DODGE RAM 1999 Service Repair Manual
Manufacturer: DODGE, Model Year: 1999, Model line: RAM, Model: DODGE RAM 1999Pages: 1691, PDF Size: 40.34 MB
Page 1021 of 1691
![DODGE RAM 1999 Service Repair Manual \
\
\
\
\
\
\
Engine Oil Ambient Temperature Above 10 F](/img/12/56915/w960_56915-1020.png "DODGE RAM 1999 Service Repair Manual \
\
\
\
\
\
\
Engine Oil Ambient Temperature Above 10 F")
\
\
\
\
\
\
\
Engine Oil Ambient Temperature Above 10 F SAE 15W-40
(
1) (-12 C) To Over 30 F (-1 C)
\
\
\
\
\
Ambient Temperature Less Than SAE 10W-30
0 F (-18 C) To Over 30 F(-1 C)
\
\
\
\
\
Ambient Temperature Less Than With Block Heater:
-10 F(-23 C) Up To 0 F (-18 C) SAE 10W-30
Without Block Heater:
SAE 5W-30
\
\
\
\
\
\
\
Engine All 50/50 Mixture Of
Coolant Distilled Water &
Ethylene Glycol
\
\
\
\
\
\
\
Brake Fluid All DOT 3
\
\
\
\
\
\
\
Steering All Mopar Multi-Mileage
Linkage Lubricant
Lubricant
\
\
\
\
\
\
\
(
1) - SAE 10W-30 engine oil is preferred for use in all Dodge
trucks. Use only API approved oil with Starburst Symbol.
\
\
\
\
\
\
\
FLUID CAPACITIES
\
\b\
\
\
\b\
\
\
Item Condition Specification (1)
\
\
\
\
\
\
\
Engine Oil Capacity, Upper Safe Mark 10 Qts. (9.5L)
\
\
\
\
\
Capacity, Lower Safe Mark 8 Qts. (7.5L)
\
\
\
\
\
\
\
Engine Drained 26 Qts. (24.5L)
Coolant
\
\
\
\
\
\
\
(
1) - Capacities are recommended or calculated levels. Always use
dipstick (if available) to measure level.
\f
\
\
\
\
\
\
\
108,000 MILE (173,000 KM)/108 MONTH NORMAL SERVICE
108,000 MILE (173,000 KM)/108 MONTH NORMAL SERVICE\
\
\
\
\
\
\
VERIFY
\b\
\
\
\
\
\
\
Last Major Service Was Performed.
\
\
\
\
\
\
\
INSPECT
\b\
\
\
\
\
\
\
Exhaust System
\
\
\
\
\
\
\
Brake Hoses
\
\
\
\
\
\
\
Brake Linings
\
\
\
\
\
\
\
Drive Belts
\
\
\
\
\
\
\
Water Pump Weep Hole For Blockage
\
\
\
\
\
\
\
SERVICE
\b\
\
\
\
\
\
\
Page 1022 of 1691
![DODGE RAM 1999 Service Repair Manual Rotate Tires
\
\
\
\
\
\](/img/12/56915/w960_56915-1021.png "DODGE RAM 1999 Service Repair Manual Rotate Tires
\
\
\
\
\
\")
Rotate Tires
\
\
\
\
\
\
\
Lubricate Steering Linkage
\
\
\
\
\
\
\
Clean Fuel Strainer
\
\
\
\
\
\
\
REPLACE
\b\
\
\
\
\
\
\
Engine Oil
\
\
\
\
\
\
\
Engine Oil Filter
\
\
\
\
\
\
\
Engine Coolant
\
\
\
\
\
\
\
Fuel Filter
\
\
\
\
\
\
\
Transfer Case Fluid
\
\
\
\
\
\
\
LUBRICATION SPECIFICATIONS
\
\b\
\
\
\b\
\
\
Material Condition Specification
\
\
\
\
\
\
\
Engine Oil Ambient Temperature Above 10 F SAE 15W-40
(
1) (-12 C) To Over 30 F (-1 C)
\
\
\
\
\
Ambient Temperature Less Than SAE 10W-30
0 F (-18 C) To Over 30 F(-1 C)
\
\
\
\
\
Ambient Temperature Less Than With Block Heater:
-10 F(-23 C) Up To 0 F (-18 C) SAE 10W-30
Without Block Heater:
SAE 5W-30
\
\
\
\
\
\
\
Engine All 50/50 Mixture Of
Coolant Distilled Water &
Ethylene Glycol
\
\
\
\
\
\
\
Brake Fluid All DOT 3
\
\
\
\
\
\
\
Steering All Mopar Multi-Mileage
Linkage Lubricant
Lubricant
\
\
\
\
\
\
\
Transfer Case All ATF+2 Type 7176
Fluid Or DEXRON III ATF
\
\
\
\
\
\
\
(
1) - SAE 10W-30 engine oil is preferred. Use only API approved
oil with Starburst Symbol.
