Vehicle Identification Number
Warranty Start Date
Selling Retailer Code
Moving?
²Name and address changes.............................page 5
²How to get service...................................page 15
IMPORTANT MESSAGE REGARDING YOUR
MAINTENANCE BOOK AND WARRANTY COVERAGE
Your New Vehicle Limited Warranty requires that you perform
the scheduled maintenance at the time or metrage shown in
your Owner's Manual. If you do not do so, and your vehicle
fails as a result of your failure to maintain it properly, repairs
may not be covered under your warranty.
Chrysler recommends that you use this Maintenance Service
Schedule Book to keep a written record of maintenance
performed on your vehicle.
For 24-hour Roadside Assistance
Dial 1-800-363-4869
²Give us your Vehicle Identification Number, licence plate
number and odometer reading.
²Tell us where you are and the number from which you are
calling.
See page 20 for details.
Page 2 of 68
JOBNAME: 146224AspenHEV 2009 PAGE: 1 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/ibc
INTRODUCTION
The oil change indicator system will remind you
that it is time to take your vehicle in for scheduled
maintenance. Based on engine operation condi-
tion the oil change indicator message will illumi-
nate, this means that service is required for your
vehicle. Have your vehicle serviced as soon as
possible, within the next 800 km. The oil change
indicator message will not monitor the time since
the last oil change. Change your vehicles oil if it
has been 6 months since your last oil change even
if the oil change indicator message is NOT illu-
minated. Change your engine oil more often if
you drive your vehicle off-road for an extendedperiod of time.Under no circumstances should
oil change intervals exceed 10,000 km or
6 months, whichever comes first.Your dealer
will reset the oil change indicator message after
completing the scheduled oil change. If this
scheduled oil change is performed by someone
other than your dealer the message can be reset by
referring to the steps described in the Owner's
Manual.
The performance of all scheduled service work is
required to maintain your vehicle in good operat-
ing condition. Chrysler Canada Inc. reserves the
right to deny warranty coverage if the vehicle has
not been properly maintained. While we do not
insist that such work be performed by factory
authorized retailers, we strongly recommend that
an authorized Chrysler, Jeeptor Dodge Retailer
perform this work.AT EACH STOP FOR FUEL
²Check the engine oil level about 5 minutes
after a fully warmed engine is shut off. Check-
ing the oil level while the vehicle is on level
ground will improve the accuracy of the oil
level reading. Add oil only when the level is at
or below the ADD or MIN mark.
²Check the windshield washer solvent and add
if required.
ONCE A MONTH
²Check tire pressure and look for unusual wear
or damage.
²Inspect the battery and clean and tighten the
terminals as required.
²Check the fluid levels of coolant reservoir,
brake master cylinder, power steering and
transmission and add as needed.
²Check all lights and other electrical items for
correct operation.
²Check and clean wiper blades. Replace if
required.
AT EACH OIL CHANGE
²Change the engine oil filter.
²Inspect the brake hoses and lines.
VISUAL INSPECTIONS Ð
INSPECT FOR SIGNS OF COMPONENT
DETERIORATION AND PHYSICAL DAMAGE.
MAINTENANCEScheduled maintenance must be completed to provide the best vehicle
performance and reliability. The limited warranties in the warranty booklet DO NOT COVER
repairs required due to improper maintenance. We strongly suggest you keep track of scheduled
maintenance and keep receipts or other documents. Use only recommended MopartLubricants
and genuine MopartParts. In the event that a condition arises between maintenance intervals,
please contact your retailer. AVOID PROLONGED PERIODS OF IDLING.
NOTE: WHERE TIME (MONTHS) AND METRAGE ARE INDICATED, FOLLOW THE
INTERVAL THAT OCCURS FIRST.
Page 3 of 68
JOBNAME: 146224AspenHEV 2009 PAGE: 1 SESS: 35 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/warranty
TO OUR CUSTOMERS:
This booklet explains the maintenance schedule, the limited warranties, and optional
service contracts that apply to your new vehicle. It explains exactly what's covered,
how long each warranty lasts, and what you must do to keep the warranties in force.
Please read the warranties and other information in this booklet carefully.
THIS BOOKLET SHOULD BE KEPT IN YOUR VEHICLE.
In this booklet,9Chrysler Retailer9means any authorized retailer who sells and services
Chrysler, Jeep
tor Dodge vehicles.
9Chrysler9and9Chrysler Canada9mean Chrysler Canada Inc.
9Chrysler parts9mean Mopar
tor AutoparŸ brand parts designed for Chrysler, Jeeptand Dodge
vehicles by Chrysler Motors LLC.
Chrysler and Dodge are registered trademarks of Chrysler Canada Inc., a wholly owned subsidiary of Chrysler LLC.
Jeep is a registered trademark of Chrysler LLC used under licence by Chrysler Canada Inc. Mopar is a registered
trademark of Chrysler LLC. Autopar is a registered trademark of Chrysler Canada Inc.
CONTENTS
Warranty Information...............4Your rights and responsibilities..........4
About your warranties...............6
3/60 Basic Warranty.................7
5/100 Powertrain Warranty.............8
5/100 Diesel Engine Warranty...........9
8/130 Hybrid System Warranty..........9
Corrosion Warranty.................9
Emission Warranties................10
What is not covered................12
How to get service.................15
Other things you should know..........16
Customer Assistance...............18Arbitration.....................19
5/100 Roadside Assistance Program.....20
Optional Service Contracts...........24
Maintenance Service Schedule Coupons
