sensor CHEVROLET TRAX 2016 1.G Owner's Manual

Chevrolet TRAX Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9159371) - 2016 - crc - 5/21/15
278 Vehicle Care
driver side front tire, passenger side
front tire, passenger side rear tire,
and driver side rear. See your
dealer for service or to purchase a
relearn tool. A TPMS relearn tool
can also be purchased. See Tire
Pressure Monitor Sensor Activation
Tool at
www.gmtoolsandequipment.com or
call 1-800-GM TOOLS
(1-800-468-6657).
There are two minutes to match the
first tire/wheel position, and
five minutes overall to match all four
tire/wheel positions. If it takes
longer, the matching process stops
and must be restarted.
The TPMS sensor matching
process is:1. Set the parking brake.
2. Turn the ignition to ON/RUN with the engine off.
3. Use the MENU button to select the Vehicle Information Menu
(Menu 2) in the Driver
Information Center (DIC). 4. Use the thumbwheel (or up and
down arrows) to scroll to the
Tire Pressure Menu Item
screen.
5. Press and hold the SET/CLR button to begin the sensor
matching process.
A message requesting
acceptance of the process may
display.
6. If requested, press the SET/ CLR button again to confirm
the selection.
The horn sounds twice to
signal the receiver is in relearn
mode and the TIRE LEARN or
TIRE LEARNING ACTIVE
message displays on the DIC
screen.
7. Start with the driver side front tire.
8. Place the relearn tool against the tire sidewall, near the valve
stem. Then press the button to
activate the TPMS sensor.
A horn chirp confirms that the sensor identification code has
been matched to this tire and
wheel position.
9. Proceed to the passenger side front tire, and repeat the
procedure in Step 8.
10. Proceed to the passenger side rear tire, and repeat the
procedure in Step 8.
11. Proceed to the driver side rear tire, and repeat the procedure
in Step 8. The horn sounds two
times to indicate the sensor
identification code has been
matched to the driver side rear
tire, and the TPMS sensor
matching process is no longer
active. The TIRE LEARN or
TIRE LEARNING ACTIVE
message on the DIC display
screen goes off.
12. Turn the ignition to LOCK/OFF.
13. Set all four tires to the recommended air pressure
level as indicated on the Tire
and Loading Information label.

Chevrolet TRAX Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9159371) - 2016 - crc - 5/21/15
284 Vehicle Care
to the generation of heat and its
ability to dissipate heat when
tested under controlled
conditions on a specified indoor
laboratory test wheel. Sustained
high temperature can cause the
material of the tire to degenerate
and reduce tire life, and
excessive temperature can lead
to sudden tire failure. The grade
C corresponds to a level of
performance which all
passenger car tires must meet
under the Federal Motor Safety
Standard No. 109. Grades B and
A represent higher levels of
performance on the laboratory
test wheel than the minimum
required by law. Warning: The
temperature grade for this tire is
established for a tire that is
properly inflated and not
overloaded. Excessive speed,
underinflation, or excessive
loading, either separately or in
combination, can cause heat
buildup and possible tire failure.Wheel Alignment and Tire
Balance
The tires and wheels were aligned
and balanced at the factory to
provide the longest tire life and best
overall performance. Adjustments to
wheel alignment and tire balancing
are not necessary on a regular
basis. Consider an alignment check
if there is unusual tire wear or the
vehicle is significantly pulling to one
side or the other. Some slight pull to
the left or right, depending on the
crown of the road and/or other road
surface variations such as troughs
or ruts, is normal. If the vehicle is
vibrating when driving on a smooth
road, the tires and wheels may need
to be rebalanced. See your dealer
for proper diagnosis.
Wheel Replacement
Replace any wheel that is bent,
cracked, or badly rusted or
corroded. If wheel nuts keep coming
loose, the wheel, wheel bolts, and
wheel nuts should be replaced.
If the wheel leaks air, replace it.Some aluminum wheels can be
repaired. See your dealer if any of
these conditions exist.
Your dealer will know the kind of
wheel that is needed.
Each new wheel should have the
same load-carrying capacity,
diameter, width, offset, and be
mounted the same way as the one it
replaces.
Replace wheels, wheel bolts, wheel
nuts, or Tire Pressure Monitor
System (TPMS) sensors with new
GM original equipment parts.
{Warning
Using the wrong replacement
wheels, wheel bolts, or wheel
nuts can be dangerous. It could
affect the braking and handling of
the vehicle. Tires can lose air,
and cause loss of control, causing
a crash. Always use the correct
wheel, wheel bolts, and wheel
nuts for replacement.

Chevrolet TRAX Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9159371) - 2016 - crc - 5/21/15
338 OnStar
.Obtain the Wi-Fi®hotspot name
or SSID and password,
if equipped.
