![MITSUBISHI MONTERO 1998 Service Manual ABBREVIATIONS
1998 Mitsubishi Montero
GENERAL INFORMATION
COMMONLY USED ABBREVIATION
"A" ABBREVIATION TABLE
"A" ABBREVIATION TABLE \
\](/img/19/57333/w960_57333-24.png "MITSUBISHI MONTERO 1998 Service Manual ABBREVIATIONS
1998 Mitsubishi Montero
GENERAL INFORMATION
COMMONLY USED ABBREVIATION
\"A\" ABBREVIATION TABLE
\"A\" ABBREVIATION TABLE \
\")
ABBREVIATIONS
1998 Mitsubishi Montero
GENERAL INFORMATION
COMMONLY USED ABBREVIATION
"A" ABBREVIATION TABLE
"A" ABBREVIATION TABLE \
\
\
\
\
\
\
ABBREVIATION DEFINITION
\
\b\
\
\
\
\
\
A Amperes
A/C Air Conditioning
A/T Automatic Transmission/Transaxle
AAP Auxiliary Accelerator Pump
AB Air Bleed
ABCV Air Bleed Control Valve
ABDC After Bottom Dead Center
ABRS Air Bag Restraint System
ABS Anti-Lock Brake System
AC Alternating Current
ACC A/C Clutch Compressor
ACCS A/C Cycling Switch
ACCUM Accumulator
ACCY Accessory
ACT Air Charge Temperature Sensor
ACV Thermactor Air Control Valve
ADJ Adjust or Adjustable
ADV Advance
AFS Airflow Sensor
AI Air Injection
AIR or A.I.R. Air Injection Reactor
AIS Air Injection System
ALCL Assembly Line Communications Link
ALDL Assembly Line Diagnostic Link
ARC Automatic Ride Control
ASCD Automatic Speed Control Device
ASCS Air Suction Control Solenoid
ASD Auto Shutdown
ASDM Air Bag System Diagnostic Module
ASV Air Suction Valve
ATC Automatic Temperature Control
ATDC After Top Dead Center
ATF Automatic Transmission Fluid
ATS Air Temperature Sensor
AXOD Automatic Transaxle Overdrive
Abs. Absolute
Accy. Accessory
Alt. Alternator or Altitude
Amp. Ampere
Assy. Assembly
Auto. Automatic
Aux. Auxiliary
Avg. Average
\
\
\
\
\
\
\
\f
"B" ABBREVIATION TABLE
"B" ABBREVIATION TABLE
Page 246 of 1501
C - SPECIFICATIONS
1998 Mitsubishi Montero
1998 ENGINE PERFORMANCE
Mitsubishi - Service & Adjustment Specifications
Diamante, Eclipse, Galant, Mirage, Montero, Montero Sport,
3000GT
INTRODUCTION
Use this article to quickly find specifications related to
servicing and on-vehicle adjustments. This is a quick reference
article to use when you are familiar with an adjustment procedure and
only need a specification.
CAPACITIES
BATTERY SPECIFICATIONS TABLE \
\
\
\
\
\
Application Group Size CCA Rating
Diamante ................ 57NAS .................... 520
Eclipse .................. 86 ........... 430 Or ( 1) 525
Galant ................... D26 ..................... 490
Mirage ................. 55B24L .................... 433
Montero ............... 75D26R-MF .................. 490
Montero Sport .......... 75D23R .................... 520
3000GT ................ 75D23R-MF .................. 520
( 1) - Used on 2.0L non-turbo with A/T.
\
\
\
\
\
\
NOTE: Refill capacities are approximate. Correct fluid level
should be determined by mark on dipstick, if applicable.
FLUID CAPACITIES TABLE
\
\
\
\
\
\
Application Quantity
Automatic Transaxle
(Mitsubishi Plus/Mopar Plus/Dexron-II)
Diamante .............................. 9.0 Qts. (8.5L)
Eclipse
2.0L
Non-Turbo ......................... 9.1 Qts. (8.6L)
Turbo ............................. 7.1 Qts. (6.7L)
2.4L ................................ 6.4 Qts. (6.1L)
Galant ................................ 6.3 Qts. (6.0L)
Mirage ................................ 8.2 Qts. (7.8L)
3000GT ................................ 7.9 Qts. (7.5L)
Automatic Transmission
(Mitsubishi Plus/Mopar Plus/Dexron II)
Montero .............................. 10.0 Qts. (9.8L)
Montero Sport ........................ 10.4 Qts. (9.8L)
Cooling System
(Includes Heater & Reserve Tank)
Diamante ............................... 10 Qts. (9.5L)
Eclipse & Galant ...................... 7.4 Qts. (7.0L)
Mirage
1.5L ................................ 5.3 Qts. (5.0L)
1.8L ................................ 6.3 Qts. (6.0L)
Page 249 of 1501
Oil ................................................. 7500
Oil Filter .................................... (3) 15,000
Spark Plugs ....................................... 30,000
Spark Plug Wires .................................. 60,000
Timing & Balance Shaft Belts ...................... 60,000
( 1) - Inspect fluid every 15,000 miles. Replace fluid if
evidence of contamination appears, after repairing
reason for contamination.
