Page 92 of 246
91
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
This diagnostic system indicates the pres-
ence of deteriorated components or sys-
tem malfunctioning (see section “Warn-
ing lights and messages”) by the turning on
of the instrument panel warning light U
(together with the message on the dis-
play).
NOTE The car is provided with a diag-
nostic connector that can be interfaced
with appropriate tools, which makes it
possible to read the error codes stored in
the control units, together with a series of
specific parameters for engine operation
and diagnosis. This test can also be per-
formed by traffic controller agents.IMPORTANT: After a servicing operation
at Fiat Dealership aimed to eliminate mal-
functioning connected to the EOBD sys-
tem, in order to check the system thor-
oughly it could be required to run a bench
test and, if necessary, road tests which
may also call for a long journey.EOBD SYSTEM
The European On Board Diagnostic sys-
tem (EOBD), fitted to engine electronic
control units, allows monitoring and warn-
ing of any malfunction to the electronic
systems that could increase exhaust emis-
sions.
The objective is:
❒To keep system efficiency under con-
trol;
❒Warn when a fault causes emission lev-
els to increase;
❒Warn of the need to replace deterio-
rated components.
083-104 BRAVO GB 10-05-2007 9:10 Pagina 91
Page 142 of 246
141
SAFETY
DEVICES
CORRECT USE
OF THE CAR
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
WARNING
LIGHTS AND
MESSAGES
GENERAL WARNINGS ...................................................... 142
LOW BRAKE FLUID.............................................................. 142
HANDBRAKE ON ................................................................. 142
BRAKE PAD WEAR .............................................................. 142
AIR BAG FAILURE ................................................................. 143
FRONT PASSENGER AIR BAG/
SIDE BAGS DEACTIVATED ......................................................... 143
SEAT BELTS NOT FASTENED ........................................... 144
LOW BATTERY CHARGE .................................................. 144
LOW ENGINE OIL PRESSURE........................................... 144
EXHAUSTED OIL ................................................................. 144
LOW ENGINE OIL LEVEL .................................................. 145
“DUALDRIVE” ELECTRIC POWER
STEERING FAILURE............................................................... 145
“DUALDRIVE” ELECTRIC POWER STEERING
ACTIVATION ........................................................................ 145
ENGINE COOLANT HIGH TEMPERATURE................. 146
INCOMPLETE DOOR LOCKING..................................... 146
BOOT OPEN ........................................................................... 146
BONNET OPEN ..................................................................... 146
GENERIC FAILURE INDICATION .................................. 147
DIESEL PARTICULATE FILTER CLOGGED .................. 147
FUEL RESERVE......................................................................... 148
EOBD/INJECTION SYSTEM FAILURE ............................. 148
ESP SYSTEM ............................................................................ 149
HILL HOLDER FAILURE ..................................................... 149GLOW PLUG WARMING ................................................. 149
GLOW PLUG WARMING FAILURE ................................ 149
WATER IN DIESEL FUEL FILTER ...................................... 150
ABS SYSTEM FAILURE .......................................................... 150
EBD SYSTEM FAILURE ......................................................... 150
CAR PROTECTION SYSTEM
FAILURE FIAT CODE............................................................ 151
ALARM FAILURE .................................................................... 151
THEFT ATTEMPT ................................................................... 151
LOW TYRE PRESSURE ........................................................ 151
CHECK TYRE PRESSURE ................................................... 151
TYRE PRESSURE UNSUITABLE FOR SPEED ................. 151
EXTERNAL LIGHTS FAILURE ............................................ 153
BRAKE LIGHTS FAILURE..................................................... 153
REAR FOGLIGHTS ................................................................ 153
FRONT FOG LIGHTS ........................................................... 153
LEFT-HAND DIRECTION INDICATOR ........................ 153
RIGHT-HAND DIRECTION INDICATOR .................... 153
SIDE/TAILLIGHTS AND LOW BEAMS............................ 154
FOLLOW ME HOME ............................................................ 154
MAIN BEAMS ........................................................................... 154
CRUISE CONTROL ............................................................. 154
POSSIBLE PRESENCE OF ICE ON THE ROAD ............ 154
LIMITED RANGE ................................................................... 154
ASR SYSTEM ........................................................................... 154
SPEED LIMIT EXCEEDED ................................................... 154
SPORT FUNCTION ACTIVATION ................................. 154
W W
A A
R R
N N
I I
N N
G G
L L
I I
G G
H H
T T
S S
A A
N N
D D
M M
E E
S S
S S
A A
G G
E E
S S
141-154 BRAVO GB 10-05-2007 9:17 Pagina 141
Page 149 of 246
148
SAFETY
DEVICES
CORRECT USE
OF THE CAR
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
WARNING
LIGHTS AND
MESSAGES
FUEL RESERVE
(amber)
Turning the ignition key to
MARthe warning light turns on,
but it should go off after few seconds.
The warning light turns on when about 8
litres fuel are left in the tank.
IMPORTANT The warning light flashes to
indicate a failure, contact Fiat Dealership
as soon as possible to have the system
checked.
ç
EOBD/INJECTION
SYSTEM FAILURE
(amber)
Under normal conditions, turning
the ignition key to MAR, the warning light
turns on, but it should go off when the en-
gine has started.
If the warning light stays on or turns on
when travelling, means a fault in the sup-
ply/ignition system which could cause high
emissions at the exhaust, possible lack of
performance, poor handling and high con-
sumption levels.
The display will show the dedicated mes-
sage.
In these conditions it is possible to con-
tinue driving without however requiring
heavy effort or high speed from the en-
gine. Prolonged use of the car with the
warning light on may cause damages. Con-
tact Fiat Dealership as soon as possible.
The warning light turns off if the fault dis-
appears, but it is still stored by the system.
U
If, turning the ignition key to
MAR, the warning light Udoes not turn on or if it turns
on glowing steadily or flashing
when travelling (on certain versions to-
gether with the message on the dis-
play), contact Fiat Dealership as soon
as possible. Warning light
Uoperation
can be checked by traffic agents by
proper equipment. Comply with laws
and regulations of the country where
you are driving.
Petrol engines only
Warning light turning on flashing indicates
the possibility of damage to the catalyst.
If the light flashes, it is necessary to release
the accelerator pedal to lower the speed
of the engine until the warning light stops
flashing; continue the journey at moder-
ate speed, trying to avoid driving condi-
tions that may cause further flashing and
contact Fiat Dealership as soon as possi-
ble.
