Rear seats
 Move the corresponding front seat for ward if necessary.  Position the seat belt between the outer and centre head restraints to avoid trapping the belt when repositioning the seat backrest.  Place the head restraints in the low position.
Folding the backrest
 Pull control 1 for wards to release the seat back 2 .  Fold the seat back 2 on to the cushion.
 Straighten the seat back 2 and secure it.  Check that the red indicator, located next to the control 1 , is no longer visible.  Put the seat belt back in place on the side of the seat backrest.
Repositioning the seat backrest
When repositioning the seat backrest, take care not to trap the seat belts.

Access
System which provides full automatic locking or unlocking of the doors and the boot while driving. You can activate or deactivate this function.
Anti-intrusion security
Locking
When the speed exceeds 6 mph (10 km/h), the doors and the boot lock automatically.
Unlocking
 Press button A to unlock the doors and the boot. Above 6 mph (10 km/h), this locking is temporary.
If one of the doors is open, the automatic central locking does not take place. If the boot is open, the automatic central locking of the doors is active.
Activation
 Press button A until an audible signal is heard and a message appears in the multifunction screen.
Deactivation
 Press button A again until an audible signal is heard and a message appears in the multifunction screen.

1. Driver's electric window control.2. Passenger's electric window control.
- manual mode Press or pull the control gently. The window stops when the control is released. - automatic mode Press or pull the control firmly. The window opens or closes fully when the control is released.  Pressing the control again stops the movement of the window.
The electric window controls remain operational for approximately 45 seconds after the ignition is switched off or until the vehicle is locked after a door is opened. If the passenger 's window cannot be operated from the driver's door control panel, carry out the operation from the passenger's door control panel, and vice versa.
Electric windows Fitted with a safety anti-pinch system.
One-touch electric windows
There are two options:
After approximately ten consecutive complete opening/closing movements
of the window, a protection function is activated which only authorises closing of the window to prevent damage to the
electric window motor. Once the window is closed, the controls will become available again after
approximately 40 minutes.

Fittings
Mats
Removable carpet protection.
When fitting the mat for the first time, on the driver's side use only the fixings provided in the wallet attached. The other mats are simply placed on the carpet.
Fitting Removal
To remove the mat on the driver's side:  move the seat as far back as possible,
 unclip the fixings,  remove the mat.
Refitting
To refit the mat on the driver's side:  position the mat correctly,  refit the fixings by pressing,  check that the mat is secured correctly.
To avoid any risk of jamming of the pedals: - only use mats which are suited to the fixings already present in the vehicle; these fixings must be used, - never fit one mat on top of another. The use of mats not approved by
CITROËN may inter fere with access to the pedals and hinder the operation of the cruise control/speed limiter.

Fittings
Mats
Removable carpet protection.
When fitting the mat for the first time, on the driver's side use only the fixings provided in the wallet attached. The other mats are simply placed on the carpet.
Fitting Removal
To remove the mat on the driver's side:  move the seat as far back as possible,
 unclip the fixings,  remove the mat.
Refitting
To refit the mat on the driver's side:  position the mat correctly,  refit the fixings by pressing,  check that the mat is secured correctly.
To avoid any risk of jamming of the pedals: - only use mats which are suited to the fixings already present in the vehicle; these fixings must be used, - never fit one mat on top of another. The use of mats not approved by
CITROËN may inter fere with access to the pedals and hinder the operation of the cruise control/speed limiter.

153Fittings
To remove the shelf:  unhook the two cords,  raise the shelf slightly, then remove it.
There are several options for storing the shelf: - either upright behind the front seats, - or flat at the base of the boot.
Rear parcel shelf
The hooks can be used to secure shopping bags.
Hooks
Access to the storage box
An additional hook under the shelf is used to hold up the boot floor using its cord, to facilitate access to the tools
and spare wheel or the temporary puncture repair kit...

Passenger airbag OFF
Child seats recommended by
CITROËN
CITROËN offers a complete range of recommended child seats which are secured using a three point seat belt :
Group 0+: from bir th to 13 kgGroups 1, 2 and 3: from 9 to 36 kg

L1"RÖMER Baby-Safe Plus" Installed in the rear wards-facing position.
L2"KIDDY Life" The use of the restraining cushion is compulsory for carrying young children (from 9 to 18 kg).
Groups 2 and 3: from 15 to 36 kg

L3"RECARO Star t''
L4"KLIPPAN Optima" From the age of 6 years (approximately 22 kg), the booster is used on its own.

