lights Citroen C4 2011 2.G Owner's Manual

4
EXTERIOR

Parking sensors
This system measures the size of a
free parking space between two ve-
hicles or obstacles.



170

Stop & Start system

This system puts the engine temporarily
on standby during stops in the traffi c (traf-
fi c lights, traffi c jams, etc...). The engine
restarts automatically as soon as you want
to move off. The Stop & Start system al-
lows reductions of fuel consumption and
exhaust emissions, as well as noise levels
when stationary
.



158

Welcome lighting
This additional exterior and interior light-
ing, controlled remotely, makes your
approach to the vehicle easier when the
light is poor.



100, 108


Directional lighting
This lighting automatically provides
additional visibility when cornering.



101

Cornering lighting
At low speed, this lighting automati-
cally provides additional visibility
when cornering, at junctions, when
parking... making use of the corre-
sponding front foglamp.



102

1
41

Passenger's
airbag system
fi xed in the
seat belt and
passenger's front
airbag warning
lamps display. The control switch, located
in the glove box, has been
placed in the "ON"
position.
The passenger's front airbag
is activated.
In this case, do not install a
"rear facing" child seat. Move the control switch to the "OFF"

position to deactivate the passenger's
front airbag.
In this case, you can install a "rear
facing" child seat.

Warning lamp



is on



Cause



Action/Observations




Stop & Start


fi xed. The Stop & Start system has
put the engine in STOP mode
at a vehicle stop (traffi c lights,
traffi c jam, or other...). The warning lamp goes off and the
engine restarts automatically in START
mode, as soon as you want to move off.

fl ashes for a few
seconds, then
goes off. STOP mode is temporarily
unavailable.
or
START mode is invoked
automatically. Refer to "Driving - § Stop & Start" for
special cases with STOP mode and
START mode.


Parking space
sensors


fi xed. The parking space sensors
function is selected. To start measurement, operate the direction
indicator on the side of the space to be
measured, and do not exceed 12 mph
(20 km/h). A message is displayed once the
measurement has been completed.

Automatic
wiping


fi xed. The wiper control is pushed
downwards.
Automatic front wiping is activated.


Lighting
rheostat


fi xed. The lighting rheostat is
making an adjustment. You can adjust the level of illumination of
the instruments between 1 and 16.

2
MULTIFUNCTION SCREENS
54

Choice of language
Once this menu has been selected, you
can choose the language used by the
display from a pre-defi ned list.
For safety reasons, confi gura-
tion of the multifunction screen
by the driver must only be done
when stationary.
)

Press the "
" or "
" buttons to set the
value required (15, 30 or 60 seconds),
then press the "OK"
button to confi rm.


)
Press the "
" or "
" buttons, then
the "OK"
button to select the "OK"

box and confi rm or press the "ESC"

button to cancel.
For example: setting of the duration of
the "follow-me-home" lighting


)
Press the "
" or "
" buttons, to se-
lect the "Defi ne the vehicle param-
eters" menu, then the " OK
" button.

)
Press the "
" or "
" buttons to
select the "Interior lighting" line,
then the "OK"
button; then follow
the same procedure to select the
"Follow-me-home headlamps" line.
Display confi guration
This menu gives access to the following
settings:


- "Choice of units",

- "Date and time adjustment",

- "Display parameters",

- "Brightness".


Choice of sounds
This menu allows you to choose a fam-
ily of polyphonic sounds from the four
available. These sounds are grouped
together in a family and are adapted
to suit the situation and context (alert,
confi rmation, rejection, direction indica-
tors, lighting left on, key in ignition...).


- "Driving assistance":


●
"Parking brake automatic" (Auto-
matic electric parking brake; see
the "Driving" section),

●
"Rear wipe in reverse gear" (Rear
wiper coupled to reverse gear;
see the "Visibility" section),

●
"Speeds memorised" (Memoris-
ing speeds; see the "Driving" sec-
tion).



- "Vehicle lighting" (see the "Visibility"
section):


●
"Directional headlamps" (Main/
additional directional lighting),

●
"Daytime lights" (Daytime running
lamps).



- "Interior lighting" (see the "Visibility"
section:


●
"Follow-me-home headlamps"
(Automatic operation of headlamps
after switching off the ignition),

●
"Welcome lighting" (Exterior and
interior welcome lighting).