( 2) - Inspect fluid every 30,000 miles. Replace fluid if
evidence of contamination appears, after repairing
reason for contamination.
( 3) - Replace oil filter at oil change if annual mileage is
less than 7500 miles.
\
\
\
\
\
\
REPLACEMENT INTERVALS TABLE (MIRAGE) \
\
\
\
\
\
Component Miles
Air Filter ........................................ 30,000
Automatic Transaxle Fluid ............................ ( 1)
Coolant .............................................. ( 2)
Oil ................................................. 7500
Oil Filter .................................... ( 3) 15,000
Spark Plugs ....................................... 30,000
Spark Plug Wires .................................. 60,000
Timing Belt ....................................... 60,000
( 1) - Inspect fluid every 15,000 miles. Replace fluid if
evidence of contamination appears, after repairing
reason for contamination.
( 2) - Inspect fluid every 30,000 miles. Replace fluid if
evidence of contamination appears, after repairing
reason for contamination.
( 3) - Replace oil filter at oil change if annual mileage is
less than 7500 miles.
\
\
\
\
\
\
REPLACEMENT INTERVALS TABLE (MONTERO) \
\
\
\
\
\
Component Miles
Air Filter ........................................ 30,000
Automatic Transmission Fluid ......................... ( 1)
Coolant ........................................... 30,000
Front & Rear Axle Fluid ( 2) ....................... 30,000
Oil ................................................. 7500
Oil Filter .................................... ( 3) 15,000
Manual Transmission .................................. ( 4)
Spark Plugs ( 5) ................................... 60,000
Spark Plug Wires .................................. 60,000
Timing Belt ....................................... 60,000
( 1) - Inspect fluid every 15,000 miles. Replace fluid if
evidence of contamination appears, after repairing
reason for contamination.
( 2) - Limited-slip differential.
( 3) - Replace oil filter at oil change if annual mileage is
less than 7500 miles.
( 4) - Inspect fluid every 30,000 miles. Replace fluid if
evidence of contamination appears, after repairing
reason for contamination.
Page 250 of 1501
![MITSUBISHI MONTERO 1998 Service Manual (5) - Use Platinum spark plugs only. \
\
\
\
\
\
REPLACEMENT INTERVALS TABLE (MON](/img/19/57333/w960_57333-249.png "MITSUBISHI MONTERO 1998 Service Manual (5) - Use Platinum spark plugs only. \
\
\
\
\
\
REPLACEMENT INTERVALS TABLE (MON")
(5) - Use Platinum spark plugs only. \
\
\
\
\
\
REPLACEMENT INTERVALS TABLE (MONTERO SPORT) \
\
\
\
\
\
Component Miles
Air Filter ........................................ 30,000
Automatic Transmission
Except 4WD ......................................... ( 1)
4WD ............................................. 30,000
Axle Fluid ( 2) .................................... 30,000
Coolant ........................................... 30,000
Oil ................................................. 7500
Oil Filter .................................... ( 3) 15,000
Spark Plugs ( 4) ................................... 60,000
Spark Plug Wires .................................. 60,000
Timing Belt ....................................... 60,000
( 1) - Inspect fluid every 15,000 miles. Replace fluid if
evidence of contamination appears, after repairing
reason for contamination.
( 2) - Limited-slip differential.
( 3) - Replace oil filter at oil change if annual mileage is
less than 7500 miles.
( 4) - Use Platinum spark plugs only.
\
\
\
\
\
\
REPLACEMENT INTERVALS TABLE (3000GT) \
\
\
\
\
\
Component Miles
Air Filter ........................................ 30,000
Automatic Transaxle Fluid ............................ ( 1)
Coolant ........................................... 30,000
Oil
Non-Turbo ......................................... 7500
Turbo ............................................. 5000
Oil Filter
Non-Turbo ....................................... 15,000
Turbo ........................................... 10,000
Spark Plugs
Except Platinum ................................. 30,000
Platinum ........................................ 60,000
Spark Plug Wires ( 2) .............................. 60,000
Timing Belt ....................................... 60,000
( 1) - Inspect fluid every 15,000 miles. Replace fluid if
evidence of contamination appears, after repairing
reason for contamination.
