key CHRYSLER 300 LX 2006 Workshop Manual

Rear Power Distribution Center Fuses
Cavity Fuse Circuits
1 60 Amp
YellowIgnition Off Draw (IOD)
2 40 Amp
GreenBattery
3——
4 40 Amp
GreenBattery
5 30 Amp
PinkHeated Seats - if equipped
6 20 Amp
YellowFuel Pump
7——
8 15 Amp
BlueIgnition Switch/Occupant
Classification Module (OCM)
9 20 Amp
YellowConsole Power Outlet
10——
Cavity Fuse Circuits
11 25 Amp
C/BRKRCluster - without power
memory seat/Driver Seat
Switch - with power memory
seat/Memory Module - if
equipped
12 25 Amp
C/BRKRPassenger Seat Switch
13 25 Amp
C/BRKRDoor Modules - except base/
Driver Door Lock Switch -
base/Driver Express Power
Window Switch - if equipped/
Passenger Door Lock Switch -
base
14 10 Amp
RedAC Heater Control/Cluster/
Sentry Key Remote Keyless
Entry
15 20 Amp
YellowTrailer Tow Brake Module - if
equipped
16——
17 20 Amp
YellowCluster
330 MAINTAINING YOUR VEHICLE
ProCarManuals.com

Cavity Fuse Circuits
18 20 Amp
YellowSelectable Power Outlet
19 10 Amp
RedStop Lights
20——
21——
22——
23——
24——
25——
26——
27 10 Amp
RedAirbag/Occupant Classifica-
tion Module
28 10 Amp
RedCurtain Airbag - if equipped
29 5 Amp
OrangeAntilock Brakes Module/
Cluster/Front Control Module
(FCM)/Powertrain Control
Module (PCM)/Sentry Key
Remote Keyless Entry/Stop
LightsCavity Fuse Circuits
30 10 Amp
RedDoor Modules/Power Mirrors
- if equipped/Steering Control
Module
31——
32——
33——
34——
35 5 Amp
OrangeAmplifier - if equipped/
Antenna/Ignition Delay/
Overhead Console - if
equipped/Passenger Door
Lock & Express Power Win-
dow Switch - if equipped/
Power Mirrors - if equipped/
Rain Sensor - if equipped/
Rear Defrost
36 20 Amp
YellowHands Free Phone - if
equipped/Media System
Monitor DVD - if equipped/
Radio/Satellite Receiver - if
equipped
MAINTAINING YOUR VEHICLE 331
7
ProCarManuals.com

CAUTION!
Do not touch the new bulb with your fingers. Oil
contamination will severely shorten bulb life. If the
bulb comes in contact with an oily surface, clean the
bulb with rubbing alcohol.
Low Beam Headlight, High Beam Headlight, and
Park/Turn Light–300C
High Intensity Discharge Headlights (HID)—If
Equipped
The headlights are a type of high voltage discharge tube.
High voltage can remain in the circuit even with the
headlight switch off and the key removed.Because of
this, you should not attempt to service a headlight bulb
yourself. If a headlight bulb fails, take your vehicle to
an authorized dealer for service.
WARNING!
A transient high tension occurs at the bulb sockets of
High Intensity Discharge (HID) headlights when the
headlight switch is turned ON. It may cause serious
electrical shock or electrocution if not serviced prop-
erly. See your authorized dealer for service.
336 MAINTAINING YOUR VEHICLE
ProCarManuals.com

Ball Joints............................ 309
Battery............................... 306
Jump Starting........................ 282
Keyless Transmitter Replacement (RKE)..... 24
Location.........................283,306
Bearings.............................. 321
Belts, Drive........................... 303
Body Mechanism Lubrication.............. 309
B-Pillar Location....................... 239
Brake Assist System..................... 116
Brake, Parking......................... 223
Brake System.......................225,317
Anti-Lock (ABS)...................... 225
Fluid Check......................318,347
Hoses.............................. 317
Warning Light....................... 144
Brake/Transmission Interlock.............. 222
Break-In Recommendations, New Vehicle...... 60
Bulb Replacement...................... 334
Bulbs, Light........................... 333
Calibration, Compass.................... 155
Capacities, Fluid....................... 344Caps, Filler
Fuel............................... 257
Radiator (Coolant Pressure).............. 314
Car Washes........................... 322
Carbon Monoxide Warning.............60,256
Cargo Tie-Downs....................... 135
Cassette Tape and Player Maintenance....... 191
Catalytic Converter..................... 304
CD (Compact Disc) Player.............164,171
Cellular Phone.......................... 70
Chains, Tire........................... 251
Changing A Flat Tire.................... 275
Chart, Tire Sizing....................... 236
Child Restraint...................52,55,56,58
Child Restraint Tether Anchors............. 56
Child Safety Locks....................... 19
Clean Air Gasoline...................... 254
Climate Control........................ 192
Clock.......................162,166,172,188
Compact Disc (CD) Maintenance........... 192
Compact Spare Tire..................... 246
Compass............................. 154
Compass Calibration.................... 155
INDEX 375
10
ProCarManuals.com