\
\
\
\
\
\
\
FLUID CAPACITIES
\
\b\
\
\
\b\
\
\
Item Condition Specification (1)
\
\
\
\
\
\
\
Engine Oil Capacity, Upper Safe Mark 10 Qts. (9.5L)
\
\
\
\
\
Capacity, Lower Safe Mark 8 Qts. (7.5L)
\
\
\
\
\
\
\
Engine Drained 26 Qts. (24.5L)
Coolant
\
\
\
\
\
\
\
Transfer Case NV241 HD 6.5 Pts. (3.5L)
Fluid
\
\
\
\
\
\
\
Page 1023 of 1691
![DODGE RAM 1999 Service Repair Manual (1) - Capacities are recommended or calculated levels. Always use
dipstick (if available) to measure level.
\f
\
\](/img/12/56915/w960_56915-1022.png "DODGE RAM 1999 Service Repair Manual (1) - Capacities are recommended or calculated levels. Always use
dipstick (if available) to measure level.
\f
\
\")
(1) - Capacities are recommended or calculated levels. Always use
dipstick (if available) to measure level.
\f
\
\
\
\
\
\
\
114,000 MILE (183,000 KM)/114 MONTH NORMAL SERVICE
114,000 MILE (183,000 KM)/114 MONTH NORMAL SERVICE\
\
\
\
\
\
\
VERIFY
\b\
\
\
\
\
\
\
Last Major Service Was Performed.
\
\
\
\
\
\
\
INSPECT
\b\
\
\
\
\
\
\
Exhaust System
\
\
\
\
\
\
\
Brake Hoses
\
\
\
\
\
\
\
Engine Coolant Level, Hoses & Clamps
\
\
\
\
\
\
\
SERVICE
\b\
\
\
\
\
\
\
Rotate Tires
\
\
\
\
\
\
\
Lubricate Steering Linkage
\
\
\
\
\
\
\
REPLACE
\b\
\
\
\
\
\
\
Engine Oil
\
\
\
\
\
\
\
Engine Oil Filter
\
\
\
\
\
\
\
LUBRICATION SPECIFICATIONS
\
\b\
\
\
\b\
\
\
Material Condition Specification
\
\
\
\
\
\
\
Engine Oil Ambient Temperature Above 10 F SAE 15W-40
(
1) (-12 C) To Over 30 F (-1 C)
\
\
\
\
\
Ambient Temperature Less Than SAE 10W-30
0 F (-18 C) To Over 30 F(-1 C)
\
\
\
\
\
Ambient Temperature Less Than With Block Heater:
-10 F(-23 C) Up To 0 F (-18 C) SAE 10W-30
Without Block Heater:
SAE 5W-30
\
\
\
\
\
\
\
Engine All 50/50 Mixture Of
Coolant Distilled Water &
Ethylene Glycol
\
\
\
\
\
\
\
Brake Fluid All DOT 3
\
\
\
\
\
\
\
Steering All Mopar Multi-Mileage
Linkage Lubricant
Lubricant
\
\
\
\
\
\
\
(
1) - SAE 10W-30 engine oil is preferred for use in all Dodge
trucks. Use only API approved oil with Starburst Symbol.
