light Acura RL 2002 3.5 Owner's Guide

If you unlock the doors with the
remote transmitter, but do not open
any of the doors within 30 seconds,
the doors automatically relock and
the security system sets.
You cannot lock any of the doors
with the remote transmitter if any
door is not f ully closed or the key is
in the ignition switch. You cannot
unlock any of the doors with the key
in the ignition switch.
To open the trunk, push the Trunk
Release button f or approximately
one second.
You can open the trunk with the
remote transmitter regardless of the
position of the main switch in the
glove box. The trunk will not open if
the key is in the ignition switch.You can program the keyless entry
system so it does not beep when you
lock and unlock the doors. This
procedure only turns of f the beep;
the exterior lights will still f lash.
To turn this feature off, stand near
the car with the remote transmitter.
Press and hold the Trunk Release
button, then press the Lock button
within one second. You should see
the LED on the remote transmitter
come on f or one second. Release the
buttons af ter the LED goes out.
To turn this feature on, repeat the
above procedure. You should see the
LED blink twice.
Af ter you program the remote
transmitter, make sure the trunk lid
is closed.Panic mode allows you to remotely
activate your car’s security system to
attract attention. When activated, the
horn will sound, and the exterior
lights will f lash, f or about 30 seconds.
To activate panic mode, press and
hold the PANIC button for about two
seconds.
To cancel Panic mode bef ore 30
seconds, press any button on the
remote transmitter. You can also
turn the ignition switch to ON (II).
Panic mode will not activate if the
ignition switch is in the ON (II)
position.T urning t he Beep Of f and On
Panic Mode
Keys and Locks
Inst rument s and Cont rols80
01/09/28 19:38:11 31SZ3660_083

The glove box light comes on only
when the parking lights are on. Open the glove box by pulling the
bottom of the handle. Close it with a
f irm push. Lock or unlock the glove
box with the master key. Glove Box
Keys and Locks
Inst rument s and Cont rols85
An open glove box can cause
serious injury to your passenger
inacrash,evenifthe
passenger is wearing the seat
belt.
Always keep the glove box
closed while driving.
01/09/28 19:39:05 31SZ3660_088

Adjust the outside mirrors with the
adjustment button on the driver’s
door armrest:Turn the ignition switch ON (II).
Move the selector switch to L
(driver’s side) or R (passenger’s
side).
Keeptheinsideandoutsidemirrors
clean and adjusted f or best visibility.
Be sure to adjust the mirrors bef ore
you start driving.
The inside mirror has an automatic
anti-glare mechanism. When the
AUTO switch is pushed in, the
indicator will light. When the mirror
senses light f rom the headlights of
the car behind you, the mirror
surf ace will automatically darken to
reduce the glare.1.
2.
CONT INUED
A djusting the Power Mirrors
Mirrors
Inst rument s and Cont rols91
S SE
EL
LEE C
CT TO
OR R S
SWWI ITT C
CH H
O
ON
N S
STTA
A R
R
I
IN ND DI
ICCA A T
TO
OR R
A
A
N
NT TI
IG
GL LAA R
REE
I
IN ND DI
ICCA A T
TO
OR R
A
A N
NT TI
IG
GL LAA R
REE S
SWWI ITT C
CH H
01/09/28 19:40:01 31SZ3660_094

The outside mirrors are heated to re-
move fog and frost. With the ignition
switchON(II),turnontheheaters
by pressing the button. The light in
the button comes on as a reminder.
Press the button again to turn the
heaters off.
When you f inish, move the
selector switch to the center (off)
position. This turns of f the
adjustment button so you can’t
move a mirror out of position by
accidentally bumping the button.
Move the mirror right, left, up or
down by pushing the adjustment
button in that direction. Outside mirror positions can be
stored in the driving position
memory system (see page ). 4.
3. 93
Mirrors
Inst rument s and Cont rols92
H H
E
EA
A T
TE
ED
D M
MI
IRRR ROOR R B
BUUT TT
TO
ON N
A
A D
DJ
JUUS STTM
M E
EN
NT T B
BUUT TT
TO
ON N
01/09/28 19:40:09 31SZ3660_095