Press
Qto connect to an
Advisor to:
. Verify account information or
update contact information.
. Get driving directions.
. Receive a Diagnostic check of
the vehicle's key operating
systems.
. Receive Roadside Assistance.
. Manage Wi-Fi Settings,
if equipped.
Press
>to get a priority connection
to an OnStar Advisor available 24/
7 to:
. Get help for an emergency.
. Be a Good Samaritan or
respond to an AMBER Alert.
. Get assistance in severe
weather or other crisis situations
and find evacuation routes.
OnStar Services
Emergency
OnStar Emergency Services require
a specific OnStar subscription plan.
With Automatic Crash Response, in
many crashes, built-in sensors can
automatically alert a specially
trained OnStar Advisor who is
immediately connected to the
vehicle to help.
Press
>for a priority connection to
an OnStar Advisor who can contact
emergency service providers, direct
them to your exact location, and
relay important information.
With OnStar Crisis Assist, specially
trained Advisors are available
24 hours a day, 7 days a week, to
provide a central point of contact,
assistance, and information during a
crisis.
With Roadside Assistance, Advisors
can locate a nearby service provider
to help with a flat tire, a battery
jump, or an empty gas tank.
Security
If equipped, OnStar provides these
services:
. With Stolen Vehicle Assistance,
OnStar Advisors can use GPS to
pinpoint the vehicle and help
authorities quickly recover it.
. With Remote Ignition Block,
if equipped, OnStar can block
the engine from being started.
. With Stolen Vehicle Slowdown,
if equipped, OnStar can work
with law enforcement to
gradually slow the vehicle down.
Navigation
OnStar navigation requires a
specific OnStar subscription plan.
Press
Qto receive Turn-by-Turn
directions or have them sent to the
vehicle’s navigation screen,
if equipped.
Turn-by-Turn Navigation
1. PressQto connect to an
Advisor.

Chevrolet TRAX Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9159371) - 2016 - crc - 5/21/15
352 Index
Lamps (cont'd)Headlamps, Front Turn
Signal, and Parking
Lamps . . . . . . . . . . . . . . . . . . . . . . 257
License Plate . . . . . . . . . . . . . . . . . 258
Malfunction Indicator . . . . . . . . . 101
On Reminder . . . . . . . . . . . . . . . . . 109
Reading . . . . . . . . . . . . . . . . . . . . . . 127
Lap-Shoulder Belt . . . . . . . . . . . . . . . 52
LATCH System
Replacing Parts after aCrash . . . . . . . . . . . . . . . . . . . . . . . . . 80
LATCH, Lower Anchors and Tethers for Children . . . . . . . . . . . . 75
Liftgate . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Lighting Illumination Control . . . . . . . . . . . 126
Lights
Airbag Readiness . . . . . . . . . . . . . 100
Antilock Brake System(ABS) Warning . . . . . . . . . . . . . . 104
Brake System Warning . . . . . . . 103
Charging System . . . . . . . . . . . . . 101
Cruise Control . . . . . . . . . . . . . . . . 109
Daytime Running Lamps (DRL) . . . . . . . . . . . . . . . . 108
Door Ajar . . . . . . . . . . . . . . . . . . . . . 109 Lights (cont'd)
Engine Coolant
Temperature Warning . . . . . . . 106
Engine Oil Pressure . . . . . . . . . . 107
Flash-to-Pass . . . . . . . . . . . . . . . . . 123
Front Fog Lamp . . . . . . . . . . . . . . 108
High-Beam On . . . . . . . . . . . . . . . . 108
High/Low Beam Changer . . . . . 123
Immobilizer . . . . . . . . . . . . . . . . . . . 108
Low Fuel Warning . . . . . . . . . . . . 107
Reduced Engine Power . . . . . . 108
Safety Belt Reminders . . . . . . . . . . 99
Service Vehicle Soon . . . . . . . . . 103
StabiliTrak
®OFF . . . . . . . . . . . . . 105
Tire Pressure . . . . . . . . . . . . . . . . . 106
Traction Control System (TCS)/StabiliTrak
®. . . . . . . . . . 106
Traction Off . . . . . . . . . . . . . . . . . . . 105
Ultrasonic Parking Sensor . . . . 105
Up-Shift . . . . . . . . . . . . . . . . . . . . . . 104
Warning, Power Steering . . . . . 105
Link Smartphone . . . . . . . . 170, 172, 174
Locks Automatic Door . . . . . . . . . . . . . . . . . 31
Delayed Locking . . . . . . . . . . . . . . . . 30
