Page 42 of 1808
GT-R Overview
GTR
Illustrated table of contents
0
Safety — Seats, seat belts and supplemental restraint
systemInstruments and controlsPre-driving checks and adjustmentsDisplay screen, heater, air conditioner and audio systemsStarting and drivingIn case of emergencyAppearance and careDo-it-yourselfMaintenance and schedules
123456789
Technical and consumer information
10
Index
11
Page 78 of 1808
0 Illustrated table of contentsSeats, seat belts and Supplemental Restraint
System (SRS).................................................................................... 0-2
Front ................................................................................................ 0-2
Rear .................................................................................................. 0-3
Exterior front ................................................................................... 0-4
Exterior rear ..................................................................................... 0-6 Passenger compartment ...................................................... 0-7
Cockpit ................................................................................................ 0-8
Instrument panel ........................................................................ 0-9
Meters and gauges ................................................................ 0-10
Engine compartment ........................................................... 0-11
Warning and indicator lights .......................................... 0-12
Page 162 of 1808
GT-R Overview
GTR
Illustrated table of contents
0
Safety — Seats, seat belts and supplemental restraint
systemInstruments and controlsPre-driving checks and adjustmentsDisplay screen, heater, air conditioner and audio systemsStarting and drivingIn case of emergencyAppearance and careDo-it-yourselfMaintenance and schedules
123456789
Technical and consumer information
10
Index
11
Page 198 of 1808
0 Illustrated table of contentsSeats, seat belts and Supplemental Restraint
System (SRS).................................................................................... 0-2
Front ................................................................................................ 0-2
Rear .................................................................................................. 0-3
Exterior front ................................................................................... 0-4
Exterior rear ..................................................................................... 0-6 Passenger compartment ...................................................... 0-7
Cockpit ................................................................................................ 0-8
Instrument panel ........................................................................ 0-9
Meters and gauges ................................................................ 0-10
Engine compartment ........................................................... 0-11
Warning and indicator lights .......................................... 0-12
Page 210 of 1808
1 Safety — Seats, seat belts and sup-plemental restraint system
Page 212 of 1808
NOTICE
Make sure the front seatback does
not contact the rear seat when re-
clining the seat. When the front seat
is reclined to the rearmost position, it
may contact the rear seat. This may
cause an indentation in the seat-
back.
FRONT SEATS
Front power seat adjustmentOperating tips
.The power seat motor has an auto-
reset overload protection circuit. If the
motor stops during operation, wait 30
seconds, then reactivate the switch.
. Do not operate the power seat switch
for a long period of time when the
engine is off. This will discharge the
battery.
Safety — Seats, seat belts and supplemental restraint system
1-3
Page 214 of 1808
, hold the knob
,
and tilt the seatback forward.
2. Use the seat adjustment switchto
slide the seat forward to a position
where it will be easier to enter or exit
the rear seats. Fold the shoulder belt
guide for easier access to the rear
seat.
To return the seatback to its original
position, hold the knob
, raise the seat- back, and use the seat adjustment switch
to adjust the seat position.
WARNING
Head restraints/headrests supple-
ment the other vehicle safety sys-
tems. They may provide additional
protection against injury in certain
rear end collisions.
Head restraints/headrests must be
adjusted properly, as specified in this
section. Check the adjustment after
someone else uses the seat. Failure
to follow these instructions can re-
duce the effectiveness of the head
restraints/headrests. This may in-
crease the risk of serious injury or
death in a collision.
Safety
Page 219 of 1808
Fastening the seat belts1. Adjust the seat. (
“Seats” page 1-2)
2. Slowly pull the seat belt out of the retractor and insert the tongue into
the buckle until you hear and feel the
latch engage.
.
The retractor is designed to lock
during a sudden stop or on im-
pact. A slow pulling motion per-
mits the belt to move, and allows
you some freedom of movement
in the seat.
.
If the seat belt cannot be pulled
from its fully retracted position,
firmly pull the belt and release it. Then smoothly pull the belt out of
the retractor.
Page 220 of 1808
The ELR locks the seat belt when the
vehicle slows down rapidly or during
impacts.
The Automatic Locking Retractor (ALR)
mode or child restraint mode locks the
seat belt for child restraint installation.
When the ALR mode is activated the seat
belt cannot be extended again until the
seat belt tongue is detached from the
buckle and fully retracted. The seat belt
returns to the ELR mode after the seat
belt is fully retracted.
(
“Front passenger air bag and
status light” page 1-42)
WARNING
When fastening the seat belts, be
certain that seatbacks are comple-
tely secured in the latched position.
If they are not completely secured,
passengers may be injured in an
accident or sudden stop.
Unfastening the seat beltsTo unfasten the seat belt, push the
button on the buckle. The seat belt
automatically retracts.
Checking seat belt operationSeat belt retractors are designed to lock
seat belt movement by two separate
methods:
. When the belt is pulled quickly from
the retractor.
. When the vehicle slows down rapidly.
To increase your confidence in the seat
belts, check the operation as follows:
. Grasp the shoulder belt and pull for-
ward quickly. The retractor should
lock and restrict further belt move-
ment.
If the retractor does not lock during this
check or if you have any question about
seat belt operation, see a GT-R certified
NISSAN dealer.
Safety — Seats, seat belts and supplemental restraint system
1-11
Page 244 of 1808
Sit upright and well back.
WARNING
.The front air bags ordinarily will
not inflate in the event of a side
impact, rear impact, rollover, or
lower severity frontal collision.
Always wear your seat belts to
help reduce the risk or severity of
injury in various kinds of acci-
dents.
. The front passenger air bag will
not inflate if the passenger air
bag status light is lit or if the front
passenger seat is unoccupied.
(
“Front passenger air bag
and status light” page 1-42)
. The seat belts and the front air
bags are most effective when you
are sitting well back and upright
in the seat. The front air bags
inflate with great force. Even with
the NISSAN Advanced Air Bag
System, if you are unrestrained,
leaning forward, sitting sideways
or out of position in any way, you
are at greater risk of injury or
death in a crash. You may also
receive serious or fatal injuries
from the front air bag if you are
up against it when it inflates.
Always sit back against the seat-
Safety — Seats, seat belts and supplemental restraint system
1-35
