Page 3 of 388
57L20-03E
FOREWORDAll information in this manual is based
on the latest product information avail-
able at the time of publication. Due to
improvements or other changes, there
may be discrepancies between informa-
tion in this manual and your vehicle.
SUZUKI MOTOR CORPORATION
reserves the right to make production
changes at any time, without notice and
without incurring any obligation to
make the same or similar changes tovehicles previously built or sold.
SUZUKI MOTOR CORPORATION
believes in conservation and protection of
Earth’s natural resources.
To that end, we encourage every vehicle
owner to recycle, trade in, or properly dis-
pose of, as appropriate, used motor oil,
coolant, and other fluids, batteries and
tires.IF YOU HAVE ANY PROBLEMS WITH
YOUR SUZUKI:
Please review the New Vehicle Warranty
Information booklet supplied with your
SUZUKI. Should you have a question or
problem regarding the warranty or service
of your vehicle, please take the following
action:
Consult the Service Manager and the
Owner of the Suzuki Automotive Dealer-
ship. Explain your problem and ask for
their assistance in resolving your problem.
The Owner of the dealership is in the very
best position to assist you as he or she is
vitally concerned with your continued satis-
faction.
If
, a fter doing so, y ou stil l require further
ass ist an ce, an d y ou purch ased y our
SUZUKI in the con tin ental Un ited States ,
p lea se con tact the American Suzuki Cus-
tomer Rela tions Depa rtment b y tele pho ne
a t 1-80 0-934 -0934 or in writing at:
Amer ican Suzuki Motor Cor por atio n
A utomotiv e Cus tomer Relations
3 251 East Impe rial Hi ghway
Brea , CA 928 21-6795 If you purchased your SUZUKI in Canada
please contact the Suzuki Canada Cus-
tomer Relations Department by telephone
at 1-905-889-2677 extension 2254 or in
writing at:
Suzuki Canada Inc.
Customer Relations
100 East Beaver Creek Road
Richmond Hill, On
L4B 1J6
In the event you require assistance related
to your SUZUKI, while temporarily travel-
ling in either the United States or Canada,
you may wish to cont
act the Suzuki Cus-
tomer Relations Department directly of the
country in which you are temporarily oper-
ating your vehicle.
Please be certain to provide us with the fol-
lowing information: the model, Vehicle
Identification Number, mileage, accesso-
ries involved, event dates, your concern,
and any other comments which you may
have. When we receive your correspon-
dence, we will be pleased to contact the
Owner of your dealership and assist in
resolving your concern.
For owners outside the continental United
States, please refer to the distributor’s
address listed in your Warranty Information
booklet.
Page 13 of 388
ILLUSTRATED TABLE OF CONTENTS
57L20-03E
INSTRUMENT PANEL1. Front Fog Light Switch (if equipped)(P.2-105)
2. Lighting Control Lever (P.2-100)/ Turn Signal Control Lever (P.2-105)
3. Shift Paddles (if equipped) (P.3-17)
4. Instrument Cluster (P.2-68)
5. Windshield Wiper and Washer Lever (P.2-107)
6. Front Seat Heater Switch (if equipped) (P.2-28)
7. Hazard Warning Switch (P.2-106)
8. ESP
® OFF Switch (P.3-33)
9. Parking Sensor Switch (if equipped) (P.3-26)
10. 2WD/i-AWD (intelligent All Wheel Drive) Switch (if equipped) (P.3-19)
11. Trunk lid unlatch switch (P.2-5)
12. Engine Hood Release Handle (P.5-75)
13. Tilt/Telescoping/Steering Lock Lever (P.2-110)
14. Engine Switch (P.3-2)
15. Universal Serial Bus (USB) Socket (P.5-81)
16. Accessory Socket (P.5-80)/ Cigarette Lighter (if equipped) (P.5-81)
17. Heated Rear Window and Heated Outside Rearview Mirrors Switch
(if equipped) (P.2-111)
57L1F006
1
3
2
4
7
6
14
13
12
11
9 10
17
16
15
8 5
3
6
Page 18 of 388
1-1FUEL RECOMMENDATION
57L20-03E
Fuel Recommendation
60A004
Your vehicle requires regular unleaded
gasoline with a minimum rating of 87 pump
octane ((R + M)/2 method). In some areas,
the only fuels that are available are oxy-
genated fuels.
