NISSAN 350Z 2007 Z33 Engine Lubrication System Workshop Manual

LU-1
ENGINE LUBRICATION SYSTEM
B ENGINE
CONTENTS
C
D
E
F
G
H
I
J
K
L
M
SECTION LU
A
LU
Revision: 2006 November2007 350Z
ENGINE LUBRICATION SYSTEM
PRECAUTIONS .......................................................... 2
Precautions for Battery Service ................................ 2
Precautions for Liquid Gasket .................................. 2
LIQUID GASKET APPLICATION PROCEDURE ..... 2
PREPARATION ........................................................... 3
Special Service Tools ............................................... 3
Commercial Service Tools ........................................ 3
LUBRICATION SYSTEM ............................................ 4
Lubrication Circuit .................................................... 4
System Chart ........................................................... 5
ENGINE OIL ............................................................... 6
Inspection ................................................................. 6
ENGINE OIL LEVEL ............................................. 6
ENGINE OIL APPEARANCE ................................ 6
ENGINE OIL LEAKAGE ........................................ 6
OIL PRESSURE CHECK ...................................... 7
Changing Engine Oil ................................................ 7OIL FILTER ................................................................. 9
Removal and Installation .......................................... 9
REMOVAL ............................................................. 9
INSTALLATION ..................................................... 9
INSPECTION AFTER INSTALLATION .................. 9
OIL PUMP ................................................................. 10
Removal and Installation ........................................ 10
REMOVAL ........................................................... 10
INSTALLATION ................................................... 10
INSPECTION AFTER INSTALLATION ................ 10
Disassembly and Assembly .................................... 10
DISASSEMBLY ................................................... 10
INSPECTION AFTER DISASSEMBLY ................ 11
ASSEMBLY ......................................................... 12
SERVICE DATA AND SPECIFICATIONS (SDS) ...... 13
Standard and Limit .................................................. 13
OIL PRESSURE .................................................. 13
OIL CAPACITY (APPROXIMATE) ....................... 13
OIL PUMP ........................................................... 13
REGULATOR VALVE .......................................... 13

LU-2
PRECAUTIONS
Revision: 2006 November2007 350Z
PRECAUTIONSPFP:00001
Precautions for Battery ServiceNBS00018
Before disconnecting the battery, lower both the driver and passenger windows. This will prevent any interfer-
ence between the window edge and the vehicle when the door is opened/closed. During normal operation, the
window slightly raises and lowers automatically to prevent any window to vehicle interference. The automatic
window function will not work with the battery disconnected.
Precautions for Liquid GasketNBS00019
LIQUID GASKET APPLICATION PROCEDURE
1. Removal old liquid gasket adhering to the liquid gasket application surface and the mating surface.

Remove liquid gasket completely from the liquid gasket application surface, mounting bolts, and bolt
holes.
2. Wipe the liquid gasket application surface and the mating surface with white gasoline (lighting and heating
use) to remove adhering moisture, grease and foreign materials.
3. Apply liquid gasket to the liquid gasket application surface.
Use Genuine RTV Silicone Sealant or equivalent. Refer to GI-45, "
RECOMMENDED CHEMICAL
PRODUCTS AND SEALANTS" .

Within five minutes of liquid gasket application, install the mating component.

If liquid gasket protrudes, wipe it off immediately.

Do not retighten mounting bolts or nuts after the installation.

After 30 minutes or more have passed from the installation, fill engine oil and engine coolant.

PREPARATION
LU-3
C
D
E
F
G
H
I
J
K
L
MA
LU
Revision: 2006 November2007 350Z
PREPARATIONPFP:00002
Special Service ToolsNBS0001A
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Commercial Service ToolsNBS0001B
Tool number
(Kent-Moore No.)
Tool nameDescription
ST25051001
(J25695-1)
Oil pressure gaugeMeasuring oil pressure
Maximum measuring range: 2,452 kPa (25
kg/cm
2 , 356 psi)
ST25052000
(J25695-2)
HoseAdapting oil pressure gauge to oil pan (upper)
KV10115801
(J38956)
Oil filter wrenchRemoving oil filter
a: 64.3 mm (2.531 in)
NT050
S-NT559
S-NT375
Tool nameDescription
Power toolLoosening nuts and bolts
Deep socketRemoving and installing oil pressure sensor
a: 24 mm (0.94 in)
PBIC0190E
PBIC2072E