On With Wipers...................103,108
Passing............................. 106
Switch..........................102,103
Time Delay.......................... 105
Washers......................... 110,310
Heated Seats........................... 92
Heater, Engine Block.................... 210
High Beam/Low Beam Select (Dimmer)
Switch............................... 106
Hitches
Trailer Towing....................... 264
Holder, Cup........................... 133
HomeLink(Garage Door Opener)
Transmitter........................... 123
Hood Release.......................... 99
Horn................................. 12
Hoses............................316,319
Ignition
Key ................................ 11
Illuminated Entry....................... 15
Immobilizer (Sentry Key).................. 12
Infant Restraint......................... 53Information Center, Vehicle............... 150
Instrument Cluster................141,142,143
Instrument Panel and Controls............. 140
Instrument Panel Lens Cleaning............ 324
Interior Appearance Care................. 323
Interior Fuses.......................... 326
Interior Lights......................... 101
Intermittent Wipers (Delay Wipers)......... 109
Introduction............................ 4
Jack Location.......................... 277
Jack Operation......................... 278
Jacking Instructions..................... 278
Jump Starting......................... 282
Key, Programming....................... 14
Key, Replacement....................... 13
Key, Sentry (Immobilizer).................. 12
Key-In Reminder........................ 12
Keyless Entry System..................... 20
Keys................................. 11
Knee Bolster........................... 39
INDEX 379
10
ProCarManuals.com

Synthetic........................... 302
Viscosity.........................301,344
Onboard Diagnostic System............295,296
Opener, Garage Door (HomeLink) ......... 123
Operator Manual (Owner’s Manual).......... 4
Overhead Console...................... 122
Overheating, Engine..................146,274
Owner’s Manual (Operator Manual).......4,369
Panic Alarm........................... 22
Park Assist System, Rear................. 114
Parking Brake......................... 223
Parking On Hill........................ 224
Passing Light.......................... 106
Pedals, Adjustable....................... 98
Personal Settings....................... 158
Pets.................................. 59
Phone, Cellular......................... 70
Phone, Hands-Free (UConnect™) ............ 70
Placard, Tire and Loading Information....... 239
Power
Brakes............................. 225
Distribution Center.................... 326Door Locks.......................... 16
Mirrors............................. 69
Outlet (Auxiliary Electrical Outlet)........ 131
Seats............................... 90
Steering............................ 228
Steering, Checking.................... 309
Sunroof............................ 128
Tilt/Telescoping Steering Column......... 112
Windows............................ 26
Pregnant Women and Seat Belts............. 38
Preparation for Jacking................... 276
Pretensioners
Seat Belts............................ 36
Programmable Electronic Features....124,127,158
Programming Transmitters
(Remote Keyless Entry)...............124,127
Radial Ply Tires........................ 246
Radiator Cap (Coolant Pressure Cap)........ 314
Radio Broadcast Signals.................. 163
Radio Operation..................164,171,192
Radio Remote Controls.................. 189
Radio, Satellite......................... 183
382 INDEX
ProCarManuals.com

