FORD EXPEDITION 1998 1.G Owner's Guide

Turn the temperature control to
the desired temperature.
You can get warm or cool air
through either the overhead
registers or floor vent by turning
the auxiliary mode selector:
²Far left for airflow to the
overhead registers.
²Far right for airflow to the rear
floor vent.
²Anywhere between PANEL and
FLOOR to vary airflow between
the outlets.
WARM COOL
HI
COOL WARMPANEL FLOOR
OFF
LO
PANEL FLOOR
Controls and features
31

POSITIONS OF THE IGNITION
1. ACCESSORY, allows the
electrical accessories such as the
radio to operate while the engine
is not running.
2. LOCK, locks the steering wheel,
automatic transmission gearshift
lever and allows key removal.
3. OFF, shuts off the engine and all
accessories without locking the
steering wheel.
4. ON, all electrical circuits
operational. Warning lights
illuminated. Key position when
driving.
5. START, cranks the engine.
Release the key as soon as the
engine starts.
TURN SIGNAL CONTROL
²Push down to activate the left
turn signal.
²Push up to activate the right
turn signal.
3
1
2
5
4
Controls and features
32

SPEED CONTROL
To turn speed control on
²Press ON.
Vehicle speed cannot be controlled
until the vehicle is traveling at or
above 48 km/h (30 mph).
Do not use the speed
control in heavy traffic or
on roads that are winding,
slippery, or unpaved.
Do not shift the gearshift
lever into N (Neutral) with
the speed control on.
To turn speed control off
²Press OFF or
²Turn off the vehicle ignition.
Once speed control is switched off,
the previously programmed set
speed will be erased.
ON
OFF
ON
OFF
Controls and features
33

To set a speed
²Press SET ACC/SET ACCEL.
For speed control to operate,
the speed control must be ON
and the vehicle speed must be
greater than 48 km/h (30 mph).
If you drive up or down a steep
hill, your vehicle speed may vary
momentarily slower or faster than
the set speed. This is normal.
Speed control cannot reduce the
vehicle speed if it increases above
the set speed on a downhill. If
your vehicle speed is faster than
the set speed while driving on a
downhill, you may want to shift to
the next lower gear or apply the
brakes to reduce your vehicle
speed.
If your vehicle slows down more
than 16 km/h (10 mph) below your
set speed on an uphill, your speed
control will disengage. This is
normal. Pressing
RES/RSM/RESUME will re-engage
it.
Do not use the speed
control in heavy traffic or
on roads that are winding,
slippery, or unpaved.
RES
SET
ACCEL
COAST
Controls and features
34

To set a higher set speed
²Press and hold SET ACC/SET
ACCEL. Release the control
when the desired vehicle speed
is reached or
²Press and release SET ACC/SET
ACCEL. Each press will increase
the set speed by 1.6 km/h (1
mph) or
²Accelerate with your accelerator
pedal, then press and release
SET ACC/SET ACCEL.
You can accelerate with the
accelerator pedal at any time
during speed control usage.
Releasing the accelerator pedal will
return your vehicle to the
previously programmed set speed.
To set a lower set speed
²Press and hold CST/COAST.
Release the control when the
desired speed is reached or
²Press and release CST/COAST.
Each press will decrease the set
speed by 1.6 km/h (1 mph) or
RES
SET
ACCEL
COAST
RES
SET
ACCEL
COAST
Controls and features
35

²Depress the brake pedal. When
the desired vehicle speed is
reached, press SET ACC/SET
ACCEL.
To disengage speed control
²Depress the brake pedal.
Disengaging the speed control will
not erase the previously
programmed set speed.
Pressing OFF will erase the
previously programmed set speed.
RES
SET
ACCEL
COAST
ON
OFF
Controls and features
36

To return to a previously set
speed
²Press RES/RSM/RESUME. For
RES/RSM/RESUME to operate,
the vehicle speed must be faster
than 48 km/h (30 mph).
TILT STEERING
Pull the tilt steering control toward
you to move the steering wheel up
or down. Hold the control while
adjusting the wheel to the desired
position, then release the control.
Never adjust the steering
wheel when the vehicle is
moving.
RES
SET
ACCEL
COAST
Controls and features
37

HAZARD FLASHER
For information on the hazard
flasher control, refer toHazard
lights controlin theRoadside
emergencieschapter.
WINDSHIELD WIPER/WASHER
CONTROLS
Rotate the windshield wiper
control to the desired interval, low
or high speed position.
The bars of varying length are for
intermittent wipers. When in this
position rotate the control upward
for fast intervals and downward for
slow intervals.
Push the control on the end of the
stalk to activate washer. Push and
hold for a longer wash cycle.
Rear window wiper/washer
controls
Rotate (and hold as desired) the
rear wiper/washer control to either
position.
From either position, the control
will automatically return to the
INT2 or OFF position.
For rear wiper operation, rotate
the rear window wiper and washer
control to the desired position.
Select:
INT 2 Ð One second interval rear
wiper.
Controls and features
38

INT1ÐTensecond interval rear
wiper.
OFF Ð Rear wiper and washer off.
Speed dependent wipers
When the windshield wiper control
is set on the intermittent settings,
speed-sensitive front wipers
automatically adjust as the
vehicle's speed increases.
HIGH BEAMS
Push forward to activate.
FLASH TO PASS
Pull back to activate and release to
deactivate.
OVERDRIVE CONTROL
Activating overdrive
(Overdrive) is the normal drive
position for the best fuel economy.
The overdrive function allows
automatic upshifts to second, third
and forth gear.
Controls and features
39

Deactivating overdrive
Press the transmission control at
the end of the gearshift lever. The
transmission control indicator light
TCIL (OFF) will illuminate on the
end of the gearshift lever
The transmission will operate in
gears one through three. To return
to normal overdrive mode, press
the transmission control again. The
TCIL (OFF) will no longer be
illuminated.
When you shut off and re-start
your vehicle, the transmission will
automatically return to normal
(Overdrive) mode.
OVERHEAD CONSOLE
The appearance of your vehicle's
overhead console will vary
according to your option package.
Forward storage bin
(if equipped)
Press the release control to open
the storage compartment. The
door will open slightly and can be
moved to full open.
The storage compartment may be
used to secure sunglasses or a
similar object.
OVERDRIVE
OVERDRIVEOFF
Controls and features
40
