Controls Near the Steering Wheel
82
WINDSHIELD
WIPERS/WASHERS
INSTRUMENT PANEL
BRIGHTNESS HAZARD WARNING BUTTON
HEADLIGHTS/TURN SIGNALS/
FOG LIGHTS
REAR WINDOW
DEFOGGER BUTTON
SEAT HEATER
SWITCHES
HORN
MIRROR CONTROLS STEERING WHEEL ADJUSTMENTREMOTE AUDIO
CONTROL BUTTONS HANDSFREELINK
BUTTONS CRUISE CONTROL
BUTTONS
VEHICLE STABILITY
ASSIST (VSA) OFF
SWITCH (P.84)
(P.85)
(P.203)
(P.101) (P.88)(P.150) (P.160)
(P.83)
(P.86)
(P.106) (P.153) (P.87)
TM

When you f inish, move the
selector switch to the center (off)
position. This turns of f the
adjustment switch to keep your
settings.The outside mirrors are heated to
remove fog and frost. With the
ignition switch in the ON (II)
position, turn on the heaters by
pressing the button. The indicator in
the button comes on as a reminder.
Press the button again to turn the
heaters off.
Depending on the position of the
selector switch, the lef t or right side
mirror will pivot downward slightly
when you shif t the transmission into
reverse. In the lef t position, the lef t
mirror pivots. In the right position,
the right mirror pivots. This gives
you a better view of that side of the
vehicle while parallel parking. The
mirror returns to its original position
when you take the transmission out
of reverse. To turn this f eature of f ,
leave the switch in the center
position.
Outside mirror positions can be
stored in the driving position
memory system (see page ). 3.
103
Mirrors
Power Mirror Heaters
102
HEATED MIRROR BUTTON

Follow these precautions whenever
you use the seat heaters:
Both f ront seats are equipped with
seat heaters. The passenger seat
only has heaters in the seat bottom
because of the side airbag system.
The ignition switch must be in the
ON (II) position to use them. Push
theHIsideof theswitchtorapidly
heat up the seat. After the seat
reaches a comf ortable temperature,
pushtheLOsideof theswitch.This
will keep the seat warm. In HI, the heater turns of f when the
seat gets warm, and turns back on
after the seat temperature drops.
In LO, the heater runs continuously.
It does not cycle with temperature
changes.
Use the HI setting only to heat the
seats quickly, because it draws
large amounts of current f rom the
battery.
If the engine is lef t idling f or an
extended period, do not use the
seat heaters even on the LO
setting. It can weaken the battery,
causing hard starting.
Seat Heaters
106
SEAT HEATER SWITCHES

The f low-through ventilation system
draws in outside air, circulates it
through the interior, then exhausts it
through vents near the rear window.Set the temperature to maximum.
Make sure the A/C is of f .
Select and fresh air mode.
Set the f an to the desired speed.
The heater uses engine coolant to
warm the air. If the engine is cold, it
will be several minutes bef ore you
f eel warm air coming f rom the
system. Select and fresh air mode.
Set the f an to the desired speed.
Adjust the warmth of the air with
the temperature control buttons.
When you select , the system
automatically switches to f resh air
mode and turns on the A/C.
Thedriver’ssidemodeand
passenger’s side mode can be
selected separately when the dual
button is pressed. However, when
is selected on the driver’s
side, mode selection on the
passenger’s side is not possible.
When is selected, the
passenger’s temperature cannot be
set separately f rom the driver’s.
You can set the temperatures and
modes f or the driver’s side and the
passenger’s side separately when
this button is pressed (indicator on).
When the indicator in the DUAL
button is off, you can adjust both
sides to the same temperature and
mode with the driver’s side
temperature control buttons and
mode control button.
Use the mode control button to
select the vents the air flows from.
Some air will flow from the
dashboard vents in all modes.
Air flows from the center
and corner vents in the dashboard.
Airf low is divided between
the f loor vents and the def roster
vents at the base of the windshield.
Air f lows f rom the def roster
vents at the base of the windshield. Airf low is divided between
the vents in the dashboard and the
f loor vents. Air f lows f rom the f loor
vents. When you select , the
system automatically switches to
f resh air mode. 1.
2.
3.
4.
1.
2.
3.
Vents, Heating, and A/C
Ventilation
Using the Heater
Dual Button
Mode Control Button
Features
123

