Benz Limited Warranty.
Warning!
G
Under extremely strenuous operating condi-
tions, this moisture content can lead to the
formation of bubbles in the system, thus re-
ducing the system’s efficiency.
Therefore, the brake fluid must be replaced
regularly. Refer to your vehicle’s
Maintenance Booklet for replacement inter-
val.
