ELECTRICAL TROUBLESHOOTING
MANUAL
SERIES 3 – E36/7 (Z3 Roadster and M Roadster )
SCHEM ATICS MODEL YEAR 1998
0100.0INDEX
0110.0
INTRODUCTION
0140.0
SYMBOLS
0670.0
POWER DISTRIBUTION CHART

0670.1
FUSE CHART

0670.2
POWER DISTRIBUTION

0670.3
FUSE DETAILS
0670.4GROUND DISTRIBUTION
0670.5
DATA LINK


1210.17


ENGINE CONTROL SYSTEM
MS41.1 (6–CYLINDER M52/S52)




1210.20



ENGINE CONTROL SYSTEM
(DME M5.2, 4–CYLINDER M44)

1230.0
CHARGING SYSTEM
1240.0START
1290.0
E–BOX FAN


2460.2


ELECTRONIC TRANSMISSION
CONTROL (EGS A4S 270R)




3234.0



SUPPLEMENTAL RESTRAINT
SYSTEM (AIR BAG)

3450.0
SLIP CONTROL (ABS)
3450.1SLIP CONTROL (ABS/ASC)
3614.0
TIRE INFLATION SYSTEM
5116.0
POWER MIRRORS
5126.0
ZKE CENTRAL LOCKING (ZV)

5133.0
ZKE POWER WINDOWS (FH)

5200.0
POWER SEATS

5203.0
HEATED SEATS

5430.2
ELECTRO–HYDRAULIC
CONVERTIBLE TOP




6100.0



CENTRAL BODY ELECTRONICS
(ZKE IV)

6133.0
HORN

6135.0
DRIVE–AWAY PROTECTION
(EWS II)

6160.1
WIPER/WASHER MODULE (WWM)
6167.1
HEADLIGHT WASHER (SRA)




6169.0



WINDSHIELD WASHER JET
HEATERS

6211.0
INSTRUMENT CLUSTER
6213.3DIGITAL CLOCK
6300.0
LIGHT SWITCH DETAILS
6312.0
HEADLIGHTS/FOG LIGHTS
6313.0
TURN/HAZARD LIGHTS

6314.0
PARK/TAIL/UNDERHOOD LIGHTS




6320.0



LICENSE PLATE/LUGGAGE
COMPARTMENT LIGHTS
6322.0BACK UP LIGHTS
6325.0
BRAKE LIGHTS
6330.3
INTERIOR LIGHTS
6332.0
INTERIOR ACCESSORIES

6350.0
CRASH CONTROL MODULE

6424.0
REAR WINDOW DEFOGGER

6450.6
INTEGRATED HEATING– AND
CLIMATE CONTROL

6510.1
RADIO/HIFI


6561.0


CELLULAR TELEPHONE
(PROVISIONS)

6571.0
CRUISE CONTROL (TEMPOMAT)

6575.2
ANTI–THEFT SYSTEM (ALPINE)

6581.3
BOARD COMPUTER (BC – LOW)
7000.0COMPONENT LOCATION CHART
7100.0
COMPONENT LOCATION VIEWS
8000.0
SPLICE LOCATION VIEWS

8500.0
CONNECTOR VIEWS



#""$
Pin Assignments (6-Cylinder)
 !""





E = Input, A = Output, M = Ground
X8500
Pin Type Description/Function Connection
177
Not used
178MGroundShift-lock
179Not used
180ASolenoid valve 3 control (–)Transmission valve unit
181AHydraulic pressure regulator control (–)Transmission valve unit
182Not used
183Not used
184EGear range signal L2Automatic transmission range switch
185EGear range signal L4Automatic transmission range switch
186EBrake pedal positionBrake light switch
187Not used
188Not used
189EManual mode signalProgram switch
190EOutput speed (–)Transmission valve unit
191MGround for shieldShield for speed sensor
192Not used
193Not used
194EKick-down signalKick-down switch
195EASC signalSlip control module
196EAutomatic mode signalProgram switch
197EOil temperature signal (–)Transmission valve unit
198EOil temperature signal (+)Transmission valve unit
199Not used
200Not used
201AFault indicator signalInstrument cluster
202EBattery voltageB+ jump start junction point
203AM-program indicationProgram switch
204MGroundGround point
205Not used
206ASolenoid valve 1 control (–)Transmission valve unit



#""$
Pin Assignments (4-Cylinder)
 !""





E = Input, A = Output, M = Ground
X8500
Pin Type Description/Function Connection
265
Not used
266AShift-lock solenoid controlShift-lock
267Not used
268ASolenoid valve 3 control (–)Transmission valve unit
269AHydraulic pressure regulator control (–)Transmission valve unit
270MGroundGround point
271Not used
272EGear range signal L2Automatic transmission range switch
273EGear range signal L4Automatic transmission range switch
274EBrake pedal positionBrake light switch
275Not used
276ESport mode signalNot used
277EManual mode signalProgram switch
278EOutput speed (–)Transmission valve unit
279MGround for shieldShield for speed sensor
280Not used
281AS-program indicationNot used
282EKick-down signalKick-down switch
283Not used
284EAutomatic mode signalProgram switch
285EOil temperature signal (–)Transmission valve unit
286EOil temperature signal (+)Transmission valve unit
287Not used
288Not used
289AFault indicator signalInstrument cluster
290EBattery voltageB+ jump start junction point
291AM-program indicationProgram switch
292MGroundGround point
293Not used
294ASolenoid valve 1 control (–)Transmission valve unit

ELECTRONIC TRANSMISSION CONTROL (EGS A4S 270R)





 !""



#""$


A8500
TRANSMISSION
CONTROL MODULE
(EGS)
20 13
.5 GE/BL
3 13
.5 GE/BRX8565
1
24 X69
5 X8503
.5 GE/WS
A
X85032S8503
PROGRAM SWITCH
0) OFF
1) AUTOMATIC
2) MANUAL
GROUND
DISTRIBUTION
0670.4
X1001712P90
FRONT POWER
DISTRIBUTION BOX
FUSE DETAILS
0670.3
4527
X8564
E
.5 GE/WS.5 GE/WS .5 GE/BLM
M .5 GE/BR .5 GE/WS
26 X8500
POWER
DISTRIBUTION
0670.2
X6411
6 RT
1RT
ENGINE CONTROL
SYSTEM MS41.1
(6–CYLINDER M52)
1210.17
F2610A
31
&#
15
&#
15
0
2 1
+#$#)
X8500
6–CYLINDER

ELECTRONIC TRANSMISSION CONTROL (EGS A4S 270R)





 !""



#""$


A8500
TRANSMISSION
CONTROL MODULE
(EGS)
20 13X8500
12
.5 GE/BL
3 13
.5 GE/BL
NOT USED .5 GE/BLX8565
1
24 22 X69
5 X8503
.5 GE/WS .5 GE/GN
A
X85032S8503
PROGRAM SWITCH
0) OFF
1) AUTOMATIC
2) MANUAL
GROUND
DISTRIBUTION
0670.4
X1001712P90
FRONT POWER
DISTRIBUTION BOX
FUSE DETAILS
0670.3
23
452717
X8564X8576
ES
.5 GE/WS .5 GE/GN.5 GE/WS .5 GE/GN .5 GE/BLM
M
.5 GE/BR .5 GE/WS
26 X8500
POWER
DISTRIBUTION
0670.2
X6410
6 RT
1RT
ENGINE CONTROL
SYSTEM (DME M5.2,
4–CYLINDER M44)
1210.20
F2610A
31
&#
15
&#
15
&#
15
NOT USED
0
2 1
+#$#)
4–CYLINDER