\
\
\
\
\
\
\
FLUID CAPACITIES
\
\b\
\
\
\b\
\
\
Page 1024 of 1691
![DODGE RAM 1999 Service Repair Manual Item Condition Specification (1)
\
\
\
\
\
\](/img/12/56915/w960_56915-1023.png "DODGE RAM 1999 Service Repair Manual Item Condition Specification (1)
\
\
\
\
\
\")
Item Condition Specification (1)
\
\
\
\
\
\
\
Engine Oil Capacity, Upper Safe Mark 10 Qts. (9.5L)
\
\
\
\
\
Capacity, Lower Safe Mark 8 Qts. (7.5L)
\
\
\
\
\
\
\
Engine Drained 26 Qts. (24.5L)
Coolant
\
\
\
\
\
\
\
(
1) - Capacities are recommended or calculated levels. Always use
dipstick (if available) to measure level.
\f
\
\
\
\
\
\
\
120,000 MILE (192,000 KM)/120 MONTH NORMAL SERVICE
120,000 MILE (192,000 KM)/120 MONTH NORMAL SERVICE\
\
\
\
\
\
\
VERIFY
\b\
\
\
\
\
\
\
Last Major Service Was Performed.
\
\
\
\
\
\
\
INSPECT
\b\
\
\
\
\
\
\
Exhaust System
\
\
\
\
\
\
\
Brake Hoses
\
\
\
\
\
\
\
Engine Coolant Level, Hoses & Clamps
\
\
\
\
\
\
\
Front Wheel Bearings (4x2)
\
\
\
\
\
\
\
SERVICE
\b\
\
\
\
\
\
\
Rotate Tires
\
\
\
\
\
\
\
Lubricate Steering Linkage
\
\
\
\
\
\
\
Automatic Transmission Bands
\
\
\
\
\
\
\
REPLACE
\b\
\
\
\
\
\
\
Engine Oil
\
\
\
\
\
\
\
Engine Oil Filter
\
\
\
\
\
\
\
Automatic Transmission Fluid & Filter
\
\
\
\
\
\
\
Air Cleaner Filter
\
\
\
\
\
\
\
Spark Plugs
\
\
\
\
\
\
\
Ignition Cables
\
\
\
\
\
\
\
LUBRICATION SPECIFICATIONS
\
\b\
\
\
\b\
\
\
Material Condition Specification
\
\
\
\
\
\
\
Engine Oil Ambient Temperature Above 10 F SAE 15W-40
(
1) (-12 C) To Over 30 F (-1 C)
\
\
\
\
\
Ambient Temperature Less Than SAE 10W-30
0 F (-18 C) To Over 30 F(-1 C)
Page 1025 of 1691
![DODGE RAM 1999 Service Repair Manual \
\
\
\
\
Ambient Temperature Less Than With Block Heate](/img/12/56915/w960_56915-1024.png "DODGE RAM 1999 Service Repair Manual \
\
\
\
\
Ambient Temperature Less Than With Block Heate")
\
\
\
\
\
Ambient Temperature Less Than With Block Heater:
-10 F(-23 C) Up To 0 F (-18 C) SAE 10W-30
Without Block Heater:
SAE 5W-30
\
\
\
\
\
\
\
Engine All 50/50 Mixture Of
Coolant Distilled Water &
Ethylene Glycol
\
\
\
\
\
\
\
Brake Fluid All DOT 3
\
\
\
\
\
\
\
Steering All Mopar Multi-Mileage
Linkage Lubricant
Lubricant
\
\
\
\
\
\
\
Automatic All ATF+2 Type 7176
Transmission
Fluid
\
\
\
\
\
\
\
Wheel Bearing All High Temperature Multi-
Grease -Purporse EP Grease
\
\
\
\
\
\
\
(
1) - SAE 10W-30 engine oil is preferred. Use only API approved
oil with Starburst Symbol.
