Page 2 of 492
TABLE OF CONTENTSIndex
2
tC_OM_OM21054U_(U)
1-1. Key informationKeys ..................................... 26
1-2. Opening, closing and locking the doors
Smart key system................. 30
Wireless remote control ....... 48
Side doors ............................ 54
Back door ............................. 61
1-3. Adjustable components (seats, mirrors,
steering wheel)
Front seats ........................... 67
Rear seats ............................ 73
Head restraints ..................... 75
Seat belts ............................. 77
Steering wheel ..................... 84
Anti-glare inside rear view mirror .................. 85
Outside rear view mirrors ..... 87
1-4. Opening and closing the windows and moon roof
Power windows .................... 89
Moon roof ............................. 93
1-5. Refueling Opening the fuel tank cap .... 97 1-6. Theft deterrent system
Engine immobilizer system .............................. 102
Theft prevention labels (for U.S.A.) ....................... 105
1-7. Safety information Correct driving posture ....... 106
SRS airbags ....................... 108
Front passenger occupant classification system ......... 123
Child restraint systems ....... 129
Installing child restraints ..... 135
2-1. Driving procedures Driving the vehicle .............. 150
Engine (ignition) switch (vehicles without a smart
key system) ...................... 165
Engine (ignition) switch (vehicles with a smart
key system) ...................... 169
Automatic transmission ...... 178
Manual transmission........... 185
Turn signal lever ................. 187
Parking brake ..................... 188
Horn .................................... 189
2-2. Instrument cluster Gauges and meters ............ 190
Indicators and warning lights ................................. 194
1Before driving
2When driving
Page 3 of 492
1
2
3
4
5
6
7
3
tC_OM_OM21054U_(U)
2-3. Operating the lights and windshield wipers
Headlight switch .................. 199
Windshield wipers and washer .............................. 204
Rear window wiper and washer .............................. 208
2-4. Using other driving systems Cruise control ...................... 211
Driving assist systems ........ 215
2-5. Driving information Cargo and luggage ............. 220
Vehicle load limits ............... 225
Winter driving tips ............... 226
Trailer towing ...................... 232
Dinghy towing (automatic transmission) .................... 233
Dinghy towing (manual transmission) .................... 234
3-1. Using the air conditioning system and defogger
Air conditioning system ....... 238
Rear window and outside rear view mirror defogger
switch ................................ 245 3-2. Using the audio system
Using the AUX port/USB port........................... 247
Using the steering wheel audio switches.................. 248
Using the microphone ........ 249
3-3. Using the interior lights Interior lights list ................. 250
• Interior lights..................... 251
3-4. Using the storage features List of storage features ....... 253
• Glove box ......................... 254
• Console box ..................... 255
• Auxiliary box ..................... 256
• Cup holders ...................... 256
• Bottle holders ................... 257
3-5. Other interior features Sun visors........................... 258
Vanity mirrors ..................... 259
Clock .................................. 260
Power outlet ....................... 261
Seat heaters ....................... 262
Sunshades ......................... 264
Assist grips ......................... 266
Floor mat ............................ 267
Luggage compartment features ............................ 269
3Interior features
Page 4 of 492
TABLE OF CONTENTSIndex
4
tC_OM_OM21054U_(U)
4-1. Maintenance and careCleaning and protecting the vehicle exterior ........... 274
Cleaning and protecting the vehicle interior ............ 278
4-2. Maintenance Maintenance requirements .................... 281
General maintenance ......... 284
Emission inspection and maintenance (I/M)
programs .......................... 288
4-3. Do-it-yourself maintenance Do-it-yourself service precautions ...................... 289
Hood................................... 294
Positioning a floor jack ....... 296
Engine compartment .......... 298
Tires ................................... 314
Tire inflation pressure......... 325
Wheels ............................... 329
Wireless remote control/ electronic key battery ....... 332
Checking and replacing fuses ................. 338
Light bulbs .......................... 349 5-1. Essential information
Emergency flashers ............ 362
If your vehicle needs to be towed ........................... 363
If you think something is wrong ............................ 372
Fuel pump shut off system .............................. 373
