13Familiarisation
Interior


6-speed electronic gearbox
system
This system offers driving combining a fullyautomatic mode and a manual mode.


Interior mood lighting

This dimmed lighting of the passenger compartment improves visibility inside the
vehicle when the light is poor.

Audio and communication
s
ystems
These systems benefit from the followingtechnologies: radio, CD player, USB player,
Bluetooth system, satellite navigation system
with colour screen, auxiliary sockets. Radio
20
5
139
349
297

Electric parking brake

It combines the functions of automaticapplication on switching off the engine and
automatic release when moving off. Manual application and release remains
possible.
1
94
eMyWay satellite navigation system


Massage function

This system gives a lumbar massage for a period of 60 minutes. The massage is done in6 cycles of 10 minutes each.
91

Roof consoles - Centre consoles
A.
Rear view mirror.
B
. Microphone for audio and telematic system.C.
Interior mood lighting.D.Emergency call/Assistance call. E.Courtesy lamp/Map reading lamps.

1
.Central adjustable air vents. 2. Monochrome screen and seat belt and front airbag warning lamp screen or colour
and mapping screen. 3. eMyWay Audio or satellite navigationsystem.4.Central switch panel.
5.Heating/air conditioning controls.
6. USB port/auxiliary Jack socket and cigarette lighter/12 V accessory socket. 7.Gear lever, manual or electronic gearboxsystem.8.
Manual or electric parking brake9.Portable ashtray.
10. Front armrest.

Interior fi ttings
1.Sun visor(see "Familiarisation - § Panoramic
windscreen") 2.Ticket/card holder
3.Illuminated glove box(see details on a following page)4. Door pockets5.USB port/Auxiliary socket(see details on a following page)6.Cigar lighter/12 V accessory socket(see details on following pages)7.Por table ashtray(see details on following pages)8.Centre armrest with storage(see details on a following page)

Cigarette lighter/12 V
accessory socket
)To use the cigarette lighter, press it in and wait a few seconds until it pops outautomatically. )To connect a 12 V accessory (max power:
120 W
), remove the cigarette lighter and connect a suitable adaptor.
You can use this socket to connect a telephone
charger, a bottle warmer...
After use, put the cigarette lighter back intoplace straight away.




















USB port/auxiliary
socket

Connected to the USB por t, theportable device charges automatically while in use.
The "AU X "
connection box, located in thecentre console, comprises an auxiliary JACK
socket and/or a USB por t.
It permits the connection of a por table device,
such as a di
gital audio player of the iPod® or ®
USB memory stick type.
It reads cer tain audio file formats allowing them
to be heard via the vehicle's speakers.
You can manage these files using the steering
mounted controls or the audio system control
panel and display them on the multi
functionscreen.
F
or more information on the use of this equipment, refer to the "Audio and Telematics" section.

Large multifunctional
storage unit
This storage unit is closed by a sliding shutter.
It contains:
- the USB por t and 12 V/auxiliary sockets 1
,
- a retractable suppor t 2
to receive your mobile phone or por table device,
- a space ventilated by a closeable nozzle 3 ,
to keep food and drinks fresh if the air conditioning is operating.
It is illuminated only when the slidingshutter is fully open.The sliding shutter can be par tly closed up to the level of the retractable suppor t, so as to keep the storage unit cool.

Changing a bulb

The headlamps are fitted withpolycarbonate glass with a protectivecoating:)do not clean them using a dryor abrasive cloth, nor with adetergent or solvent product,)use a sponge and soapy water, )when using a high pressurewasher on persistent marks, do not keep the lance directed towards the lamps or their edges for too long, so as not to damage their protective coating and seals.
)Do not touch the bulb directly withyour fingers, use lint-free cloths.Changing a bulb should only be doneafter the headlamp has been switched off for a few minutes (risk of seriousburns).It is imperative to use onlyanti-ultraviolet (UV) type bulbs in order not to damage the headlamp.
Always replace a failed bulb with anew bulb with the same type and specification.


Risk of electrocution

Xenon bulbs (D1S-35W) must be replaced by a CITROËN dealer or aqualified workshop.


Bulbs with lugs, type H1, H7... take careto position them correctly to ensure thebest lighting.