Oxygenated fuels which meet the mini-
mum octane requirement and the require-
ments described below may be used in
your vehicle without jeopardizing the New
Vehicle Limited Warranty.
NOTE:
Oxygenated fuels are fuels which contain
oxygen-carrying additives such as MTBE
or alcohol.
Gasoline Containing MTBEUnleaded gasoline containing MTBE
(methyl tertiary butyl ether) may be used in
your vehicle if the MTBE content is not
greater than 15%. This oxygenated fuel
does not contain alcohol.
Gasoline/Ethanol blends
Blends of unleaded gasoline and ethanol
(grain alcohol), also known as gasohol,
may be used in your vehicle if the ethanol
content is not greater than 10%.
Gasoline/Methanol blends
Fuels containing 5% or less methanol
(wood alcohol) may be suitable for use in
your vehicle if they contain cosolvents and
corrosion inhibitors. Do NOT USE fuels
containing more than 5% methanol under
any circumstances. Fuel system damage
or vehicle performance problems resulting
from the use of such fuels are not the
responsibility of SUZUKI and may not be
covered under the New Vehicle Limited
Warranty.
Fuel Pump LabelingIn some states, pumps that dispense oxy-
genated fuels are required to be labeled for
the type and percentage of oxygenate and
whether important additives are present.
Such labels may provide enough informa-
tion for you to determine if a particular
blend of fuel meets the requirements listed
above. In other areas, pumps may not be
clearly labeled as to the content or type of
oxygenate and additives. If you are not
sure that the fuel you intend to use meets
these requirements, check with the service
station operator or the fuel supplier.
NOTE:
To help clean the air, SUZUKI recom-
mends you use the oxygenated fuels.
However, if you are not satisfied with the
driveability or fuel economy of your vehicle
when you are using an oxygenated fuel,
switch back to the regular unleaded gaso-
line.
CAUTION
Be careful not to spill fuel containing
alcohol while refueling. If fuel is
spilled on the vehicle body, wipe it up
immediately. Fuels containing alco-
hol can cause paint damage, which is
not covered under the New Vehicle
Limited Warranty.
Fuel Recommendation: 1, 2
Page 21 of 388
2-2
BEFORE DRIVING
57L20-03E
Immobilizer SystemThe immobilizer system is an anti-theft fea-
ture, which checks whether the keyless
start system remote controller that is com-
municating via radio waves with the vehicle
has been registered to the vehicle’s key-
less start system. If the remote controller is
not a registered one, the system will refuse
to start the engine using it.Immobilizer/Keyless Start System
Warning Light
85K2210
This light is on the instrument cluster.
When you press the engine switch to
change the ignition mode to “ON”, the
light comes on briefly so you can check
that the light is working. If the light is
flashing, the engine cannot be started.
The light also flashes when the “remote
controller outside” warning works.NOTE:
The immobilizer/keyless start system is
normal if this light goes out in 2 seconds
after pressing the engine switch to
change the ignition mode to “ON”. If the
light fails to go out in this period, there is
something wrong with the system. There
is also a problem with the system if the
light remains on for 5 seconds after the
engine switch is pressed when the
switch is in any other ignition mode than
“ON”.
Illumination or flashing of the light may
be accompanied by a message on the
information display in the instrument
cluster.
NOTE:
If you lose your keyless start system
remote controller, see your SUZUKI
dealer as soon as possible to have the
lost one deactivated, then have the new
remote controller made by them.
If you own other vehicles with keyless
start system remote controller, keep
those remote controllers away from the
engine switch when using your SUZUKI,
or the engine may not be started
because they may interfere with your
SUZUKI’s immobilizer system.
