Electronic Speed Control — If Equipped......102
▫To Activate..........................102
▫To Set At A Desired Speed...............103
▫To Deactivate........................103
▫To Resume Speed.....................103
▫To Vary The Speed Setting...............103
▫Manual Transaxle.....................104
▫To Accelerate For Passing...............104
Garage Door Opener — If Equipped.........105
▫Programming The Universal Transceiver.....106
▫“Rolling Code” Programming............108
▫Canadian Programming/Gate Programming . . 109
▫Operation...........................110▫Reprogramming A Single Button..........110
▫Security............................110
Overhead Console — If Equipped...........111
▫Compass/Temperature Display...........112
▫Automatic Compass Calibration...........113
▫Compass Variance Selection..............113
▫Manual Compass Calibration.............114
▫Outside Temperature...................114
Power Sunroof — If Equipped.............114
▫Express Open Feature..................115
▫Wind Buffeting.......................117
▫Sunroof Maintenance...................117
Electrical Power Outlets..................117
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 65
3
Page 72 of 368
The UConnect™ system can be used with any Hands
Free Profile certified Bluetooth™ cellular phone. If your
cellular phone has a different profile (i.e. headset profile),
you will not be able to use any UConnect™ features.
The UConnect™ system is fully integrated into your
vehicle, including your vehicle’s stereo system. All voice
prompts as well as the other party’s voice in a conversa-
tion will be played over your vehicle’s stereo system. The
volume of the UConnect™ system can be controlled
through your normal stereo controls.
The radio display will be used for visual prompts from
the UConnect™ system such as caller ID.
Operation
Voice commands can be used in the operation of the
UConnect™ system and to navigate through the UCon-
nect™ menu structure. Voice commands should be given
after each UConnect™ system prompt. You will beprompted for a specific command and then guided
through the available options. There are two ways to give
commands to the UConnect™ system:
•You can sayDialat theReadyprompt. When
prompted for the phone number you wish to dial, say
the phone number (123 456 7890).
•Alternatively as you become familiar with the UCon-
nect™ system, you can combine the commands and
sayDial 123 456 7890.
Pairing a Cellular Phone to the UConnect™ System
To begin using your UConnect™ system, you must pair
your compatible Bluetooth™ enabled cellular phone. To
complete the registration process, you will need to refer-
ence your cellular phone owner’s manual.
•Press the ’Phone’ button to begin.
•After theReadyprompt, saySetup Phone Pairing.
72 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Page 110 of 368
The Universal Transceiver light will flash slowly and
then rapidly when the programming is successful.
NOTE:When programming such a garage door opener
or gate, unplug the device to prevent possible damage to
the garage door or gate motor.
Operation
Press and hold the desired button on the Universal
Transceiver until the garage door or other device begins
to operate. The light in the display shows that the signal
is being transmitted. The hand held transmitter may also
be used at any time.
Reprogramming A Single Button
1. Press and hold the Universal Transceiver button to be
reprogrammed. Do not release until step 4 has been
completed.2. When the indicator light begins to flash slowly (after
20 seconds) position the hand held transmitter one to
three inches away from the button to be trained.
3. Press and hold the hand held transmitter button.
4. The Universal Transceiver indicator light will begin to
flash, first slowly, then rapidly. When the indicator lights
begin to flash rapidly, release both buttons.
Security
If you sell your vehicle, be sure to erase the frequencies.
To erase all of the previously trained frequencies, hold
down both outside buttons until the indicator light
begins to flash.
110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Page 111 of 368
This device complies with part 15 of FCC rules and with
RS-210 of Industry Canada. Operation is subject to the
following conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference that may be
received including interference that may cause undesired
operation.
NOTE:Changes or modifications not expressly ap-
proved by the party responsible for compliance could
void the user’s authority to operate the equipment.
HomeLinkis a trademark owned by Johnson Controls,
Inc.OVERHEAD CONSOLE — IF EQUIPPED
This feature has a compass/temperature display and two
map lamps. The overhead console is located on the
headliner between the sun visors.
Overhead Console
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 111
3
Page 112 of 368
Compass/Temperature Display
This display provides the outside temperature and one of
eight compass readings to indicate the direction the
vehicle is facing.
WARNING!
Even if the display still reads a few degrees above
32°F ( 0°C), the road surface may be icy, particularly
in woods or on bridges. Drive carefully under such
conditions to prevent an accident and possible per-
sonal injury or property damage.
STEP Button Functions:
1. US
2. Metric
3. Off
4. Magnetic Zone Selection
5. Manual Compass Calibration
Step Button
112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Page 113 of 368
Automatic Compass Calibration
The automatic calibrating feature of the compass elimi-
nates the need to calibrate the compass due to normal
varying conditions.
Compass Variance Selection
Variance is the difference between magnetic North and
geographic North. For proper compass function, the
correct variance zone must be set. Refer to the variance
map for the correct variance zone. To check the variance
zone, the ignition switch must be on and the compass/
temperature displayed. Press and hold the STEP button
for about 5 to 10 seconds until ZONE and the number
appears in the display. The number displayed is the
variance zone used by the compass. To change the zone,
press the STEP button to scroll through numbers 1
through 15.
