Bass, Treble, Balance, and Fader are
each adjustable.
These two
modes adjust the strength of the
sound coming f rom each speaker.
BAL adjusts the side-to-side strength,
while FAD adjusts the f ront-to-back
strength.
Use the TRE/BAS
modes to adjust the tone to your
liking. Ifyouwanttoadjustthesoundwhile
the radio or CD is playing, push the
AUDIO DISPLAY button and then
push the TUNE/SOUND knob or
touch the SOUND icon in the display.
The current setting is shown on the
display.
You select which of these you want
to adjust by pressing the TUNE/
SOUND knob. The mode changes
from BASS to TREBLE to FADER to
BALANCE,andthenbacktothe
selected audio mode, each time you
press the knob. Turn the knob to
adjust the setting to your liking.
When the level reaches the center,
you will see ‘‘ ’’ in the display.
The system will automatically return
the display to the selected audio
mode about 5 seconds af ter you stop
adjusting a mode.
On vehicles without navigation system On vehicles with navigation system
CONT INUED
Adjusting the Sound
Adjusting the Sound
Balance/Fader
Treble/Bass
Features
175
——yy
(y
y

´µ
You select which of these you want
to adjust by pressing the TUNE/
SOUND knob. The mode changes
from BASS to TREBLE to FADER to
BALANCE,andthenbacktothe
selected audio mode, each time you
press the button. You can also select
themodebytouchingthe
adjustment bar on the display
directly. To adjust the TREBLE and BASS,
touch or on each side of the
TREBLE or BASS adjustment bar.
The adjustment bar shows you the
current setting.
The Left/Right BALANCE adjusts
the side-to-side strength, while
Front/Rear FADER adjust the front-
to-back strength. To adjust the Left/
Right BALANCE, touch the ‘‘L’’ or
‘‘R’’ icon. To adjust the Front/Rear
FADER, touch the ‘‘FR’’ or ‘‘RR’’ icon.
The system will automatically return
the display to the selected audio
mode about 5 seconds af ter you stop
adjusting a mode.
Adjusting the Sound
176
ADJUSTMENT BARS
——yy
(y
y

Your vehicle is capable of receiving
XM
Satellite Radio anywhere in the
United States, except Hawaii and
Alaska.
XM
is a registered trade mark of
XM Satellite Radio, Inc.
XM Satellite Radio receives signals
f rom two satellites to produce clear,
high-quality digital reception. It
of f ers many channels in several
categories. Along with a large
selection of dif f erent types of music,
XM Satellite Radio also allows you to
view channel and category selections
in the audio display.
CONT INUED
U.S. Models only
Satellite Digital Radio
Playing the XMSatellite Radio (U.S. Models)
Features
179
SCAN
BUTTON
PWR/VOL
KNOB TUNE/
SOUND
KNOB
PRESET
BUTTONS
SCAN BUTTON
AUDIO DISPLAY
BUTTON
CATEGORY/CHANNEL MODE
INDICATOR
PWR/VOL
KNOB
MODE
ICON
SCAN
ICON
UPPER DISPLAY
PRESET ICONS
SOUND
ICON
XM BUTTON
XM BUTTON
without navigation system
with navigation system
SEEK/SKIP
CATEGORY BAR
SEEK/SKIP
CATEGORY BAR
DISP/MODE BUTTON
TUNE/
SOUND
KNOB
——yy
(y
y

