366 VEHICLE CARE
8. Route the hook end of the strapthrough the wheel.
9. Attach the hook to the cargo tie-down in the rear of the
vehicle.
10. Tighten the strap.
The compact spare is for temporary
use only. Replace the compact spare
tire with a full-size tire as soon as
you can.
Compact Spare Tire
{Warning
Driving with more than one
compact spare tire at a time could
result in loss of braking and
handling. This could lead to a crash
and you or others could be injured.
Use only one compact spare tire at
a time.
If this vehicle has a compact spare
tire, it was fully inflated when new;
however, it can lose air over time.
Check the inflation pressure regularly.
It should be 420 kPa (60 psi).
Caution
Exceeding the 80 km/h (50 mph)
maximum speed when a compact
spare assembly is installed can
damage the vehicle’s driveline
components. Stop as soon as possible and check
that the spare tire is correctly inflated
after being installed on the vehicle.
The compact spare tire is designed for
temporary use only. The vehicle will
perform differently with the spare tire
installed and it is recommended that
the vehicle speed be limited to
80 km/h (50 mph). To conserve the
tread of the spare tire, have the
standard tire repaired or replaced as
soon as convenient and return the
spare tire to the storage area.
When using a compact spare tire, the
AWD (if equipped), ABS, and Traction
Control systems may engage until the
spare tire is recognized by the vehicle,
especially on slippery roads. Adjust
driving to reduce possible wheel slip.Caution
When the compact spare is
installed, do not take the vehicle
through an automatic car wash
with guide rails. The compact spare
can get caught on the rails which
can damage the tire, wheel, and
other parts of the vehicle.

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-12533370) -
2019 - crc - 1/23/19
VEHICLE CARE 367
Do not use the compact spare on
other vehicles.
Do not mix the compact spare tire or
wheel with other wheels or tires. They
will not fit. Keep the spare tire and its
wheel together.
Caution
Tire chains will not fit the compact
spare. Using them can damage the
vehicle and the chains. Do not use
tire chains on the compact spare.
Jump Starting
Jump Starting - North
America
For more information about the
vehicle battery, seeBattery - North
America 0316.
If the battery has run down, try to use
another vehicle and some jumper
cables to start your vehicle. Be sure to
use the following steps to do it safely.
{Warning
WARNING: Battery posts,
terminals, and related accessories
contain lead and lead compounds,
chemicals known to the State of
California to cause cancer and birth
defects or other reproductive harm.
Batteries also contain other
chemicals known to the State of
California to cause cancer. WASH
HANDS AFTER HANDLING. For
more information go to
www.P65Warnings.ca.gov/
passenger-vehicle. See
California Proposition 65 Warning
0 289 and the back cover.
{Warning
Batteries can hurt you. They can be
dangerous because:
. They contain acid that can
burn you.
. They contain gas that can
explode or ignite.
. They contain enough
electricity to burn you.
If you do not follow these steps
exactly, some or all of these things
can hurt you.
Caution
Ignoring these steps could result in
costly damage to the vehicle that
would not be covered by the vehicle
warranty. Trying to start the vehicle
by pushing or pulling it will not
work, and it could damage the
vehicle.

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-12533370) -
2019 - crc - 1/23/19
VEHICLE CARE 369
Caution
If any accessories are left on or
plugged in during the jump starting
procedure, they could be damaged.
The repairs would not be covered
by the vehicle warranty. Whenever
possible, turn off or unplug all
accessories on either vehicle when
jump starting.
4. Turn the ignition off. Turn off all lights and accessories in both
vehicles, except the hazard
warning flashers if needed.
{Warning
An electric fan can start up even
when the engine is not running and
can injure you. Keep hands,
clothing, and tools away from any
underhood electric fan.
{Warning
Using a match near a battery can
cause battery gas to explode. People
have been hurt doing this, and
some have been blinded. Use a
flashlight if you need more light.
Battery fluid contains acid that can
burn you. Do not get it on you.
If you accidentally get it in your
eyes or on your skin, flush the place
with water and get medical help
immediately.
{Warning
Fans or other moving engine parts
can injure you badly. Keep your
hands away from moving parts
once the engine is running.
5. Connect one end of the red positive (+) cable to the remote
positive (+) terminal on the
discharged battery. 6. Connect the other end of the red
positive (+) cable to the
positive (+) terminal of the good
battery.
7. Connect one end of the black negative (–) cable to the
negative (–) terminal of the good
battery.
