spark plugs Acura RDX 2013 Owner's Manual

273
uuMaintenance Minder
TMuTo Use Maintenance Minder
TM
Continued
Maintenance
■
Maintenance Service Items
1Maintenance Service Items•Independent of the Maintenance Minder
information, replace the brake fluid every 3 years.•Inspect idle speed every 160,000 miles (256,000
km).•Adjust the valves during services A, B, 1, 2, or 3 if
they are noisy.
Maintenance Minder Message
System Message Indicator
Sub Items
Main
Item
*1: If the message
SERVICE does not appear more than 12 months after the display is reset, change the
engine oil every year.
# : See information on maintenance and emissions warranty.
*2: If you drive in dusty conditions, replace the air cleaner element every 15,000 miles (24,000 km).
*3: If you drive primarily in urban areas that have high concentrations of soot in the air from industry and from diesel-powered vehicles, replace the dust and pollen filter every 15,000 miles (24,000 km).CODE
Maintenance Main Items
A
●Replace engine oil
*1
B
●Replace engine oil
*1 and oil filter
●Inspect front and rear brakes, service as necessary●Check parking brake adjustment●Inspect tie rod ends, steering gearbox, and boots●Inspect suspension components●Inspect driveshaft boots●Inspect brake hoses and lines (Including ABS/VSA)●Inspect all fluid levels and condition of fluids●Inspect exhaust system
#
●Inspect fuel lines and connections
#
*4: If you drive regularly in very high temperatures (over 110 °F, 43 °C), in very low temperatures (under - 20 °F, -29 °C), or tow a trailer, replace every 60,000 miles/100,000 km.CODE
Maintenance Sub Items
1
●Rotate tires
2
●Replace air cleaner element
*2
●Replace dust and pollen filter
*3
●Inspect drive belt
3●Replace transmission and transfer fluid
*
4
●Replace spark plugs●Replace timing belt and inspect water pump
*4
●Inspect valve clearance
5●Replace engine coolant
6
●Replace rear differential fluid
*
* Not available on all models

344Information
Specifications■Vehicle Specifications*1: 2WD models
*2: AWD modelsModel
Acura RDX
No. of Passengers:
Front 2
Rear 3
Total 5
Weights:Gross Vehicle
Weight Rating
U.S.:
4,850 lbs (2,200 kg)
*1
4,982 lbs (2,260 kg)
*2
Canada:
2,260 kg
Gross Axle Weight
Rating (Front)
U.S.:
2,557 lbs (1,160 kg)
*1
2,623 lbs (1,190 kg)
*2
Canada:
1,190 kg
Gross Axle Weight
Rating (Rear)
U.S.:
2,293 lbs (1,040 kg)
*1
2,381 lbs (1,080 kg)
*2
Canada:
1,080 kg
Gross Combined Weight
Rating U.S.: 6,349 lbs (2,880 kg)
*1
6,482 lbs (2,940 kg)
*2
Canada:
2,940 kg
Air Conditioning:Refrigerant Type
HFC-134a (R-134a)
Charge Quantity
15.2 – 16.9 oz (430 – 480 g)
Lubricant Type
ND-OIL8
■
Engine Specifications
■ Fuel
■ Battery
■ Washer FluidDisplacement
211.8 cu-in (3,471 cm
3)
Spark Plugs NGK ILZKR7B11
DENSO SXU22HCR11
Type
Unleaded premium gasoline, Pump octane
number of 91 or higher
Fuel Tank Capacity 16 US gal (60 ℓ)
Capacity/Type
60AH(5)/72AH(20)
Tank Capacity
U.S.: 2.6 US qt (2.5 ℓ)
Canada: 5.1 US qt (4.85 ℓ)
■ Light Bulbs
■ Brake FluidHeadlights (High Beams)
60W (HB3)
Headlights (Low Beams) 35W (D2S)
*
55W (H11)
*
Fog Lights
*1
55W (H11)
Front Turn Signal/Parking Lights 28/8W (Amber)
Side Turn Signal Lights
(on Door Mirrors)
LED
Front Side Marker Lights 5W (Amber)
Rear Side Marker/Brake/Taillights
21/5W
Taillights 3CP
Back-Up Lights
16W
Rear Turn Signal Lights 21W
High-Mount Brake Light
16W
Rear License Plate Light 5W
Cargo Area Lights
5W
Vanity Mirror Lights 1.4W
Interior Lights
Map Lights
LED
Ceiling Light
8W
Door Courtesy Lights 2CP
Console Compartment Light
1.4W
Glove Box Light 1.4W
Foot Light
LED
Center Pocket Light LED
Specified
Acura Heavy Duty Brake Fluid DOT 3
* Not available on all models

