RECOMMENDED FLUIDS, LUBRICANTS AND GENUINE PARTS
Engine
Component Fluids, Lubricants and Genuine Parts
Engine Coolant MopartAntifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Or-
ganic Additive Technology) P/N 5011764AB or equivalent.
Engine Oil Use SAE 5W-30, API Certified, meeting material standard MS-6395. Refer to
oil viscosity chart for alternative grade.
Engine Oil Filter MopartEngine Oil Filter, P/N 5281090 or equivalent.
Spark Plugs Refer to the Vehicle Emission Control Information label in the engine com-
partment.
Fuel Selection (all except 5.7L) 87 Octane, (R+M)/2 Method
Fuel Selection (5.7L) 89 Octane, (R+M)/2 Method, Mid-Grade Preferred (87 Octane acceptable)
MAINTAINING YOUR VEHICLE 381
7

At Each Stop for Fuel
²Check the engine oil level about 5 minutes after a fully
warmed engine is shut off. Checking the oil level while
the vehicle is on level ground will improve the accu-
racy of the oil level reading. Add oil only when the
level is at or below the ADD or MIN mark.
²Check the windshield washer solvent and add if
required.
Once a Month
²Check tire pressure and look for unusual wear or
damage.
²Inspect the battery and clean and tighten the terminals
as required.
²Check the fluid levels of coolant bottle, brake master
cylinder, and transmission and add as needed.
²Check all lights and all other electrical items for correct
operation.
At Each Oil Change
²Change the engine oil filter.
²Inspect the exhaust system.
²Inspect the brake hoses.
²Inspect the CV joints (if equipped) and front suspen-
sion components.
²Check the automatic transmission fluid level.
²Check the manual transmission fluid level.
²Check the coolant level, hoses, and clamps.
Tire Rotation
²Rotate the tires at 6,000 miles (10 000 km).
386 MAINTENANCE SCHEDULES
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 93,000 96,000 99,000 100,000 102,000
(Kilometers) (149 000) (154 000) (158 000) (160 000) (163 000)
Change engine oil and engine oil filter. X X X X
Lubricate outer tie rod ends 2500/3500 (4X4) mod-
els only.XX
Flush and replace engine coolant.X
Flush and replace Power Steering Fluid. X
Inspect brake linings. X
394 SCHEDULE ªBº
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 36,000 42,000 48,000 54,000 60,000 66,000
(Kilometers) (58 000) (67 000) (77 000) (84 000) (96 000) (106 000)
[Months] [36] [42] [48] [54] [60] [66]
Change engine oil and engine oil filter. X XXXXX
Check transfer case fluid level (4X4). X
Lubricate outer tie rod ends 2500/3500 (4X4)
models only.X X XXXX
Flush and replace engine coolant at 60
months, regardless of mileage.X
Inspect brake linings. X X
Replace engine air cleaner filter.X
Replace spark plugs.X
Inspect PCV valve, replace as necessary.X*
Replace ignition cables.X
398 SCHEDULE ªAº
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 102,000 108,000 114,000 120,000
(Kilometers) (163 000) (173 000) (182 000) (192 000)
[Months] [102] [108] [114] [120]
Change engine oil and engine oil filter. X X X X
Drain and refill transfer case fluid (4X4). X
Flush and replace engine coolant, if not done at 60 mos. X
Lubricate outer tie rod ends 2500/3500 (4X4) models only. X X X X
Inspect brake linings. X
Inspect auto tension drive belt and replace if required
(3.7L/4.7L/5.7L).X³X³
Replace ignition cables.X
Replace engine air cleaner filter.X
Replace spark plugs.X
Inspect PCV Valve, replace as necessary X*
* This maintenance is recommended by the manufacture
to the owner, but is not required to maintain the emis-
sions warranty.³ This maintenance is not required if previously replaced.
Inspection and service should also be performed anytime a
malfunction is observed or suspected. Retain all receipts.
400 SCHEDULE ªAº
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Adding Fuel........................259,295
Air Cleaner, Engine...................334,357
Air Conditioner Maintenance............327,338
Air Conditioning Refrigerant.......327,328,338,339
Air Conditioning System.............187,327,338
Air Conditioning System, Zone Control........ 191
Air Pressure, Tires....................244,251
Airbag..............................45,50
Airbag Light.........................70,144
Airbag On/Off Switch..................... 50
Airbag, Side............................ 53
Alarm..............................29,147
Alignment and Balance................... 250
Alterations/Modifications, Vehicle............. 7
Antifreeze (Engine Coolant)..............346,379
Anti-Lock Brake System................... 231
Anti-Lock Warning Light...............148,232
Anti-Theft System.....................29,147
Appearance Care........................ 361Ashtray............................... 127
Automatic Transmission
Adding Fluid......................... 353
Fluid and Filter Changes................. 355
Fluid Level Check...................... 352
Fluid Type........................354,382
Shift Indicator........................ 147
Shifting............................. 208
Special Additives...................... 355
Axle Fluid.......................272,350,382
Axle Lubrication.....................272,350
Ball Joints............................. 340
Battery............................... 337
Emergency Starting..................... 312
Bearings.............................. 355
Belts, Drive............................ 333
Belts, Seat.............................. 34
Body Mechanism Lubrication............... 341
414 INDEX

Disposal
Engine Oil........................... 347
Door Ajar............................. 145
Door Locks............................. 16
Door Opener, Garage..................... 120
Drive Belts............................ 333
Drive Shaft Universal Joints................ 341
Dual Rear Wheels.....................255,309
E-85 Fuel............................. 262
Electric Rear Window Defrost..........78,191,195
Electrical Power Outlets................... 126
Electronic Speed Control................... 109
Emergency Brake........................ 229
Emergency, In Case of
Freeing Vehicle When Stuck............... 316
Hazard Warning Flasher................. 294
Jacking............................. 302
Jump Starting......................... 312Tow Hooks.......................... 316
Towing............................. 317
Emission Control System Maintenance......... 384
Emission Related Components.............. 336
Engine............................322,323
Air Cleaner.......................... 334
Break-In Recommendations................ 67
Compartment Identification............322,323
Coolant..........................346,381
Exhaust Gas Caution.................... 262
Flooded, Starting...................... 206
Fuel Requirements..................... 379
Oil ...........................329,379,381
Oil Selection.......................331,379
Oil Synthetic......................... 332
Temperature Gauge..................... 146
Equipment Identification Plate.............. 292
Ethylene Glycol Antifreeze................. 346
Exhaust Gas Caution..............69,136,262,343