8. Connect the other end of the black negative (–) cable to the
remote negative (–) ground
terminal on the driver side shock
tower for the discharged battery.
9. Start the engine in the vehicle with the good battery and run
the engine at idle speed for at
least four minutes.
10. Try to start the vehicle that had the dead battery. If it will not
start after a few tries, it probably
needs service.

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-12533370) -
2019 - crc - 1/23/19
VEHICLE CARE 379
Do not use cleaners that increase
gloss, especially on the instrument
panel. Reflected glare can decrease
visibility through the windshield
under certain conditions.
Caution
Use of air fresheners may cause
permanent damage to plastics and
painted surfaces. If an air freshener
comes in contact with any plastic
or painted surface in the vehicle,
blot immediately and clean with a
soft cloth dampened with a mild
soap solution. Damage caused by
air fresheners would not be covered
by the vehicle warranty.
Cargo Cover and
Convenience Net
If equipped, wash with warm water
and mild detergent. Do not use
chlorine bleach. Rinse with cold water,
and then dry completely.
Care of Seat Belts
Keep belts clean and dry.
{Warning
Do not bleach or dye seat belt
webbing. It may severely weaken
the webbing. In a crash, they might
not be able to provide adequate
protection. Clean and rinse seat belt
webbing only with mild soap and
lukewarm water. Allow the webbing
to dry.
Floor Mats
{Warning
If a floor mat is the wrong size or is
not properly installed, it can
interfere with the pedals.
Interference with the pedals can
cause unintended acceleration and/
or increased stopping distance
which can cause a crash and injury.
Make sure the floor mat does not
interfere with the pedals.
Use the following guidelines for
proper floor mat usage. .
The original equipment floor mats
were designed for your vehicle.
If the floor mats need replacing, it
is recommended that GM certified
floor mats be purchased. Non-GM
floor mats may not fit properly
and may interfere with the pedals.
Always check that the floor mats
do not interfere with the pedals.
. Do not use a floor mat if the
vehicle is not equipped with a
floor mat retainer on the driver
side floor.
. Use the floor mat with the correct
side up. Do not turn it over.
. Do not place anything on top of
the driver side floor mat.
. Use only a single floor mat on the
driver side.
. Do not place one floor mat on top
of another.
The driver side floor mat is held in
place by two button-type retainers.

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-12533370) -
2019 - crc - 1/23/19
382 SERVICE AND MAINTENANCE
Proper vehicle maintenance helps to
keep the vehicle in good working
condition, improves fuel economy, and
reduces vehicle emissions.
Because of the way people use
vehicles, maintenance needs vary.
There may need to be more frequent
checks and services. The Additional
Required Services - Normal are for
vehicles that:
.Carry passengers and cargo within
recommended limits on the Tire
and Loading Information label. See
Vehicle Load Limits 0197.
. Are driven on reasonable road
surfaces within legal driving limits.
. Use the recommended fuel. See
Recommended Fuel (2.0L L4 Turbo
Engine) 0277 or
Recommended Fuel (3.0L Twin
Turbo V6 and 4.2L Twin Turbo
V8 Engines) 0277 or
Recommended Fuel (3.6L V6 Engine)
0 277. Refer to the information in the
Maintenance Schedule Additional
Required Services - Normal chart.
The Additional Required Services -
Severe are for vehicles that are:
.
Mainly driven in heavy city traffic
in hot weather.
. Mainly driven in hilly or
mountainous terrain.
. Frequently towing a trailer.
. Used for high speed or competitive
driving.
. Used for taxi, police, or delivery
service.
Refer to the information in the
Maintenance Schedule Additional
Required Services - Severe chart.{Warning
Performing maintenance work can
be dangerous and can cause serious
injury. Perform maintenance work
only if the required information,
proper tools, and equipment are
available. If they are not, see your
dealer to have a trained technician
do the work. See Doing Your Own
Service Work 0290.