( 2) - Except vehicles equipped with Federal Emissions.
\
\
\
\
\
\
BELT ADJUSTMENT TABLE \
\
\
\
\
\
\
( 1) Deflection ( 1) Deflection
Application New Belt - In. (mm) Used Belt - In. (mm\
)
Diamante
Generator & A/C .... .24-.28 (6.0-7.2) ....... .32-.37 (8.2-9.3\
)
P/S ................ .33-.37 (8.4-9.3) ..... .46-.52 (11.7-13.4\
)
Eclipse
2.0L Non-Turbo
Page 414 of 1501
* DRIVETRAIN SYSTEMS UNIFORM INSPECTION GUIDELINES *
1998 Mitsubishi Montero
GENERAL INFORMATION
Drivetrain/Transmission Motorist Assurance Program
Standards For Automotive Repair
All Makes and Models
INTRODUCTION TO MOTORIST ASSURANCE PROGRAM (MAP)
CONTENTS
OVERVIEW OF MOTORIST ASSURANCE PROGRAM
OVERVIEW OF SERVICE REQUIREMENTS & SUGGESTIONS
Drive/Power Train Assemblies
AUTOMATIC TRANSMISSION/TRANSAXLE ASSEMBLIES
DIFFERENTIAL AND FINAL DRIVE ASSEMBLIES
MANUAL TRANSMISSION/TRANSAXLE ASSEMBLIES
TRANSFER CASE ASSEMBLIES
Drive/Power Train Components
ACTUATORS (ELECTRICAL)
ACTUATORS (VACUUM)
AXLES
BEARINGS AND RACES
BELL CRANKS
BELL HOUSINGS
BUSHINGS (EXTERNAL)
CABLES (SPEEDOMETER)
CABLES (TV, DETENT AND SHIFT)
CARRIER BEARINGS
CLUTCH CABLES AND CABLE HOUSINGS
CLUTCH DISCS (MANUAL TRANSMISSION)
CLUTCH FORKS
CLUTCH LINKAGES (MECHANICAL)
CLUTCH MASTER CYLINDERS
CLUTCH PEDALS
CLUTCH PIVOTS
CLUTCH PRESSURE PLATES
CLUTCH RELEASE BEARINGS
CLUTCH SLAVE CYLINDERS (CONCENTRIC)
CLUTCH SLAVE CYLINDERS (CONVENTIONAL OR EXTERNAL)
COMPANION FLANGES
CONNECTORS
COOLER BYPASS VALVES
COOLER LINES
COOLERS
CV JOINTS
DIP STICK TUBES
DIP STICKS (FLUID LEVEL INDICATORS)
DOWEL PINS, GUIDES AND PILOT HOLES
DRIVE SHAFT FLANGES
DRIVE SHAFTS AND HALF SHAFTS
DUST BOOTS
ENGINE MOUNTS
EXCITER RINGS
FILLER TUBES
FILTERS AND SCREENS
Page 470 of 1501
Door Lock Control Unit Behind left side of dash.
ELC 4-Speed Automatic Transmission
Control Module Behind left side of dash.
Engine Control Module (ECM) Behind right kick panel.
Keyless Entry Control Unit Behind right side quarter
panel.
Rear Differential Lock Control Unit Mounted on top of left rear
wheelwell.
SRS Air Bag Control Unit Behind center of dash.
Sun Roof Control Unit On center of roof, behind
sun roof.
Variable Shock Absorber Control Unit Behind left rear wheelwell,
behind quarter panel.
4WD Indicator Control Unit Behind center of dash.
\
\
\
\
\
\
\
MOTORS
\
\
\
\
\
\
\
Component Component Location \
\
\
\
\
\
\
Blower Motor Behind right side of dash.
Condenser Fan Motor On left front of engine
compartment.
Fuel Pump In fuel tank.
Headlight Washer Motor Right side of engine
compartment, in washer fluid
reservoir.
Idle Air Control Motor On throttle body.
Motor Antenna Rear of right front wheelwell.
Rear Differential Lock Air Pump On left rear of vehicle.
Rear Washer Motor In rear of cargo area.
Rear Wiper Motor On center of tailgate.
Sun Roof Motor On center of roof, behind
sun roof.
Windshield Washer Motor Bottom of windshield washer
reservoir.
Windshield Wiper Motor On left side of firewall.
