Page 2 of 213
4
2c
2e7b
7a
2d
2d
7a
7b
2c
2e
4
7
1
FAMILIARISATION
Exterior
23
25
R e a r r o o f fl a p
T h e r e a r r o o f fl a p i s o n l y
c o m p a t i b l e w i t h s i d e h i n g e d d o o r s .
Changing bulbs
142
1 3 6 ,
137
Spare wheel and
repair kit
Side-hinged rear doors
Tailgate and rear screen
U s e t h e s t r a p t o c l o s e t h e r e a r
t a i l g a t e .
C l o s e b y p r e s s i n g fi r m l y
w i t h o u t s l o w i n g t h e t r a v e l o f
t h e t a i l g a t e .
22
A s y m m e t r i c a l ( 2 / 3 - 1 / 3 ) .
T h i s l o c k m a k e s i t p o s s i b l e
t o k e e p t h e l a r g e d o o r c l o s e d
a n d d r i v e w i t h t h e s m a l l d o o r
o p e n .
T h i s c o n t r o l p e r m i t s o p e n i n g
t o a p p r o x i m a t e l y 1 8 0 ° .
Parking assistance 100
Page 19 of 213
22
Accesses
TAILGATE
From inside
Emergency control
In the event of a central unlocking
operating fault, this permits unlocking
of the tailgate from the inside.
Insert a small screwdriver in the
opening, between the door and the
fl o o r . T o u n l o c k t h e l o c k , m o v e t h e
catch to the left then push the tailgate.
From outside
Locking/unlocking is by means of the
remote control.
To open, press the control below the
trim then raise the tailgate.
A pull strap is available to close the
tailgate in the high position.
Guide the closing of the tailgate to the
balance point of its travel then apply
a fi n a l p r e s s o n t h e t a i l g a t e t o c l o s e i t
fully.
Operation in the event of a
battery failure
Front and side passenger doors
In the event of a malfunction of the
battery or of the central locking, use
the lock to lock the doors mechanically.
To open the door and get out of the
vehicle, pull the interior control.
To lock the door, insert the key in
the lock, located on the edge of the
door, then turn it one eighth of a
turn .
Driver’s door
Insert the key in the lock, then turn
it to the right to lock or to the left to
unlock.
Page 20 of 213
22
Accesses
TAILGATE
From inside
Emergency control
In the event of a central unlocking
operating fault, this permits unlocking
of the tailgate from the inside.
Insert a small screwdriver in the
opening, between the door and the
fl o o r . T o u n l o c k t h e l o c k , m o v e t h e
catch to the left then push the tailgate.
From outside
Locking/unlocking is by means of the
remote control.
To open, press the control below the
trim then raise the tailgate.
A pull strap is available to close the
tailgate in the high position.
Guide the closing of the tailgate to the
balance point of its travel then apply
a fi n a l p r e s s o n t h e t a i l g a t e t o c l o s e i t
fully.
Operation in the event of a
battery failure
Front and side passenger doors
In the event of a malfunction of the
battery or of the central locking, use
the lock to lock the doors mechanically.
To open the door and get out of the
vehicle, pull the interior control.
To lock the door, insert the key in
the lock, located on the edge of the
door, then turn it one eighth of a
turn .
Driver’s door
Insert the key in the lock, then turn
it to the right to lock or to the left to
unlock.
Page 21 of 213
23
Accesses
READY TO GO
2
Tailgate screen
The opening rear screen allows you to
access the rear of the vehicle directly,
without having to open the tailgate.
Opening
After unlocking the vehicle using the
remote control or the key, press the
control and raise the rear screen to
open it.
Closing
Close the rear screen by pressing
the centre of the glass until it is fully
closed.
HINGED REAR DOORS
From outside
To open, pull the handle towards you. Pull the lever to open the right-hand
door.
To close, start with the right-hand door
then close the left-hand door.
W i t h t h e r o o f r e a r fl a p , t h e r e a r b u m p e r
has been strengthened to serve as a
footrest on accessing the vehicle.
The tailgate and tailgate screen cannot
both be open at the same time, to
prevent damage to the glass and the
screen itself. The hinged rear doors are
asymmetrical (2/3 - 1/3), with the
smaller door on the right.
T h e y a r e fi t t e d w i t h a c e n t r a l l o c k .
Page 22 of 213
23
Accesses
READY TO GO
2
Tailgate screen
The opening rear screen allows you to
access the rear of the vehicle directly,
without having to open the tailgate.
Opening
After unlocking the vehicle using the
remote control or the key, press the
control and raise the rear screen to
open it.
Closing
Close the rear screen by pressing
the centre of the glass until it is fully
closed.
