Climate Controls 179
or replaced by one from a salvage
vehicle. It should only be replaced
by a new evaporator to ensure
proper and safe operation.
During service, all refrigerants
should be reclaimed with proper
equipment. Venting refrigerants
directly to the atmosphere is harmful
to the environment and may also
create unsafe conditions based on
inhalation, combustion, frostbite,
or other health-based concerns.

Cadillac XT5 Owner Manual (GMNA-Localizing-MidEast-10260744) - 2017 -
crc - 1/14/16
Driving and Operating 181
Conversions and Add-Ons
Add-On ElectricalEquipment . . . . . . . . . . . . . . . . . . 248Driving Information
Distracted Driving
Distraction comes in many forms
and can take your focus from the
task of driving. Exercise good
judgment and do not let other
activities divert your attention away
from the road. Many local
governments have enacted laws
regarding driver distraction. Become
familiar with the local laws in
your area.
To avoid distracted driving, always
keep your eyes on the road, hands
on the wheel, and mind on the drive.
. Do not use a phone in
demanding driving situations.
Use a hands-free method to
place or receive necessary
phone calls.
. Watch the road. Do not read,
take notes, or look up
information on phones or other
electronic devices.
. Designate a front seat
passenger to handle potential
distractions. .
Become familiar with vehicle
features before driving, such as
programming favorite radio
stations and adjusting climate
control and seat settings.
Program all trip information into
any navigation device prior to
driving.
. Wait until the vehicle is parked
to retrieve items that have fallen
to the floor.
. Stop or park the vehicle to tend
to children.
. Keep pets in an appropriate
carrier or restraint.
. Avoid stressful conversations
while driving, whether with a
passenger or on a cell phone.
{Warning
Taking your eyes off the road too
long or too often could cause a
crash resulting in injury or death.
Focus your attention on driving.

Cadillac XT5 Owner Manual (GMNA-Localizing-MidEast-10260744) - 2017 -
crc - 1/14/16
186 Driving and Operating
clear roads in shaded areas.
The surface of a curve or an
overpass can remain icy when
the surrounding roads are clear.
Avoid sudden steering
maneuvers and braking while
on ice.
. Turn off cruise control.
. Select All-Wheel Drive (AWD)
mode. See Driver Mode Control
0 208 andAll-Wheel
Drive 0202.
Blizzard Conditions
Stop the vehicle in a safe place and
signal for help. Stay with the vehicle
unless there is help nearby. Get
help and keep everyone in the
vehicle safe:
.
Turn on the hazard warning
flashers.
. Tie a red cloth to an outside
mirror.
{Warning
Snow can trap engine exhaust
under the vehicle. This may
cause exhaust gases to get
inside. Engine exhaust contains
carbon monoxide (CO), which
cannot be seen or smelled. It can
cause unconsciousness and even
death.
If the vehicle is stuck in snow:
. Clear snow from the base of
the vehicle, especially any
blocking the exhaust pipe.
. Open a window about 5 cm
(2 in) on the vehicle side
that is away from the wind,
to bring in fresh air.
. Fully open the air outlets on
or under the instrument
panel.
. Adjust the climate control
system to circulate the air
inside the vehicle and set
(Continued)
Warning (Continued)
the fan speed to the highest
setting. See“Climate
Control Systems.”
For more information about CO,
see Engine Exhaust 0197.
To save fuel, run the engine for
short periods to warm the vehicle
and then shut the engine off and
partially close the window. Moving
about to keep warm also helps.
If it takes time for help to arrive,
when running the engine, push the
accelerator pedal slightly so the
engine runs faster than the idle
speed. This keeps the battery
charged to restart the vehicle and to
signal for help with the headlamps.
Do this as little as possible, to
save fuel.
If the Vehicle Is Stuck
Slowly and cautiously spin the
wheels to free the vehicle when
stuck in sand, mud, ice, or snow.