When the correct variance is selected release the step
button and the Compass/Temperature display will re-
turn to normal after approximately 15 seconds.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 113
3
Page 114 of 368
Manual Compass Calibration
If the compass appears erratic, inaccurate, abnormal or
the vehicle is new, you may calibrate the compass. Prior
to calibrating the compass make sure the proper zone is
selected. Refer to “Magnetic Zone Selection”.Find an
open area away from large metal objects. With the vehicle
running, press and hold the STEP button for (about 10 to
15 seconds). The display will illuminate the CAL indica-
tor. Drive slowly (about 5 mph) in 3 complete 360 circles.
The CAL indicator will turn off and the compass will be
calibrated.
NOTE:
•The compass needs to go through a manual calibration
to insure proper operation when taking vehicle deliv-
ery.
•The STEP button must be pressed for 10 to 15 seconds
to place the compass into CAL mode. Regardless of
whether the CAL indicator is already illuminated.
Outside Temperature
Because engine temperature can increase the displayed
temperature, temperature readings are not updated
when the vehicle is not moving.
If the display shows49°F (45°C) or 140°F (60°C), see
your authorized dealer for repair.
POWER SUNROOF — IF EQUIPPED
The power sunroof control is located between the sun
visors on the overhead console.
114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Page 141 of 368
The light will flash when the Traction Control System is
controlling traction.
16. Door Ajar Indicator
This vacuum fluorescent display indicator illuminates
the word “DOOR”, when a door is not completely closed.
If the door is open for more than 8 minutes, the light will
turn off.
17. Odometer/Trip Odometer
The odometer shows the total distance the vehicle has
been driven. The trip odometer shows the trip distance
since the last reset.
U.S. Federal regulations require that upon transfer of
vehicle ownership, the seller certify to the purchaser the
correct mileage that the vehicle has been driven. There-
fore, if the odometer reading changes during repair or
replacement, be sure to keep a record of the reading
before and after the service so the correct mileage can be
determined.18. Trip Indicator
This vacuum fluorescent display indicator will illuminate
when the Trip Odometer is in use.
By pushing the trip button, located next to the instrument
cluster, the odometer will toggle between total distance
and trip distance. In the trip odometer mode, holding the
trip button for more than 2 seconds will reset the trip
odometer to “0”.
19. Cruise Indicator — If Equipped
This indicator shows that the Speed Control
System is ON. (See page 102 for more informa-
tion.)
NOTE:The word “SET”will notilluminate when the
Speed Control System is on.
UNDERSTANDING YOUR INSTRUMENT PANEL 141
4
Page 143 of 368
Certain conditions such as a loose or missing gas cap,
poor fuel quality, etc. may illuminate the light after
engine start. The vehicle should be serviced if the light
stays on through several of your typical driving cycles. In
most situations the vehicle will drive normally and will
not require towing.
If the Malfunction Indicator Light flashes when the
engine is running, serious conditions may exist that
could lead to immediate loss of power or severe catalytic
converter damage. The vehicle should be serviced as
soon as possible if this occurs. (See page 266 for more
information.)
23. Front Fog Light Indicator — If Equipped
This light shows when the front fog lights are ON.
(See page 97 for more information.)24. Low Fuel Light
When the fuel level drops to about 1/8 tank, the
fuel symbol will light and a single chime will
sound. The light will remain on until fuel is added.
If the fuel level drops to approximately 1.0 gallon (3.75
Liter), the fuel symbol will flash several times and the
chime will sound several times.
25. AutoStick Gear Position— If Equipped
This vacuum fluorescent display indicator illuminates
when the gearshift lever is moved to the AutoStick
position and shows the current gear selection.
26. Fuel Door Reminder
This symbol is a reminder that the Fuel Filler Door is
located on the front passenger’s (right) side of the vehicle.
UNDERSTANDING YOUR INSTRUMENT PANEL 143
4
Page 144 of 368
27. Odometer/Trip Odometer Reset Knob
Press the knob to switch between the odometer and trip
odometer. While the trip odometer is being displayed,
press and hold this knob for a few seconds to reset the
trip odometer to zero miles/kilometers.
ELECTRONIC DIGITAL CLOCK
The clock and radio each use the display panel built into
the radio. A digital readout shows the time in hours and
minutes whenever the ignition switch is in the ON or
ACC position and the time button is pressed.
When the ignition switch is in the OFF position, or when
the radio frequency is being displayed, time keeping is
accurately maintained.
Clock Setting Procedure
1. Turn the ignition switch to the ON or ACC position
and press the time button. Using the tip of a ballpoint pen
or similar object, press either the hour (H) or minute (M)
buttons on the radio.
2. Press the H button to set hours or the M button to set
minutes. The time setting will increase each time you
press a button.
RADIO GENERAL INFORMATION
Radio Broadcast Signals
Your new radio will provide excellent reception under
most operating conditions. Like any system, however, car
radios have performance limitations, due to mobile op-
eration and natural phenomena, which might lead you to
believe your sound system is malfunctioning. To help
144 UNDERSTANDING YOUR INSTRUMENT PANEL