HINGED REAR DOORS
From outside
To open, pull the handle towards you. Pull the lever to open the right-hand
door.
To close, start with the right-hand door
then close the left-hand door.
W i t h t h e r o o f r e a r fl a p , t h e r e a r b u m p e r
has been strengthened to serve as a
footrest on accessing the vehicle.
The tailgate and tailgate screen cannot
both be open at the same time, to
prevent damage to the glass and the
screen itself. The hinged rear doors are
asymmetrical (2/3 - 1/3), with the
smaller door on the right.
T h e y a r e fi t t e d w i t h a c e n t r a l l o c k .
Page 128 of 213
123
ACCESSORIES
5
Equipment
OTHER ACCESSORIES
These accessories and parts, having
been tested and approved for reliability
and safety, are all adapted to your
vehicle. A wide range of recommended
accessories and original parts is
offered.
A further range is also available,
structured around comfort, leisure and
maintenance:
A n t i - t h e f t a l a r m , w i n d o w e n g r a v i n g ,
fi r s t a i d k i t , h i g h v i s i b i l i t y j a c k e t , r e a r
parking assistance, warning triangle, ...
Seat covers compatible with air bags
for the front seats, bench seat, rubber
mats, carpet mats, snow chains, blinds,
tailgate bicycle carrier, ...
To prevent the mat from becoming
caught under the pedals:
- e n s u r e t h a t t h e m a t a n d i t s fi x i n g s are positioned correctly,
- n e v e r fi t o n e m a t o n t o p o f a n o t h e r . A u d i o e q u i p m e n t , h a n d s - f r e e k i t ,
speakers, CD changer, navigation, ...
Regardless of the audio and telematic
e q u i p m e n t o f f e r e d o n t h e m a r k e t , t h e
technical constraints linked with the
fi t t i n g o f e q u i p m e n t o f t h e s e p r o d u c t
groups mean that the special features
o f t h e e q u i p m e n t a n d i t s c o m p a t i b i l i t y
with the capacities of your vehicle's
s t a n d a r d e q u i p m e n t m u s t b e t a k e n
into account. Please ask a CITROËN
dealer for further information before
fi t t i n g s u c h e q u i p m e n t .
Maximum weights on bars
- M o d u t o p T r a n s v e r s e b a r s o n
longitudinal bars: 75 Kg (these
bars are not compatible with the
M o d u t o p r o o f ) . Installing radiocommunication
transmitters
You are advised to contact a CITROËN
dealer before installing accessory
radiocommunication transmitters with
external aerial on your vehicle.
The CITROËN network will inform you
o f t h e c h a r a c t e r i s t i c s ( f r e q u e n c y b a n d ,
maximum output power, aerial position,
s p e c i fi c c o n d i t i o n s o f i n s t a l l a t i o n ) o f
t h e t r a n s m i t t e r s w h i c h c a n b e fi t t e d ,
i n a c c o r d a n c e w i t h t h e M o t o r V e h i c l e
Electromagnetic Compatibility Directive
(2004/104/EC).
F r o n t m u d fl a p s , r e a r m u d fl a p s ,
15/17 inch alloy wheels, wheelarch
trim, leather steering wheel, ...
Screenwash, interior and exterior
cleaning and maintenance products,
spare bulbs, ...
Page 152 of 213
146
Changing a bulb
NUMBER PLATE LIGHTS
- Unscrew the two nuts.
- P u s h t h e p i n s .
- If necessary, disconnect the connector to remove the light.
- C h a n g e t h e b u l b .
With tailgate
- M o v e a s i d e t h e p l a s t i c l e n s u s i n g a
screwdriver.
- C h a n g e t h e b u l b .
- R e p l a c e t h e p l a s t i c l e n s a n d p r e s s on it.
THIRD BRAKE LIGHT
Type A , W16W - 16W
With hinged doors
- U n c l i p t h e i n t e r i o r t r i m .
- Disconnect the connector by moving aside its tab.
- T u r n t h e b u l b h o l d e r a q u a r t e r t u r n a n t i c l o c k w i s e .
- C h a n g e t h e b u l b .
- P u t t h e b u l b h o l d e r b a c k i n p l a c e and reconnect the connector.
- P u t t h e t r i m b a c k i n p l a c e .
Type A , W5W - 5W
Page 161 of 213
156
Dimensions
REAR DOORS (mm)
M Max threshold with 205/65 R15 tyre and tailgate trim 582
Hinged doors Tailgate
Small Large
N Useful opening height (under panel) 1 118 1 313
O Width 495 543 1 582
Page 162 of 213
157
Dimensions
TECHNICAL DATA
8
SLIDING SIDE DOORS (mm)
P Useful height 1 009
Q Useful width 650
- Height under raised tailgate 1 892