Cadillac XT5 Owner Manual (GMNA-Localizing-MidEast-10260744) - 2017 -
crc - 1/14/16
194 Driving and Operating
be flooded with too much
gasoline. Try pushing the
accelerator pedal all the way to
the floor and hold it there, then
press ENGINE START/STOP
for up to a maximum of
15 seconds. Wait at least
15 seconds between each try,
to allow the cranking motor to
cool down. When the engine
starts, let go of the button and
the accelerator. If the vehicle
starts briefly but then stops
again, do the same thing. This
clears the extra gasoline from
the engine. Do not race the
engine immediately after
starting it. Operate the engine
and transmission gently until
the oil warms up and lubricates
all moving parts.
Stop/Start System
{Warning
Exiting the vehicle without first
shifting into P (Park) may cause
the vehicle to move. You or others(Continued)
Warning (Continued)
may be injured. Because the
vehicle has the auto engine stop/
start feature, the vehicle's engine
might seem to be shut off;
however, once the brake pedal is
released, the engine will start up
again.
Shift to P (Park) and turn the
ignition to LOCK/OFF, before
exiting the vehicle.
The vehicle has a fuel saving stop/
start system to shut off the engine to
help conserve fuel.
Auto Engine Stop/Start
When the brakes are applied and
the vehicle is at a complete stop,
the engine may turn off. When
stopped, the tachometer displays
AUTO STOP. See Tachometer
0 121. When the brake pedal is
released or the accelerator pedal is
pushed, the engine will restart.
Auto Stop may be deactivated if: .
A minimum vehicle speed is not
reached.
. The engine or transmission is
not at the required operating
temperature.
. The outside temperature is not
in the required operating range,
typically below −10 °C (14 °F) or
above 50 °C (122 °F).
. The transmission is in any gear
other than D (Drive).
. The battery is low.
. The battery has been
disconnected.
. The interior comfort level has not
reached the required level for
the climate control system or
defog settings. See Dual
Automatic Climate Control
System 0171.
. The Auto Stop time is greater
than two minutes.

Cadillac XT5 Owner Manual (GMNA-Localizing-MidEast-10260744) - 2017 -
crc - 1/14/16
240 Driving and Operating
.Do not tow a trailer during the
first 800 km (500 mi), to prevent
damage to the engine, axle,
or other parts.
. Then, during the first 800 km
(500 mi) of trailer towing, do not
drive over 80 km/h (50 mph) and
do not make starts at full throttle.
. The vehicle can tow in D (Drive).
Use a lower gear if the
transmission shifts too often.
. Do not use Adaptive Cruise
Control when towing.
. The Forward Automatic Braking
System should be set to Off
when towing. See Forward
Automatic Braking (FAB) 0229.
. Turn off Parking Assist and Rear
Cross Traffic Alert when towing.
. Turn off Lane Keep Assist (LKA).
See Lane Keep Assist
(LKA) 0235.{Warning
When towing a trailer, exhaust
gases may collect at the rear of
the vehicle and enter if the
liftgate, trunk/hatch, or rear-most
window is open.
When towing a trailer:
. Do not drive with the
liftgate, trunk/hatch,
or rear-most window open.
. Fully open the air outlets on
or under the instrument
panel.
. Also adjust the climate
control system to a setting
that brings in only outside
air. See “Climate Control
Systems” in the Index.
For information about carbon
monoxide, see Engine
Exhaust 0197.
Towing a trailer requires a certain
amount of experience. The
combination you are driving is
longer and not as responsive as the vehicle itself. Get acquainted with
the handling and braking of the rig
before setting out for the open road.
Before starting, check all trailer hitch
parts and attachments, safety
chains, electrical connectors, lamps,
tires, and mirrors. If the trailer has
electric brakes, start the
combination moving and then apply
the trailer brake controller by hand
to be sure the brakes work.
During the trip, check occasionally
to be sure that the load is secure
and the lamps and any trailer
brakes still work.
Towing with a Stability Control
System
When towing, the sound of the
stability control system might be
heard. The system is reacting to the
vehicle movement caused by the
trailer, which mainly occurs during
cornering. This is normal when
towing heavier trailers.