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-12533370) -
2019 - crc - 1/23/19
426 INDEX
IndexA
Accessories and Modifications . . . . . 290
Accessory Power . . . . . . . . . . . . . . . . . . . . 206
Active Fuel Management . . . . . . . . . . . 208
Adaptive Cruise Control . . . . . . . . . . . . 229
Add-On Electrical Equipment . . . . . . 287
Additional InformationOnStar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 416
Additional Maintenance and Care . . . . . . . . . . . . . . . . . . . . . . . . . . . 389
Adjustments Lumbar, Front Seats . . . . . . . . . . . . . . . . 65
Lumbar, Rear Seats . . . . . . . . . . . . . . . . . 74
Thigh Support . . . . . . . . . . . . . . . . . . . . . . 66
Air Cleaner/Filter, Engine . . . . . . . . . . 304
Air Conditioning . . . . . . . . . . . . . . .175, 180
Air Filter Life System . . . . . . . . . . . . . . . . . . . . . . . . 304
Air Filter, Passenger
Compartment . . . . . . . . . . . . . . . . . . . . . 187
Air Vents . . . . . . . . . . . . . . . . . . . . . . . . . . . . 187
Airbag System Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
How Does an Airbag Restrain? . . . . . 88
Passenger Sensing System . . . . . . . . . 90
What Makes an Airbag Inflate? . . . . 88
What Will You See after anAirbag Inflates? . . . . . . . . . . . . . . . . . . . 88 Airbag System (cont'd)
When Should an Airbag
Inflate? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
Where Are the Airbags? . . . . . . . . . . . . 85
Airbags Adding Equipment to theVehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Passenger Status Indicator . . . . . . . 138
Readiness Light . . . . . . . . . . . . . . . . . . . 138
Servicing Airbag-Equipped Vehicles . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
System Check . . . . . . . . . . . . . . . . . . . . . . . 84
Alarm Vehicle Security . . . . . . . . . . . . . . . . . . . . . 49
Alert Lane Change . . . . . . . . . . . . . . . . . . . . . . 271
Rear Pedestrian . . . . . . . . . . . . . . . . . . . 260
Side Blind Zone (SBZA) . . . . . . . . . . 270
All-Season Tires . . . . . . . . . . . . . . . . . . . . . 340
All-Wheel Drive . . . . . . . . . . . . . . . .216, 317
Antilock Brake System (ABS) . . . . . . 217 Warning Light . . . . . . . . . . . . . . . . . . . . 143
Appearance Care
Exterior . . . . . . . . . . . . . . . . . . . . . . . . . . . . 372
Interior . . . . . . . . . . . . . . . . . . . . . . . . . . . . 376
Armrest Storage . . . . . . . . . . . . . . . . . . . . . 115
Ashtrays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125
Assistance Systems for Driving . . . . 262

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-12533370) -
2019 - crc - 1/23/19
INDEX 427
Assistance Systems for Parkingand Backing . . . . . . . . . . . . . . . . . . . . . . . 253
Auto Stop Stop/Start System . . . . . . . . . . . . . . . . 203
Automatic Climate Control System . . . . . 175, 180
Dimming Mirrors . . . . . . . . . . . . . . . . . . . 53
Door Locks . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Forward Braking . . . . . . . . . . . . . . . . . . 264
Headlamp System . . . . . . . . . . . . . . . . 169
Transmission . . . . . . . . . . . . . . . . . . . . . . 210
Transmission Fluid . . . . . . . . . . . . . . . 303
Vehicle Hold Light . . . . . . . . . . . . . . . . 144
Automatic Transmission Manual Mode . . . . . . . . . . . . . . . . . . . . . 215
Automatic Vehicle Hold (AVH) . . . . 220
B
Battery
Exterior Lighting BatterySaver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 173
Load Management . . . . . . . . . . . . . . . . 173
Power Protection . . . . . . . . . . . . . . . . . . 173
Battery - North America . . . . . .316, 367
Blade Replacement, Wiper . . . . . . . . . 319
Brake Parking, Electric . . . . . . . . . . . . . . . . . . 218
System Warning Light . . . . . . . 141, 142 Brake Pad Life System . . . . . . . . . . . . . . 315
Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 314
Antilock . . . . . . . . . . . . . . . . . . . . . . . . . . . 217
Assist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 219
Fluid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 315
Pad Life System . . . . . . . . . . . . . . . . . . . 315
Braking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 191
Automatic Forward . . . . . . . . . . . . . . . 264
Braking System Front Pedestrian (FPB) . . . . . . . . . . . 266
Break-In, New Vehicle . . . . . . . . . . . . . . 200
Bulb Replacement
