service indicator Oldsmobile Silhouette 1999 Owner's Manuals

yellowblue
2-95
Low Coolant Warning Light
United States Canada
If this light comes on, your system is low on coolant and
the engine may overheat.
See ªEngine Coolantº in the Index and have your
vehicle serviced as soon as possible.
Malfunction Indicator Lamp (Service
Engine Soon Light in the United States or
Check Engine Light in Canada)
United States Canada
Your vehicle is equipped with a computer which
monitors operation of the fuel, ignition and emission
control systems.
This system is called OBD II (On
-Board
Diagnostics
-Second Generation) and is intended to assure
that emissions are at acceptable levels for the life of the
vehicle, helping to produce a cleaner environment. The
SERVICE ENGINE SOON or CHECK ENGINE light
comes on to indicate that there is a problem and service is
required. Malfunctions often will be indicated by the
system before any problem is apparent. This may prevent
more serious damage to your vehicle. This system is also
designed to assist your service technician in correctly
diagnosing any malfunction.

yellowblue
3-27
After you clean the player, press and hold EJECT for
five seconds to reset the CLN indicator. The radio will
display
--- to show the indicator was reset.
Cassettes are subject to wear and the sound quality
may degrade over time. Always make sure the cassette
tape is in good condition before you have your tape
player serviced.
Care of Your Compact Discs
Handle discs carefully. Store them in their original cases
or other protective cases and away from direct sunlight
and dust. If the surface of a disc is soiled, dampen a
clean, soft cloth in a mild, neutral detergent solution and
clean it, wiping from the center to the edge.
Be sure never to touch the signal surface when handling
discs. Pick up discs by grasping the outer edges or the
edge of the hole and the outer edge.
Care of Your Compact Disc Player
The use of CD lens cleaner discs is not advised, due to
the risk of contaminating the lens of the CD optics with
lubricants internal to the CD mechanism.
Integrated Windshield Antenna
The antenna in your vehicle is a very thin, metal layer in
the windshield. If you look near the edges of the
windshield, you can see the outline of the antenna. The
connector is at the top of the windshield, where the
headliner ends.
If you experience difficulty with remote transmitters,
such as a garage door opener, try pointing the device
through the very top of the windshield.

yellowblue
6-4
If your vehicle is certified to meet California Emission
Standards (indicated on the underhood emission control
label), it is designed to operate on fuels that meet
California specifications. If such fuels are not available
in states adopting California emissions standards, your
vehicle will operate satisfactorily on fuels meeting
federal specifications, but emission control system
performance may be affected. The malfunction indicator
lamp on your instrument panel may turn on and/or your
vehicle may fail a smog
-check test. (See ªMalfunction
Indicator Lampº in the Index.) If this occurs, return to
your authorized Oldsmobile dealer for diagnosis to
determine the cause of failure. In the event it is
determined that the cause of the condition is the type of
fuels used, repairs may not be covered by your warranty.
Some gasolines that are not reformulated for low
emissions may contain an octane
-enhancing additive
called methylcyclopentadienyl manganese tricarbonyl
(MMT); ask your service station operator whether or not
the fuel contains MMT. General Motors does not
recommend the use of such gasolines. If fuels containing
MMT are used, spark plug life may be reduced and your
emission control system performance may be affected.
The malfunction indicator lamp on your instrument
panel may turn on. If this occurs, return to your
authorized Oldsmobile dealer for service.To provide cleaner air, all gasolines in the United States
are now required to contain additives that will help
prevent deposits from forming in your engine and fuel
system, allowing your emission control system to
function properly. Therefore, you should not have to add
anything to the fuel. In addition, gasolines containing
oxygenates, such as ethers and ethanol, and
reformulated gasolines may be available in your area to
contribute to clean air. General Motors recommends that
you use these gasolines, particularly if they comply with
the specifications described earlier.
NOTICE:
Your vehicle was not designed for fuel that
contains methanol. Don't use it. It can corrode
metal parts in your fuel system and also damage
plastic and rubber parts. That damage wouldn't
be covered under your warranty.