Door . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Power Door . . . . . . . . . . . . . . . . . . . . . 30 Locks (cont'd)
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Loss of Control . . . . . . . . . . . . . . . . . 195
Low Fuel Warning Light . . . . . . . . . 107
Lower Anchors and Tethers for Children (LATCH
System) . . . . . . . . . . . . . . . . . . . . . . . . 75
Lumbar Adjustment . . . . . . . . . . . . . . 43 Front Seats . . . . . . . . . . . . . . . . . . . . . 43
M
Maintenance
Records . . . . . . . . . . . . . . . . . . . . . . 319
Maintenance and Care
Additional . . . . . . . . . . . . . . . . . . . . . 314
Maintenance Schedule . . . . . . . . . 308 Recommended Fluids andLubricants . . . . . . . . . . . . . . . . . . . 317
Malfunction Indicator Lamp . . . . . 101
Manual Mode . . . . . . . . . . . . . . . . . . . 213
Manual Transmission . . . . . . . . . . . 214
Fluid . . . . . . . . . . . . . . . . . . . . . . . . . . 242
Messages Engine Oil . . . . . . . . . . . . . . . . . . . . . 111
Tire . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
Vehicle . . . . . . . . . . . . . . . . . . . . . . . . 111
Mirrors Automatic Dimming
Rearview . . . . . . . . . . . . . . . . . . . . . . 36

Chevrolet TRAX Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9159371) - 2016 - crc - 5/21/15
Index 353
Mirrors (cont'd)Convex . . . . . . . . . . . . . . . . . . . . . . . . . 35
Folding . . . . . . . . . . . . . . . . . . . . . . . . . 35
Heated . . . . . . . . . . . . . . . . . . . . . . . . . 35
Manual Rearview . . . . . . . . . . . . . . . 36
Power . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Mirrors, Interior Rearview . . . . . . . . 36
Monitor System, Tire Pressure . . . . . . . . . . . . . . . . . . . . . . 275
Multi-band Antenna . . . . . . . . . . . . . 145
N
Navigation OnStar®. . . . . . . . . . . . . . . . . . . . . . 338
Net, Convenience . . . . . . . . . . . . . . . 88
New Vehicle Break-In . . . . . . . . . . . 203
O
Odometer . . . . . . . . . . . . . . . . . . . . . . . . 98 Trip . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
Off-Road Recovery . . . . . . . . . . . . . . . . . . . . . 195
Oil Engine . . . . . . . . . . . . . . . . . . . . . . . . 238
Engine Oil Life System . . . . . . . 240
Messages . . . . . . . . . . . . . . . . . . . . . 111
Pressure Light . . . . . . . . . . . . . . . . 107
Older Children, Restraints . . . . . . . 68
Online Owner Center . . . . . . . . . . . 326 OnStar . . . . . . . . . . . . . . . . . . . . . . . . . 336
OnStar
®Additional
Information . . . . . . . . . . . . . . . . . . . . 341
OnStar
®Connections . . . . . . . . . . . 339
OnStar®Diagnostics . . . . . . . . . . . . 341
OnStar®Emergency . . . . . . . . . . . . 338
OnStar®Navigation . . . . . . . . . . . . . 338
OnStar®Overview . . . . . . . . . . . . . . 337
OnStar®Security . . . . . . . . . . . . . . . 338
Operation Infotainment System . . . . . . . . . . 136
Ordering Service Publications . . . . . . . . . . 332
Outlets Power . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Overheating, Engine . . . . . . . . . . . . 247
Overview . . . . . . . . . . . . .131, 133, 135
Owner Manual Indicator . . . . . . . . 103
P
Park
Shifting Into . . . . . . . . . . . . . . . . . . . 207
Shifting Out of . . . . . . . . . . . . . . . . 208
Parking . . . . . . . . . . . . . . . . . . . . . . . . . 209 Brake . . . . . . . . . . . . . . . . . . . . . . . . . 217
Brake and P (Park)Mechanism Check . . . . . . . . . . 254
Over Things That Burn . . . . . . . 210 Parking (cont'd)
Ultrasonic Sensor Light . . . . . . . 105
Parking Assist . . . . . . . . . . . . . . . . . . 224
Passenger Airbag Status Indicator . . . . . . . . . . . . . . . . . . . . . . 100
Passenger Compartment Air Filter . . . . . . . . . . . . . . . . . . . . . . . . . . 189
Passenger Sensing System . . . . . 63
Perchlorate Materials Requirements, California . . . . . . 232
Personalization Vehicle . . . . . . . . . . . . . . . . . . . . . . . .114
Phone Bluetooth . . . . . . . . . . . 153, 154, 162
Hands-Free . . . . . . . . . . . . . . . . . . . 168
Pictures and Movies . . . . . . . . . . . . . .175, 181, 182