LU-4
LUBRICATION SYSTEM
Revision: 2006 November2007 350Z
LUBRICATION SYSTEMPFP:15010
Lubrication CircuitNBS0001C
PBIC5026E

LUBRICATION SYSTEM
LU-5
C
D
E
F
G
H
I
J
K
L
MA
LU
Revision: 2006 November2007 350Z
System ChartNBS0001D
PBIC5027E

LU-6
ENGINE OIL
Revision: 2006 November2007 350Z
ENGINE OILPFP:KLA92
InspectionNBS0001E
ENGINE OIL LEVEL
NOTE:
Before starting engine, put vehicle horizontally and check the engine oil level. If engine is already started, stop
it and allow 10 minutes before checking.
1. Pull out oil level gauge and wipe it clean.
2. Insert oil level gauge and make sure the engine oil level is within
the range (A) shown in the figure.
3. If it is out of range, adjust it.
NOTE:
When checking oil level, insert oil level gauge (1) with its tip aligned with oil level gauge guide on cylinder
head.
ENGINE OIL APPEARANCE

Check engine oil for white turbidity or heavy contamination.

If engine oil becomes turbid and white, it is highly probable that it is contaminated with engine coolant.
Repair or replace damaged parts.
ENGINE OIL LEAKAGE
Check for oil leakage around the following areas:

Oil pans (lower and upper)

Oil pan drain plug

Oil pressure sensor

Oil filter

Valve timing control cover

Mating surface between cylinder head and rocker cover

Mating surface between front timing chain case and rear timing chain case

Mating surface between rear timing chain case and cylinder head

Mating surface between rear timing chain case and cylinder block

Mating surface between rear timing chain case and oil pan (upper)

Mating surface between cylinder block and cylinder head

Mating surface between lower cylinder block and cylinder block

Crankshaft oil seals (front and rear)

Camshaft position sensor and exhaust valve timing control position sensor.
PBIC4931E
2 : Engine cover
: Engine front
PBIC4932E

ENGINE OIL
LU-7
C
D
E
F
G
H
I
J
K
L
MA
LU
Revision: 2006 November2007 350Z
OIL PRESSURE CHECK
WARNING:

Be careful not to burn yourself, as engine oil may be hot.

Oil pressure check should be done in “Neutral position” (M/T models) or “Parking position” (A/T
models).
1. Check the engine oil level. Refer to LU-6, "
ENGINE OIL LEVEL" .
2. Remove undercover with power tool.
3. Disconnect harness connector at oil pressure sensor, and
remove oil pressure sensor using deep socket (commercial ser-
vice tool).
CAUTION:
Do not drop or shock oil pressure sensor.
4. Install the oil pressure gauge (SST) and hose (SST).
5. Start the engine and warm it up to normal operating temperature.
6. Check the engine oil pressure with engine running under no-load.
NOTE:
When the engine oil temperature is low, the engine oil pressure becomes high.
Engine oil pressure [Engine oil temperature at 80 °C (176 °F)]
kPa (kg/cm2 , psi)
If difference is extreme, check engine oil passage and oil pump for engine oil leaks.
7. After the inspections, install oil pressure sensor as follows:
a. Remove old liquid gasket adhering to oil presser sensor and the mating surface.
b. Apply liquid gasket and tighten oil pressure sensor to the specification.
Use Genuine RTV Silicone Sealant or equivalent. Refer to GI-45, "
RECOMMENDED CHEMICAL
PRODUCTS AND SEALANTS" .
c. After warming up engine, make sure there is no leakage of engine oil with running engine.
Changing Engine OilNBS0001F
WARNING:

Be careful not to burn yourself, as engine oil may be hot.
1 : Oil pressure switch
A: 2WD
: Engine front
PBIC4933E
SLC926
Engine speed Approximate discharge pressure
Idle speed More than 98 (1.0, 14)
2,000 rpm More than 294 (3.0, 43)
: 14.7 N·m (1.5 kg-m, 11 ft-lb)

LU-8
ENGINE OIL
Revision: 2006 November2007 350Z

Prolonged and repeated contact with used engine oil may cause skin cancer. Try to avoid direct
skin contact with used engine oil. If skin contact is made, wash thoroughly with soap or hand
cleaner as soon as possible.
1. Warm up engine, put vehicle horizontally and check for oil leakage from engine components. Refer to LU-
6, "ENGINE OIL LEAKAGE" .
2. Stop the engine and wait for 10 minutes.
3. Loosen oil filler cap and then remove drain plug.
4. Drain engine oil.
5. Install drain plug with new washer. Refer to EM-26, "
OIL PAN AND OIL STRAINER" .
CAUTION:
Be sure to clean drain plug and install with new washer.
6. Refill with new engine oil.
Engine oil specification and viscosity:
Refer to MA-11, "
RECOMMENDED FLUIDS AND LUBRICANTS" .
Engine oil capacity (Approximate):
Unit: (US qt, lmp qt)
CAUTION:

When filling engine oil, do not pull out oil level gauge.

