NISSAN JUKE 2017 F15 / 1.G Quick Reference Guide

QUICK REFERENCE GUIDE
2017
JUKE

2
3
14
5
9
16
13
1718
19
20
21
14
15
12
11
7
6
8
*See your Owner’s Manual for information.1 Vehicle Information Display*2 Headlight and Turn Signal Switch3 Low Tire Pressure Warning Light4 Instrument Brightness

Control Switch*5 Twin Trip Odometer Reset

Switch* / Trip Computer

Mode Switch

Wiper and

Washer Switch7 Steering Wheel Switches for
Audio* / Bluetooth®
/ Siri®
Eyes Free
8 Cruise Control9 Outside Mirr or Control Switch10 Paddle Shif ters*11 Tilt Steering Adjustment*
12 Vehicle Dynamic Control (VDC)
OFF Switch*13 All-Wheel Drive (AWD) Switch*14 Fuel-filler Door Release15 Hood Release*16 Hazard Warning Flasher Switch*
17 Audio and Navigation System18 Integrated Control System19 Auxiliary Jack*20 USB Connection Port21 Power Outlet*
610

NEW SYSTEM FEATURESAround View® Monitor (AVM) with Moving Object Detection (MOD) (if so equipped)..2
SiriusXM Travel Link and SiriusXM Traffic (if so equipped) .............................4
Siri® E
yes Free
........................................................................\
..4
ESSENTIAL INFORMATIONFuel Efficient Driving ...................................................................5
Tir e Pressure Monitoring System (TPMS) ..............................................5
L
oose Fuel Cap
........................................................................\
.6
F

uel-filler Door .......................................................................\
..
6
T

owing Your Vehicle
....................................................................6

USB (Universal Serial Bus) Connection Port/Aux Jack and iPod® Interface
...........
7
Set

ting Display Brightness and Button Brightness
....................................7
Clock Set/A

djustment .................................................................
7
FIRST DRIVE FEATURESNissan Intelligent Key® System ........................................................9
Lif tgate Release.......................................................................10
He
ated Seats (if so equipped)
.........................................................10
Outside Mirr

or Control Switch .........................................................
11
S

tarting/Stopping the Engine .........................................................
11
He

adlight Control Switch .............................................................
12
Wiper and

Washer Switch
.............................................................13
He

ater and Air Conditioner (automatic) (with Integrated Control System)
(if so equipped)
........................................................................\
14
Driv

e Mode (with Integrated Control System) (if so equipped) .......................
15
FM/AM/SiriusXM® Satel

lite Radio with CD Player (if so equipped)
....................16
Cruise C

ontrol
........................................................................\
.17
Se

at Adjustments
.....................................................................17
SYSTEM GUIDE
Trip Computer .......................................................................\
.18
T ext Messaging .......................................................................\
18
NissanC

onnect
SM Mobile Apps (if so equipped).......................................19
Bluetooth® Hands-free Phone System ...............................................20
• S

ystem Operating Tips ...........................................................
20
Bluetooth® S

ystem without Navigation (if so equipped) .............................
20
Bluetooth® S

ystem with Navigation (if so equipped)
.................................22
Na

vigation System (if so equipped)
...................................................24
TABLE OF CONTENTS
Additional information about your vehicle is also available in your Owner’s Manual,
Navigation System Owner’s Manual and at www.NissanUSA.com.
Please see your Owner’s Manual for important safety information and system operation limitations.
• A c ellular telephone should not be used for any purpose while driving so full attention may be
given to vehicle operation.
•

A
lways wear your seat belt.
•

Supplemental air bags do not r
eplace proper seat belt usage.
•

Childr
en 12 and under should always ride in the rear seat properly secured in child restraints or
seat belts according to their age and weight.
•

Do not drink and driv
e.
F

or more information, refer to the “Safety — Seats, seat belts and supplemental restraint
system (section 1)”, the “Heater, air conditioner, audio and phone systems (section 4)” and the
“Starting and driving (section 5)” of your Owner’s Manual.

2
AROUND VIEW® MONITOR (AVM) WITH MOVING OBJECT
DETECTION (MOD) (if so equipped)
With the ignition switch in the ON position,
the Around View® Monitor is activated by
pressing the CAMERA button
1, located
on the navigation unit, or by moving the
shif t lever to the R (REVERSE) position. The
monitor displays various views of the position
of the vehicle.
When the v ehicle is in the P (PARK), N (NEUTRAL) or D (DRIVE) position and the
CAMERA button
1 is pressed, the following views will display in order:
NEW SYSTEM FEATURES
When the vehicle is in the R (REVERSE) position and the CAMERA button 1 is
pressed, the following views will display in order:
1
Start from any Control Panel screen
Front view & front-side viewPress
Press Press
Front view & bird’s-eye view
Rear view & bird’s-eye view
PressRear view & front-side viewPress
The colored guide lines on the display screen indicate vehicle width and
approximate distances to objects with reference to the vehicle body line.