Cadillac XT5 Owner Manual (GMNA-Localizing-MidEast-10260744) - 2017 -
crc - 1/14/16
Index 331
Automatic (cont'd)Door Locks . . . . . . . . . . . . . . . . . . . . . 34
Forward Braking . . . . . . . . . . . . . . 229
Headlamp System . . . . . . . . . . . . 165
Transmission . . . . . . . . . . . . . . . . . 198
Transmission Fluid . . . . . . . . . . . 256
Automatic Transmission Manual Mode . . . . . . . . . . . . . . . . . 201
B
Battery . . . . . . . . . . . . . . . . . . . . . . . . . 264Exterior Lighting BatterySaver . . . . . . . . . . . . . . . . . . . . . . . 169
Jump Starting . . . . . . . . . . . . . . . . . 301
Power Protection . . . . . . . . . . . . . 169
Voltage and Charging
Messages . . . . . . . . . . . . . . . . . . . 141
Blade Replacement, Wiper . . . . . 266
Brake Parking, Electric . . . . . . . . . . . . . . 204
System Warning Light . . . . . . . . 129
Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . 263 Antilock . . . . . . . . . . . . . . . . . . . . . . . 203
Assist . . . . . . . . . . . . . . . . . . . . . . . . . 205
Fluid . . . . . . . . . . . . . . . . . . . . . . . . . . 263
System Messages . . . . . . . . . . . . 141
Braking . . . . . . . . . . . . . . . . . . . . . . . . . 182 Automatic Forward . . . . . . . . . . . 229 Braking System
Front Pedestrian (FPB) . . . . . . . 230
Break-In, New Vehicle . . . . . . . . . . 191
Bulb Replacement Back-up Lamps . . . . . . . . . . . . . . . 269
Halogen Bulbs . . . . . . . . . . . . . . . . 268
Headlamp Aiming . . . . . . . . . . . . . 268
Headlamps . . . . . . . . . . . . . . 268, 269
License Plate Lamps . . . . . . . . . 270
Buying New Tires . . . . . . . . . . . . . . . 289
C
Capacities and Specifications . . . . . . . . . . . . . . . . . 326
Carbon Monoxide Engine Exhaust . . . . . . . . . . . . . . . 197
Liftgate . . . . . . . . . . . . . . . . . . . . . . . . . 36
Winter Driving . . . . . . . . . . . . . . . . 185
Cargo Cover . . . . . . . . . . . . . . . . . . . . . . . . . 102
Management System . . . . . . . . . 104
Tie-Downs . . . . . . . . . . . . . . . . . . . . 104
Caution, Danger, and Warning . . . . 2
Center Console Storage . . . . . . . . 102
Chains, Tire . . . . . . . . . . . . . . . . . . . . 292
Charging Wireless . . . . . . . . . . . . . . . . . . . . . . .114
Charging System Light . . . . . . . . . 126 Check
Malfunction Indicator
Engine Light . . . . . . . . . . . . . . . . 127
Child Restraints Infants and Young Children . . . . . 85
Lower Anchors and Tethersfor Children . . . . . . . . . . . . . . . . . . . 90
Older Children . . . . . . . . . . . . . . . . . . 83
Securing . . . . . . . . . . . . . . . . . . . . 95, 97
Systems . . . . . . . . . . . . . . . . . . . . . . . . 87
Cigarette Lighter . . . . . . . . . . . . . . . . 115
Circuit Breakers . . . . . . . . . . . . . . . . 271
Cleaning
Exterior Care . . . . . . . . . . . . . . . . . 305
Interior Care . . . . . . . . . . . . . . . . . . 310
Climate Control Systems
Dual Automatic . . . . . . . . . . . . . . . 171
Rear . . . . . . . . . . . . . . . . . . . . . . . . . . 176
Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
Cluster, Instrument . . . . . . . . 117, 119
Compact Spare Tire . . . . . . . . . . . . 300
Compartments Storage . . . . . . . . . . . . . . . . . . . . . . . 101
Control Traction and Electronic
Stability . . . . . . . . . . . . . . . . . . . . . 206
Control of a Vehicle . . . . . . . . . . . . . 182
