Page 4 of 135
30-06-200376
YOUR AT A GLANCE4
THE ELECTRIC
RETRACTABLE ROOF Opening the roof Park the vehicle on level ground. Ensure that the screen 1is
hooked on (nothing must be placed on the screen; if thereis luggage in the boot, it mustnot cause the screen to liftup).
Check that there are noobjects on the rear shelf.
Close the boot correctly.
When stationary , with the
handbrake applied, turn theignition key to position M.
Completely release the two
hooks 2; this operation is vali-
dated by an audible signal.
Pull button 3until you hear a
signal which confirms that theroof opening operation is com-plete.
Note: during this operation, the
windows open. Closing the roof
Ensure that the screen 1is
hooked on.
Close the boot correctly.
When stationary , with the
handbrake applied, turn the ignition key to position M.
Press button 3until you hear a
signal which confirms that theroof closing operation is com-plete.
Only then, lock the two hooks2.
Note: the window control switches
become operational again afterthe roof manoeuvre. The roof must not beoperated when a load-ed luggage carrier is fit-ted on the boot lid.
During roof opening or closingoperations, to avoid risk of
injury, ensure that no-one is inthe proximity of the movingparts.
Never switch the ignition off during roof manoeuvres. Never release button 3 for more than five minutes whenthe roof is in an intermediateposition (neither completelyopen nor completely closed).
However, if there is any dan-
ger, release the controlswitch; the operation will
stop instantly. You canresume the cycle until theaudible signal ceases.
Page 5 of 135
30-06-20038584
5YOUR AT A GLANCE
ELECTRIC WINDOWS
1. Driver's electric windows
switch
2. Passenger's electric windows switch
These control the front window and the rear quarter panel win-dow on their respective sides. Manual operation Press the switch (to open) or pull it (to close) without goingbeyond the point of resis-
tance. The window stops assoon as the switch isreleased. The rear quarter panel win- dow can only open when thefront window is completelyopen, after being inactive forone second.
Automatic operation ¥ Opening
The windows open automatically (with the ignition key in theRunning position, engine on).
Press the switch past the pointof resistance:
- a brief press opens the front window completely; thenanother brief press completelyopens the rear quarter panel
window,
- a long press opens the front window completely, then the
rear quarter panel window.
¥ Closing
Only the front window on thedriver's side closes automatically(engine running or vehicle beingdriven), when the rear quarterpanel window is closed. Briefly pull the switch past the point of resistance to com-pletely close the front windowon the driver's side.
Note: the window switches
are inoperative when theroof is being adjusted. ELECTRIC MIRRORS
Turn knob
3to the right or to the
left to select the corresponding
mirror. Move knob 3in all four directions
to adjust. Electrically folding mirrors With the ignition on, turn knob 3
to position A.
Page 6 of 135
30-06-2003
6YOUR AT A GLANCE
73
ELECTRONIC IMMOBILISER This locks the engine control sys- tem a few moments after the igni-tion has been switched off andtherefore prevents starting of thevehicle by anyone who does not
have the key. Operation Each key has an electronic chip, which has a special code. When the ignition is switched on, the key code is recognised andstarting is possible. If the key does not have a code
or has a different code from that
stored in the system memory, thevehicle will not start. Additional key
You can store up to 5 keys in the
memory.If you require an additional key or
wish to change a faulty key, you
must visit a PEUGEOT dealerwith the confidential card and allthe keys in your possession. Key in ignition If you leave the key in the ignition, a buzzer reminds you ofthis when opening the driver's
door.
Confidential card This contains the identification code, which is required if anywork is carried out on the system
by a PEUGEOT dealer. Thiscode is concealed by a film,which must not be removedunless required. Keep your card in a safe place, never in your vehicle.
When buying a second-hand car:
- ensure that you are given the confidential card;
- it is advisable to have the key codes memorised by a PEUGEOT dealer to ensure that the keys in your possessionare the only ones which can start the vehicle.
Do not make any modifications to the electronic immobilser system.
Page 7 of 135
7YOUR AT A GLANCE
72
Starting the engine
Do not press the accelerator.
Operate the starter, without
releasing the key, until theengine turns. THE KEYS The keys operate independently the locks for the doors, the boot(opening), the fuel filler flap, thesteering lock and the glove boxas well as operating the passen-ger air bag disarming switch.Never race a coldengine.
