engine oil capacity CHEVROLET SUBURBAN 2008 10.G Owners Manual

When to Add Engine Oil
If the oil is below the cross-hatched area at the tip of the
dipstick, add at least one quart/liter of the recommended
oil. This section explains what kind of oil to use. For
engine oil crankcase capacity, seeCapacities and
Specifications on page 5-126.
Notice:Do not add too much oil. If the engine
has so much oil that the oil level gets above the
cross-hatched area that shows the proper operating
range, the engine could be damaged.SeeEngine Compartment
Overview on page 5-16
for the location of the
engine oil ll cap.
Be sure to add enough oil to put the level somewhere in
the proper operating range. Push the dipstick all the
way back in when you are through.
5-18

Maintenance Replacement Parts
Replacement parts identied below by name, part number, or specication can be obtained from your dealer/retailer.
Maintenance Replacement Parts
Part GM Part Number ACDelco Part Number
Engine Air Cleaner/Filter
High Capacity Filter 15908915 A3085C
Standard Filter 15908916* A3086C*
Oil Filter 89017524 PF48
Spark Plugs 12571164 41-985
Wiper Blades
Front – 21.6 inches (55.0 cm) 25877402 —
Rear – 11.8 inches (30.0 cm) 25820122 —
*15908915 (A3085C) high-capacity air cleaner lter may be substituted.
6-15