yellowblue
6-29 Brake Wear
Your vehicle has front disc brakes and rear drum brakes.
Disc brake pads have built
-in wear indicators that make
a high
-pitched warning sound when the brake pads are
worn and new pads are needed. The sound may come
and go or be heard all the time your vehicle is moving
(except when you are pushing on the brake
pedal firmly).
CAUTION:
The brake wear warning sound means that soon
your brakes won't work well. That could lead to
an accident. When you hear the brake wear
warning sound, have your vehicle serviced.
NOTICE:
Continuing to drive with worn-out brake pads
could result in costly brake repair.
Some driving conditions or climates may cause a brake
squeal when the brakes are first applied or lightly
applied. This does not mean something is wrong with
your brakes.
Properly torqued wheel nuts are necessary to help
prevent brake pulsation. When tires are rotated, inspect
brake pads for wear and evenly torque wheel nuts in the
proper sequence to GM specifications.
Your rear drum brakes don't have wear indicators, but if
you ever hear a rear brake rubbing noise, have the rear
brake linings inspected immediately. Also, the rear
brake drums should be removed and inspected each time
the tires are removed for rotation or changing. When
you have the front brake pads replaced, have the rear
brakes inspected, too.
Brake linings should always be replaced as complete
axle sets.
See ªBrake System Inspectionº in Section 7
of this manual under Part C ªPeriodic
Maintenance Inspections.º

yellowblue
6-42
When It's Time for New Tires
One way to tell when it's
time for new tires is to
check the treadwear
indicators, which will
appear when your tires have
only 1/16 inch (1.6 mm) or
less of tread remaining.
You need a new tire if any of the following statements
are true:

You can see the indicators at three or more places
around the tire.

You can see cord or fabric showing through the
tire's rubber.

The tread or sidewall is cracked, cut or snagged deep
enough to show cord or fabric.
The tire has a bump, bulge or split.

The tire has a puncture, cut or other damage that
can't be repaired well because of the size or location
of the damage.
Buying New Tires
To find out what kind and size of tires you need, look at
the Certification/Tire label.
The tires installed on your vehicle when it was new had
a Tire Performance Criteria Specification (TPC Spec)
number on each tire's sidewall. When you get new tires,
get ones with that same TPC Spec number. That way
your vehicle will continue to have tires that are designed
to give proper endurance, handling, speed rating,
traction, ride and other things during normal service on
your vehicle. If your tires have an all
-season tread
design, the TPC number will be followed by an ªMSº
(for mud and snow).
If you ever replace your tires with those not having a
TPC Spec number, make sure they are the same size,
load range, speed rating and construction type (bias,
bias
-belted or radial) as your original tires.

yellowblue
9-2
Brake
Adjustment 6-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid 6-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Master Cylinder 6-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parking 2-47 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Pedal Travel 6-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacing System Parts 6-30 . . . . . . . . . . . . . . . . . . . . . . . .
System Warning Light 2-90, 6-28 . . . . . . . . . . . . . . . . . . . .
Trailer 4-36 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Transaxle Shift Interlock (BTSI) 2-50 . . . . . . . . . . . . . . . . .
Transaxle Shift Interlock Check 7-32 . . . . . . . . . . . . . . . . . .
Wear 6-29 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brakes, Anti-Lock 4-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Braking 4-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Braking in Emergencies 4-11 . . . . . . . . . . . . . . . . . . . . . . . . . .
Break-In, New Vehicle 2-37 . . . . . . . . . . . . . . . . . . . . . . . . . .
BTSI 2-50 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BTSI Check 7-32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Bucket Seats 1-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Adjusting 1-16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Folding or Reclining the Seatback 1-15 . . . . . . . . . . . . . . . .
Removing 1-17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacing 1-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Bulb Replacement 6-31 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Canada, Ordering Service and Owner Publications 8-11 . . .
Canadian Roadside Assistance 8-7 . . . . . . . . . . . . . . . . . . . . . .
Capacities and Specifications 6-63 . . . . . . . . . . . . . . . . . . . . . .
Captain's Chairs 1-21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Removing 1-21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacing 1-22 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Carbon Monoxide 2-52, 4-28, 4-36 . . . . . . . . . . . . . . . . . . . . Cassette
Deck Service 7
-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tape Player 3-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tape Player Care 3-26 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CD Adapter Kits 3-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Center Rear Passenger Position
Bench Seat 1
-52 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Bucket Seat 1-54 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Certification/Tire Label 4-29 . . . . . . . . . . . . . . . . . . . . . . . . . .
Chains
Safety 4
-36 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tire 6-46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Changing a Flat Tire 5-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Charging System Indicator Light 2-90 . . . . . . . . . . . . . . . . . . .
Checking Your Restraint Systems 1-88 . . . . . . . . . . . . . . . . . .
Chemical Paint Spotting 6-53 . . . . . . . . . . . . . . . . . . . . . . . . . .
Child Restraints 1-70 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Built-in 1-59 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cleaning Built-in 6-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Removing from a Built-in 1-67 . . . . . . . . . . . . . . . . . . . . . .
Securing in a Built-in 1-61 . . . . . . . . . . . . . . . . . . . . . . . . . .
Securing in a Rear Outside Seat Position 1-76 . . . . . . . . . . .
Securing in the Center Seat Position (Bucket Seat) 1-80 . . . . .
Securing in the Center Seat Position
(Third Row Bench Seat) 1
-78 . . . . . . . . . . . . . . . . . . . . . .
Securing in the Right Front Seat Position 1-82 . . . . . . . . . .
Storing a Built-in 1-68 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Top Strap 1-75 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Where to Put 1-74 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cigarette Lighter 2-79 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Circuit Breakers and Fuses 6-57 . . . . . . . . . . . . . . . . . . . . . . .
Cleaner, Air 6-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