Never run the engine in anenclosed space. Do not make any modications to the steering lock. Central locking
From the driver's door, the keys allow you to:
- simultaneously lock the doors
and the boot,
- simultaneously unlock the doors alone.
You can only unlock the boot by using the boot lock. The remote control Pressing button A
allows you to lock the doors and bootby remote control. This is confirmed by the fixed lighting ofthe direction indica-tors for approximate-ly two seconds. Pressing button B
allows you to unlock the doors alone. This is confirmed by the rapid flashing of the direction indicatorsfor approximately two seconds.
STARTING The four positions of the key in the ignition:
STOP position:
the ignition is off.
1st notch, Accessories position:
the ignition is off but the acces-sories can be used. 2nd notch, Running position: the ignition is on. Starting position:
operates the starter. Steering lock Before starting, unlock the steer-
ing if necessary, by gently turningthe steering wheel at the same
time as you turn the key. It is advisable to press the clutch pedal while operating the starter
to make starting easier.
30-06-2003
Page 8 of 135
30-06-2003
8YOUR AT A GLANCE
7880
STEERING WHEEL CONTROLS Lights stalk Front and rear lights(ring A)
Lights off Side lights
Dipped / main beam headlamps Automatic lighting of headlamps
Automatic lighting of headlamps
To activate or deactivate the function, place the key in theaccessories position, the lightsstalk in position 0 and press theend of the stalk for more thanfour seconds. Windscreen wipers
2 Fast wipe
1 Normal wipe
I Intermittent wipe
or AUTO Automatic wipe
0 Off
Single wipe
Automatic wipe In the AUTO position, the wiper
operates automatically and adjusts its speed to the inten-sity of the rainfall.
Windscreen wash Pull the windscreen wiper stalk towards you.
Front/rear fog lamps
(ring B)
Front fog lamps (1strotation of the ring for-wards) Front and rear foglamps (2nd rotationof the ring forwards)
Page 11 of 135
30-06-2003
11YOUR AT A GLANCE
9367
FRONT AIR BAGS Disarming the passenger air bag* Insert the ignition key in the switch 1and turn it to:
- the ONposition; the passenger
air bag is armed,
- the OFFposition; the passenger
air bag is disarmed.
Operating check
With the ignition on (2nd notch),illumination of this warning light,accompanied by an audible sig-nal and the message"Passenger air bag deactivat-ed" on the multifunction display,
indicates that the passenger airbag is disarmed (switch in the"OFF" position).
The warning lightremains on through-out the disarmingprocess. ''ISOFIX'' MOUNTINGS
Available on the front passenger seat, Isofix mountings allow fit-ting of a
special child seat sold
by PEUGEOT dealers. The locks incorporated in the child seat fit onto the 'Isofix'mountings, ensuring reliable,
safe and fast fitting. The childseat must be fitted in the rear-wards-facing position for childrenless than 13kg (in this event it
is essential to disarm the pas-senger air bag). Follow the instructions for fitting the child seat in theinstallation brochure.
Precautions regarding thepassenger air bag
Vehicle fitted with a passenger air bag disarming switch:
- disarm the air
bag if you install a rearwards-fac-ing child seat
- arm the air bag for an adult pas-
senger.
Vehicle not fitted with a passengerair bag disarming switch:
- do not install a rear- wards-facing child seat on the frontpassenger seat.
Never place your feet or anyobject on the fascia panel.
* According to destination.
Page 20 of 135
30-06-2003
PEUGEOT SERVICING
22
TYPES OF SERVICE Each vehicle has its own servicing cycle, based upon the engine type.
This cycle consists of alternating two types of service, A and C, intermediate visits and a few additional operations depend- ing on your vehicle; these correspond to key stages in the life of your vehicle. When the first service is carried out and at each subsequent service, your dealer will advise you of the type and content of the next service due.
Intermediate top-up visitincorporated in the ServicingSchedule.
These services are to be carried out with
10W40 synthetically based oil
minimum. They can also be carried out with 5W30 Fuel Economy oilor with 5W40
synthetic oil .
Arduous conditions of use (see corresponding section).
* Whichever comes first. THE MAINTENANCE CYCLE FOR YOUR 206 CC
Service every 20,000 miles (30,000 km) or 2 years
80,000 (120,000) 100,000 (150,000) 120,000 (180,000) 140,000 (210,000) 160,000 (240,000) MILES (KM) 20,000 (30,000) 40,000 (60,000) 60,000 (90,000)
1st service at 6,000 miles (10,000 km) or 6 months*.