Radio (Sound Systems)................164,171
Rain Sensitive Wiper System.............. 107
Rear Park Assist System.................. 114
Rear Seat, Folding....................... 94
Rear Window Defroster.................. 193
Rearview Mirrors........................ 67
Reclining Front Seats..................... 91
Recorder, Event Data..................... 51
Recreational Towing..................... 272
Refrigerant............................ 308
Reminder, Seat Belt...................... 37
Remote Keyless Entry (RKE)............... 20
Remote Sound System (Radio) Controls...... 189
Remote Trunk Release.................... 29
Replacement Tires...................... 249
Reporting Safety Defects................. 369
Restraint, Head......................... 94
Restraints, Occupant..................... 31
Rocking Vehicle When Stuck.............. 285
Rotation, Tires......................... 252
Safety Checks Inside Vehicle............... 61
Safety Checks Outside Vehicle.............. 61Safety Defects, Reporting................. 369
Safety Information, Tire.................. 234
Safety Tips............................. 60
Satellite Radio......................... 183
Satellite Radio Antenna.................. 185
Schedule, Maintenance................... 350
Seat Belt Maintenance................... 325
Seat Belt Reminder...................... 37
Seat Belts.............................. 32
Adjustable Upper Shoulder Anchorage...... 36
And Pregnant Women.................. 38
Child Restraint....................52,53,58
Extender............................ 38
Front Seat............................ 33
Operating Instructions.................. 33
Pretensioners......................... 36
Reminder........................... 147
Seats................................. 90
Easy Entry........................... 97
Heated.............................. 92
Lumbar Support....................... 92
Memory............................. 95
Power.............................. 90
INDEX 383
10
ProCarManuals.com

Rear Folding......................... 94
Reclining............................ 91
Security Alarm (Theft Alarm)............... 25
Selection of Coolant (Antifreeze).........313,346
Self-Sealing Tires....................... 229
Sentry Key (Immobilizer).................. 12
Service Assistance...................... 366
Service Contract........................ 368
Service Engine Soon Light
(Malfunction Indicator).................. 149
Service Manuals........................ 369
Setting the Clock..............162,166,172,188
Settings, Personal....................... 158
Shift Speeds........................... 210
Shoulder Belt Upper Anchorage............. 36
Side Airbag............................ 47
Signals, Turn.......................... 143
Slippery Surfaces, Driving On............. 284
SmartBeams........................... 104
Snow Chains (Tire Chains)................ 251
Snow Tires............................ 252
Spare Tire.......................246,247,277
Spark Plugs........................... 303Speed Control (Cruise Control)............. 119
Speedometer.......................... 143
Starting.............................. 208
Engine Fails to Start................... 209
Starting and Operating................... 208
Steering
Linkage............................ 309
Power...........................228,309
Tilt Column....................... 111,112
Wheel, Tilt....................... 111,112
Steering Wheel Mounted Sound System
Controls............................ 189
Storage...........................135,332
Storage, Vehicle.....................202,332
Storing Your Vehicle..................... 332
Sun Roof............................. 128
Sunglasses Storage...................... 122
Supplemental Restraint System - Airbag....... 39
System, Navigation..................... 188
Tachometer........................... 143
Telescoping Steering Column........... 111,112
Temperature Control, Automatic (ATC)....... 196
384 INDEX
ProCarManuals.com

Trailer Towing......................... 262
Cooling System Tips................... 272
Hitches............................. 264
Minimum Requirements................ 267
Trailer and Tongue Weight.............. 266
Wiring............................. 269
Trailer Towing Guide.................... 264
Trailer Weight......................... 264
Transmission.......................... 320
Automatic.....................210,215,320
Fluid.............................. 347
Shifting............................ 210
Transmitter Battery Service
(Remote Keyless Entry)................... 24
Transmitter, Garage Door Opener
(HomeLink) .......................... 123
Transmitter, Remote Keyless Entry (RKE)...... 20
Transporting Pets........................ 59
Tread Wear Indicators................... 248
Trip Odometer Reset Button............... 147
Trunk Release, Emergency................. 31
Trunk Release Remote Control.............. 29
Turn Signals........................105,143Uniform Tire Quality Grades.............. 371
Universal Transmitter.................... 123
Unleaded Gasoline...................... 253
Vanity Mirrors.......................... 70
Variance, Compass...................... 155
Vehicle Certification Label................ 260
Vehicle Identification Number (VIN).......... 6
Vehicle Loading..................240,260,261
Vehicle Modifications/Alterations............ 7
Vehicle Storage......................202,332
Vehicle Theft Alarm (Security Alarm)......... 25
Video Entertainment System
(Rear Seat Video System)................. 186
Warning Flasher, Hazard................. 274
Warnings and Cautions.................... 6
Warranty Information.................... 368
Washer, Adding Fluid..............109,110,310
Washers, Headlight..................... 110
Washers, Windshield.................... 107
Washing Vehicle........................ 322
Wheel Alignment and Balance............. 250
386 INDEX
ProCarManuals.com