In case of attaching any metal objects to
the keyless start system remote control-
ler, it may not start the engine.1. For USA
This device complies with Part 15 of the
FCC Rules. Operation is subject to the fol-
lowing two conditions:
(1) this device may not cause harmful
interference, and (2) this device must
accept any interference received, including
interference that may cause undesired
operation.
NOTE:
Changes or modifications not expressly
approved by the party responsible for com-
pliance could void the user’s authority to
operate the equipment.
WARNING
Never leave the keyless start system
remote controller in the vehicle when
leaving the vehicle.
CAUTION
The keyless start system remote con-
troller is a sensitive electronic instru-
ment. To avoid damaging the keyless
start system remote controller:
Do not expose it to impacts, mois-
ture or high temperature such as
on the dashboard under direct sun-
light.
Keep the keyless start system
remote controller away from mag-
netic objects.
Door Locks: 3, 5, 8
Page 23 of 388
2-4
BEFORE DRIVING
57L20-03E
To lock a rear door from outside the vehi-
cle, turn the lock knob forward and close
the door. You do not need to pull and hold
the door handle as you close the door.Power Door Locking SystemYou can lock and unlock all the doors
simultaneously by:
Turning the key in a driver’s door lock, or
Pushing the power door locking switch
located on the driver’s side or the front
passenger’s side door panel.
57L21006
(1) LOCK
(2) UNLOCK
(3) Rear
(4) Front
(when using the key)
To lock all the doors simultaneously, insert
the key in a driver’s door lock and turn thetop of the key toward the front of the vehi-
cle once.
To unlock all the doors simultaneously,
insert the key in a driver’s door lock and
turn the top of the key toward the rear of
the vehicle twice.
To unlock only one of the driver’s doors,
insert the key in that door lock and turn the
top of the key toward the rear of the vehicle
once.
Driver’s side
57L21007
(1) LOCK
(2) UNLOCKFront passenger’s side
57L21008
(1) LOCK
(2) UNLOCK
(when using the power door locking
switch)
To lock or unlock all the doors simulta-
neously, depress the front or rear of the
switch (5) or (6), respectively.
NOTE:
You can also lock or unlock all doors by
operating the remote controller. Refer to
“Keyless Start System Remote Control-
ler” in this section.
You can also lock or unlock all doors by
pushing the request switch on the door
handle. Refer to “Keyless Start System
Remote Controller” in this section.
(2)
(1)
(4)(3)
(1)
(2)
(5)
EXAMPLE
(1)
(2)
(6)
EXAMPLE
Door Locks: 3, 5, 8
Page 26 of 388
2-7BEFORE DRIVING
57L20-03E
57L21013
(1) “LOCK” button
(2) “UNLOCK” button
(3) “TRUNK LID UNLOCK” button
(4) “PANIC” button
“LOCK” button (1) / “UNLOCK” button
(2) function
You can lock or unlock all doors simulta-
neously by operating the remote controller
near the vehicle.
To lock the doors, push the “LOCK” but- ton (1).
To unlock the driver’s door, push the “UNLOCK” button (2) once.
To unlock other doors, wait a second or
two, then push the “UNLOCK” button (2)
a second time. If you “double-click” too
fast, the doors will not unlock.
The turn signal lights will flash once when
the doors are locked. When the doors are unlocked:
The turn signal lights will flash twice.
If the interior light switch is in the
“DOOR” position, the interior light will
turn on for about 15 seconds and then
fade out. If you press the engine switch
during this time, the light will start to fade
out immediately.
Be sure the doors are locked after you
operate the “LOCK” button (1).
If no door is opened within about 30 sec-
onds after the “UNLOCK” button (2) is
operated, the doors will automatically lock
again.
NOTE:
The maximum operating distance of the remote controller is about 5 m (16 ft.),
but this can vary depending on the sur-
roundings, especially near other trans-
mitting devices such as radio towers or
CB (Citizen’s Band) radios.