L5"RÖMER KIDFIX" Can be fitted to the vehicle's ISOFIX mountings. The child is restrained by the seat belt.

Passenger airbag OFF
Child seats recommended by
CITROËN
CITROËN offers a complete range of recommended child seats which are secured using a three point seat belt :
Group 0+: from bir th to 13 kgGroups 1, 2 and 3: from 9 to 36 kg

L1"RÖMER Baby-Safe Plus" Installed in the rear wards-facing position.
L2"KIDDY Life" The use of the restraining cushion is compulsory for carrying young children (from 9 to 18 kg).
Groups 2 and 3: from 15 to 36 kg

L3"RECARO Star t''
L4"KLIPPAN Optima" From the age of 6 years (approximately 22 kg), the booster is used on its own.

L5"RÖMER KIDFIX" Can be fitted to the vehicle's ISOFIX mountings. The child is restrained by the seat belt.

161Child safety
Locations for child seats secured using the seat belt
In accordance with European regulations, this table indicates the options for installing child seats secured using the seat belt and universally approved (a) in relation to the weight of the child and the seat in the vehicle.
Seat
Weight of the child/ indicative age
Less than 13 kg (groups 0 (b) and 0+) Up to ≈ 1 year
From 9 to 18 kg(group 1) From 1 to ≈ 3 years
From 15 to 25 kg(group 2) From 3 to ≈ 6 years
From 22 to 36 kg (group 3) From 6 to ≈ 10 years
Front passenger seat (c)
- fixed U(R1)U(R1)U(R1)U(R1)
- height adjustable U(R2)U(R2)U(R2)U(R2)
Outer rear seats UUUU
Centre rear seat XXXX
(a) Universal child seat: child seat which can be i nstalled in all vehicles using the seat belt. (b) Group 0: from bir th to 10 kg. Infant car seats and "car cots" cannot be installed on the front passenger seat. (c) Consult the legislation in force in your country before installing your child on this seat. U : seat suitable for the installation of a child seat secured using the seat belt and universally approv ed "rear facing" and/or "for ward facing". U(R1) : identical to U , with the vehicle's seat backrest inclined fully for wards. U(R2) : identical to U , with the vehicle's seat adjusted to the highest p osition. X : seating position not suitable for installing a child seat for the weight group indicated.

Advice on child seats
The incorrect installation of a child seat in a vehicle compromises the child's protection in the event of an accident. Remember to fasten the seat belts or the child seat harnesses keeping the slack relative to the child's body to a minimum, even for shor t journeys. When installing a child seat using the seat belt, ensure that the seat belt is tightened correctly on the child seat and that it secures the child seat firmly on the seat of your vehicle. Move the seat for wards if necessary. For optimum installation of the "for wards-facing" child seat, ensure that the back of the child seat is in contact with the back of the vehicle's seat and that the head restraint does not cause any discomfor t. If the head restraint has to be removed, ensure that it is stored or attached securely to prevent it from being thrown around the vehicle in the event of sharp braking.
Children under the age of 10 must not travel in the "for wards-facing" position on the front passenger seat, unless the rear seats are already occupied by other children, cannot be used or are absent. Deactivate the passenger airbag when a "rear wards-facing" child seat is installed on the front seat. Other wise, the child would risk being seriously injured or killed if the airbag were to inflate.
Installing a booster seat
The chest par t of the seat belt must be positioned on the child's shoulder without touching the neck.
Ensure that the lap par t of the seat belt passes correctly over the child's thighs. CITROËN recommends the use of a booster seat which has a back, fitted with a seat belt guide at shoulder level.
As a safety precaution, do not leave: - a child or children alone and unsuper vised in a vehicle, - a child or an animal in a vehicle which is exposed to the sun, with the windows closed, - the keys within reach of children inside the vehicle. To prevent accidental opening of the doors
and rear windows, use the "Child lock". Take care not to open the rear windows by more than one third. To protect young children from the rays of the sun, fit side blinds on the rear windows.