To remove f og f rom inside the
windows:Select . When you select , the system automatically
switches to f resh air mode and
turns on the A/C. (The A/C ON
indicator will not come on in U.S.
vehicles, if the A/C was of f to
start with.)
Adjust the temperature so the
airflow feels warm.
Select to help clear the
rear window.
When you switch to another mode
f rom , the A/C turns of f . But
if it was on to start with, it stays on.
Air conditioning, as it cools, removes
moisture from the air. When used in
combination with the heater, it
makes the interior warm and dry.
Switch the f an on.
Turn on the air conditioning.
Select and fresh air mode.
Adjust the temperature to your
pref erence.
This setting is suitable f or all driving
conditions whenever the outside
temperature is above 32°F (0°C).
Air conditioning places an extra load
on the engine. Watch the engine
coolant temperature gauge (see page
). If it moves near the red zone,
turn of f the A/C until the gauge
reading returns to normal.
Turn on the A/C by pressing the
button. The indicator in the button
comesonwhenafanspeedis
selected.
Make sure the temperature is set
to maximum heat.
Select .
If the outside air is humid, select
recirculation mode. If the outside
air is dry, select f resh air mode.
Set the f an to the desired speed. you can
cool it down more rapidly by partially
opening the windows, turning on the
A/C, and setting the fan to
maximum speed in f resh air mode. 1.
2.
3.
4.
1.
2.
3.
66
1.
2.
3.
4.
5.
If the interior is very warm,
Vents, Heating, and A/C
To Def og and Def rost
Dehumidif y the Interior
Using the A/C
124

The disc changer can play these disc
formats:CD
CD-R
DVD-A
DTS
DVD-A discs not meeting DVD
verification standards may not be
playable.
The changer cannot play DVD-V,
DVD-R/RW, MP3, or WMA f ormats.
Some CD-DA and CD-ROM mixed
discs are not playable.
‘‘DTS’’ and ‘‘DTS Digital Surround’’
are registered trademarks of Digital
Theater System, Inc. To load multiple discs in one
operation:
Your vehicle’s audio system has an
in-dash disc changer that holds up to
six discs. You operate this disc
changer with the same controls used
f or the radio. To operate the disc
changer, the ignition switch must be
in the ACCESSORY (I) or ON (II)
position.
With the ignition switch in the
ACCESSORY (I) or ON (II)
position, press and hold the LOAD
button until you hear a beep and
see ‘‘LOAD’’ in the display, then
release the button.
Insert a disc into the slot. Insert it
only about half way; the drive will
pull it in the rest of the way.
When the ‘‘DISC LOAD’’ appears
in the display, insert the next disc
into the slot.
Repeat this until all six positions
are loaded. The system will thenbegin playing the last disc loaded.
If you stop loading discs bef ore all
six positions are f illed, the system
will wait f or 15 seconds, stop the load
operation, and begin playing the last
disc loaded.
If you press the LOAD button while
a disc is playing, the system will stop
playing that disc and start the
loading sequence. It will then play
the disc just loaded. The disc number f or an empty
position is highlighted and the
green load indicator comes on.
When you see ‘‘LOAD’’ in the
display, insert the disc into the slot.
Insert it only about halfway; the
drive will pull it in the rest of the
way. Press and release the LOAD
button.
To load a single disc:
1.
2.
3.
4. 1.
2.
L oading Discs in the Changer
Playing Discs
141
TM
Do not use discs with adhesive labels.
The label can curl up and cause the
disc to jam in the unit.

´´
Although this seems like a simple
procedure, you should take several
precautions.
You cannot start a vehicle with an
automatic transmission by pushing
or pulling it. Open the hood, and check the
physical condition of the battery.
In very cold weather, check the
condition of the electrolyte. If it
seems slushy or like ice, do not try
jump starting until it thaws.
Turn of f all the electrical acces-
sories: heater, A/C, stereo system,
lights, etc. Put the transmission in
neutral or Park, and set the
parking brake.
The numbers in the illustration
show you the order to connect the
jumper cables.
Connect one jumper cable to the
positive ( ) terminal on your
battery. Connect the other end to
the positive ( ) terminal on the
booster battery.
1.
2.
3.
Jump Starting
To Jump Start Your Vehicle:
252
A battery can explode if you do
not follow the correct procedure,
seriously injuring anyone
nearby.
Keep all sparks, open flames,
and smoking materials away
from the battery.If a battery sits in extreme cold, the
electrolyte inside can f reeze.
Attempting to jump start with a f rozen
battery can cause it to rupture.

ÎÎ
ÎÎ
No.
No. Amps. Circuits Protected Circuits Protected
Amps.
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
1
2
3
4
5 15 A
30 A
7.5 A 10 A
7.5 A Left Headlight Low Beam
Rear Defroster Coil
Left Headlight High Beam
Small Light
Right Headlight High Beam Right Headlight Low Beam
Back Up
IGP
Condenser Fan
Front Fog Light
Daytime Running Light
Radiator Fan Motor
MG Clutch Relay
Horn, Stop
Rear Defroster
Back UP, ACC
Hazard Warning
VSA Pump Motor Relay
VSA Fail Safe Relay
FI ECU (ECM/PCM)
Power Seat
Heater Motor
Battery
IGI Main
15 A
7.5 A 15 A
30 A
20 A
15 A
30 A
7.5 A 20 A
40 A
40 A
15 A
30 A
40 A
40 A
40 A
40 A
120 A 50 A
U.S. models Canadian models
1: 2:
1
2
Fuse Locations
T aking Care of t he Unexpect ed
261
UNDER-HOOD FUSE BOX
