compression ratio FIAT BARCHETTA 2003 1.G Owners Manual

ENGINE CODE - BODY VERSION
137
Engine type code Body version code
188A6.000 183SB1AA 01
PAINT IDENTIFICATION
PLATE fig. 4
The plate is fastened to the inside of
the hood seat cover.
It bears the following data:
A- Paint manufacturer
B- Colour name
C- Fiat colour code
D- Respray and touch-up code
fig. 4
P5S00687m
ENGINE
GENERAL FEATURES
Engine Code
Cycle
Number and layout of cylinders
Number of valves per cylinder
Bore x stroke mm
Capacity cm3
Compression ratio
Maximum power output (EEC) kW
HP
at rpm
Peak torque (EEC) Nm
m.kg
at rpm
188A6.000
Otto
4 in line
4
82.0x82.7
1747
10.3 ± 0.15
96
130
6300
158
16.7
4300