yellowblue
9-6
Inspections
Brake System 7-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Exhaust Systems 7-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front Drive Axle Boot and Seal 7-34 . . . . . . . . . . . . . . . . . .
Radiator and Heater Hose 7-34 . . . . . . . . . . . . . . . . . . . . . .
Steering 7-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Suspension 7-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Throttle System 7-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Instrument Panel 2-84 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cleaning 6-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cluster 2-86 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuse Block 6-57 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Light Intensity Control 2-63 . . . . . . . . . . . . . . . . . . . . . . . . .
Switchbank 2-12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interior Lamps 2-63 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Control 2-63 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Override Switch 2-64 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Jack, Tire 5-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Jump Starting 5-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Key in the Ignition 2-32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Key Lock Cylinders Service 7-31 . . . . . . . . . . . . . . . . . . . . . .
Keys 2-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Labels
Certification/Tire 4-29 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service Parts Identification 6-55 . . . . . . . . . . . . . . . . . . . . .
Tire-Loading Information 4-29 . . . . . . . . . . . . . . . . . . . . . .
Vehicle Identification Number 6-55 . . . . . . . . . . . . . . . . . . .
Lamps
Cargo 2
-66 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Delayed Illumination 2-65 . . . . . . . . . . . . . . . . . . . . . . . . . .
Dome 2-66 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Exit Lighting 2
-65 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Exterior 2-61 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fog 2-63 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Illuminated Entry 2-64 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interior 2-63 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
On Reminder 2-62 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Last Door Closed Locking 2-6 . . . . . . . . . . . . . . . . . . . . . . . . .
Last Door Closed Locking and Lockout Prevention 2-16 . . . .
Leaving Your Vehicle 2-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Leaving Your Vehicle with the Engine Running 2-49 . . . . . . .
Liftgate 2-31 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lighter 2-79 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lights
Air Bag Readiness 1
-40, 2-89 . . . . . . . . . . . . . . . . . . . . . . .
Anti-Lock Brake System Warning 2-91, 4-7 . . . . . . . . . . . .
Brake System Warning 2-90, 6-28 . . . . . . . . . . . . . . . . . . . .
Charging System Indicator 2-90 . . . . . . . . . . . . . . . . . . . . . .
Check Engine 2-95 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Door Ajar 2-99 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine Coolant Temperature Warning 2-94 . . . . . . . . . . . . .
Low Coolant Warning 2-95, 6-24 . . . . . . . . . . . . . . . . . . . .
Low Fuel Warning 2-101 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Low Oil Level 2-100, 6-11 . . . . . . . . . . . . . . . . . . . . . . . . .
Low Traction 2-93, 4-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Oil Pressure 2-98 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PASS-Key
III Security 2-99 . . . . . . . . . . . . . . . . . . . . . . .
Power Sliding Door Warning Light 2-99 . . . . . . . . . . . . . . .
Safety Belt Reminder 1-24, 2-92 . . . . . . . . . . . . . . . . . . . . .
Service Engine Soon 2-95 . . . . . . . . . . . . . . . . . . . . . . . . . .
Traction Control System Warning 2-92, 4-10 . . . . . . . . . . .
Loading Your Vehicle 4-29 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lockout Deterrent 2-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

