Description
2-1
2
EAU63371
Left view
16789
3 4,52
1. Fuse box 2 (page 7-36)
2. Fuel tank cap (page 4-20)
3. Spring preload adjuster (page 4-27)
4. Fast compression damping force adjuster (page 4-27)
5. Slow compression damping force adjuster (page 4-27)
6. Rebound damping force adjuster (page 4-27)
7. Shift pedal (page 4-17)
8. Engine oil filter cartridge (page 7-13)
9. Engine oil drain bolt (page 7-13)
UBN6E1E0.book Page 1 Thursday, October 5, 2017 2:48 PM
Page 13 of 114
Description
2-2
2
EAU63391
Right view
1,2,3,45,6,7
8
101112 9
1. Fuse box 1 (page 7-36)
2. Main fuse (page 7-36)
3. ABS motor fuse (page 7-36)
4. Battery (page 7-34)
5. Spring preload adjuster (page 4-25)
6. Rebound damping force adjuster (page 4-25)
7. Compression damping force adjuster (page 4-25)
8. Coolant reservoir (page 7-17)
9. Engine oil filler cap (page 7-13)
10.Engine oil dipstick (page 7-13)
11.Brake pedal (page 4-18)
12.Rear brake fluid reservoir (page 7-26)
UBN6E1E0.book Page 2 Thursday, October 5, 2017 2:48 PM
Page 93 of 114
Periodic maintenance an d a djustment
7-36
7
EAU2370A
Replacin g the fuses
The main fuse, the ABS motor fuse,
and fuse box 1 are located under the
rider seat. (See page 4-23.)
TIP
To access the ABS motor fuse, remove
the starter relay cover by pulling it up-
ward.
Fuse box 2 is located under panel A.
(See page 7-7.)
If a fuse is blown, replace it as follows.
1. Turn the key to “OFF” and turn off the electrical circuit in question.
2. Remove the blown fuse, and then install a new fuse of the specified
amperage. WARNING! Do not
use a fuse of a hi gher ampera ge
ratin g than recommen ded to
avoi d causin g extensive dam-
a g e to the electrical system an d
possi bly a fire.
[EWA15132]
1. ABS motor fuse
2. Starter relay cover
3. ABS motor spare fuse
4. Main fuse
1. Fuse box 1
2. Fuel injection system fuse
3. ABS ECU fuse
4. Terminal fuse 1 (for optional equipment)
5. Electronic throttle valve fuse
6. Backup fuse (for clock and immobilizer sys-
tem)
7. ABS solenoid fuse
8. Spare fuse
2
3
4
1
2
1
3
4
5
8
6
7
1. Fuse box 2
2. Hazard fuse
3. Headlight fuse
4. Ignition fuse
5. Signaling system fuse
6. Right radiator fan motor fuse
7. Left radiator fan motor fuse
8. Spare fuse
2
1
3
4
5
8
6
7