The door locks cannot be operated with the remote controller if the ignition mode
has been changed to “LOCK” (OFF) with
the engine switch, or if any door is open.
If any door is open, you cannot lock the
door by operating the remote controller,
however Y O U C A N unlock the door.
You cannot lock the door unless all of the
door are closed completely.
If you lose one of the remote controllers, ask your SUZUKI dealer as soon as pos-
sible for a replacement. Be sure to have
your dealer program the new remote controller code in your vehicle’s memory
so that the old code is erased.
“TRUNK LID UNLOCK” button (3) func-
tion
Push and hold the “TRUNK LID UNLOCK”
button pressed for more than 1 second; the
trunk lid will be unlatched and open
slightly.
NOTE:
The trunk lid cannot be operated with the
remote controller if the engine switch is in
any other ignition mode than “LOCK”
(OFF).
“PANIC” button (4) function
This function is to get the attention of oth-
ers.
Press the “PANIC” button (4) for more than
1 second. The headlights and taillights will
blink for about 30 seconds. Also, the horn
will sound intermittently for about 30 sec-
onds at the same time.
To cancel the “PANIC” mode, press any
button (PANIC, LOCK, UNLOCK or
TRUNK LID UNLOCK) on the remote con-
troller. You can also press the engine
switch to cancel the “PANIC” mode.
NOTE:
The “PANIC” button function will not acti-
vate when you have changed the ignition
mode to “ACC” by pressing the engine
switch.
(2)(1)(3)(4)
EXAMPLE
Door Locks: 3, 5, 8
Page 33 of 388
2-14
BEFORE DRIVING
57L20-03E
1. For USA
This device complies with Part 15 of the
FCC Rules. Operation is subject to the fol-
lowing two conditions:
1) This device may not cause harmful
interference, and
2) This device must accept any interfer-
ence received, including interference
that may cause undesired operation.
NOTE:
Changes or modifications not expressly
approved by the party responsible for com-
pliance could void the user’s authority to
operate the equipment.2. For Canada
This device complies with Industry Canada
Standard RSS-210. Operation is subject to
the following two conditions:
1) This device may not cause interference,
and
2) This device must accept any interfer-
ence, including interference that may
cause undesired operation of the
device.
The term “IC:” before the certification/reg-
istration number only signifies that the
Industry Canada technical specifications
were met.
Theft Deterrent Alarm SystemThe theft deterrent alarm system is armed
in about 20 seconds after you lock the
doors using the keyless start system
remote controller or by pushing the request
switch on the driver’s or front passenger’s
door handle. (The system, however, is not
armed when the engine hood or trunk lid is
open.)
Once the system is armed, any attempt to
open a door by using any other means (*)
than the keyless start system remote con-
troller or the request switch will cause the
alarm to be triggered.
* These means include the following:
–The key
– The lock lever on a door
– The power door lock knob
– The trunk lid unlatch switch
– The engine hood release handle
WARNING
Swallowing a lithium battery may
cause serious internal injury. Do not
allow anyone to swallow a lithium
battery. Keep lithium batteries away
from children and pets. If swallowed,
contact a physician immediately.
CAUTION
The remote controller is a sensitive
electronic instrument. To avoid dam-
aging it, do not expose it to dust or
moisture or tamper with internal
parts.
Head Restraints: 3
Seat Belts and Child Restraint Systems: 3
Page 36 of 388
2-17BEFORE DRIVING
57L20-03E
1) With the ignition mode changed to “ON”
by pressing the engine switch, close all
the doors as well as the engine hood
and the trunk lid and push the unlock
end (backward end) of the power door
locking switch (1) of the driver’s door.
Turn the knob control on the lighting
control lever to the OFF position (4).
NOTE:
All operations included in the following
steps 2) and 3) must be completed within
15 seconds.
2) Turn the knob control on the lighting
control lever to the position (5) and
then to the OFF position (4). Repeat
this operation 4 times with the control
finally set to the OFF position.