2
MULTIFUNCTION SCREENS
57

Vehicle parameters
This menu is used to activate or deac-
tivate certain driving and comfort sys-
tems, classifi ed in different categories:


- "Access to the vehicle" (see
"Access" section):


●
"Plip action" (Selective unlocking
of the driver's door),

●
"Unlocking only boot" (Selective
unlocking of the boot).



- "Driving assistance":


●
"Parking brake automatic" (Auto-
matic electric parking brake; see
"Driving" section),

●
"Rear wipe in reverse gear" (Rear
wiper coupled to reverse gear;
see "Visibility" section),

●
"Speeds memorised" (Memoris-
ing speeds; see "Driving" sec-
tion).



- "Vehicle lighting" (see "Visibility"
section):


●
"Directional headlamps" (Main/
additional directional lighting),

●
"Daytime lights" (Daytime running
lamps).



- "Interior lighting" (see "Visibility"
section):


●
"Follow-me-home " (Automatic
timed operation of headlamps),

●
"Welcome lighting" (Interior/exte-
rior welcome lighting).


Display confi guration
This menu is used to confi gure:


- the display language of the central
colour screen, from a pre-defi ned
list,

- the units: temperature (°Celsius ou
°Fahrenheit) and fuel consumption
(l/100 km, mpg or km/l),

- the colour schemes of the central
screen.


Choice of sounds
This menu allows you to choose a fam-
ily of polyphonic sounds from the four
available. These sounds are grouped
together in a family and are adapted
to suit the situation and context (alert,
confi rmation, rejection, direction indica-
tors, lighting left on, key in ignition...).

9
DRIVING
158
STOP & START
The Stop & Start system puts the en-
gine temporarily on standby - STOP
mode - during stops in the traffi c (red
lights, traffi c jams, or other...). The en-
gine restarts automatically - START
mode - as soon as you want to move
off. The restart takes place instantly,
quickly and silently.
Perfect for urban use, the Stop & Start
system reduces fuel consumption and
exhaust emissions as well as the noise
level when stationary.

Operation


Going into engine STOP mode
The "ECO"
warning lamp comes
on in the instrument panel and the
engine goes into standby:


- with a manual gearbox
, at speeds
below 12 mph (20 km/h), when you
put the gear lever into neutral and
release the clutch pedal, If your vehicle is fi tted with
the system, a time counter
calculates the sum of the pe-
riods in STOP mode during a
journey. It resets itself to zero every time
the ignition is switched on with the key.

- with the 6-speed electronic gear-
box system
, at a speed below
5 mph (8 km/h), when you press the
brake pedal or put the gear lever
into position N
. With the automatic gearbox
system, for your comfort dur-
ing parking maoeuvres, STOP
mode is not available for a few
seconds after coming out of re-
verse gear.
STOP mode does not affect the
functionality of the vehicle, such
as braking, power steering, for
example.
Special cases: STOP mode
unavailable
STOP mode is not invoked when:


- the driver's door is open,

- the driver's seat belt is not fastened,

- the vehicle has not exceeded 6 mph
(10 km/h) since the last engine start
using the key,

- the electric parking brake is applied
or being applied,

- the engine is needed to maintain a
comfortable temperature in the pas-
senger compartment,

- demisting is active,

- some special conditions (battery
charge, engine temperature, brak-
ing assistance, ambient tempera-
ture...) where the engine is needed
to assure control of a system.
In this case, the "ECO"
warning
lamp fl ashes for a few seconds,
then goes off. Never refuel with the engine in
STOP mode; you must switch off
the ignition with the key.

This operation is perfectly normal.

306
09 SCREEN MENU MAP





Personalisation-configuration
Defi ne the vehicle parameters
Access to the vehicle

Plip action
Drivin
g position setting

Unlocking boot only
Driving assistance

Parking brake automatic

Rear wipe in reverse gear
S
peeds memorised
Vehicle lighting

Directional headlamps
Da
ytime lights
Interior li
ghting
Follow-me-home headlamps
Welcome li
ghting
Choice of language Displa
y confi guration
Choice of units
Date and time adjustment
Display parameters
Brightness
Choice of sounds
1
2
3
3
3
2
3
3
3
2
3
3
2
3
3
1
1
2
2
2
2
1