Press and release the MEMO
buttononthecontrolpanel.You
will hear a beep. Immediately
press and hold one of the memory
buttons (1 or 2) until you hear two
beeps. The indicator light in the
memory button will come on. The
current positions of the driver’s
seat, steering wheel, and outside
mirrors are now stored.
Your Acura has a memory f eature
f or the steering wheel, driver’s seat,
and outside mirror positions.
Turn the ignition switch ON (II).
You cannot add a new driving
position in the memory unless the
ignition switch is ON (II). You can
recall a memorized position with
the ignition switch in any position.
Store a driving position as explained
in this section only when the car is
parked.
Two seat, steering wheel, and
outside mirror positions f or dif f erent
drivers or driving conditions can be
stored in separate memories. You
select a memorized position by
pushing the appropriate button.
Adjust the seat to a comfortable
position (see page ). Adjust
the steering wheel to a
comf ortable position (see page). Adjust the outside mirrors
f or best visibility (see page ). 3.
1.
2.
71 86
91
CONT INUED
St oring a Driving Posit ion in Memory
Driving Posit ion Memory Syst em
Inst rument s and Cont rols93
M ME
EM
M O
O B
BUUT TT
TO
ON N
01/09/28 19:40:19 31SZ3660_096

Doing any of the f ollowing af ter
pressing the MEMO button will
cancel the storing procedure.Not pressing a memory button
within 5 seconds.
Readjusting the seat or steering
position.
You can select memorized positions
as f ollows.Make sure the parking brake is set
and the shif t lever is in Park.
Insert the key in the ignition
switch. If you do not insert the key
in the ignition switch, the steering
wheel will not adjust to the
memorized position until you do. Press the desired memory button
(1 or 2) until you hear a beep, then
release the button.
The system will move the seat,
steering wheel and outside mirrors
to the memorized positions. The
indicator light in the selected
memory button will f lash during
movement. When the adjustments
are complete, you will hear two
beeps and the indicator light will
remain on.
Readjusting the outside mirror
position.
Each memory button stores only one
driving position. Storing a new
position erases the previous setting
stored in that button’s memory. If
you want to add a new position while
retaining the current one, use the
other memory button.
All stored driving positions will be
lost if your car’s battery goes dead or
is disconnected. 3.
1.
2.Select ing a Memorized Posit ion
Driving Posit ion Memory Syst em
Inst rument s and Cont rols94
M M E
EM
M O
ORRYY B
BUUT TT
TO
ON NSS
01/09/28 19:40:31 31SZ3660_097

The HI or LO indicator lights and
remains lit until you turn it of f by
pushing the opposite side of the
switch lightly. The indicator will turn
off.Follow these precautions whenever
you use the seat heaters:
Use the HI setting only to heat the
seats quickly. Select the LO
setting when the seats f eel warm.
The HI setting draws large
amounts of current f rom the
battery.
Do not use the seat heaters, even
on the LO setting, if the engine is
lef t idling f or an extended period.
They can weaken the battery,
causing hard starting.
In LO, the heater runs continuously.
It does not cycle with temperature
changes. In HI, the heater turns of f when the
seat gets warm, and turns back on
after the seat’s temperature drops. It
continues to cycle as long as you
leave it set on HI. The HI indicator
remains lit as a reminder that you
have the heater on.
Because of the sensors f or the side
airbag system, there is no heater in
the passenger’s seat-back. To use the ski sleeve:
Pull down the rear seat armrest.
Open the trunk pass-through
cover by sliding the knob down-
ward and pulling on the cover.
Theskisleeveallowsyoutocarry
skis or other long objects saf ely
without soiling or damaging the
interior of your car. It attaches to the
trunk pass-through.
1. Ski Sleeve
Seat Heaters, Ski Sleeve
Inst rument s and Cont rols96
K KN
NO OBB
L
LIIDD
01/09/28 19:40:56 31SZ3660_099

