8W-53 WIPERS
Component Page
Data Link Connector................. 8W-53-2
Front Control Module............. 8W-53-2, 3, 4
Fuse 8............................ 8W-53-3
G104............................ 8W-53-3, 4
G105.............................. 8W-53-4
Instrument Cluster................... 8W-53-2
Integrated Power Module.......... 8W-53-2, 3, 4Component Page
Multi-Function Switch................ 8W-53-2
Washer Fluid Level Switch............. 8W-53-4
Washer Pump Motor-Front............. 8W-53-4
Wiper High/Low Relay.............. 8W-53-3, 4
Wiper Motor-Front................. 8W-53-3, 4
Wiper On/Off Relay.................. 8W-53-3
DR8W-53 WIPERS 8W - 53 - 1

8W-54 TRAILER TOW
Component Page
Brake Lamp Switch.................. 8W-54-5
Electric Brake Provision............... 8W-54-5
Front Control Module............. 8W-54-2, 3, 5
Fuse 1............................ 8W-54-5
Fuse 15.......................... 8W-54-2, 3
Fuse 19............................ 8W-54-5
Fuse 24............................ 8W-54-5
Fuse 33.......................... 8W-54-2, 3
Fuse 46.......................... 8W-54-2, 3Component Page
Fuse 47.......................... 8W-54-2, 3
G104.......................... 8W-54-2, 4, 5
Integrated Power Module.......... 8W-54-2, 3, 5
Park Lamp Relay.................. 8W-54-2, 3
PTCNo.5........................ 8W-54-2, 3
Trailer Tow Connector............ 8W-54-2, 3, 4
Trailer Tow Connector-Add On...... 8W-54-3, 4, 5
Trailer Tow Left Turn Relay.......... 8W-54-2, 3
Trailer Tow Right Turn Relay......... 8W-54-2, 3
DR8W-54 TRAILER TOW 8W - 54 - 1

8W-62 POWER MIRRORS
Component Page
A/C-Heater Control................... 8W-62-3
Driver Door Module................ 8W-62-2, 3
Fuse 27............................ 8W-62-3
Fuse 36............................ 8W-62-3
Fuse 48............................ 8W-62-2Component Page
G302............................ 8W-62-2, 3
Heated Mirror Relay................. 8W-62-3
Integrated Power Module............ 8W-62-2, 3
Power Mirror-Left.................. 8W-62-2, 3
Power Mirror-Right.................. 8W-62-3
DR8W-62 POWER MIRRORS 8W - 62 - 1

4WD SWITCH (MANUAL TRANSFER CASE)-2WAY
CAV CIRCUIT FUNCTION
1 K77 18BR/WT TRANSFER CASE POSITION SENSOR INPUT
2 Z901 18BK GROUND
A/C COMPRESSOR CLUTCH (DIESEL) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 C3 18DB/YL A/C COMPRESSOR CLUTCH RELAY OUTPUT
2 Z816 18BK GROUND
A/C COMPRESSOR CLUTCH (GAS) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 C3 20DB/YL A/C CLUTCH RELAY OUTPUT
2 Z153 18BK/GY GROUND
A/C HEATER CONTROL C1 - BLACK 16 WAY
CAV CIRCUIT FUNCTION
1 F504 20GY/PK FUSED IGNITION SWITCH OUTPUT (RUN)
2 Z24 18BK/OR GROUND
3 C121 20DB/DG SENSOR GROUND
4 C29 20DB MODE DOOR 2 DRIVER
5- -
6 C21 20DB/LG EVAPORATOR TEMPERATURE SENSOR SIGNAL
7- -
8 E16 20OR/GY PANEL LAMPS DRIVER
9 C61 20DB/LG BLEND DOOR DRIVER
10 C801 20DB/OR MODE DOOR 1 DRIVER
11 C34 20DB/LB COMMON DOOR DRIVER
12 C32 20DB/TN RECIRCULATION DOOR DRIVER
13 C33 20LB/BR (DUAL ZONE) PASSENGER BLEND DOOR DRIVER
14 - -
15 C110 20DB/LB DEFOGGER RELAY CONTROL
16 D25 20WT/VT PCI BUS
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 5