yellowblue
9-7
Locks
Automatic Door 2-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Canceling the Sliding Door Security 2-31 . . . . . . . . . . . . . .
Cylinders 7-31 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Door 2-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ignition Transaxle Check 7-33 . . . . . . . . . . . . . . . . . . . . . . .
Key Lock Cylinder Service 7-31 . . . . . . . . . . . . . . . . . . . . .
Last Door Closed Locking 2-6 . . . . . . . . . . . . . . . . . . . . . . .
Lockout Deterrent 2-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power Door 2-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Sliding Door 2-24 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Sliding Door Child Security 2-29 . . . . . . . . . . . . . . . . . . . . .
Sliding Door Delayed Locking 2-6 . . . . . . . . . . . . . . . . . . .
Loss of Control 4-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Low Coolant Warning Light 2-95, 6-24 . . . . . . . . . . . . . . . . .
Low Fuel Warning Light 2-101 . . . . . . . . . . . . . . . . . . . . . . . .
Low Oil Level Light 2-100, 6-11 . . . . . . . . . . . . . . . . . . . . . .
Low Traction Light 2-93, 4-9 . . . . . . . . . . . . . . . . . . . . . . . . .
Lubricants and Fluids 7-35 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lubrication Service, Body 7-31 . . . . . . . . . . . . . . . . . . . . . . . .
Luggage Carrier 2-76 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lumbar Control 1-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance, Normal Replacement Parts 6-65 . . . . . . . . . . .
Maintenance Record 7-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance Schedule 7-1 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
How This Section is Organized 7-2 . . . . . . . . . . . . . . . . . . .
Long Trip/Highway Definition 7-6 . . . . . . . . . . . . . . . . . . .
Long Trip/Highway Intervals 7-7 . . . . . . . . . . . . . . . . . . . . .
Owner Checks and Services 7-30 . . . . . . . . . . . . . . . . . . . . .
Periodic Maintenance Inspections 7-34 . . . . . . . . . . . . . . . .
Recommended Fluids and Lubricants 7-35 . . . . . . . . . . . . . Scheduled Maintenance Services 7
-4 . . . . . . . . . . . . . . . . . .
Short Trip/City Definition 7-5 . . . . . . . . . . . . . . . . . . . . . . .
Short Trip/City Intervals 7-5 . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance, Underbody 6-53 . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance When Trailer Towing 4-39 . . . . . . . . . . . . . . . . .
Malfunction Indicator Lamp 2-95 . . . . . . . . . . . . . . . . . . . . . .
Matching Transmitters to Your Vehicle 2-10 . . . . . . . . . . . . . .
Mirrors 2-67 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Convex Outside 2-68 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Heated Outside 2-68 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inside Day/Night Rearview 2-67 . . . . . . . . . . . . . . . . . . . . .
Power Remote Control 2-67 . . . . . . . . . . . . . . . . . . . . . . . . .
Visor Vanity 2-80 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Mountain Roads 4-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Multifunction Alarm Locks and Lighting Choices 2-13 . . . . .
Arming and Disarming the Content
Theft
-Deterrent System 2-21 . . . . . . . . . . . . . . . . . . . . . . .
Automatic Door Locks 2-15 . . . . . . . . . . . . . . . . . . . . . . . . .
Content Theft-Deterrent System 2-19 . . . . . . . . . . . . . . . . .
Delayed Illumination and Exit Lighting 2-14 . . . . . . . . . . .
Entering Programming Mode 2-14 . . . . . . . . . . . . . . . . . . . .
Exiting Programming Mode 2-23 . . . . . . . . . . . . . . . . . . . . .
Last Door Closed Locking and Lockout Prevention 2-16 . . . .
Remote Driver's Unlock Control 2-17 . . . . . . . . . . . . . . . . .
Remote Lock and Unlock Confirmation 2-18 . . . . . . . . . . .
Multifunction Lever 2-55 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Net, Convenience 2-74 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
NEUTRAL(N) 2-44 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
New Vehicle ªBreak-Inº 2-37 . . . . . . . . . . . . . . . . . . . . . . . . .
Night Vision 4-16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Normal Maintenance Replacement Parts 6-65 . . . . . . . . . . . . .