5-2. Steps to take in an emergency If a warning light turns on or a warning buzzer
sounds... .......................... 374
If you have a flat tire ........... 392
If the engine will not start .................................. 406
If the shift lever cannot be shifted from P (automatic
transmission) .................... 409
If you lose your keys ........... 410
If the electronic key does not operate properly ......... 411
If the vehicle battery is discharged .................... 415
If your vehicle overheats..... 419
If the vehicle becomes stuck ................................. 422
If your vehicle has to be stopped in an
emergency........................ 424
4Maintenance and care5When trouble arises
Page 6 of 492
6
tC_OM_OM21054U_(U)
Front side marker lights P. 199
Hood P. 294
Windshield wipers P. 204
Outside rear view mirrors
P. 87
Side turn signal lights
P. 187
Moon roof P. 93
Pictorial indexExterior
Daytime running lights
P. 201
Parking lights P. 199
Headlights P. 199
Accessory lights P. 199
Front turn signal lights
P. 187
Page 7 of 492
7
tC_OM_OM21054U_(U)
: If equipped
Tires
●Rotation
● Replacement
● Inflation pressure
● Information
P. 314
P. 392
P. 325
P. 443
License plate lights P. 199
Tail lights P. 199
Side doors P. 54
Rear side marker lights P. 199Rear window wiper P. 208
Fuel filler door P. 97Rear window defogger
P. 245
Back door P. 61
Rear turn signal lights
P. 187
Page 9 of 492
9
tC_OM_OM21054U_(U)
Sun visors P. 258
Vanity mirrors
P. 259
Inside rear view mirror P. 85
SRS curtain shield airbags P. 108
Front interior lights
Moon roof switch
Microphone P. 251
P. 93
P. 249
Rear interior light P. 251
Rear sunshade P. 264
Moon roof
Front sunshade P. 93
P. 264
A
Assist grips P. 266
: If equipped
Page 15 of 492
15
tC_OM_OM21054U_(U)
Paddle shift switches P. 178
Headlight switch
Turn signal lever P. 199
P. 187
Steering wheel audio switches
P. 248
SRS driver airbag
Horn P. 108
P. 189
Cruise control switch
P. 211
Engine (ignition) switch (vehicleswithout a smart key system)
P. 165
Windshield wipers and washer switch
Rear window wiper and washer switch
P. 204
P. 208
B
: If equipped
Page 17 of 492
17
tC_OM_OM21054U_(U)
Luggage compartment
Cargo hooks P. 269Cargo hooks P. 269
Auxiliary boxes P. 269
Luggage cover P. 270
Pictorial index
: If equipped
Luggage compartment
light
P. 62
Page 36 of 492
36 1-2. Opening, closing and locking the doors
tC_OM_OM21054U_(U)
■Alarms and warning indicators
A combination of exterior and interior alarms as well as warning lights are
used to prevent theft of the vehicle and unforeseeable accidents resulting
from erroneous operation.
●When any warning lights come on
Take appropriate measures depending on which warning light comes on.
( P. 382)
The following table describes circumstances and correction procedures
when only alarms are sounded.
AlarmSituationCorrection procedure
Interior alarm
pings once and
exterior alarm
sounds once for
10 seconds An attempt was made to
lock the doors using the
entry function while the
electronic key was still
inside the passenger com-
partment
Retrieve the elec-
tronic key from the
passenger compart-
ment and lock the
doors again
An attempt was made to
exit the vehicle and lock
the doors without first turn-
ing the “ENGINE START
STOP” switch off Turn the “ENGINE
START STOP” switch
off and lock the doors
again
Exterior alarm
sounds once for
10 seconds An attempt was made to
lock the vehicle while a
door is open Close all of the doors
and lock the doors
again
Page 44 of 492
44 1-2. Opening, closing and locking the doors
tC_OM_OM21054U_(U)
■Notes for the unlocking function
●Gripping the side door handle when wearing a glove may not unlock or
lock the door.
● A sudden approach to the effective range or door handle operation may
prevent the doors from being unlocked. In this case, return the door han-
dle to the original position and check that the doors have unlocked before
pulling the door handle.
● If there is another electronic key in the detection area, it may take slightly
longer to unlock the doors after one of the side door handles are gripped.
■ When the vehicle is not driven for extended periods
●To prevent theft of the vehicle, do not leave the electronic key within 6 ft.
(2 m) of the vehicle.
● The smart key system can be deactivated in advance. Contact your
Scion dealer for details.
■ To operate the system properly
Make sure to carry the electronic key when operating the system. Do not get
the electronic key too close to the vehicle when operating the system from
the outside of the vehicle.
Depending on the position and holding condition of the electronic key, the
key may not be detected correctly and the system may not operate properly.
(The alarm may go off accidentally, or the door lock prevention may not
operate.)
■ If the smart key system does not operate properly
● Locking and unlocking the doors: Use the mechanical key. ( P. 4 1 1 )
● Starting the engine: P. 412