µµ
µ
To listen to the XM satellite Radio,
turn the ignition switch to the
ACCESSORY (I) or ON (II) position.
Push the PWR/VOL knob to turn on
the audio system, and press the XM
button. Adjust the volume turning
the PWR/VOL knob. The last
channel you listened to will show in
the display.
To switch between the
category mode and channel mode,
press and hold the DISP/MODE
button until the mode changes. On
models with navigation system,
touch the MODE icon on the display.
In channel mode, you can select all
of the available channels. In category
mode, such as Jazz, Rock, Classical,
etc., you can select all of the
channels within that category. Turn the TUNE knob to
change channel selections. Turn the
knob right f or higher numbered
channels and lef t f or lower
numbered channels. In the category
mode, you can only select channels
within that category.
Each time you press and
release the DISP/MODE button, the
display changes in the f ollowing
sequence: Channel name, category,
artist name, and music title.
To operate the XM Radio, Press the
AUDIO DISPLAY button to view the
XM Radio control display.
On vehicles without navigation system
On vehicles with navigation system
Playing the XMSatellite Radio (U.S. Models)
Operating the XM Radio
MODET UNE
DISP
180
——y
y
(y
y

µ
µ
µ Youcanstoreupto12
preset channels using each side of
the preset bar or preset icons on the
screen. Each side of the bar stores
one channel f rom the XM1 band and
one channel f rom the XM2 band. Pick a preset number (icon) you
want f or that channel. Press and
hold the bar (icon) until you hear a
beep.
Repeat steps2and3to store the
f irst six channels.
Once a channel is stored, press and
release the proper side of the preset
bar (icon) to tune to it.
To store a channel:
Press the XM button. Either XM1
or XM2 will show in the display.
Usethetune,seek,orscan
function to tune to a desired
channel. Press the XM button again or
touch the other XM icon (XM1 or
XM2) on the audio display. Store
the next six channels using steps 2
and 3.
In category mode, only channels
within that category can be selected.
In channel mode, all channels can be
selected.
Press either side of the CATEGORY
bar ( or ) to select another
category.
The scan f unction gives
you a sampling of all channels while
in the channel mode. In the category
mode, only the channels within that
category are scanned. To activate
scan, press the SCAN button or
touch the SCAN icon on the screen.
The system plays each channel in
numerical order f or a f ew seconds,
then selects the next channel. When
you hear a channel you want to listen
to, press the button or touch the icon
again. 1.
2.3.
4.
5.
CONT INUED
Preset
SEEK /SK IP (CA T EGORY)
SCAN
Playing the XMSatellite Radio (U.S. Models)
Features
181
——yy
(y
y

Satellite radio receives signals f rom
two satellites to produce clear, high-
quality digital reception. It of f ers
many channels in several categories.
Along with a large selection of
dif f erent types of music, satellite
radio also allows you to view channel
and category selections in the audio
display.
TheXMsatellitesareinorbitover
the equator; therefore, objects south
of the vehicle may cause satellite
reception interruptions. To help
compensate f or this, ground-based
repeaters are placed in major
metropolitan areas. Satellite signals
aremorelikelytobeblockedbytall
buildings and mountains the f arther
north you travel f rom the equator. Satellite Radio Signals
Playing the XMSatellite Radio (U.S. Models)
182
Signal may be
blocked by
mountains or
large obstacles
to the south.
SATELLITE
GROUND
REPEATER
——y
y
(y
y