Convenience Net . . . . . . . . . . . . . . . 105

Cadillac XT5 Owner Manual (GMNA-Localizing-MidEast-10260744) - 2017 -
crc - 1/14/16
332 Index
Convex Mirrors . . . . . . . . . . . . . . . . . . 44
CoolantEngine . . . . . . . . . . . . . . . . . . . . . . . . 258
Engine Temperature Gauge . . 123
Engine TemperatureWarning Light . . . . . . . . . . . . . . . 132
Cooling System . . . . . . . . . . . . . . . . . 257
Engine Messages . . . . . . . . . . . . 142
Cornering Lamps . . . . . . . . . . . . . . . 167
Courtesy Lamps . . . . . . . . . . . . . . . . 168
Cover Cargo . . . . . . . . . . . . . . . . . . . . . . . . . 102
Cruise Control . . . . . . . . . . . . . . . . . . 209 Light . . . . . . . . . . . . . . . . . . . . . . . . . . 134
Messages . . . . . . . . . . . . . . . . . . . . 142
Cruise Control, Adaptive . . . . . . . . 212
Cupholders . . . . . . . . . . . . . . . . . . . . . 101
D
Danger, Warning, and Caution . . . . 2
Data Collection
Infotainment System . . . . . . . . . . 329
Data Recorders, Event . . . . . . . . . 328
Daytime Running Lamps (DRL) . . . . . . . . . . . . . . . . . . 165
Defensive Driving . . . . . . . . . . . . . . . 182
Delayed Locking . . . . . . . . . . . . . . . . . 34
Distracted Driving . . . . . . . . . . . . . . . 181
Dome Lamps . . . . . . . . . . . . . . . . . . . 168 Door
Ajar Light . . . . . . . . . . . . . . . . . . . . . 135
Ajar Messages . . . . . . . . . . . . . . . 142
Delayed Locking . . . . . . . . . . . . . . . . 34
Locks . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Power Locks . . . . . . . . . . . . . . . . . . . . 34
Drive Belt Routing, Engine . . . . . . 327
Drive Systems
All-Wheel Drive . . . . . . . . . . 202, 266
Driver Assistance Systems . . . . . 219
Driver Information Center (DIC) . . . . . . . . . . . . . . . . . . 135
Driver Mode Control . . . . . . . . . . . . 208
Driving Assistance Systems . . . . . . . . . . 226
Characteristics andTowing Tips . . . . . . . . . . . . . . . . . 239
Defensive . . . . . . . . . . . . . . . . . . . . . 182
For Better Fuel Economy . . . . . . . 24
Hill and Mountain Roads . . . . . . 185
If the Vehicle is Stuck . . . . . . . . . 186
Loss of Control . . . . . . . . . . . . . . . 183
Off-Road Recovery . . . . . . . . . . . 183
Vehicle Load Limits . . . . . . . . . . . 187
Wet Roads . . . . . . . . . . . . . . . . . . . 184
Winter . . . . . . . . . . . . . . . . . . . . . . . . 185
Dual Automatic Climate Control System . . . . . . . . . . . . . . . . 171
E
Electric Parking Brake . . . . . . . . . . 204
Electric Parking Brake Light . . . . 129
Electrical Equipment,Add-On . . . . . . . . . . . . . . . . . . . . . . . 248
Electrical System Engine Compartment FuseBlock . . . . . . . . . . . . . . . . . . . . . . . . 272
Fuses and Circuit Breakers . . . 271
Instrument Panel Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . 275
Overload . . . . . . . . . . . . . . . . . . . . . 271
Rear Compartment Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . 277
Engine Air Cleaner/Filter . . . . . . . . . . . . . 256
Check and Service EngineSoon Light . . . . . . . . . . . . . . . . . . 127
Compartment Overview . . . . . . . 252
Coolant . . . . . . . . . . . . . . . . . . . . . . . 258
Coolant Temperature
Gauge . . . . . . . . . . . . . . . . . . . . . . 123
Coolant Temperature Warning Light . . . . . . . . . . . . . . . 132
Cooling System . . . . . . . . . . . . . . . 257
Cooling System Messages . . . 142