ADJUSTABLE PEDAL SWITCH (EXCEPT MEMORY) - BLUE 6 WAY
CAV CIRCUIT FUNCTION
1 P206 18LG/LB ADJUSTABLE PEDALS MOTOR REVERSE
2 A72 18RD/OR ADJUSTABLE PEDAL RELAY OUTPUT
3- -
4 Z146 18BK GROUND
5 F504 20GY/PK FUSED IGNITION SWITCH OUTPUT (RUN)
6 P205 18LG/WT ADJUSTABLE PEDALS MOTOR FORWARD
AIRBAG CONTROL MODULE C1 - 24 WAY
CAV CIRCUIT FUNCTION
1- -
2- -
3 D25 20WT/VT PCI BUS
4- -
5 Z104 18BK/LG GROUND
6 G104 20VT/GY PASSENGER AIRBAG INDICATOR DRIVER
7 R104 20LB/LG PASSENGER AIRBAG MUX SWITCH RETURN
8 R106 20LG/LB PASSENGER AIRBAG MUX SWITCH SENSE
9- -
10 - -
11 - -
12 - -
13 - -
14 - -
15 - -
16 - -
17 R43 20LG/BR DRIVER SQUIB 1 LINE 1
18 R45 20LG/OR DRIVER SQUIB 1 LINE 2
19 R44 20LB/OR PASSENGER SQUIB 1 LINE 2
20 R42 20LB/BR PASSENGER SQUIB 1 LINE 1
21 R61 20LG/VT DRIVER SQUIB 2 LINE 1
22 R63 20LG/WT DRIVER SQUIB 2 LINE 2
23 R64 20LB/WT PASSENGER SQUIB 2 LINE 1
24 R62 20LB/VT PASSENGER SQUIB 2 LINE 2
8W - 80 - 8 8W-80 CONNECTOR PIN-OUTSDR

AMPLIFIER AUDIO C1 (PREMIUM) - GRAY 12 WAY
CAV CIRCUIT FUNCTION
1 X53 20DG LEFT FRONT SPEAKER (+)
2 X55 20DG/BR LEFT FRONT SPEAKER (-)
3 X57 20DG/OR LEFT REAR SPEAKER (-)
4 Z513 18BK GROUND
5 X11 20DG RADIO 12 VOLT OUTPUT
6 X56 20GY/BR RIGHT FRONT SPEAKER (-)
7 X54 20GY RIGHT FRONT SPEAKER (+)
8 X51 20DG/DB LEFT REAR SPEAKER (+)
9 X58 20GY/OR RIGHT REAR SPEAKER (-)
10 X52 20GY/DB RIGHT REAR SPEAKER (+)
11 Z907 18BK GROUND
12 D25 20WT/VT PCI BUS
AMPLIFIER AUDIO C2 (PREMIUM) - GRAY 18 WAY
CAV CIRCUIT FUNCTION
1 A116 18YL/RD FUSED B(+)
2- -
3- -
4 X295 18GY/DG LEFT REAR SPEAKER (-)
5 X154 18GY/YL RIGHT FRONT DOOR SPEAKER (+)
6 X153 18DG/YL LEFT FRONT DOOR SPEAKER (+)
7 X208 18GY/DG RIGHT INSTRUMENT PANEL SPEAKER (+)
8 X299 18GY/YL LEFT INSTRUMENT PANEL SPEAKER (-)
9 A116 18YL/RD FUSED B(+)
10 - -
11 - -
12 X205 18GY/LG LEFT REAR SPEAKER (+)
13 X296 18DG/GY RIGHT REAR SPEAKER (-)
14 X206 18DG/LG RIGHT REAR SPEAKER (+)
15 X156 18GY/LB RIGHT FRONT DOOR SPEAKER (-)
16 X155 18DG/LB LEFT FRONT DOOR SPEAKER (-)
17 X298 18GY/LG RIGHT INSTRUMENT PANEL SPEAKER (-)
18 X209 18GY/OR LEFT INSTRUMENT PANEL SPEAKER (+)
ASHTRAY LAMP-2WAY
CAV CIRCUIT FUNCTION
1 L70 18WT/GY FUSED PARK LAMP RELAY OUTPUT
2 Z923 18BK GROUND
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 11

