Downloaded from www.Manualslib.com manuals search engine ENGINE
87
Setting the valve timing.
- Turn the crankshaft to bring camshaft to its pegging point.
- Peg the crankshaft, using tool[3].
- Peg the camshaft, using tool[5].
Untighten :
- The three screws (25).
- The screw (23)of the tensioner roller (24).
- Remove the timing belt (26).
Checks.
IMPERATIVE : just prior to refitting, carry out the checks below:
Check :
- That the rollers (24) and (27)and the water pump(22) are turning freely.
(Without play and without tightness).
- Absence of traces of oil leaks (Crankshaft and camshaft sealing rings).
- Absence of leaks of coolant fluid (Water pump).
NOTE :Replace defective components(If necessary).
CHECKING AND SETTING THE VALVE TIMING
Engine : 4HX
B1EP15ADB1BP298C
Page 146 of 259
Downloaded from www.Manualslib.com manuals search engine FEATURES OF MULTIPOINT INJECTION SYSTEM
Summary
1)Accelerator pedal position sensor
(2)Denox catalyser downstream oxygen sensor
(3)Denox catalyser
(4)Downstream exhaust gas temperature sensor
(5)3-function precatalyser
(6)Precatalyser upstream oxygen sensor
(7) Upstream exhaust gas temperature sensor
(8)Petrol pressure regulator
(9)Petrol high pressure pump
(10)Knock sensor
(11) EGR electrovalve
(12)Canister purge electrovalve
(13)Motorised butterfly housing
(14)Canister reservoir
(15)Fuel pump and tank assembly
(16) Fuel tank
(17)Inlet air temperature sensor
(18) Inlet air pressure sensor(19)Engine coolant temperature sensor
(20) Sparking plug
(21) Ignition coil block
(22) High pressure injector
(23) Engine oil temperature sensor
(24)Engine speed sensor
(25)Inlet camshaft dephaser electrovalve
(26) Camshaft position sensor
(27)Petrol high pressure sensor
(28) Power steering pressure sensor
(29) Aircon fluid pressure sensor
(30)Cooling fan unit
(31)ABS block
(32)Clutch pedal sensor
(33)Brake pedal sensor
(34)Air conditioning ECU
(35) Engine management ECU
(36)Built-in systems interface BSI
(37)Rev counter
(38) Coded immobiliser
(39)Vehicle cruise control
(40) Diagnostic connector
B1HP1C6P
143
INJECTION
Page 200 of 259
Downloaded from www.Manualslib.com manuals search engine 197
RECOMMENDATIONS - PRECAUTIONS (AL 4 AUTOMATIC GEARBOX)
Engines : 6FZ - RFN - RHZ
Procedure to be followed prior to carrying out repairs on AL4 autoactive gearbox
CLUTCH
GEARBOX
DRIVESHAFTS
If a gearbox malfunction occurs, there are two possible configurations
depending on the seriousness of the fault :
- Gearbox in back-up mode with a replacement programme of
(the fault values are taken in substitution).
- Gearbox in back-up mode with an emergency programme
(3rd hydraulic).
WARNING : In the emergency programme, an impact is felt when
changing P/R, N/RandN/D.
Réception client.
Discuss with the customer, to find out all the malfunction symptoms..
Oil quality – Oil level.
If the gearbox has suffered a serious fault resulting in a malfunction or
the destruction of a clutch, the oil will overheat and become
contaminated with impurities : the oil is said to be «burnt».
This is characterised by a black colour and the presence of an
unpleasant smell.
ESSENTIAL : The gearbox must be replaced.Oil quality.
See corresponding operation.
An excessive oil level can result in the following consequences :
- Excessive heating of the oil.
- Oil leaks.
An insufficent level causes the destruction of the gearbox.
Top up the level of oil in the gearbox (if necessary).
Check using a diagnostic tool.
Read the fault codes (engine and gearbox).
Absence de codes défauts.
Carry out parameter measures, actuator tests and a road test.
Presence of fault codes.
Carry out the necessary repairs.
Delete the fault codes.
Carry out a road test to check the repair and, if need be, modify the
gearbox ECU parameters (this is essential after an initialisation of the ECU).
Page 206 of 259
Downloaded from www.Manualslib.com manuals search engine 203
CLUTCH
GEARBOX
DRIVESHAFTS
4 HP 20 GEARBOX CONTROLS
Engines : XFX - 4HX
Selection control (continued).