Depending on where you drive, you
may experience reception problems.
Interf erence can be caused by any of
these conditions:Drivingonaneast/westroadwith
a mountain on the south side of
the road.
There may be other geographic
situations that could af f ect satellite
radio reception. Driving on a single lane road
alongside dense trees taller than
50 ft. (15 m) to the south of you. Driving on the lower level of a
multi-tiered road. Driving on a road beside a vertical
wall, steep clif f , or hill to the south
of you. Driving in tunnels.
Driving on the north side of a
large commercial truck on an
east/west road.
If your XM Radio service has expired
or you purchased your vehicle f rom
a previous owner, you can listen to a
sampling of the broadcasts available
on XM Satellite Radio. With the
ignition switch in the ACCESSORY
(I) or ON (II) position, push the
PWR/VOL knob to turn on the audio
system and press the CD/AUX XM
button. A variety of music types and
styles will play.
If you decide to purchase XM
satellite radio service, contact XM
Radio at
, or at
1-800-852-9696. You will need to give
them your radio I.D. number and
your credit card number. Turn the TUNE knob until ‘‘0’’
appears in the display. Your I.D. will
appear in the display.
Af ter you have registered with XM
Radio, keep your audio system in the
SAT Radio mode while you await
activation. This should take about 30
minutes.
While awaiting activation, make sure
your vehicle remains in an open area
with good reception. Once your
audio system is activated, ‘‘category’’
or ‘‘CH’’ will appear in the display
and you will be able to listen to XM
Radio broadcasts. XM Radio will
continue to send an activation signal
to your vehicle for at least 12 hours
from activation request. If the
service has not been activated after
36 hours, contact XM Radio.As required by the FCC:
Changes or modif ications not expresslyapproved by the party responsible f orcompliance could void the user’sauthority to operate the equipment.
www.xmradio.com
CONT INUED
Playing the XMSatellite Radio (U.S. Models)
Receiving Satellite Radio Service To get your XM Satellite radio ID
number:Features
183
——yy
(y
y

Your audio system will accept
auxiliary inputs f rom a portable
cassette player, MP3 player, etc.To use the jack, turn down the
volume of the portable unit, and
pivot the cover up, then plug in a
mini-jack cable between the portable
unit and the jack. You will see AUX
in the display and the system
automatically switches to AUX mode.
To adjust the volume, turn the PWR/
VOL knob.
To take the system out of AUX mode,
press the AM/FM, or CD/AUX or
CD/AUX/XM (U.S. models only)
button. To return to AUX mode
while the jack is connected, press the
CD/AUX or CD/AUX/XM button.
Auxiliary Input Jack
Auxiliary Input Jack
184
——yy
(y
y

Playing Discs
186
CD SLOT
CD LOAD INDICATOR
LOAD BUTTON
SEEK/SKIP BARSCAN BUTTON
CD/AUX BUTTON CH DISC BAR
AUDIO DISPLAY BUTTON
UPPER DISPLAY
DISC SCAN ICON TRACK REPEAT ICON
TRACK SCAN ICON CH DISC ICONS
SOUND ICON
TRACK RANDOM ICON
DISC REPEAT ICON
With navigation system
TRACK ICON DISC ICON
U.S. model is shown.
——yy
(y
y

CONT INUED
To load multiple discs in one
operation:Press the LOAD button until you
hear a beep and see ‘‘LOAD’’ in
the display.
To load only one CD, press and
release the LOAD button.
The disc number f or an empty
position is highlighted and the red
light starts blinking.
Insert the disc into the CD slot
when the green CD load indicator
comes on. Insert it only about
half way; the drive will pull it in the
rest of the way. You will see
‘‘BUSY’’ in the display as the CD
load indicator turns red and blinks
as the CD is loaded. You cannot load and play 3-inch
(8-cm)discsinthissystem.
When the CD load indicator turns
green and ‘‘LOAD’’ appears in the
display again, insert the next CD
in the slot.
Do not try to insert a disc until
‘‘LOAD’’ appears. You could
damage the audio unit.
Repeat steps 1 through 3 until all
six positions are loaded. If you are
not loading all six positions, the
system begins playing the last CD
loaded.
Your audio system has an in-dash
CD changer that holds up to six CDs,
providing several hours of
continuous entertainment. You
operate this CD changer with the
same controls used f or the radio.
To load CDs or operate the CD
changer, the ignition switch must be
in the ACCESSORY (I) or ON (II)
position.
For best results when using CD-R or
CD-RW discs, use only high quality
discs labeled f or audio use. When
recording a CD-R or CD-RW, the
recordingmustbeclosedinorder
f or the disc to be used by CD player. 1.
2.
3.
4.
5.
L oading CDs in the Changer
Operating the CD Changer
Playing Discs
Features
187
Do not use CDs with adhesive labels.
The label can curl up and cause the CD
to jam in the unit.
——y
y
(y
y