3) Push the lock end (forward end) of the
power door lock switch (1) to lock the
doors, and then the unlock end (back-
ward end) to unlock the doors. Repeat
these operations 3 times and finally
push the lock end of the switch.Every time you perform the series of the
above steps, the state of the theft deterrent
alarm system changes from the currently
selected one to the other. You can check
whether the system is enabled or disabled
by the number of interior buzzer beeps at
the end of the procedure as follows.
NOTE:
You cannot disable the theft deterrent
alarm system while it is in the armed
condition.
If you fail to complete the operations in
step 2) and 3) within 15 seconds, per-
form the procedure again from the
beginning.
Make sure all doors are closed when
performing the above procedure.
WindowsPower Window ControlsDriver’s side
57L21024
The power windows can be operated when
the ignition mode is changed to “ON” by
pressing the engine switch.
The driver’s door has switches (1), (2), (4),
(5), to operate the driver’s window, the
front passenger’s window, the rear left win-
dow and the rear right window, respec-
tively.
System state Number of beeps
Disabled Once
Enabled 4 times
(4)(1)
(2)
(5)
EXAMPLE
Seat Belts and Child Restraint Systems: 3
Page 41 of 388
2-22
BEFORE DRIVING
57L20-03E
The auto dimming rearview mirror is
automatically deactivated while the gear-
shift lever is in the “R” position.
57L30020
Outside Rearview Mirrors
79J033
Adjust the outside rearview mirrors so you
can just see the side of your vehicle in the
mirrors.
The passenger’s side mirror is a convex
(curved surface) mirror. Objects seen in
this mirror will look smaller and appear far-
ther away than when seen in a flat mirror.
Power Mirror Control
57L21029
The switch to control the power rearview
mirrors is located on the driver’s door
panel. You can adjust the mirrors after
pressing the engine switch to change the
ignition mode to “ACC” or “ON”. To adjust
the mirrors:
1) Move the selector switch to the left or
right to select the mirror you wish to
adjust.
2) Press the outer part of the switch that
corresponds to the direction you wish to
move the mirror.
3) Return the selector switch to the center
position to help prevent unintended
adjustment.
CAUTION
Do not touch or cover the sensor
(3) since this may impair normal
operation of the system. Blocking
glare from the sensor with an
object such as a shade, sticker,
accessory or baggage may also
impair proper operation of the sys-
tem.
Do not hook anything heavy on the
mirror, or the mirror may break
under the weight.
(3)
(3)
WARNING
Be careful when judging the size or
distance of a vehicle or other object
seen in the side convex mirror. Be
aware that objects look smaller and
appear farther away than when seen
in a flat mirror.EXAMPLE
(2)
(4)(3) (1)
(1)
(3) (2)
(4)
EXAMPLE
Seat Belts and Child Restraint Systems: 3
Page 47 of 388
2-28
BEFORE DRIVING
57L20-03E
57L21037
To reinstall the head restraint, insert the
head restraint bars into the holes (4) and
push the head restraint down.
Front Seat Heater
(if equipped)
57L21038
(1) Driver’s seat heater switch
(2) Passenger’s seat heater switch
With the ignition mode changed to “ON” by
pressing the engine switch, push in one or
both of the seat heater switches to warm
the corresponding seat(s).
When a seat heater switch is pushed,
the heater inside the corresponding seat
operates.
Heating intensity can be adjusted to one
of three levels: L (low), M (medium) and
H (high). Every time you press the seat heater
switch, the indicators inside the switch
light one at a time in the following
sequence to indicate the selected heater
operation.
– L (low): Weak heating (Only the L indi-
cator lights.)
– M (medium): Moderate heating (The L
and M indicators light.)
– H (high): Strong heating (The L, M and
H indicators light.)
– OFF: Heater turned off (No indicator
illuminates.)
86G064
(4)
(2) (1)
Seat Belts and Child Restraint Systems: 3