This is necessary in order to benefit from the warranty
Page 36 of 135
30-06-2003
YOUR 206 CC IN DETAIL
36
GENERAL FUNCTIONS On/off With the ignition key in the accessories or ignition position, press button Ato switch the set on or off.
The set can operate for 30 minutes without the vehicle ignition being switched on.
Anti-theft systemThe audio system is coded in such a way that it can operate only on your vehicle. It would not function if fitted to anoth- er vehicle. The anti-theft system is automatic and requires no action on your part. ADJUSTING THE VOLUME Press the button Cto increase the volume, or button Bto decrease it.
Continuous pressure on buttons Band Callows a gradual adjustment of the volume.
AUDIO SETTINGS Press button Gseveral times in succession to access the bass (BASS), treble (TREB), loudness (LOUD),
fader (FAD) , balance (BAL)and automatic volume correction settings.
Exit from audio mode is automatic after a few seconds without pressing any button, or by pressing button G
after configuration of the automatic volume correction. Note: bass and treble settings are specific to each source. It is possible to set them differently for radio, CD
or CD changer.
Page 68 of 135
30-06-2003
YOUR 206 CC IN DETAIL69
Groups 2 and 3: from 15 to 36 kg L4 - ''Recaro Start'': installed in the rear with a three-point seat belt.
The height and width of the seat back and length of the seat cushion must be adjusted according to the age and build of your child.
L5 - "Klippan Optima": installed in the rear with a three-point seat belt. From the age of 6 years (approximately 22 kg), the booster is used on itsown.
Refer to the "Summary table for the installation of child seats".
Never leave one or more children alone and unsuper-vised in a vehicle. Never leave a child or an
animal in a vehicle which is expo- sed to the sun and has the win-dows closed.
To protect your young children from the sun, fit blinds on the rearwindows. Never leave the keys within reach of children inside the vehicle. Disarm the passenger air bag when installing a "rearwardsfacing" child seat on the front pas-senger seat. Otherwise, the childwould risk being killed or seriouslyinjured were the air bag to inflate. Observe strictly the recommenda- tions for assembling and securingthe child seat as shown in the childseat instructions.
To prevent the doors from opening
accidentally, use the child lock*. Also, do not open the rear windows more than a third*.
* According to model.
Page 71 of 135
30-06-2003
YOUR 206 CC IN DETAIL
72
Changing the battery of the remote control
Warning that the battery is flat is given by an audible signal accompa-nied by the message
''Remote
control battery low'' on the multi-
function display.
To replace the battery, remove the screw then unclip the casing using acoin at the ring (CR 2016/3 volt battery). If the remote control does not work after the battery has been changed,reprogramme the remote control.
THE KEYS The keys allow you to
independent-
ly operate the locks on the doors,
the tailgate (opening), the fuel filler cap, the steering lock, the glove boxand the passenger air bag disarmingcontrol and to switch on the ignition. Central locking From the driver's door the keys allow you:
Ðto lock or unlock the doors and tail-
gate simultaneously,
Ð to unlock simultaneously just thedoors.
Unlocking the boot is possible
only by using the boot key. If one of the doors is open, the cen- tral locking does not work. The remote control This fulfils the same functions as the
key, at a distance. Locking Pressing button
Alocks the vehicle
by remote control. This is displayed by the continuouslighting of the direction indicators forapproximately two seconds. Unlocking Pressing button Bunlocks just the
doors. This is shown by the rapid flashingof the direction indicators. Notes: if the vehicle is locked and
the unlocking control is pressed inadvertently without the doorsbeing opened within 30 seconds, the
vehicle will lock again automatically.
Avoid pressing the buttons of your remote control out of range of your
vehicle. You risk causing it not towork and the remote control wouldhave to be reprogrammed.
Key in ignition
A buzzer sounds on opening the dri-
ver's door, if the key has been left inthe ignition. Locating your car
To locate your car in a car park, if you have locked it:
press button A, the courtesy light
comes on and the direction indi- cators flash for a few seconds.Programming the remote control Switch off the ignition.
Switch the ignition on again.
Press button Aimmediately.
Switch off the ignition and remove the remote control key from the
ignition lock. The remote control isnow working again.