\
\
\
\
\
\
\
FLUID CAPACITIES
\
\b\
\
\
\b\
\
\
Item Condition Specification (1)
\
\
\
\
\
\
\
Engine Oil Capacity, Upper Safe Mark 10 Qts. (9.5L)
\
\
\
\
\
Capacity, Lower Safe Mark 8 Qts. (7.5L)
\
\
\
\
\
\
\
Engine Drained 26 Qts. (24.5L)
Coolant
\
\
\
\
\
\
\
Automatic 46RE: Dry Fill 17 Qts. (16L)
Transmission
\
\
\
\
\
Fluid 47RE: Dry Fill 17 Qts. (16L)
\
\
\
\
\
\
\
(
1) - Capacities are recommended or calculated levels. Always use
dipstick (if available) to measure level.
\f
\
\
\
\
\
\
\
LUBRICATION SPECIFICATIONS
LUBRICATION SPECIFICATIONS TABLE\
\b\
\
\
\b\
\
\
Material Condition Specification
\
\
\
\
\
\
\
Engine Oil Ambient Temperature Above 10 F SAE 15W-40
(
1) (-12 C) To Over 30 F (-1 C)
\
\
\
\
\
Ambient Temperature Less Than SAE 10W-30
0 F (-18 C) To Over 30 F(-1 C)
\
\
\
\
\
Ambient Temperature Less Than With Block Heater:
-10 F(-23 C) Up To 0 F (-18 C) SAE 10W-30
Without Block Heater:
SAE 5W-30
\
\
\
\
\
\
\
Page 1026 of 1691
Engine All 50/50 Mixture Of
Coolant Distilled Water &
Ethylene Glycol
\
\
\
\
\
\
\
Brake Fluid All DOT 3
\
\
\
\
\
\
\
Automatic All ATF+2 Type 7176
Transmission
Fluid
\
\
\
\
\
\
\
Transfer Case All ATF+2 Type 7176
Fluid Or DEXRON III ATF
\
\
\
\
\
\
\
Manual All 75W-90 Synthc. API GL4
Transmission
Fluid
\
\
\
\
\
\
\
Steering All Mopar Multi-Mileage
Linkage Lubricant
Lubricant
\
\
\
\
\
\
\
Wheel Bearing All High Temperature Multi-
Grease -Purporse EP Grease
\
\
\
\
\
\
\
Rear Axle All Mopar Hypoid Lubricant
Lubricant SAE 80W-90
(
2) GL-5 Gear Lube
\
\
\
\
\
\
\
4x4 Front All Mopar Hypoid Lubricant
Axle SAE 80W-90
Lubricant GL-5 Gear Lube
\
\
\
\
\
\
\
Power All Mopar Power Steering
Steering Fluid Or Equivalant
Fluid (
3) Petroleum Based
\
\
\
\
\
\
\
Clutch All Multipurpose Grease
Linkage NLGI Grade 2 E.P.
Lubricant
\
\
\
\
\
\
\
A/C All R-134a
Refrigerant
\
\
\
\
\
\
\
A/C All Polyalkalene Glycol
Refrigerant SP10 PAG
Oil Refrigerant Oil
\
\
\
\
\
\
\
(
1) - SAE 10W-30 engine oil is preferred for use in all Dodge
trucks. Use only API approved oil with Starburst Symbol.
(
2) - Axles with Limited-Slip Differentials require the use of
a 5% Friction Modifier, such as Mopar Gear Oil Additive
Friction Modifier.
(
3) - Never add gear oil, automatic transmission fluid or
hydroboost power steering fluid.