"Multimedia":
audio systems, steering mounted audio controls,speakers, Hi-Fi module, Bluetooth hands-freesystem, por table satellite navigation system,semi-integral suppor t bracket for por tablenavigation system, speed camera detector, USBBox, reversing camera, por table video screen,por table video suppor t bracket, 230 V/50 Hz socket, 230 V/12 V adaptor, Wi-Fi on board...
B
y visiting a CITROËN dealer you can also
obtain cleaning and maintenance products
(interior and exterior) - including ecological
products in the "TECHNATURE" range,
products for topping up (screenwash...), paint
touch-up pens and aerosols for the exact colour
of
your vehicle, refills (sealant car tridge for the
temporary puncture repair kit...), ...

Installation of radio communication transmitters

Before installing any after-market radiocommunication transmitter, you can contact a CITROËN dealer for the specification of transmitters which can
be fitted (frequency, maximum power, aerial position, specific installation requirements), in line with the Vehicle Electromagnetic Compatibility Directive (2004/104/EC).



The fitting of electrical equipment or accessories which are not recommended by CITROËN may resultin a failure of your vehicle's electronicsystem and excessive electricalconsumption.
Please note this precaution.You are advised to contact a CITROËNrepresentative to be shown the range of recommended equipment and accessories.


Depending on the legislation in forcein the country, it may be compulsory to have a high visibility safety vest, warning triangle and spare bulbs andfuses available in the vehicle.

03
A press on the OK dial gives access to
short-cut menus according to the display in the screen.
GENERAL OPERATION







DISPLAY ACCORDING TO CONTEXT

RADIO:


Activate/Deactivate TA


Activate/Deactivate RDS


MUSIC MEDIA PLAYERS,
CD or USB (according to
media):
Play modes:

Normal

Random

Random on all media

Re
petition


TELEPHONE
(call in progress):

Private mode

FULL SCREEN MAP OR IN A
NEW WINDOW:

Stop/Restore guidance Select destination
Enter an address
Directory
GPS coordinates
Divert route
Move the map
Info. on location
Select as destination
Select as sta
ge
Save this place (contacts)
Quit map mode

Guidance criteria
Put call on hold


DTMF ring tones

Hang up
1
1
1
1
1
1
1
1
2
2
2
2
2
1
2
2
2
1
1
1
1
1
1

05
2 1
1
2
3
TRAFFIC INFORMATION






PRINCIPAL TMC SYMBOLS


Red and yellow triangle: traffi c information, for example:
Black and blue trian
gle: general information, for example:







RECEIVING TA MESSAGES


The TA (Traffi c Announcement) function gives priority to TA alert messages. To operate, this function needs good reception of a radio station transmitting this type of message. When a traffi c report is
transmitted, the current audio source (Radio, CD, USB, ...) is interrupted
automatically to play the TA message. Normal playback of the audiosource resumes at the end of the transmission of the message.
Press RADIO
to display the "FM/AMband " menu.
Select " Guidance options
" then confi rm.
Select " Activate/Deactivate TA
" then confi rm.

The volume settin
g for TA mesages can be adjusted only during the
transmission of this type of alert.

333
08

CD, MP3 CD/USB PLAYER


The audio equipment will only play audio fi les with ".m4a, .wma, .m4b, .aac, .fl ac, .ogg and.mp3" fi le extensions and with a bit rate of
between 32 Kbps and 320 Kbps.
It also supports VBR
(Variable Bit Rate) mode.
No other type of fi le (.mp4, .m3u...) can be played.
WMA fi les must be of the standard wma 9 type.
The sampling rates supported are 11, 22, 44 and 48 KHz.

It is advisable to restrict
fi le names to 20 characters, without using of special characters (e.g. : " " ? ; ˘) to avoid any playing and displayingproblems.

In order to be able to pla
y a recorded CDR or CDRW, when recording
it is preferable to select the ISO 9660 level 1, 2 or Joliet standard.
If the disc is recorded in another format it ma
y not be played correctly.

It is recommended that the same recording standard is always used for an individual disc, with as low a speed as possible (4x maximum)for optimum sound quality.
In the particular case o
f a multi-session CD, the Joliet standard isrecommended.
INFORMATION AND ADVICE
The s
ystem supports USB mass storage or iPod
devices via the USB port (suitable cable not supplied).

Control of the peripheral device is with the audiosystem controls.

Other peripherals, not recognised on connection, must
be connected to the auxiliary socket using a Jack cable (not supplied).
In order to be read, a USB memor
y stick must be formatted FAT 16 or 32.