\
\
\
\
\
\
\
SENDING UNITS & SENSORS
Page 473 of 1501
Outside Air Temperature Sensor Below left headlamp.
Park/Neutral Position Sensor On left side of transmission.
Throttle Position Sensor On throttle body.
Vehicle Speed Sensor (VSS) On transmission tailshaft.
Volume Airflow Sensor In air cleaner duct (includes
intake air temperature sensor
& barometric pressure sensor).
\
\
\
\
\
\
\
SOLENOIDS & SOLENOID VALVES
\
\
\
\
\
\
\
Component Component Location \
\
\
\
\
\
\
ABS Hydraulic Unit (w/Built-In
Solenoid Valve) In right rear corner of engine
compartment.
Cruise Control Actuator (w/Built-In
Control Valve & Release Valve)
(Calif.) In right rear of engine
compartment.
Cruise Control Actuator (w/Built-In
Control Valve & Release Valve)
(Federal) In left rear of engine
compartment.
EGR Solenoid In right rear of engine
compartment.
ELC 4-Speed Automatic Transmission
Control Solenoid Inside transmission.
Evaporative Emission Purge Solenoid On front of engine.
Evaporative Emission Ventilation
Solenoid In left rear of engine
compartment.
Solenoid Valves "A" & "B" In right side of engine
compartment.
\
\
\
\
\
\
\
SWITCHES
\
\
\
\
\
\
\
Component Component Location \
\
\
\
\
\
\
A/T Fluid Temperature Switch On left side of transmission.
Brake Fluid Level Switch In brake master cylinder
reservoir.
Center Differential Lock Detection
Switch On transfer case.
Page 723 of 1501
purge control valve, or vacuum hose routing.
DTC P0443
Evaporative (EVAP) purge control valve circuit failure.
Possible causes are: connector or harness, or faulty EVAP solenoid.
DTC P0446
Evaporative (EVAP) emission control system vent control
failure. Possible causes are: connector or harness, faulty EVAP vent
solenoid.
DTC P0450
Evaporative (EVAP) emission control system pressure sensor
failure. Possible causes are: connector or harness, or faulty fuel
tank differential pressure sensor.
DTC P0455
Evaporative (EVAP) emission control system large leak
detected. Possible causes are: connector or harness, faulty EVAP purge
solenoid, purge control valve, or vacuum hose routing.
DTC P0500
Vehicle Speed Sensor (VSS) failure. Possible causes are:
connector or harness, or faulty VSS.
DTC P0505
Idle Air Control (IAC) system failure. Possible causes are:
connector or harness, or faulty IAC motor.
DTC P0510
Closed Throttle Position (TP) switch failure. Possible causes\
are: connector or harness, or faulty closed TP switch.
DTC P0551
Power Steering Pressure (PSP) sensor failure. Possible causes\
are: connector or harness, or faulty PSP sensor.
DTC P0705
Automatic transaxle/transmission range sensor circuit
failure. Possible causes are: connector or harness, or faulty PNP
switch.
DTC P0710
Automatic transaxle/transmission fluid sensor failure.
Possible causes are: connector or harness, or faulty
transaxle/transmission sensor.
DTC P0715
Automatic transaxle input/turbine speed sensor circuit
failure. Possible causes are: connector or harness, or pulse
generator.
DTC P0720
Automatic transaxle input/turbine speed sensor circuit
failure. Possible causes are: connector or harness, or pulse
generator.
DTC P0725
Engine speed input circuit failure. Possible causes are:
connector or harness.