Headlamp Aiming . . . . . . . . . . . . . . . . 321
Headlamps . . . . . . . . . . . . . . . . . . . . . . . . 321
Buying New Tires . . . . . . . . . . . . . . . . . . . 355
C
Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . 122
California Perchlorate MaterialsRequirements . . . . . . . . . . . . . . . . . . . 290
California Proposition 65 Warning . . . . . . . . . . . . .289, 316, 367, Back Cover
Canadian Vehicle Owners . . . . . . . . . . . . . 2
Capacities and Specifications . . . . . . 397
Carbon Monoxide Engine Exhaust . . . . . . . . . . . . . . . . . . . 209 Carbon Monoxide (cont'd)
Trunk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Winter Driving . . . . . . . . . . . . . . . . . . . . 195
Cargo
Tie-Downs . . . . . . . . . . . . . . . . . . . . . . . . . 117
Caution, Danger, and Warning . . . . . . . . 2
Center Console Storage . . . . . . . . . . . . . 116
Chains, Tire . . . . . . . . . . . . . . . . . . . . . . . . . 359
Charging Wireless . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
Charging System Light . . . . . . . . . . . . . 139
Check Engine Light (MalfunctionIndicator) . . . . . . . . . . . . . . . . . . . . . . . . 139
Child Restraints Infants and Young Children . . . . . . . . 97
Lower Anchors and Tethersfor Children . . . . . . . . . . . . . . . . . . . . . . 102
Older Children . . . . . . . . . . . . . . . . . . . . . . 96
Securing . . . . . . . . . . . . . . . . . . . . . . 108, 111
Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
Cigarette Lighter . . . . . . . . . . . . . . . . . . . . 125
Circuit Breakers . . . . . . . . . . . . . . . . . . . . . 322
Cleaning Exterior Care . . . . . . . . . . . . . . . . . . . . . . 372
Interior Care . . . . . . . . . . . . . . . . . . . . . . 376
Climate Control Systems Automatic . . . . . . . . . . . . . . . . . . . . 175, 180

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-12533370) -
2019 - crc - 1/23/19
428 INDEX
Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122
Cluster, Instrument . . . . . . . . . . . .127, 130
Collision Damage Repair . . . . . . . . . . . 408
Compact Spare Tire . . . . . . . . . . . . . . . . . 366
CompartmentsStorage . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
Compass . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122
Connected Services
Connections . . . . . . . . . . . . . . . . . . . . . . . 423
Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . 425
Navigation . . . . . . . . . . . . . . . . . . . . . . . . . 422
Connections Connected Services . . . . . . . . . . . . . . . 423
Control Traction and ElectronicStability . . . . . . . . . . . . . . . . . . . . . . . . . . 220
Control of a Vehicle . . . . . . . . . . . . . . . . 191
Convenience Net . . . . . . . . . . . . . . . . . . . . 117
Convex Mirrors . . . . . . . . . . . . . . . . . . . . . . 52
Coolant Engine Temperature Gauge . . . . . . 135
Engine Temperature Warning
Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146
Cooling . . . . . . . . . . . . . . . . . . . . . . . . .175, 180
Cooling System . . . . . . . . . . . . . . . . . . . . . 307
Cornering Lamps . . . . . . . . . . . . . . . . . . . 170
Courtesy Lamps . . . . . . . . . . . . . . . . . . . . . 171 Courtesy Transportation
Program . . . . . . . . . . . . . . . . . . . . . . . . . . . . 407
Cruise Control . . . . . . . . . . . . . . . . . . . . . . . 227 Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 149
Cruise Control, Adaptive . . . . . . . . . . . 229
Cruise Control, Super . . . . . . . . . . . . . . . 237
Cupholders . . . . . . . . . . . . . . . . . . . . . . . . . . 115
Customer Assistance . . . . . . . . . . . . . . . 403 Offices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 403
Text Telephone (TTY) Users . . . . . 403
Customer Information
Publications OrderingInformation . . . . . . . . . . . . . . . . . . . . . . 410
Customer Satisfaction Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . 401
D
Damage Repair, Collision . . . . . . . . . . . 408
Danger, Warning, and Caution . . . . . . . . 2
Data CollectionInfotainment System . . . . . . . . . . . . . 413
OnStar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 413
Data Recorders, Event . . . . . . . . . . . . . . 412
Daytime Running Lamps (DRL) . . . 168
Defensive Driving . . . . . . . . . . . . . . . . . . . 191
Delayed Locking . . . . . . . . . . . . . . . . . . . . . 40
Diagnostics Connected Services . . . . . . . . . . . . . . . 425 Distracted Driving . . . . . . . . . . . . . . . . . . 190