µThe MAIN switch controls power to
the passenger’s window. With this
switch of f , the passenger’s window
cannot be raised or lowered. The
MAIN switch does not af f ect the driv-
er’s window. Keep the MAIN switch
off whenyouhavechildreninthecar
so they do not injure themselves by
operating the window unintentionally.
The lights inside the switches come
onwhenyouturntheparkinglights
or headlights on.
The master control panel also con-
tains these extra features:
To open the driver’s
window f ully, push the window
switch f irmly down, then release it.
The window automatically goes
down all the way. To stop the
window f rom going all the way down,
pull back on the window switch
brief ly.
To open or close the driver’s window
partially, push down or pull back on
the window switch lightly and hold it.
The window will stop when you
release the switch. To close the driver’s window f ully,
pull back the window switch f irmly,
then release it. The window
automatically goes all the way up. To
stop the window f rom going all the
way up, push down on the window
switch brief ly. If the driver’s window runs into any
obstacle while it is closing
automatically, it will stop, and then
reverse direction. To close the
window, remove the obstacle, then
use the window switch again.
Auto reverse stops sensing when the
window is almost closed. You should
always check that all passengers and
objects are away from the window
bef ore closing it.
CONT INUED
Inst rument s and Cont rols
AUTO
Power Windows
Auto Reverse
99
01/09/28 19:41:22 31SZ3660_102

There are two switches on the
ceiling near the f ront ceiling light.
The ignition switch must be ON (II).
To open the moonroof , pull the
OPEN/CLOSE switch backward and
hold it until the moonroof reaches
the desired position.
If your car’s battery is disconnected
or goes dead, or the driver’s window
f use is removed, the AUTO f unction
will be disabled. The power window
system needs to be reset af ter
reconnecting the battery or installing
the f use. You should do the f ollowing.
Pull back on the driver’s window
switch to close the window
completely then hold the switch
forafurthersecondortwomore. Start the engine. Push down on
the driver’s window switch until
the window is f ully open.
If the power windows do not operate
properly af ter resetting, have your
car checked by an Acura dealer. The power window system has a key-
of f delay f unction. The windows will
stilloperateforuptotenminutes
after you turn off the ignition.
Opening either f ront door cancels
the delay function. You must turn
the ignition switch ON (II) again
bef ore you can raise or lower the
windows.
1.
2. Moonroof
Power Windows, Moonroof
Inst rument s and Cont rols100
O OP
PE
EN
N/ /C
CL LOOS SEE
S
SW WI ITT C
CH H
01/09/28 19:41:32 31SZ3660_103

When you push and hold the TILT-
UP switch, the rear of the moonroof
will tilt up. To close it, push the
OPEN/CLOSE switch f orward. If
you pull the switch backward and
hold it, the moonroof will tilt down
and then open. The AUTO f unction
cannot work with the moonroof in
the tilt up position.
To close the moonroof , push the
OPEN/CLOSE switch f orward and
hold it. The moonroof will not close
completely; it will stop about 5.1
inches (130 mm) away f rom being
closed. Make sure your passengers
are clear of the moonroof , then
release the switch and push it
f orward again to close the moonroof
completely.
The moonroof has an AUTO
f unction. To open the moonroof f ully,
pull the OPEN/CLOSE switch
backward f irmly until it clicks, then
release it. The moonroof opens
automatically all the way. To stop the
moonroof f rom opening all the way,
push the switch forward briefly. To
open the moonroof partially, pull the
OPEN/CLOSE switch backward
lightly and hold it until the moonroof
reaches the desired position. The
AUTO f unction only works to open
the moonroof .
Moonroof
Inst rument s and Cont rols101
T T
I
ILLT T -
-U
UP P S
SWWI ITT C
CH HIf you try to open the moonroof in
below-f reezing temperatures, or when
it is covered with snow or ice, you can
damage the moonroof panel or motor.
01/09/28 19:41:39 31SZ3660_104