\f
\
\
\
\
\
\
\
FLUID CAPACITIES
FLUID CAPACITIES TABLE\
\b\
\
\
\b\
\
\
Item Condition Specification (1)
Page 1027 of 1691
![DODGE RAM 1999 Service Repair Manual \
\
\
\
\
\
\
Engine Oil Capacity, Upper Safe Mark](/img/12/56915/w960_56915-1026.png "DODGE RAM 1999 Service Repair Manual \
\
\
\
\
\
\
Engine Oil Capacity, Upper Safe Mark")
\
\
\
\
\
\
\
Engine Oil Capacity, Upper Safe Mark 10 Qts. (9.5L)
\
\
\
\
\
Capacity, Lower Safe Mark 8 Qts. (7.5L)
\
\
\
\
\
\
\
Engine Drained 26 Qts. (24.5L)
Coolant
\
\
\
\
\
\
\
Automatic 46RE: Dry Fill 17 Qts. (16L)
Transmission
\
\
\
\
\
Fluid 47RE: Dry Fill 17 Qts. (16L)
\
\
\
\
\
\
\
Manual NV4500 4 Qts. (3.8L)
Transmission
Fluid
\
\
\
\
\
\
\
Rear Axle DANA 70 Model 267 (2WD) 7 Pts. (3.3L)
Lubricant
\
\
\
\
\
DANA 70 Model 267 (4WD) 7.8 Pts. (3.6L)
\
\
\
\
\
DANA 80 Model 286 (2WD) 6.8.Pts. (3.2L)
\
\
\
\
\
DANA 80 Model 286 (4WD) 10.1 Pts. (4.8L)
\
\
\
\
\
\
\
Rear Axle Model 267 (2WD) 7 Pts. (3.3L)
Limited Slip
\
\
\
\
\
Differential Model 267 (4WD) 7.8 Pts. (3.6L)
\
\
\
\
\
Model 286 (2WD) 6.8 Pts. (3.2L)
\
\
\
\
\
Model 286 (4WD) 10.1 Pts. (4.8L)
\
\
\
\
\
\
\
Front Axle Model 248 7.6 Pts. (3.6L)
Lubricant
\
\
\
\
\
\
\
Transfer Case NV241 HD 6.5 Pts. (3.1L)
Fluid
\
\
\
\
\
\
\
Power Take NV021 4.6 Pts. (2.1L)
Off Adapter
\
\
\
\
\
\
\
Power Drained 2.7 Pts. (1.3L)
Steering
Fluid
\
\
\
\
\
\
\
A/C Charge Capacity 32 Oz. (.9Kg)
Refrigerant
\
\
\
\
\
\
\
Refrigerant A/C System Capacity 7.75 Oz. (230ML)
Oil
\
\
\
\
\
\
\
Fuel Tank Capacity 35 Gal. (132L)
\
\
\
\
\
\
\
(
1) - Capacities are recommended or calculated levels. Always use
dipstick (if available) to measure level.
\f
\
\
\
\
\
\
\
MISCELLANEOUS NOTES
* Once a month, check tire pressure and look for unusual wear
Page 1028 of 1691
or damage.
* Once a month, Inspect battery and clean and tighten
terminals as required.
* Once a month, check fluid levels of coolant reservoir,
brake master cylinder, power steering & transmission.
Add fluids as required.
* Once a month, check all lights and all other electrical items
for correct operation
* Once a month, Inspect and clean wiper blades as required.
* Twice a year, lubricate the external lock cylinders.
Page 1029 of 1691
SC HED ULE D S ER VIC ES - N O RM AL S ER VIC E ( G AS)
1 999 D odge P ic ku p R 1500
1997-99 MAINTENANCE
Chrysler Maintenance & Service Intervals
Gasoline Engines
Normal Service/Light Duty Trucks
DODGE; RAM PICKUP 1500: 3.9L VIN [X]
DODGE; RAM PICKUP 1500/2500: 5.2L VIN [Y]
DODGE; RAM PICKUP 1500/2500: 5.2L VIN [T]
DODGE; RAM PICKUP 1500/2500: 5.9L VIN [Z]
* READ THIS FIRST *
Before preforming maintenance on vehicle, ensure that all
cautions and warnings have been observed to prevent vehicle damage or
personal injury. See CAUTIONS & WARNINGS in MAINTENANCE INFORMATION
article in this section.
Introduction
The frequency of scheduled inspection and maintenance
services in this article are based on normal vehicle usage ONLY. The
following Severe conditions are NOT taken into account:
* Frequent short driving less than 5 Miles (8 Km).
* Frequent driving in dusty conditions.
* Frequent trailer towing.
* Extensive idling.