• R
ed 1.5 f t (0.5 m); Yellow 3 f t (1 m); Green 7 f t (2 m) and 10 f t (3 m).
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

3
There are some areas where the system will not show objects.
When in the front or rear view display, an object below the bumper or on the
ground may not be viewed
2.
When in the bird’s-eye view, a tall object near
the seam of the camera viewing areas
3 will
not appear in the monitor.
The distanc e between the objects viewed
on the Around View Monitor differs from the
actual distance.
Objects in the bird’s-eye view will appear further than the actual distance.
MOVING OBJECT DETECTION (MOD)
If the MOD system detec ts moving objects
surrounding the vehicle, a yellow frame will be
displayed on the view where the objects are detected and a chime will
sound once.
In the bir d’s-eye view, a yellow frame is displayed on those camera images (front,
rear, right, lef t) where moving objects are detected.
The yellow frame 4 is displayed on each view in the front view and rear
view modes.
When the f ollowing are displayed:



•

Blue MOD ic
on
5; the system is operative
in this view.



•


Gr

ay MOD icon
6; the system is not
operative in this view.



•


No MOD ic

on; the system is off.
The MOD system wil l turn on automatically under the following conditions:



•

When the shif
t lever is in the R (REVERSE) position.



•
When the CAMERA button
1 is pressed to switch from a different screen to
the camera view on the display.



• When the v

ehicle speed decreases below approximately 5 mph (8 km/h).



• When the ignition switch is plac
ed in the OFF position and then back to the
ON position.
Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
For more information, refer to the “Heater, air conditioner, audio and phone systems (section 4)” of your
Owner’s Manual.
654
3
2
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

4
SiriusXM TRAVEL LINK AND SiriusXM
TRAFFIC (if so equipped)
Your vehicle’s Navigation System is equipped with SiriusXM Travel Link and SiriusXM
Traffic capabilities.
SiriusXM Travel Link provides access to real-
time weather information and forecasts,
nearby fuel prices, movie listings, sports
scores and stock quotes.
SiriusXM Traffic provides information that
may help to avoid delays due to traffic
incidents. Traffic jams, roadwork, road
closures around the current location, etc.,
are represented graphically on the map by
icons depicting the nature of the event. Incidents on the route are automatically
displayed as they are approached.
Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
For more information, refer to the “Navigation (section 4)” and the “General system information
(section 6)” of your Navigation System Owner’s Manual.
NEW SYSTEM FEATURES
SIRI® EYES FREE
If you have a compatible iPhone® with Siri®, you can link your iPhone® to the Siri® Eyes Free
function in your vehicle’s Bluetooth® System.
If you have a compatible iPhone® connected to the system, press and hold the
button
1 on the steering wheel for a few seconds
and Siri® will be activated in Eyes Free mode.
Please see your Owner’s Manual for important safety
information, system limitations, and additional operating and
feature information.
For more information, refer to the “Heater, air conditioner, audio and phone systems (section 4)” of your
Owner’s Manual and visit www.NissanUSA.com/bluetooth.
1
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

5
ESSENTIAL INFORMATION
FUEL EFFICIENT DRIVING
Fuel Efficient Driving Tips can be found in your Owner’s Manual. These tips are intended to help you achieve the best fuel economy from your vehicle.
Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
For more information, refer to the “Starting and driving (section 5)” of your Owner’s Manual.
TIRE PRESSURE MONITORING SYSTEM (TPMS)
A CHECK… TIRE…PRES… warning message 1 will appear
as scrolling text in the vehicle information display
2 and
the low tire pressure warning light
3 will illuminate when
one or more tires are low in pressure and air is needed.



• The tir

e pressures should be checked when the tires are
cold. The tires are considered cold af ter the vehicle has
been parked for 3 hours or more or driven less than 1 mi
(1.6 km) at moderate speeds.
Af ter tire pressures are adjusted, drive the vehicle at speeds above 16 mph (25 km/h). The CHECK…TIRE…PRES…
warning message
1 and the low tire pressure warning
light
3 will extinguish.
When the lo w tire pressure warning
light
3 flashes for 1 minute and then
remains on, the TPMS is not functioning
properly. Have the system checked. It is
recommended you visit a Nissan dealer for
this service.
Tire pressure rises and falls depending on the heat caused by the vehicle’s operation and the outside
temperature. Low outside temperature can lower the
temperature of the air inside the tire, which can cause a lower
tire inflation pressure. This may cause the low tire pressure
warning light
3 to illuminate. If the warning light illuminates, check the tire
pressure in your tires.