Port
USB . . . . . . . . . . . . . . . . . . . . . . . . . . 147
Power Door Locks . . . . . . . . . . . . . . . . . . . . . 30
Mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Outlets . . . . . . . . . . . . . . . . . . . . . . . . . 95
Protection, Battery . . . . . . . . . . . . 128
Reduced Engine Light . . . . . . . . 108
Retained Accessory (RAP) . . . 207
Seat Adjustment . . . . . . . . . . . . . . . . 43
Steering Fluid . . . . . . . . . . . . . . . . . 248

Chevrolet TRAX Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9159371) - 2016 - crc - 5/21/15
356 Index
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . 267All-Season . . . . . . . . . . . . . . . . . . . . 267
Buying New Tires . . . . . . . . . . . . . 281
Chains . . . . . . . . . . . . . . . . . . . . . . . . 285
Changing . . . . . . . . . . . . . . . . . . . . . 287
Compact Spare . . . . . . . . . . . . . . . 291
Designations . . . . . . . . . . . . . . . . . 270
Different Size . . . . . . . . . . . . . . . . . 282
Full-Size Spare . . . . . . . . . . . . . . . 292
If a Tire Goes Flat . . . . . . . . . . . . 285
Inspection . . . . . . . . . . . . . . . . . . . . 279
Messages . . . . . . . . . . . . . . . . . . . . . 111
Pressure Light . . . . . . . . . . . . . . . . 106
Pressure Monitor Operation . . 276
Pressure Monitor System . . . . . 275
Rotation . . . . . . . . . . . . . . . . . . . . . . 279
Sidewall Labeling . . . . . . . . . . . . . 268
Terminology and Definitions . . 271
Uniform Tire Quality
Grading . . . . . . . . . . . . . . . . . . . . . 282
Wheel Alignment and Tire
Balance . . . . . . . . . . . . . . . . . . . . . 284
Wheel Replacement . . . . . . . . . . 284
When It Is Time for New Tires . . . . . . . . . . . . . . . . . . . . . . . . 280
Winter . . . . . . . . . . . . . . . . . . . . . . . . 268
Towing General Information . . . . . . . . . . 229 Towing (cont'd)
Recreational Vehicle . . . . . . . . . . 296
Vehicle . . . . . . . . . . . . . . . . . . . . . . . 295
Traction
Control System (TCS)/StabiliTrak
®Light . . . . . . . . . . . . 106
Off Light . . . . . . . . . . . . . . . . . . . . . . 105
Traction Control/Electronic Stability Control . . . . . . . . . . . . . . . 218
Trademarks and License Agreements . . . . . . . . . . . . . . . . . . . 184
Transmission Automatic . . . . . . . . . . . . . . . . . . . . . .211
Fluid, Automatic . . . . . . . . . . . . . . 241
Fluid, Manual . . . . . . . . . . . . . . . . . 242
Transportation Program, Courtesy . . . . . . . . . . . . . . . . . . . . . . 329
Triangle, Warning . . . . . . . . . . . . . . . . 89
Trip Computer . . . . . . . . . . . . . . . . . . 112
Trip Odometer . . . . . . . . . . . . . . . . . . . 98
Turn and Lane-Change
Signals . . . . . . . . . . . . . . . . . . . . . . . . 125
U
Ultrasonic Parking SensorLight . . . . . . . . . . . . . . . . . . . . . . . . . . 105
Underseat Storage . . . . . . . . . . . . . . 87
Uniform Tire Quality Grading . . . 282
Up-Shift Light . . . . . . . . . . . . . . . . . . . 104 USB Port . . . . . . . . . . . . . . . . . . . . . . . 147
Using This Manual . . . . . . . . . . . . . . . . 2
V
Vehicle
Alarm System . . . . . . . . . . . . . . . . . . 33
Canadian Owners . . . . . . . . . . . . . . . 2
Control . . . . . . . . . . . . . . . . . . . . . . . 193
Design . . . . . . . . . . . . . . . . . . . . . . . . 192
Identification Number (VIN) . . . 320
Load Limits . . . . . . . . . . . . . . . . . . . 199
Messages . . . . . . . . . . . . . . . . . . . . . 111
Personalization . . . . . . . . . . . . . . . .114
Remote Start . . . . . . . . . . . . . . . . . . . 28
Security . . . . . . . . . . . . . . . . . . . . . . . . 33
Service Soon Light . . . . . . . . . . . 103
Towing . . . . . . . . . . . . . . . . . . . . . . . . 295
Vehicle Care Tire Pressure . . . . . . . . . . . . . . . . . 273
Vehicle Data Recording and Privacy . . . . . . . . . . . . . . . . . . . . . . . . 335
Ventilation, Air . . . . . . . . . . . . . . . . . . 188
Visors . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
W
Warning Brake System Light . . . . . . . . . . . 103
