fuse chart DODGE DURANGO 2008 2.G Owners Manual

Fuses (Power Distribution Center)
Your vehicle is equipped with an electrical power distri-
bution center located in the left side of the engine
compartment.
This center contains cartridge fuses, mini fuses and
relays. A description of each fuse and component may bestamped on the inside cover otherwise the cavity number
of each fuse is stamped on the inside cover that corre-
sponds to the following chart. These fuses and relays can
be obtained from your dealer.
CavityCartridge
Fuse /
RelayMini
FuseDescription
1 30 Amp
PinkStarter
2 30 Amp
PinkFront Wiper
3 40 Amp
GreenBrake Batt
4 30 Amp
PinkJB Feed Acc # 2
5 40 Amp
GreenPower Seats
6 30 Amp
PinkRun Remote Relay
Feed
Power Distribution Center
424 MAINTAINING YOUR VEHICLE

Fuses (Integrated Power Module)
An integrated Power Module is located in the left side of
the engine compartment. This center contains cartridge
fuses, mini fuses and relays. A description of each fuse
and component may be stamped on the inside coverotherwise the cavity number of each fuse is stamped on
the inside cover that corresponds to the following chart.
CavityCartridge
Fuse /
RelayMini
FuseDescription
1 Relay Wiper On/Off Rly
2 Relay Wiper Hi/Lo Rly
3 Relay Horn Rly
4 Relay Rear Wiper Rly
5 Relay Lt Trailer-Tow Stop/
Turn Rly
6 Relay Rt Trailer-Tow
Stop/Turn Rly
7 Relay Park Lamps Rly
8 10 Amp
RedLt Park Lamps
9 10 Amp
RedTrailer-Tow Park
Lamps
Integrated Power Module
MAINTAINING YOUR VEHICLE 427