•


Check the tir

e pressures (including the spare tire) of ten and always prior to
long distance trips.
The Tire and Loading Information label contains valuable information. Please refer to the “Technical and consumer information (section 10)” of your Owner’s
Manual for the location of the Tire and Loading Information label.
Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
For more information, refer to the “Instruments and controls (section 2)”, the “Starting and driving
(section 5)” and the “Do-it-yourself (section 8)” of your Owner’s Manual.
2
3
1
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

6
ESSENTIAL INFORMATION
TOWING YOUR VEHICLE
ALL-WHEEL DRIVE (AWD) VEHICLE
An all-wheel drive vehicle must be towed with all wheels off the ground even if the vehicle is in the 2WD mode.
For proper towing and to avoid accidental damage to your vehicle, NISSAN
recommends that a service operator tow your vehicle af ter carefully reading the
Owner’s Manual precautions.
Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
For more information, refer to the “In case of emergency (section 6)” of your Owner’s Manual.
LOOSE FUEL CAP
A LOOSE FUEL CAP warning message will
appear in the vehicle information
display
1 when the fuel-filler cap is not
tightened correctly.
To tighten, turn the cap clockwise until a single click is heard.
The warning message will extinguish when the vehicle detects the fuel-filler cap is properly tightened and the reset button
2 is pressed for more than 1 second.
If the cap is not properly tightened, the Malfunction Indicator Light
may illuminate.
Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
For more information, refer to the “Instruments and controls (section 2)” and the “Pre-driving checks and
adjustments (section 3)” of your Owner’s Manual.
1
2
FUEL-FILLER DOOR
To open the fuel-filler door, pull the release 1
located on the lower instrument panel to the
lef t of the steering wheel.
The fuel-filler door is located on the
passenger’s side of
the vehicle.
Please see your Owner’s Manual for important safety
information, system limitations, and additional operating and
feature information.
For more information, refer to the “Pre-driving checks and
adjustments (section 3)” of your Owner’s Manual.
1
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

7
USB (Universal Serial Bus) CONNECTION PORT/AUX JACK AND
iPod® INTERFACE
The USB port/Aux jack 1 is located
underneath the climate controls.
When a c ompatible USB memory device, iPod®
or auxiliary device is plugged into
the USB port/Aux jack, compatible
audio files stored on the device can
be played through the vehicle’s
audio system.
Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
For more information, refer to the “Heater, air conditioner, audio and phone systems
(section 4)” of your Owner’s Manual.
1
CLOCK SET/ADJUSTMENT
FM/AM RADIO WITH COMPACT DISC (CD) PLAYER (if so equipped) AND FM/AM/SAT
RADIO WITH COMPACT DISC (CD) PLAYER (if so equipped)



1.

Pr
ess the ENTER/SETTING button
1 to
show the “Settings” screen on the display.



2.




Turn the TUNE/SCROLL knob
2 to
highlight “Clock Adjust”.



3.



Pr

ess the ENTER/SETTING button
1 to
highlight the hours or minutes and use the
TUNE/SCROLL knob
2 to adjust the value.



4.



Pr

ess the ENTER/SETTING button
1 to
set the value.
Press the BACK button 3 to return to the previous screen.
SETTING DISPLAY BRIGHTNESS AND BUTTON BRIGHTNESS
To adjust the Display Brightness and
Button Brightness:



1.
Press the D-MODE Select button.



2.
Press the SETUP button.



3.

T
urn the Selection dial to “ Display Brightness”
or “Button Brightness” then press the
ENTER button.



4.

T
urn the Selection dial to “+ ” to increase
brightness or to “- ” to decrease brightness
then press the ENTER button to apply
the selection.
Please see your Owner’s Manual for important safety
information, system limitations, and additional operating and feature information.
For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.
1
3
2
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

8
WITH NAVIGATION (if so equipped)
To adjust the time and the appearance of the clock on the display:



1.
Press the
button
4.



2.

Touch the “Settings” key.



3.

Touch the “System” key.



4.

Touch the “Clock” key.
The following settings can be adjusted:



• Time F
ormat: The clock can be set to 12 hours or 24 hours.



•

Date F
ormat: The date can be changed to one of five different formats.



•

Clock Mode:
From here, the clock mode options are:



·

Manual
: Allows for the option “Set Clock
Manually”. Touch this to begin setting the
clock manually using the “+” or “–” to
adjust the hours, minutes, day and month
up or down.



· Time Z
one: Touch the “Time Zone” key
5
to choose from the applicable time zone
list and/or touch “Daylight Savings Time”
to switch between ON and OFF.



·


A

uto: Automatically sets the clock to the vehicle’s current location.
Press the B ACK button 6 to return to the previous screen.
Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
For more information, refer to the “Heater, air conditioner, audio and phone systems (section 4)” of your
Owner’s Manual.
6
4
5
ESSENTIAL INFORMATION
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.
