Perform Maintenance At
70,000 km or 42 Months
oChange the engine oil and oil filter.Under no circumstances should the oil change
interval exceed 10 000 km or 6 months whichever occurs first.*
oRotate tires.
* Oil changes that are prompted by the oil change indicator system prior to this
schedule maintenance interval can be recorded in the oil change log section.
Perform Maintenance
At
42 Months or
70,000 km
Odometer Reading
DateRetailer Copy
Remove and attach to Repair Order
................................................................................................

JOBNAME: 146224AspenHEV 2009 PAGE: 14 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals
oChange the engine oil and oil filter.Under no circum-
stances should the oil change interval exceed 10 000 km
or 6 months whichever occurs first.*
oRotate tires.
* Oil changes that are prompted by the oil change indicator
system prior to this schedule maintenance interval can be
recorded in the oil change log section.
Perform Maintenance At
70,000 km or 42 Months
Odometer Reading
Date
Repair Order No.
CHRYSLER
RETAILERSTAMP
Signature of authorized Chrysler Canada Retailer
................................................................................................

JOBNAME: 146224AspenHEV 2009 PAGE: 15 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals
Perform Maintenance At
80,000 km or 48 Months
oChange the engine oil and oil filter.Under no circumstances should the oil change
interval exceed 10 000 km or 6 months whichever occurs first.*
oRotate tires.
oInspect the engine air filter if using your vehicle in dusty or off-road conditions;
replace if necessary.
oInspect the front suspension components, tie rod ends and boot seals; replace if
necessary.
oInspect the brake linings; replace if necessary.
oInspect the CV joints.
oInspect the exhaust system.
* Oil changes that are prompted by the oil change indicator system prior to this
schedule maintenance interval can be recorded in the oil change log section.
Perform Maintenance
At
48 Months or
80,000 km
Odometer Reading
DateRetailer Copy
Remove and attach to Repair Order
................................................................................................

JOBNAME: 146224AspenHEV 2009 PAGE: 16 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals
oChange the engine oil and oil filter.Under no circum-
stances should the oil change interval exceed 10 000 km
or 6 months whichever occurs first.*
oRotate tires.
oInspect the engine air filter if using your vehicle in dusty
or off-road conditions; replace if necessary.
oInspect the front suspension components, tie rod ends and
boot seals; replace if necessary.
oInspect the brake linings; replace if necessary.
oInspect the CV joints.
oInspect the exhaust system.
* Oil changes that are prompted by the oil change indicator
system prior to this schedule maintenance interval can be
recorded in the oil change log section.
Perform Maintenance At
80,000 km or 48 Months
Odometer Reading
Date
Repair Order No.
CHRYSLER
RETAILERSTAMP
Signature of authorized Chrysler Canada Retailer
................................................................................................

JOBNAME: 146224AspenHEV 2009 PAGE: 17 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals
Perform Maintenance At
90,000 km or 54 Months
oChange the engine oil and oil filter.Under no circumstances should the oil change
interval exceed 10 000 km or 6 months whichever occurs first.*
oRotate tires.
oInspect the front and rear axle fluid; change if using your vehicle for any of the
following: police, taxi, fleet, off-road or frequent trailer towing.
* Oil changes that are prompted by the oil change indicator system prior to this
schedule maintenance interval can be recorded in the oil change log section.
Perform Maintenance
At
54 Months or
90,000 km
Odometer Reading
DateRetailer Copy
Remove and attach to Repair Order
................................................................................................

JOBNAME: 146224AspenHEV 2009 PAGE: 18 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals
oChange the engine oil and oil filter.Under no circum-
stances should the oil change interval exceed 10 000 km
or 6 months whichever occurs first.*
oRotate tires.
oInspect the front and rear axle fluid; change if using your
vehicle for any of the following: police, taxi, fleet, off-road
or frequent trailer towing.
* Oil changes that are prompted by the oil change indicator
system prior to this schedule maintenance interval can be
recorded in the oil change log section.
Perform Maintenance At
90,000 km or 54 Months
Odometer Reading
Date
Repair Order No.
CHRYSLER
RETAILERSTAMP
Signature of authorized Chrysler Canada Retailer
................................................................................................

JOBNAME: 146224AspenHEV 2009 PAGE: 19 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals
Perform Maintenance At
100,000 km or 60 Months
oChange the engine oil and oil filter.Under no circumstances should the oil change
interval exceed 10 000 km or 6 months whichever occurs first.*
oRotate tires.
oReplace the engine air filter.
oInspect the transfer case fluid; change if using your vehicle for any of the following:
police, taxi, fleet or frequent trailer towing.
oInspect the brake linings; replace if necessary.
oFlush and replace the engine coolant at 60 months if not done at 170 000 km.
oChange the automatic transmission fluid and filter if using your vehicle for any of
the following: police, taxi, fleet or frequent trailer towing.
* Oil changes that are prompted by the oil change indicator system prior to this
schedule maintenance interval can be recorded in the oil change log section.
Perform Maintenance
At
60 Months or
100,000 km
Odometer Reading
DateRetailer Copy
Remove and attach to Repair Order
................................................................................................

JOBNAME: 146224AspenHEV 2009 PAGE: 20 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals
oChange the engine oil and oil filter.Under no circum-
stances should the oil change interval exceed 10 000 km
or 6 months whichever occurs first.*
oRotate tires.
oReplace the engine air filter.
oInspect the transfer case fluid; change if using your vehicle
for any of the following: police, taxi, fleet or frequent
trailer towing.
oInspect the brake linings; replace if necessary.
oFlush and replace the engine coolant at 60 months if not
done at 170 000 km.
oChange the automatic transmission fluid and filter if using
your vehicle for any of the following: police, taxi, fleet or
frequent trailer towing.
* Oil changes that are prompted by the oil change indicator
system prior to this schedule maintenance interval can be
recorded in the oil change log section.
Perform Maintenance At
100,000 km or 60 Months
Odometer Reading
Date
Repair Order No.
CHRYSLER
RETAILERSTAMP
Signature of authorized Chrysler Canada Retailer
................................................................................................

JOBNAME: 146224AspenHEV 2009 PAGE: 21 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals
Perform Maintenance At
110,000 km or 66 Months
oChange the engine oil and oil filter.Under no circumstances should the oil change
interval exceed 10 000 km or 6 months whichever occurs first.*
oRotate tires.
* Oil changes that are prompted by the oil change indicator system prior to this
schedule maintenance interval can be recorded in the oil change log section.
Perform Maintenance
At
66 Months or
110,000 km
Odometer Reading
DateRetailer Copy
Remove and attach to Repair Order
................................................................................................

JOBNAME: 146224AspenHEV 2009 PAGE: 22 SESS: 13 OUTPUT: Thu Jul 10 15:40:34 2008
/chrysler/chry-intl/warr-maint/146224-hghev-english/intervals
oChange the engine oil and oil filter.Under no circum-
stances should the oil change interval exceed 10 000 km
or 6 months whichever occurs first.*
oRotate tires.
* Oil changes that are prompted by the oil change indicator
system prior to this schedule maintenance interval can be
recorded in the oil change log section.
Perform Maintenance At
110,000 km or 66 Months
Odometer Reading
Date
Repair Order No.
CHRYSLER
RETAILERSTAMP
Signature of authorized Chrysler Canada Retailer
................................................................................................
