fig. 43 Press the switch in the direction of the arrow:
(A) (1) Slide the seat backward or forward.
(2) and (3) Raise or lower the seat cushion.
(2) or (3) Adjust seat cushion angle.
(B) Forward or backward. Adjust backrest angle.


Press fig. 44 switch for each area:
(1) or (2) Adjust lumbar support. (1) inflates, (2) deflates.
(3) or (4) Adjust lumbar support height. (3) moves the lumbar support up, (4) moves the lumbar support down.

WARNING
Improper use of electrical seat controls can cause serious personal injuries.
x The front seats in your vehicle can be electrically adjusted even when the vehicle key has been removed from the ignition or, on a vehicle with Keyless Access, even if there is no key in the vehicle.
x Never leave children and persons who need help in the vehicle alone because the unsupervised use of the electric seat adjustments can result in serious personal injury.
x Always make sure that no one is in the way while the front seats are being adjusted, or while calling up the stored memory settings for the front seats. In an emergency, stop automatic seat adjustment by pressing a seat adjustment switch.
NOTICE
To help prevent damage to electrical parts in the seat, do not kneel on the front seats or apply concentrated pressure to a small area of the seat or backrest.
If the vehicle battery is too weak, the electrical seat adjustment controls may not work.
Starting the engine stops seat adjustment.
When entering and exiting the vehicle, be careful not to come into contact with any switches that could change the seat adjustment.

4. Secure both seat rails of the rear seat in front and back with 2 hexagonal nuts each, tightening the nuts by hand - do not tighten them with the lug wrench yet.
5. Lift the right rear seat into the vehicle through the right rear door.
6. Set the seat rails of the rear seat first on the front anchoring studs and then on the rear studs.
7. Secure both seat rails of the rear seat in front and back with 2 hexagonal nuts each, tightening the nuts by hand - do not tighten them with the lug wrench yet.
8. To align the seat rails, press the left rear seat all the way to the left in the vehicle.
9. To align the seat rails, press the right rear seat all the way to the right in the vehicle.
10. Tighten the hexagonal nuts in the luggage compartment ⇒ fig. 101 (arrows) to 44 ft-lbs (60 Nm) using a torque wrench. If no torque wrench is available, tighten the hexagonal nuts using the lug wrench and have the torque checked at a qualified workshop as soon as possible.
11. Push the rear seats as far back as possible ⇒  Adjusting the rear seat.
12. Remove the hexagonal nuts in the rear of the footwell again, set the 3 plastic covers ⇒ fig. 100 on the studs and screw on with the hexagonal nuts.
13. Tighten the hexagonal nuts ⇒ fig. 100 (arrows) to 44 ft-lbs (60 Nm) using a torque wrench. If no torque wrench is available, tighten the hexagonal nuts using the lug wrench and have the torque checked at a qualified workshop as soon as possible.
14. Clip on the small covers (not pictured) on the hexagonal nuts ⇒ fig. 100 (arrows).
15. Install the foam insert and spare wheel in the vehicle ⇒  Compact spare wheel.
16. Install the luggage compartment floor ⇒  Variable luggage compartment floor.
17. Install the luggage compartment cover ⇒  Luggage compartment cover.
18. Install all rear head restraints ⇒  Adjusting the seating position.
WARNING
No one may ride in the back of the vehicle when the rear seat has been removed.
WARNING
An improperly installed rear seat can separate from its mountings during an accident.
x All securing bolts must be tightened to the specified torque after the rear seat has been installed.
CAUTION
Sharp-edged parts are located on the underside of the rear seat.
x Protect your hands when you lift the rear seat in or out.
NOTICE
x Have at least one person help to lift the rear seat in or out. One person should be in the vehicle and one outside.

x To secure, push the retaining pin ⇒ fig. 107 to the right.
x To close, push the retaining pin (1) to the left and guide the luggage compartment floor downwards.
Extending the luggage compartment floor forward
x Remove the luggage compartment cover ⇒  Luggage compartment cover.
x Remove the rear head restraints ⇒  Adjusting the seating position.
x Push both sections of the rear seat forward ⇒  Adjusting the seating position.
x Fold the rear backrests forward ⇒  Adjusting the seating position.
x Fold the cover forward ⇒ fig. 108 (1).
Extending the luggage compartment floor downward
x Remove the luggage compartment cover ⇒  Luggage compartment cover.
x Raise the luggage compartment floor, pull from the side pins (2) and remove it from the vehicle to the rear.
There may be a foam element with the spare wheel ⇒ fig. 107 located beneath the variable luggage
compartment floor. If a spare wheel is present, remove it ⇒  Compact spare wheel and remove the foam element from the luggage compartment.
WARNING
During hard braking or an accident, loose objects can fly through the passenger compartment and cause serious or even fatal injuries.
x Even if the luggage compartment floor panel is properly raised, it is still necessary to secure all objects.
x Objects stowed between the rear seat bench and the luggage compartment floor panel must never be more than 2/3 as high as the raised floor panel.
x Objects stowed between the rear seat bench and the raised luggage compartment floor panel must never weigh more than about 16.5 lbs. (7.5 kg).
NOTICE
Do not let the luggage compartment floor fall freely when closing it. Always guide it down into place. The trim or the luggage compartment floor could be damaged.
If you slide the rear seats forward, there is a gap between the luggage compartment floor and the rear seats. Make certain there are no objects in this space before sliding the rear seats back again.

Type of stain Recommended cleaning for fabric and upholstery
Water-based stains, such as coffee or fruit juice. – Moisten a sponge with water and rub the stain gently with a circular motion. – Wipe dry with an absorbent cloth.
Persistent stains, such as chocolate or make-up. – Use only Volkswagen-approved cleaning products. – If necessary, have the fabric or upholstery professionally cleaned.
Grease-based stains, such as oil, lipstick, etc. – Use only Volkswagen-approved cleaning products. – If necessary, have the fabric or upholstery professionally cleaned.

WARNING
If there is a malfunction in the airbag system, the airbag may not deploy correctly or at all, or it may deploy unexpectedly. This could cause fatal injuries.
x Have the airbag system inspected immediately by your authorized Volkswagen dealer or authorized Volkswagen Service Facility.
NOTICE
If the upholstery on power seats, heated seats, or seats with airbag components is wet, electrical components and the vehicle electrical system could be damaged.
x If the seating surface becomes soaked, have it dried and the system components checked immediately by an authorized Volkswagen dealer or authorized Volkswagen Service Facility.
x Do not use steam cleaners because the steam could cause the dirt to penetrate deeper into the fabric and make it impossible to remove.
x Pressure washers and cooling sprays can damage the upholstery.
NOTICE
x Clean only the carpet and floor mats with brushes. Other textile surfaces can be damaged by brushes.
x If detergent pastes or mild detergent solutions are applied with a damp cloth or sponge, the surfactants in the detergent may cause visible lines to form at the edges of the area where the detergent was applied. These lines are generally difficult or impossible to remove.
NOTICE
x Do not soak Alcantara®.
x Do not treat Alcantara® with leather care products, solvents, floor wax, shoe polish, stain remover or similar products.
x Do not use brushes for damp cleaning, because they can damage upholstery surfaces.
x Do not use a steam cleaner, because dirt will penetrate deeper into the fabric.