Dome Lamps . . . . . . . . . . . . . . . . . . . . . . . . 171
Door
Ajar Light . . . . . . . . . . . . . . . . . . . . . . . . . 149
Delayed Locking . . . . . . . . . . . . . . . . . . . . 40
Locks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Power Locks . . . . . . . . . . . . . . . . . . . . . . . . . 40
Rear Seat Pass-Through . . . . . . . . . . . . 75
Drive Belt Routing, Engine . . . . . . . . . 399
Drive Systems All-Wheel Drive . . . . . . . . . . . . . . 216, 317
Driver Assistance Systems . . . . . . . . . 252
Driver Information Center (DIC) . . . . . . . . . . . . . . . . . . . . . . . 150
Driver Mode Control . . . . . . . . . . . . . . . . 222
Driver Mode Control Light . . . . . . . . . 146
Driving Assistance Systems . . . . . . . . . . . . . . . 262
Characteristics andTowing Tips . . . . . . . . . . . . . . . . . . . . . 281
Defensive . . . . . . . . . . . . . . . . . . . . . . . . . . 191
Drunk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 191
For Better Fuel Economy . . . . . . . . . . . 27
Hill and Mountain Roads . . . . . . . . 194
If the Vehicle is Stuck . . . . . . . . . . . . 196
Loss of Control . . . . . . . . . . . . . . . . . . . . 193
Off-Road Recovery . . . . . . . . . . . . . . . . 192
Track Events and Competitive . . . 193

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-12533370) -
2019 - crc - 1/23/19
INDEX 429
Driving (cont'd)Vehicle Load Limits . . . . . . . . . . . . . . 197
Wet Roads . . . . . . . . . . . . . . . . . . . . . . . . . 193
Winter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 195
E
Electric Parking Brake . . . . . . . . . . . . . . 218
Electric Parking Brake Light . . . . . . . 143
Electrical Equipment, Add-On . . . . . 287
Electrical System
Engine Compartment FuseBlock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 323
Fuses and Circuit Breakers . . . . . . . 322
Instrument Panel Fuse Block . . . . 330
Overload . . . . . . . . . . . . . . . . . . . . . . . . . . . 322
Rear Compartment Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 332
Emergency OnStar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 415
Engine Air Cleaner/Filter . . . . . . . . . . . . . . . . . 304
Check Light (MalfunctionIndicator) . . . . . . . . . . . . . . . . . . . . . . . . 139
Compartment Overview . . . . . . . . . . 292
Coolant Temperature Gauge . . . . . 135
Coolant Temperature
Warning Light . . . . . . . . . . . . . . . . . . . 146
Cooling System . . . . . . . . . . . . . . . . . . . 307 Engine (cont'd)
Drive Belt Routing . . . . . . . . . . . . . . . . 399
Exhaust . . . . . . . . . . . . . . . . . . . . . . . . . . . . 209
Heater . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 205
Oil Life System . . . . . . . . . . . . . . . . . . . . 302
Oil Pressure Gauge . . . . . . . . . . . . . . . . 134
Oil Pressure Light . . . . . . . . . . . . . . . . . 147
Overheating . . . . . . . . . . . . . . . . . . . . . . . 312
Power Messages . . . . . . . . . . . . . . . . . . 156
Running While Parked . . . . . . . . . . . 210
Starting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 202
Engine Air Filter Life System . . . . . . 304
Entry Lighting . . . . . . . . . . . . . . . . . . . . . . 172
Equipment, Towing . . . . . . . . . . . . . . . . . 286
Event Data Recorders . . . . . . . . . . . . . . 412
Exit Lighting . . . . . . . . . . . . . . . . . . . . . . . . 172
Extended Parking . . . . . . . . . . . . . . . . . . . 209
Extender, Seat Belt . . . . . . . . . . . . . . . . . . 82
Exterior Lamp Controls . . . . . . . . . . . . 166
Exterior Lamps Off Reminder . . . . . . 168
Exterior Lighting Battery Saver . . . . 173
F
Features Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Filter, Engine Air Cleaner . . . . . . . . . . . . . . . . 304 Flash-to-Pass . . . . . . . . . . . . . . . . . . . . . . . . 168
Flashers, Hazard Warning . . . . . . . . . . 169
Flat Tire . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 359
Changing . . . . . . . . . . . . . . . . . . . . . . . . . . 361
Floor Mats . . . . . . . . . . . . . . . . . . . . . . . . . . . 379
Fluid Automatic Transmission . . . . . . . . . 303
Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 315
Washer . . . . . . . . . . . . . . . . . . . . . . . . . . . . 313
Folding Mirrors . . . . . . . . . . . . . . . . . . . . . . 53
Forward Automatic Braking . . . . . . . . 264