In positionM, selection is by an electronic sensor located close to the gear lever.
The variation of flux necessary to the movement of the sensor cells is obtained by a magnet located on
the lever itself. This enables the change of status. The information is transmitted to the gearbox ECU.
Two switches placed on the gear control gate permit the driver to choose one of the following three
driving programmes:
- Normal :The normal programme operates in the absence of the other two (Eco law, autoadaptative mode).
- Sport :Permits a more dynamic, sporty performance.
- Snow :Facilitates starting and adhesion on slippery surfaces.
To return to the normal programme, press a second time on the sport switch or snow switch.
Only when the selector is in position(P)or (N)can the engine be started.
(1)Control linkage with ball-joint.
(2)Automatic adjustment(Push-button pressed in to lock the control adjustment, springs out for the
adjustment to be made) «c» Push-button locking clip in pressed-in position.
(3) Cable sleeve stop.
The automatic gearbox is controlled by cable.
B3CP3DLC
Page 228 of 259
Downloaded from www.Manualslib.com manuals search engine 225
BRAKES
BRAKE SPECIFICATIONS
Braking system specifications
- Braking circuit at «X».
- Front brakes with ventilated discs.
- Rear brakes with non-ventilated discs.
- Handbrake lever controlling cables acting on the
front wheels.
- The compensator and main brake limiter functions
are assured by the ABS EBD system fitted as
standard at the factory on all versions.
NOTE : EBD = Electronic Brakeforce Distribution Braking circuit
B3FP12WD
Page 230 of 259
Downloaded from www.Manualslib.com manuals search engine BRAKE SPECIFICATIONS
(7) Hydraulic block
Elements
Electronic ABS MK.6047way connector.
ECU7 ITT - A Alone on the hydraulic block.
BASR MK.60 Changing only the ECU is prohibited.
2 way black connector.
Front wheel The sensors are inductive-type.
5 ITT - A 96 332 952 80 Mounted on the pivot.
sensor
Non-adjustable airgap :0.2 à 1.5 mm.
Tightening torque : 0.8 ± 0.2 m.daN
2way black connector.
Rear wheel The sensors are inductive-type.
sensor96 332 954 80 Mounted on the brake caliper support.
Non-adjustable airgap :0.15 à 1.6 mm.
Tightening torque : 0.8 ± 0.2 m.daN
Hub
4 SNRHub equipped with a bearing with an integral
bearing magnetic wheel (48pairs of poles).
ABS MK.60
Hydraulic 96 371 711 80 Installed on the front LH wheelarch.
block7 TEVES
BASK MK.604adjustment channels.
96 371 712 80 Ref. SupplierPart No.
Observations
B3FP12XC
BRAKES
227
Page 234 of 259
Downloaded from www.Manualslib.com manuals search engine B3FP13BCAB3FP13CC
BLEEDING AND FILLING THE BRAKING SYSTEM
Bleeding, filling (continued).
Filling the braking system.
WARNING : Use only those hydraulic fluids that are approved and recommended.
- Fill the brake fluid reservoir (1).
Bleeding the braking system.
WARNING: During the bleeding operation, take care to maintain the level of brake fluid in the reser-
voir and to top it up, using only brake fluid that is clean and clear.
Bleeding the primary circuit.
WARNING: The ABS should not be active during the bleeding operation.
- Front brake caliper: Bleed screw(5).
- Rear brake caliper: Bleed screw (6).
- Bleed each wheel cylinder, proceeding in the following order :
Front LH wheel.
Front RH wheel.
Rear LH wheel.
Rear RH wheel.BRAKES
231
Page 236 of 259
Downloaded from www.Manualslib.com manuals search engine 233
BRAKES
BLEEDING AND FILLING THE BRAKING SYSTEM
Bleeding, filling (continued).
Bleeding the secondary circuit.
NOTE : The bleeding apparatus is connected on the brake reservoir.
- Use LEXIAorPROXIAdiagnostic tools.
Select the menu corresponding to the vehicle :
- ABS menu.
- ESP menu.
- Follow the instructions on the diagnostic tool.
- At the end of the bleeding process, check and top up, if necessary, the brake fluid level.
- Check that the brake pedal travel has not been lengthened, otherwise repeat the bleeding procedure.
- Remove the tools.