361
Index
Shifting (Transmission)............................ 244
Shoulder Anchor ........................................ 33
Side Airbags ............................................... 44
Cutoff System ........................................... 46
Off Indicator ............................................. 46
Side Curtain Airbags .................................. 47
SMS Text Message ............................ 208, 220
Snow Tires ................................................ 309
Spare Tire ......................................... 319, 345
Spark Plugs ............................................... 344
Specifications ........................................... 344
Specified Fuel ................................... 263, 344
Speedometer .............................................. 82
SRS Airbags (Airbags) ................................ 40
Starting the Engine .................................. 240
Does Not Start ........................................ 325
Jump Starting ......................................... 328
Steering Wheel ........................................ 132
Adjusting ................................................ 132
Stopping ................................................... 261
Summer Tires ............................................ 309
Sunglasses Holder .................................... 150
Supplemental Restraint System (SRS) ....... 40
Switches (Around the Steering Wheel) ........ 2, 3, 119
Synchronized Mode ................................. 154
System Message Indicator ......................... 76
TTachometer................................................. 82
Tailgate ..................................................... 107
Unable to Open ....................................... 341
Temperature Outside Temperature Display ..................... 85
Temperature Gauge ................................... 82
Temperature Sensor ........................... 85, 155
Text Message .................................... 208, 220
Time (Setting) ............................................. 96
Tire Pressure Monitoring System (TPMS) ..................................................... 253
Indicator ............................................ 74, 336
Tires ........................................................... 301
Air Pressure ..................................... 302, 345
Checking and Maintaining....................... 301
Inspection................................................ 301
Labeling .................................................. 302
Puncture (Flat Tire)................................... 319
Regulations ............................................. 304
Rotation .................................................. 308
Spare Tire ........................................ 319, 345
Summer .................................................. 309
Tire Chains .............................................. 309
Wear Indicators ....................................... 306
Winter ..................................................... 309
Tools .......................................................... 318
Towing a Trailer ....................................... 233
Equipment and Accessories ..................... 234
Load Limits .............................................. 233 Towing Your Vehicle
................................ 237
Emergency .............................................. 340
TPMS (Tire Pressure Monitoring System) ........ 253
Indicator............................................ 74, 336
Transmission ............................................. 244
Automatic ............................................... 244
Fluid ........................................................ 284
Number................................................... 346
Sequential Shift Mode ............................. 246
Shift Lever Position Indicator.............. 70, 245
Trip Meter ................................................... 85
Troubleshooting ....................................... 317
Blown Fuse...................................... 337, 338
Brake Pedal Vibrates .................................. 18
Buzzer Sounds When Opening Door.......... 19
Emergency Towing .................................. 340
Engine Won’t Start .................................. 325
Noise When Braking .................................. 20
Overheating ............................................ 331
Puncture/Flat Tire .................................... 319
Rear Door Won’t Open...................... 19, 105
Select Lever Won’t Move ......................... 330
Warning Indicators .................................... 68
Turn Signals .............................................. 122
Indicators (Instrument Panel) ..................... 74
