Start the engine. If you are
replacing a driver’s side bulb, turn
the steering wheel all the way to
theright.If youarereplacinga
passenger’s side bulb, turn the
steering wheel to the lef t. Turn of f
the engine.Use a wrench to remove the
mounting bolts, and remove the
holding clip with a f lat-tip
screwdriver.
Use a flat-tip screwdriver to
remove the holding clips from
the edge of the inner fender
cover, and pull the inner fender
cover back. 3.
2.
1.
CONT INUED
Replacing the Front
Side Marker Light Bulb
Lights
Maint enance
523
HOLDING CLIP
HOLDING
CLIP SPOILER
BOLTS
10/07/29 12:49:01 31TK4620_528
2011 TL

Remove the socket from the
headlight assembly by turning it
one-quarter turn counterclockwise.Start the engine. If you are
replacing a driver’s side bulb, turn
the steering wheel all the way to
theright.If youarereplacinga
passenger’s side bulb, turn the
steering wheel to the lef t. Turn of f
the engine.
Remove the bulb by pulling it
straight out of its socket. Install the new bulb in the socket
by pushing it straight in the socket
until it bottoms.
Insert the socket into the
headlight assembly. Turn it
clockwise to lock it in place.
Turn on the lights to make sure
the new bulb is working.
Push the under cover in place and
set the spoiler and inner f ender
cover in the original position.
Install the bolts and tighten them
securely. Put the holding clip, and
lock it by pushing on its center.
4.
5. 6.
7.
8.
1.
9. Replacing a Front T urn Signal/
Parking L ight Bulb
Lights
524
SOCKET
BULB
10/07/29 12:49:08 31TK4620_529
2011 TL

Install the new bulb in the socket.
Turn it clockwise to lock it in place.
Insert the socket into the light
assembly. Turn it clockwise to
lock it in place.Your vehicle uses halogen light
bulbs. When replacing a bulb, handle
it by its plastic case, and protect the
glass from contact with your skin or
hard objects. If you touch the glass,
clean it with denatured alcohol and a
clean cloth. Start the engine. If you are
replacing a driver’s side bulb, turn
the steering wheel all the way to
the right. If you are replacing a
passenger’s side bulb, turn the
steering wheel to the left. Turn off
the engine.
The fog lights were properly aimed
when your vehicle was new. If you
regularly carry heavy items in the
trunk, readjustment may be
required. Adjustment should be
done by your dealer or another
qualified technician.
Turn on the lights to make sure
the new bulb is working.
Push the under cover in place and
set the spoiler and inner f ender
cover in the original position.
Install the bolts and tighten them
securely. Put the holding clip, and
lock it by pushing on its center.
6.
7.
8.
9.
1.
Replacing a Front Fog L ight Bulb
Lights
526
Halogen bulbs get very hot when lit. Oil,
perspiration, or a scratch on the glass
can cause the bulb to overheat and
shatter.