Forward Collision Alert (FCA) System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 262
Frequency Statement Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 411
Front Pedestrian Braking (FPB)
System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 266
Front Seats Heated and Ventilated . . . . . . . . . . . . . 70
Fuel Additives . . . . . . . . . . . . . . . . . . . . . . . . . . 278
Economy Driving . . . . . . . . . . . . . . . . . . . 27
Filling a Portable Fuel
Container . . . . . . . . . . . . . . . . . . . . . . . . 280
Filling the Tank . . . . . . . . . . . . . . . . . . . 278
Foreign Countries . . . . . . . . . . . . . . . . . 278
Gauge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133
Low Fuel Warning Light . . . . . . . . . 148

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-12533370) -
2019 - crc - 1/23/19
430 INDEX
Fuel (cont'd)Management, Active . . . . . . . . . . . . . . 208
Prohibited Fuels . . . . . . . . . . . . . . . . . . 277
Recommended . . . . . . . . . . . . . . . . . . . . 277
Top Tier . . . . . . . . . . . . . . . . . . . . . . . . . . . 276
Fuses Engine Compartment FuseBlock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 323
Fuses and Circuit Breakers . . . . . . . 322
Instrument Panel Fuse Block . . . . 330
Rear Compartment Fuse
Block . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 332
G
Garage Door Opener . . . . . . . . . . . . . . . . 162Programming . . . . . . . . . . . . . . . . . . . . . . 162
Gas Strut(s) . . . . . . . . . . . . . . . . . . . . . . . . . 320
Gauges Engine Coolant Temperature . . . . 135
Engine Oil Pressure . . . . . . . . . . . . . . . 134
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133
Odometer . . . . . . . . . . . . . . . . . . . . . . . . . . 133
Speedometer . . . . . . . . . . . . . . . . . . . . . . 133
Tachometer . . . . . . . . . . . . . . . . . . . . . . . 133
Trip Odometer . . . . . . . . . . . . . . . . . . . . 133
Voltmeter . . . . . . . . . . . . . . . . . . . . . . . . . . 136 Gauges (cont'd)
Warning Lights and
Indicators . . . . . . . . . . . . . . . . . . . . . . . . 126
Gear Shifting Light . . . . . . . . . . . . . . . . . 144
General Information
Service and Maintenance . . . . . . . . 381
Towing . . . . . . . . . . . . . . . . . . . . . . . . . . . . 280
Vehicle Care . . . . . . . . . . . . . . . . . . . . . . . 289
Glove Box . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
GM Mobility Reimbursement
Program . . . . . . . . . . . . . . . . . . . . . . . . . . . . 404
H
Hazard Warning Flashers . . . . . . . . . . 169
Head Restraints . . . . . . . . . . . . . . . . . . . . . . 63
Head-up Display . . . . . . . . . . . . . . . . . . . . 152
HeadlampsAiming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 321
Automatic . . . . . . . . . . . . . . . . . . . . . . . . . 169
Bulb Replacement . . . . . . . . . . . . . . . . 321
Daytime RunningLamps (DRL) . . . . . . . . . . . . . . . . . . . . 168
Flash-to-Pass . . . . . . . . . . . . . . . . . . . . . . 168
High-Beam On Light . . . . . . . . . . . . . . 148
High/Low Beam Changer . . . . . . . . . 168
Lamps On Reminder . . . . . . . . . . . . . . 149
Heated Steering Wheel . . . . . . . . . . . . . . . . . . . . 119 Heated and Ventilated Front
Seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Heated and Ventilated Rear Seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Heated Mirrors . . . . . . . . . . . . . . . . . . . . . . . 53
Heater Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 205
Heating . . . . . . . . . . . . . . . . . . . . . . . . .175, 180
High-Beam On Light . . . . . . . . . . . . . . . . 148
High-Speed Operation . . . . . . . . . . . . . . 347
Hill and Mountain Roads . . . . . . . . . . 194
Hill Start Assist (HSA) . . . . . . . . . . . . . 219
Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 291
Horn . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
How to Wear Seat Belts Properly . . . 77
HVAC . . . . . . . . . . . . . . . . . . . . . . . . . . .175, 180
I
Ignition Positions . . . . . . . . . . . . . . . . . . . 201
Immobilizer . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Indicator Pedestrian Ahead . . . . . . . . . . . . . . . . . 145
Vehicle Ahead . . . . . . . . . . . . . . . . . . . . . 144
Infants and Young Children, Restraints . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Information
Publication Ordering . . . . . . . . . . . . . 410
Infotainment . . . . . . . . . . . . . . . . . . . . . . . . 174