DTC P0740
Torque converter clutch system failure. Possible causes are:
Page 964 of 1501
![MITSUBISHI MONTERO 1998 Service Manual
\
\
\
\
\
\
\
\f
Engine Oil Ambient Temperature Less Than](/img/19/57333/w960_57333-963.png "MITSUBISHI MONTERO 1998 Service Manual
\
\
\
\
\
\
\
\f
Engine Oil Ambient Temperature Less Than")
\
\
\
\
\
\
\
\f
Engine Oil Ambient Temperature Less Than SAE 5W-30
(
1) 0\bF (-18\bC) To 100\bF (38\bC)
\
\
\
\
\
\
\f
Ambient Temperature Above 0\bF SAE 10W-30
(-18\bC) To Over 100\bF (38\bC)
\
\
\
\
\
\
\
\f
Power All Automatic Transmission
Steering Fluid DEXRON II
Fluid
\
\
\
\
\
\
\
\f
Engine All 50/50 Mixture Of
Coolant Distilled Water &
Ethylene Glycol
\
\
\
\
\
\
\
\f
Transfer Case All API Classification GL-4
SAE 75W-85W Or 75W-90
\
\
\
\
\
\
\
\f
Front Axle All API Classification GL-5
Or Higher (
2)
\
\
\
\
\
\
\
\f
Clutch Fluid All DOT 3 Or DOT 4
\
\
\
\
\
\
\
\f
Hook Lock All Multipurpose Grease
Catch, Door NLGI Grade 2
Lock Strikers
Seat Adjust-
ers, Backdoor
Lock, Parking
Brake Cable
Mechanism
\
\
\
\
\
\
\
\f
Front Wheel All Multipurpose Grease
Bearings NLGI Grade 2 Or
Equivalent
\
\
\
\
\
\
\
\f
Door Hinges, All Engine Oil
Back Door
Hinges
\
\
\
\
\
\
\
\f
A/C All HFC-134a
Refrigerant
\
\
\
\
\
\
\
\f
Manual All API Classification GL-4
Transmission SAE 75W-85W Or 75W-90
\
\
\
\
\
\
\
\f
Automatic All "ATF DEXRON II" Or
Transmission Equivalent
\
\
\
\
\
\
\
\f
Brake Fluid All DOT 3 Or DOT 4
\
\
\
\
\
\
\
\f
Rear Axle All API Classification GL-5
Or Higher (
2)
\
\
\
\
\
\
\
\f
(
1) - SAE 5W-30 engine oil is preferred. SAE 10W-30 may be used if
the Ambient Temperature is above 0\b F (-18\b C).
(
2) - SAE90, 85W-90, 80W-90 may be used in temperatures above
-10\b F (-23\b C). SAE 80W, 80W-90 may be used in temperatures
from -30\b F (-34\b C) to -10\b F (-23\b C). SAE 75W may be used
in temperatures below -30\b F (-34\b C).
\
\
\
\
\
\
\
Page 965 of 1501
![MITSUBISHI MONTERO 1998 Service Manual FLUID CAPACITIES
FLUID CAPACITIES TABLE ( 1) \
\
\
\
\
\
\](/img/19/57333/w960_57333-964.png "MITSUBISHI MONTERO 1998 Service Manual FLUID CAPACITIES
FLUID CAPACITIES TABLE ( 1) \
\
\
\
\
\
\")
FLUID CAPACITIES
FLUID CAPACITIES TABLE ( 1) \
\
\
\
\
\
\
Item Condition Specification
\
\
\
\
\
\
\
\f
Engine Oil Oil Pan 4.5 Qts. (4.3L)
(
1)
\
\
\
\
\
\
\f
Oil Filter 0.32 Qts. (0.3L)
\
\
\
\
\
\
\f
Oil Cooler 0.32 Qts. (0.3L)
\
\
\
\
\
\
\
\f
Power Drained 1.1 Qts. (1.0L)
Steering
\
\
\
\
\
\
\
\f
Automatic Drained 8.9 Qts. (8.5L)
Transmission
\
\
\
\
\
\
\
\f
Manual Drained 3.3 Qts. (3.2L)
Transmission
\
\
\
\
\
\
\
\f
Transfer Case Drained 2.6 Qts. (2.5L)
\
\
\
\
\
\
\
\f
Front Axle Drained 1.3 Qts. (1.2L)
\
\
\
\
\
\
\
\f
Rear Axle Drained 3.3 Qts. (3.2L)
\
\
\
\
\
\
\
\f
A/C Drained 27 oz (760 g)
Refrigerant
\
\
\
\
\
\
\
\f
Fuel Tank Capacity 24 gal (92L)
\
\
\
\
\
\
\
\f
(
1) - Capacities are recommended or calculated levels. Always use
dipstick to measure level.
\
\
\
\
\
\
\
WHEEL & TIRE SPECIFICATIONS
Tire specifications are imprinted on the tire side wall. The
recommended cold tire inflation pressures are listed on a label
attached to the rear face of the driver's door. These pressures
provide the best combination of ride comfort, tire wear and stability
under normal conditions.
CAUTION: DO NOT mix tires of different design such as radial ply
with bias or bias-belted tires. Mixing tire types will
adversely affect road handling and may lead to loss of
vehicle control. When using snow tires, they must be used
in set of four for maneuverability and safety. DO NOT use
tire chains on front wheels.
TIRE & WHEEL SPECIFICATIONS TABLE
\
\
\
\
\
\
Wheel Size Tire Size
15 x 6JJ (Steel or Aluminum) .................. P235/75R15
15 X 7JJ (Aluminum) ........................... P265/70R15
\
\
\
\
\
\
WHEEL TIGHTENING