The refill capacity depends on the engine oil temperature and drain time. Use these specifica-
tions for reference only.

Always use oil level gauge to determine the proper amount of engine oil in the engine.
7. Warm up engine and check area around drain plug and oil filter for oil leakage.
8. Stop engine and wait for 10 minutes.
9. Check the engine oil level. Refer to LU-6, "
ENGINE OIL LEVEL" . Oil pan drain plug:
: 34.3 N·m (3.5 kg-m, 25 ft-lb)
Drain and refill With oil filter change 4.9 (5-1/8, 4-1/4)
Without oil filter change 4.6 (4-7/8, 4)
Dry engine (Overhaul)5.5 (5-3/4, 4-7/8)

OIL FILTER
LU-9
C
D
E
F
G
H
I
J
K
L
MA
LU
Revision: 2006 November2007 350Z
OIL FILTERPFP:15208
Removal and InstallationNBS0001G
REMOVAL
WARNING:
Be careful not to get burned when engine and engine oil may be hot.
CAUTION:

Oil filter is provided with relief valve. Use Genuine NISSAN Oil Filter or equivalent.

When removing, prepare a shop cloth to absorb any engine oil leakage or spillage.

Do not allow engine oil to adhere to drive belts.

Completely wipe off any engine oil that adheres to engine and vehicle.
1. Remove undercover with power tool.
2. Using oil filter wrench [SST: KV10115801(J38956)] (B), remove
oil filter.
INSTALLATION
1. Remove foreign materials adhering to oil filter installation surface.
2. Apply engine oil to the oil seal contact surface of new oil filter.
3. Screw oil filter manually until it touches the installation surface,
then tighten it by 2/3 turn. Or tighten to specification.
INSPECTION AFTER INSTALLATION
1. Check the engine oil level. Refer to LU-6, "ENGINE OIL" .
2. Start engine, and check there is no leaks of engine oil.
3. Stop engine and wait for 10 minutes.
4. Check the engine oil level and adjust engine oil. Refer to LU-6, "
ENGINE OIL" .
A: 2WD
: Engine front
PBIC4934E
SMA010
Oil filter:
: 17.7 N·m (1.8 kg-m, 13 ft-lb)
SMA229B

LU-10
OIL PUMP
Revision: 2006 November2007 350Z
OIL PUMPPFP:15010
Removal and InstallationNBS0001I

Refer to GI-11, "Components" for symbol marks in the figure.
REMOVAL
1. Remove oil pan (lower) and oil strainer. Refer to EM-26, "OIL PAN AND OIL STRAINER" .
2. Remove front timing chain case and timing chain (primary). Refer to EM-53, "
TIMING CHAIN" .
3. Remove oil pump assembly.
INSTALLATION
CAUTION:
Before installation, apply new engine oil to the parts as instructed in the figure.
Note the following, and install in the reverse order of removal.

When installing, align crankshaft flat faces with inner rotor flat faces.
INSPECTION AFTER INSTALLATION
1. Check the engine oil level. Refer to LU-6, "ENGINE OIL" .
2. Start engine, and check there is no leaks of engine oil.
3. Stop engine and wait for 10 minutes.
4. Check the engine oil level and adjust engine oil. Refer to LU-6, "
ENGINE OIL" .
Disassembly and AssemblyNBS0001J
DISASSEMBLY
1. Remove oil pump cover.
2. Remove oil pump inner rotor and oil pump outer rotor from oil pump body.
3. After removing regulator valve plug, remove regulator valve spring and regulator valve.
1. Oil pump body 2. Oil pump outer rotor 3. Oil pump inner rotor
4. Oil pump cover 5. Regulator valve plug 6. Regulator valve spring
7. Regulator valve spring 8. Regulator valve
PBIC4935E
