Page 320 of 334
R
The jack must beplaced onafirm, flatand
non- slipsurface. Onaloose surface, alarge,
flat, load-bearing underlaymustbeused. On
a slippery surface, anon- slipunderlay must
be used, e.g.rubber mats.
R Do not use wooden blocksorsimilar objects
as ajack underlay. Otherwise, thejack will
not beable toachieve itsload-bearing capa-
city due tothe restr icted height.
R Make surethatthedistance between the
underside ofthe tires andtheground does
not exceed 1.2in(3 cm).
R Never placeyourhands andfeet under the
raised vehicle.
R Do not lieunder thevehicle.
R Do not start theengine whenthevehicle is
raised.
R Do not open orclose adoor orthe trunk lid
when thevehicle israised.
R Make surethatnopersons arepresent in
the vehicle whenthevehicle israised.
Vehicles withalloy wheels andhub caps:
the wheel boltsarecovered byahub cap.
Before youcan unscrew thewheel bolts,you
must remove thehub cap. Twodifferent var-
iants canbeinstalled. X
To remove: takesocket 0044and lugwrench
0087 from thevehicle toolkit(Ypage 280).
X Position socket0044onhub cap0043.
X Position lugwrench 0087onsocket 0044.
X Using lugwrench 0087,turn hubcap0043coun-
ter- clock wiseandremove it.
X To install: beforeinstalling, checkhub
cap 0043and thewheel areaforsoiling and
clean ifnecessary.
X Put hub cap0043inposition andturn until itis
in the right position. X
Position socket0044onhub cap0043.
X Attach lugwrench 0087tosocket 0044and
tighten hubcap0043.
The tighten ingtorque mustbe
18 lb-ft (25Nm).
i Note
thatthehub capshould betight-
ened tothe specified torqueof18 lb-ft
(25 Nm). Mercedes- Benzrecomm endsthat
you have thehub capinstalled ataqualified
specialist workshop. X
Using lugwrench 0087,loosen thebolts on
the wheel youwish tochange byabout one
full turn. Donot unscrew thebolts com-
pletely. The
jackingpoints arelocated justbehind the
front wheel housings andjust infront ofthe
rear wheel housings (arrows).
Mercedes-AMG vehiclesandvehicles with
AMG equipm ent:toprotec tthe vehicle body,
the vehicle hascovers installed nexttothe
jack ingpoints onthe outer sills. 318
Changing
awheelWheels andtires
Page 321 of 334
X
Merce
des-AMGvehic lesand vehic les
with AMG equipment: foldcover 0085
upw ards. X
Posi tion jack 0084atjacking point0083. X
Make surethefoot ofthe jack isdirectly
benea ththe jacking point.
X Turn crank 006Bclockwis euntil jack0084sits
comple telyonjacking point0083.The base of
the jack must lieevenly onthe ground .
X Turn crank 006Buntil thetire israis edamaxi-
mum of1.2 in(3 cm) from theground . Removi
ngawhe el !
Merce
des-AMGvehic les:duri ngremova l
and reposi tioning ofthe whee l,the whee l
rim can strike thecerami c-brake discand
dama geit.Therefo re,you shou ldproceed
carefu llyand getasecond personassistto
you .Alternativel y,you can useasecond
ali gnment bolt.
! Do
not placewhee lbolts insand oron a
dirty surface.The bolt andwhee lhub
threads couldotherwi sebe dama gedwhen
you screw themin. X
Unscrew theuppermost wheelbolt com-
pletel y.
X Screw alignment bolt0043into thethread
instead ofthe whee lbolt.
X Unscrew theremai ningwhee lbolts fully.
X Remo vethe whee l.
Mountin ganew wheel G
WARNING
Oile dor grea sedwhee lbolts ordama ged
whee lbolts/hu bthreads cancaus ethe
whee lbolts tocome loose.As aresul t,you
coul dlose awhee lwhi ledrivi ng.There isa
risk ofaccide nt.
Never oilorgrea sewhee lbolts. Inthe event
of dama getothe threads ,contact aqua li-
fied specia listworkshop immediately.Have
the dama gedwhee lbolts orhub threads
repla ced/renew ed.Donot continue driving. Chang
ingawhe el
319Whee lsand tires Z