C328 (DUAL REAR WHEELS) - (DRW LAMP
SIDE)
CAV CIRCUIT
1 L70 18WT/YL
2 Z948 18BK
CAMSHAFT POSITION SENSOR (DIESEL)-3WAY
CAV CIRCUIT FUNCTION
1 F855 18PK/YL 5 VOLT SUPPLY
2 K916 18BR/OR SENSOR GROUND
3 K44 18DB/GY CMP SIGNAL
CAMSHAFT POSITION SENSOR (NGC) - GRAY 3 WAY
CAV CIRCUIT FUNCTION
1 K44 20DB/GY CMP SIGNAL
2 K900 20DB/DG SENSOR GROUND
3 F856 20YL/PK 5 VOLT SUPPLY
CAPACITOR (3.7L/4.7L) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 K342 16BR/WT AUTOMATIC SHUT DOWN RELAY OUTPUT
2- -
8W - 80 - 44 8W-80 CONNECTOR PIN-OUTSDR

CENTER HIGH MOUNTED STOP LAMP/CARGO LAMP-4WAY
CAV CIRCUIT FUNCTION
1 L14 20WT/TN CARGO LAMP DRIVER
2 Z964 20BK GROUND
3 Z350 20BK/TN GROUND
4 L50 20WT/TN BRAKE LAMP SWITCH OUTPUT
CIGAR LIGHTER OUTLET - RED 3 WAY
CAV CIRCUIT FUNCTION
1 F984 18PK/YL FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
2- -
3 Z736 18BK/YL GROUND
CLEARANCE LAMP NO. 1 (HEAVY DUTY)-2WAY
CAV CIRCUIT FUNCTION
1 L70 20WT/GY FUSED PARK LAMP RELAY OUTPUT
2 Z946 20BK GROUND
CLEARANCE LAMP NO. 2 (HEAVY DUTY)-2WAY
CAV CIRCUIT FUNCTION
1 L70 20WT/GY FUSED PARK LAMP RELAY OUTPUT
2 Z946 20BK GROUND
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 45

CLEARANCE LAMP NO. 3 (HEAVY DUTY)-2WAY
CAV CIRCUIT FUNCTION
1 L70 20WT/GY FUSED PARK LAMP RELAY OUTPUT
2 Z946 20BK GROUND
CLEARANCE LAMP NO. 4 (HEAVY DUTY)-2WAY
CAV CIRCUIT FUNCTION
1 L70 20WT/GY FUSED PARK LAMP RELAY OUTPUT
2 Z946 20BK GROUND
CLEARANCE LAMP NO. 5 (HEAVY DUTY)-2WAY
CAV CIRCUIT FUNCTION
1 L70 20WT/GY FUSED PARK LAMP RELAY OUTPUT
2 Z946 20BK GROUND
CLOCKSPRING C1-6WAY
CAV CIRCUIT FUNCTION
1 Z909 20BK (DSAB ETC) GROUND
2 X20 20GY/WT (DSAB ETC) RADIO CONTROL MUX
3 V38 20VT/OR S/C SWITCH NO. 2 SIGNAL
4 V37 20VT S/C SWITCH NO. 1 SIGNAL
5 V937 20VT/BR S/C SWITCH RETURN
6 X3 20DG/VT HORN SWITCH SENSE
8W - 80 - 46 8W-80 CONNECTOR PIN-OUTSDR

CLOCKSPRING C2 - YELLOW 4 WAY
CAV CIRCUIT FUNCTION
1 R61 20LG/VT DRIVER SQUIB 2 LINE 1
2 R63 20LG/WT DRIVER SQUIB 2 LINE 2
3 R43 20LG/BR DRIVER SQUIB 1 LINE 1
4 R45 20LG/OR DRIVER SQUIB 1 LINE 2
CLOCKSPRING C3 - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 X3 20DG/VT HORN SWITCH SENSE
2 V937 20VT/BR S/C SWITCH RETURN
3 V37 20VT S/C SWITCH NO. 1 SIGNAL
4 V38 20VT/OR (DSAB ETC) S/C SWITCH NO. 2 SIGNAL
CLOCKSPRING C4-2WAY
CAV CIRCUIT FUNCTION
1 Z909 22BK GROUND
2 X20 22GY/WT RADIO CONTROL MUX
CLUTCH INTERLOCK BRAKE SWITCH-2WAY
CAV CIRCUIT FUNCTION
1 T41 20YL/DB TRS T41 SENSE
2 Z911 18BK GROUND
COIL ON PLUG NO. 1 (3.7L/4.7L) - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 K19 18DB/DG COIL CONTROL NO. 1
2 K342 16BR/WT ASD RELAY OUTPUT
3- -
DR8W-80 CONNECTOR PIN-OUTS 8W - 80 - 47