Drive Belt Routing . . . . . . . . . . . . 327
Exhaust . . . . . . . . . . . . . . . . . . . . . . 197

Cadillac XT5 Owner Manual (GMNA-Localizing-MidEast-10260744) - 2017 -
crc - 1/14/16
336 Index
MirrorsAutomatic Dimming . . . . . . . . . . . . . 45
Automatic Dimming
Rearview . . . . . . . . . . . . . . . . . . . . . . 46
Convex . . . . . . . . . . . . . . . . . . . . . . . . . 44
Folding . . . . . . . . . . . . . . . . . . . . . . . . . 44
Heated . . . . . . . . . . . . . . . . . . . . . . . . . 45
Manual Rearview . . . . . . . . . . . . . . . 46
Power . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Tilt in Reverse . . . . . . . . . . . . . . . . . . 45
Mirrors, Interior Rearview . . . . . . . . 46
Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . 208
Driver Control . . . . . . . . . . . . . . . . . 208
Monitor System, Tire Pressure . . . . . . . . . . . . . . . . . . . . . . 283
N
Net, Convenience . . . . . . . . . . . . . . 105
New Vehicle Break-In . . . . . . . . . . . 191
O
Object Detection SystemMessages . . . . . . . . . . . . . . . . . . . . . 145
Odometer . . . . . . . . . . . . . . . . . . . . . . . 121 Trip . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
Off-Road Recovery . . . . . . . . . . . . . . . . . . . . . 183
Oil Engine . . . . . . . . . . . . . . . . . . . . . . . . 253 Oil (cont'd)
Engine Oil Life System . . . . . . . 255
Engine Oil Pressure Gauge . . . 122
Messages . . . . . . . . . . . . . . . . . . . . 143
Pressure Light . . . . . . . . . . . . . . . . 133
Older Children, Restraints . . . . . . . 83
Outlets Power . . . . . . . . . . . . . . . . . . . . . . . . .114
Overheating, Engine . . . . . . . . . . . . 260
P
Park
Shifting Into . . . . . . . . . . . . . . . . . . . 195
Shifting Out of . . . . . . . . . . . . . . . . 195
Parking Brake and P (Park)Mechanism Check . . . . . . . . . . 266
Extended . . . . . . . . . . . . . . . . . . . . . 196
Over Things That Burn . . . . . . . 196
Parking Assist . . . . . . . . . . . . . . . . . . 220
Parking or Backing Assistance Systems . . . . . . . . . . 220
Passenger Airbag Status Indicator . . . . . . . . . . . . . . . . . . . . . . 126
Passenger Compartment Air Filter . . . . . . . . . . . . . . . . . . . . . . . . . . 178
Passenger Sensing System . . . . . 77
Pedestrian Ahead Indicator . . . . . 131 Personalization
Vehicle . . . . . . . . . . . . . . . . . . . . . . . 151
Power Door Locks . . . . . . . . . . . . . . . . . . . . . 34
Mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Outlets . . . . . . . . . . . . . . . . . . . . . . . .114
Protection, Battery . . . . . . . . . . . . 169
Retained Accessory (RAP) . . . 195
Windows . . . . . . . . . . . . . . . . . . . . . . . 48
Pregnancy, Using Safety Belts . . . 70
Privacy Vehicle Data Recording . . . . . . . 328
R
Reading Lamps . . . . . . . . . . . . . . . . . 168
Rear Camera Mirror . . . . . . . . . . . . . 46
Rear Climate Control System . . . 176
Rear Seat Armrest . . . . . . . . . . . . . . . 62
Rear Seats . . . . . . . . . . . . . . . . . . . . . . 60Heated . . . . . . . . . . . . . . . . . . . . . . . . . 63
Rear Storage . . . . . . . . . . . . . . . . . . . 102
Rear Vision Camera (RVC) . . . . . 220
Rear Window Washer/Wiper . . . . 112
Rearview Mirrors . . . . . . . . . . . . . . . . 46
Automatic Dimming . . . . . . . . . . . . . 46
Reclining Seatbacks . . . . . . . . . . . . . 56
Recommended Fluids and
Lubricants . . . . . . . . . . . . . . . . . . . . . 322