* More than 50% of your driving is at sustained high speeds
during hot weather, above 90
F (32 C).
If the vehicle is operated mainly under any of these
conditions, this Normal service schedule article is inadequate. DO NOT
USE. Instead, use the Severe service schedule: See
SCHEDULED SERVICES - SEVERE SERVICE (GAS) .
7,500 MILE (12,000 KM)/6 MONTH NORMAL SERVICE
7,500 MILE (12,000 KM)/6 MONTH NORMAL SERVICE\
\
\
\
\
\
\
INSPECT
\b\
\
\
\
\
\
\
Exhaust System
\
\
\
\
\
\
\
Brake Hoses
\
\
\
\
\
\
\
Engine Coolant Level, Hoses & Clamps
\
\
\
\
\
\
\
SERVICE
\b\
\
\
\
\
\
\
Rotate Tires
\
\
\
\
\
\
\
Lubricate Steering Linkage
\
\
\
\
\
\
\
REPLACE
\b\
\
\
\
\
\
\
Engine Oil (
1)
\
\
\
\
\
\
\
(
1) - If mileage is less than 7,500 miles (12,000 KM) yearly,
replace the oil filter at every oil change.
\
\
\
\
\
\
\
Page 1030 of 1691
![DODGE RAM 1999 Service Repair Manual LUBRICATION SPECIFICATIONS
\
\b\
\
\
\b\
\](/img/12/56915/w960_56915-1029.png "DODGE RAM 1999 Service Repair Manual LUBRICATION SPECIFICATIONS
\
\b\
\
\
\b\
\")
LUBRICATION SPECIFICATIONS
\
\b\
\
\
\b\
\
\
Material Condition Specification
\
\
\
\
\
\
\
Engine Oil Ambient Temperature Above 0 F SAE 10W-30
(
1) (-18 C) To Over 100 F (38 C)
\
\
\
\
\
Ambient Temperature Less Than SAE 5W-30
-20 F (-29 C) Up To 32 F (0 C)
\
\
\
\
\
\
\
Engine All 50/50 Mixture Of
Coolant Distilled Water &
Ethylene Glycol
\
\
\
\
\
\
\
Brake Fluid All DOT 3
\
\
\
\
\
\
\
Steering All Mopar Multi-Mileage
Linkage Lubricant
Lubricant
\
\
\
\
\
\
\
(
1) - SAE 10W-30 engine oil is preferred for use in all Dodge
trucks. Use only API approved oil with Starburst Symbol.
\
\
\
\
\
\
\
FLUID CAPACITIES
\
\b\
\
\
\b\
\
\
Item Condition Specification (1)
\
\
\
\
\
\
\
Engine Oil 3.9L: Drained, W/New Filter 4 Qts. (3.8L)
\
\
\
\
\
5.2L: Drained, W/New Filter 5 Qts. (4.7L)
\
\
\
\
\
5.9L: Drained, W/New Filter 5 Qts. (4.7L)
\
\
\
\
\
3.9L: Drained 3.5 Qts. (3.3L)
\
\
\
\
\
5.2L: Drained 4.5 Qts. (4.2L)
\
\
\
\
\
5.9L: Drained 4.5 Qts. (4.2L)
\
\
\
\
\
\
\
Engine 3.9L: Drained 20 Qts. (19L)
Coolant
\
\
\
\
\
5.2L: Drained 20 Qts. (19L)
\
\
\
\
\
5.9L: Drained 20 Qts. (19L)
\
\
\
\
\
\
\
(
1) - Capacities are recommended or calculated levels. Always use
dipstick (if available) to measure level.
\f
\
\
\
\
\
\
\
15,000 MILE (24,000 KM)/12 MONTH NORMAL SERVICE
15,000 MILE (24,000 KM)/12 NORMAL SERVICE\
\
\
\
\
\
\
INSPECT
\b\
\
\
\
\
\
\
Exhaust System
\
\
\
\
\
\
\
Brake Hoses
\
\
\
\
\
\
\
Engine Coolant Level, Hoses & Clamps
\
\
\
\
\
\
\
SERVICE
