Winter Operation
Use of the air Recirculation mode during winter months is
not recommended because it may cause window fogging.
Vacation Storage
Anytime you store your vehicle, or keep it out of service
(i.e. vacation) for two weeks or more, run the air condi-
tioning system at idle for about five minutes in the fresh
air and high blower setting. This will insure adequate
system lubrication to minimize the possibility of com-
pressor damage when the system is started again.
Window Fogging
Interior fogging on the windshield can be quickly re-
moved by turning the mode selector to Defrost. The
Defrost/Floor mode can be used to maintain a clear
windshield and provide sufficient heating. If side win-
dow fogging becomes a problem increase blower speed.
Vehicle windows tend to fog on the inside in mild but
rainy or humid weather.NOTE:Recirculate without A/C should not be used for
long periods as fogging may occur.
Outside Air Intake
Make sure the air intake, located directly in front of the
windshield, is free of obstructions such as leaves. Leaves
collected in the air intake may reduce airflow, and if they
enter the plenum, they could plug the water drains. In
winter months, make sure the air intake is clear of ice,
slush, and snow.
A/C Air Filter — If Equipped
The climate control system filters outside air containing
dust, pollen and some odors. Strong odors cannot be
totally filtered out. Refer to “Maintenance Procedures” in
Section 7 of this manual for filter replacement instruc-
tions.
UNDERSTANDING YOUR INSTRUMENT PANEL 291
4

Control Setting Suggestions for Various Weather Conditions
292 UNDERSTANDING YOUR INSTRUMENT PANEL

REAR WINDOW FEATURES
Electric Rear Window Defroster
The electric Rear Window Defroster Control is
located on the climate control. Press this button to
turn on the rear window defroster and the heated side
mirrors (if equipped). An LED in the button will illumi-
nate when the rear window defroster is ON. The de-
froster automatically turns off after approximately 10
minutes of operation for the first push of the button, and
will turn off after approximately 5 minutes for the second
push of the button.
CAUTION!
To avoid damaging the electrical conductors of the
rear window defroster, do not use scrapers, sharp
instruments, or abrasive window cleaners on the
interior surface of the window.
Labels can be peeled off after soaking with warm
water.
UNDERSTANDING YOUR INSTRUMENT PANEL 293
4

STARTING AND OPERATING
CONTENTS

Starting Procedures.....................299
▫Automatic Transmission................300
▫Normal Starting (Tip Start)..............301
▫Extremely Cold Weather
(Below
20°F Or
29°C)................301
▫If Engine Fails To Start.................302
▫After Starting........................303

Engine Block Heater — If Equipped.........303

Automatic Transmission..................303▫Automatic Transmission —
General Information...................304
▫Brake/Transmission Shift Interlock System . . . 306
▫4 Speed Automatic Transmission..........307
▫5 Speed Automatic Transmission..........312

AutoStick— If Equipped................318
▫AutoStickOperation..................318

All Wheel Drive — If Equipped............319

Driving On Slippery Surfaces..............319
5

▫Acceleration.........................319
▫Traction............................320

Driving Through Water..................320
▫Flowing/Rising Water..................320
▫Shallow Standing Water.................321

Parking Brake.........................322

Brake System..........................324
▫Anti-Lock Brake System — If Equipped.....325

Power Steering........................327

Multi Displacement System (MDS) —
5.7L Engine Only.......................328

Traction Control System (TCS) — If Equipped . . 328

Brake Assist System (BAS) — If Equipped.....330
Electronic Stability Program (ESP) —
If Equipped...........................331
▫Synchronizing ESP....................333
▫ESP/BAS Malfunction Indicator And
ESP/TCS Indicator Lights...............333

Tire Safety Information...................334
▫Tire Markings........................334
▫Tire Identification Number (TIN)..........338
▫Tire Loading And Tire Pressure...........340

Tires — General Information...............344
▫Tire Pressure.........................344
▫Tire Inflation Pressures.................345
▫Radial-Ply Tires......................347
▫Compact Spare Tire — If Equipped.........348
296 STARTING AND OPERATING

▫Limited Use Spare — If Equipped.........348
▫Tire Spinning........................349
▫Tread Wear Indicators..................350
▫Life Of Tire.........................350
▫Replacement Tires.....................351
▫Alignment And Balance.................352

Self-Sealing Tires — If Equipped............353

Tire Chains...........................353

Snow Tires...........................354

Tire Rotation Recommendations............354

Tire Pressure Monitor System (TPMS) —
If Equipped...........................355
▫Base System — If Equipped..............358▫Premium System — If Equipped..........360
▫General Information...................364

Fuel Requirements......................365
▫2.7L Engine.........................365
▫3.5L And 5.7L Engines..................365
▫Reformulated Gasoline.................366
▫Gasoline/Oxygenate Blends..............366
▫MMT In Gasoline.....................367
▫Materials Added To Fuel................367
▫Fuel System Cautions..................367
▫Carbon Monoxide Warnings..............368

Adding Fuel..........................369
▫Fuel Filler Cap (Gas Cap)...............369
STARTING AND OPERATING 297
5

▫Loose Fuel Filler Cap Message............371

Vehicle Loading........................372
▫Vehicle Certification Label...............372
▫Gross Vehicle Weight Rating (GVWR).......372
▫Gross Axle Weight Rating (GAWR).........373
▫Overloading.........................373
▫Loading............................374

Trailer Towing.........................375
▫Common Towing Definitions.............375▫Trailer Hitch Classification...............379
▫Trailer Towing Weights
(Maximum Trailer Weight Ratings).........380
▫Trailer And Tongue Weight..............381
▫Towing Requirements..................383
▫Towing Tips.........................388

Recreational Towing (Behind Motorhome, Etc.) . . 389
▫Towing This Vehicle Behind Another Vehicle
(Flat Towing With All Four Wheels On The
Ground)............................389
298 STARTING AND OPERATING

STARTING PROCEDURES
Before starting your vehicle, adjust your seat, adjust the
inside and outside mirrors, fasten your seat belt, and if
present, instruct all other occupants to buckle their seat
belts.WARNING!
•Never leave children alone in a vehicle. Leaving
children in a vehicle unattended is dangerous for a
number of reasons. A child or others could be
seriously or fatally injured. Don’t leave the keys in
the ignition. A child could operate power win-
dows, other controls, or move the vehicle.
•Do not leave animals or children inside parked
vehicles in hot weather; interior heat build up may
cause serious injury or death.
•Be sure to turn off the engine and remove the key
from the ignition switch if you want to rest or
sleep in your car. Accidents can be caused by
inadvertently moving the gear selection lever. Ac-
cidents can also be caused by pressing the accel-
erator pedal. This may cause excessive heat in the
exhaust system, resulting in overheating and ve-
hicle fire, which may cause serious or fatal
injuries.
STARTING AND OPERATING 299
5

Automatic Transmission
The gear selector must be in the “N” (Neutral) or “P”
(Park) position before you can start the engine. Apply the
brakes before shifting into any driving gear.CAUTION!
Damage to the transmission may occur if the follow-
ing precautions are not observed:
•Shift into PARK only after the vehicle has come to
a complete stop.
•Shift into or out of REVERSE only after the
vehicle has come to a complete stop and the engine
is at idle speed.
•Do not shift from REVERSE, PARK, or NEUTRAL
into any forward gear when the engine is above
idle speed.
•Before shifting into any gear, make sure your foot
is firmly on the brake pedal.
300 STARTING AND OPERATING
