Page 443 of 801
442 Controls in detailAutomatic transmissionIf you are driving in the manual program
modeM, upshift indicator2 in the multi-
function display advises you to upshift be-
fore the engine reaches the overspeed
range. Thus you can drive at the maximum
engine speed for each gear without over-
revving the engine.
1Gear indicator
2Upshift indicator “up”
3Engine oil temperature
4Vehicle supply voltage
Shift to the next higher gear.
The fuel supply will otherwise be inter-
rupted to prevent the engine from over-
revving.Downshifting
Briefly pull left shift paddle1
(page 438).
The transmission shifts to the next
lower gear.Kickdown
Using the kickdown when driving in the
manual program modeM is not possible.
Deactivating manual shift program
Press the program mode selector
switch (
page 440) repeatedly until
“C”or“S” appears in the multifunction
display.
or
Restart the engine.
The transmission will go to the
automatic program mode (C orS).
The manual program modeM is not
stored.
Warning!
G
On slippery road surfaces, never downshift
in order to obtain braking action. This could
result in drive wheel slip and reduced
vehicle control. Your vehicle’s ABS will not
prevent this type of loss of control.i
When you brake or stop, the transmission
shifts down to a gear from which you can easily
accelerate or drive off.
Page 607 of 801
606 OperationTires and wheelsTire ply material
1Plies in sidewall
2Plies under tread
This marking tells you about the type of
cord and number of plies in the sidewall
and under the tread.
Tire and loading terminology
Accessory weight
The combined weight (in excess of those
standard items which may be replaced) of
automatic transmission, power steering,
power brakes, power windows, power
seats, radio, and heater, to the extent that
these items are available as
factory-installed equipment (whether
installed or not).
Air pressure
The amount of air inside the tire pressing
outward on each square inch of the tire.
Air pressure is expressed in pounds per
square inch (psi), or kilopascal (kPa) or
bars.
Aspect ratio
Dimensional relationship between tire
section height and section width
expressed in percentage.Bar
Another metric unit for air pressure. There
are 14.5038 pounds per square inch (psi)
to 1 bar; there are 100 kilopascals (kPa)
to 1 bar.
Bead
The tire bead contains steel wires wrapped
by steel cords that hold the tire onto the
rim.
Cold tire inflation pressure
Tire inflation pressure when your vehicle
has been sitting for at least 3 hours or driv-
en no more than 1 mile (1.6 km).
Curb weight
The weight of a motor vehicle with stan-
dard equipment including the maximum
capacity of fuel, oil, and coolant, and, if so
equipped, air conditioning and additional
optional equipment, but without passen-
gers and cargo.
i
For illustration purposes only. Actual data
on tires are specific to each vehicle and may vary
from data shown in above illustration.
Page 717 of 801
716 Practical hintsReplacing bulbsNotes on bulb replacement
Only use 12-volt-bulbs of the same
type and with the specified watt rating.
Switch lights off before changing a bulb
to prevent short circuits.
Always use a clean lint-free cloth when
handling bulbs.
Your hands should be dry and free of oil
and grease.
If the newly installed bulb does not
come on, contact an authorized
Mercedes-Benz Center.
Have the LEDs and bulbs for the following
lamps replaced by an authorized
Mercedes-Benz Center:
the Bi-Xenon lamps
the front turn signal lamps
the front fog lamps
the additional turn signal lamps in the
exterior rear view mirrors
the parking and standing lamps
the front side marker lamps
the high mounted brake lamps
the brake, tail and rear standing lamps
the rear side marker lamps
the rear fog lamp
the rear turn signal lamps
the rear side marker lamps
the license plate lamps
Warning!
G
Bulbs and bulb sockets can be very hot. Al-
low the lamp to cool down before changing
a bulb.
Keep bulbs out of reach of children.
Halogen lamps contain pressurized gas. A
bulb can explode if you:
touch or move it when hot
drop the bulb
scratch the bulb
Wear eye and hand protection.
Because of high voltage in Xenon lamps, it is
dangerous to replace the bulb or repair the
lamp and its components. We recommend
that you have such work done by a qualified
technician.
!
Do not replace the LEDs yourself. You could
otherwise damage the LEDs or parts of the vehi-
cle. Only have the LEDs replaced by an autho-
rized Mercedes-Benz Center.
i
Have the headlamp adjustment checked
regularly.
Page 790 of 801
789 Index
O
Occupant Classification System see OCS
Occupant distribution 607
Occupant safety 40
Air bags 42
Children and air bags 58
Children in the vehicle 58
Fastening the seat belt 395
Front passenger front air bag off
indicator lamp 51
Infant and child restraint systems 59
LATCH-type child seat anchors 63
Seat belts 44, 395
OCS 47
Self-test 52
Odometer 291
Oil
Filler neck 578
Oil level see Engine oil
One-touch gearshifting 438
Operating safety 19
Voice Control 308
Ornamental moldings, Cleaning 618
Outside temperature indicator 29, 445
Overdue maintenance service 613
Overhead control panel 33Override switch 64
P
Paintwork, Cleaning 616
Panic alarm
Audible alarm and flashing
exterior lamps 66
Panic button 66
Panorama roof with power tilt/sliding
panel* 521
Opening/closing 522
Synchronizing 524
Panorama roof with tilt/sliding panel*
Cleaning 623
Parcel net in front passenger
footwell 528
Park Assist* 476
Cleaning system sensors 620
Messages in display 653, 655
System sensors 620
Warning indicators 29, 479
Parking 421, 562
Parking and standing lamps
Replacing bulbs 715
Parking lamps
Messages in display 690Parking position
Exterior rear view mirrors 391
Parktronic system* 472
Parktronic*
Cleaning system sensors 619
Malfunctioning 476
System sensors 619
Warning indicators 29, 474
Parts service 746
PASS AIR BAG OFF indicator lamp see
Front passenger front air bag off
indicator lamp
Passenger compartment 567
Passenger safety see Occupant safety
PCMCIA card
Ejecting (COMAND) 122
Loading (COMAND) 121
Pedals 559
Plastic parts, cleaning 624
POIs 229
Poly-V-belt drive 750
Layout 750
Potential problems associated with
underinflated and overinflated
tires 597
Power assistance 559
