FORD EXPLORER 1997 2.G Audio Guide

Make sure only one disc is inserted
in each slot. Each disc must be
inserted with the label surface
upward. You may insert up to six
CDs.
The magazine does not need to be
full for the changer to operate.
Radio power must be turned on to
play the CDs in the changer. The
magazine may be stored in the
glove box when not being used.
The CD magazine may be inserted
or ejected with the radio power
off.
6
5
4
3
2
16 COMPACT DISC MAGAZINECOMPACT
DIGITAL AUDIO
com_rear_seat_controls.02
Controls and features
21

REAR SEAT CONTROLS
(IF EQUIPPED)
The rear seat controls allow the
rear seat passengers to operate the
radio and use headphones.
Adjusting volume
Press the + control to increase
volume.
Press the Ð control to decrease
volume.
From the rear seat controls,
volume control can be set no
higher than the current radio
setting unless the speakers are
turned off. Refer toTurning
speakers on and off.
SEEK
– VOLUME + BAND
MEMORY
SEEK
– VOLUME + BAND
MEMORY
com_rear_adjusting_volume.01
com_rear_speakers.01
Controls and features
22

Turning the speakers on and off
Press to turn the speakers on or
off.
Using headphones
Plug a 3.5 mm headphone (not
included) into the
jack to
operate headphones with speakers
turned off.
Plug headphone jack into the
jack to operate
headphones with the speakers
turned on.
AM or FM select
Push the BAND control to change
the frequency band between AM,
FM1 and FM2.
Memory preset button
Push the MEMORY control to
access the station you have set
into memory preset 1.
SEEK
– VOLUME + BAND
MEMORY
SEEK
– VOLUME + BAND
MEMORY
com_rear_using_headphones.01
com_rear_am-fm_select.01 com_rear_memory_preset.01
Controls and features
23

Push the MEMORY control
successively to access stations 1±6.
Seek function
Press the
side of the SEEK
control to seek the next highest
radio station.
Press the
side of the SEEK
control the next lower radio
station.
In tape mode, use the SEEK
function to access the next
or
previous
selection.
In CD mode (if equipped), use the
SEEK function to access the next
or previousselection.
DISPLAY
The display screen gives
information on the status of the
audio system.
SEEK
– VOLUME + BAND
MEMORY
FM 1ST
com_rear_seek_function.01
com_display.01
Display
24

AUDIO SYSTEM CARE AND
CLEANING
Troubleshooting the CD
changer
The laser beam used in the
compact disc player is
harmful to the eyes. Do not
attempt to disassemble the case.
If sound skips:
²You may be traveling on a rough
road, playing badly scratched
discs or the disc may be dirty.
Skipping will not scratch the
discs or damage the player.
If changer does not work:
²A disc is already loaded where
you want to insert disc.
²The disc is inserted with the
label surface downward.
²The disc is dusty or defective.
²The player's internal
temperature is above 75ÉC
(167ÉF). Allow the player to
cool down before operating.
²A disc with format and
dimensions not within industry
standards is inserted.
Cleaning compact discs
Inspect all discs for contamination
before playing. If necessary, clean
discs only with an approved CD
cleaner and wipe the center out to
the edge. Do not use circular
motion.
uno_care_clean_title
com_troubleshooting_cd.01
com_cleaning_cds.01
com_cd_and_changer_care.01
Care and cleaning
25

CD and CD changer care
²Handle discs by their edges only.
Never touch the playing surface.
²Do not expose discs to direct
sunlight or heat sources for
extended periods of time.
²Do not insert more than one
disc into each slot of the CD
changer magazine.
Cleaning cassette player
Clean the tape player head with a
cassette cleaning cartridge after
ten to twelve hours of play to
maintain the best sound and
operation.
Cassette and cassette player
care
²Use only cassettes that are 90
minutes long or less.
²Do not expose tapes to direct
sunlight, high humidity, extreme
heat or extreme cold. Allow
tapes that may have been
exposed to extreme
temperatures to reach a
moderate temperature before
playing.
²Tighten very loose tapes by
inserting a finger or pencil into
the hole and turning the hub.
²Remove loose labels before
inserting tapes.
²Do not leave tapes in the
cassette player for a long time
when not being played.
com_cleaning_cassette.01
com_cassette_and_player.01
com_radio_frequency_info.01
Radio frequency information
26

RADIO FREQUENCY
INFORMATION
The Federal Communications
Commission (FCC) and the
Canadian Radio and
Telecommunications
Communications (CRTC) establish
the frequencies AM and FM
stations may use for their
broadcasts. Allowable frequencies
are:
AM 530, 540±1600, 1610 kHz steps
FM 87.9, 88.1±107.1, 107.9 Mhz
steps
Not all frequencies are used in a
given area.
RADIO RECEPTION FACTORS
Three factors can affect radio
reception:
²Distance/strength. The further
an FM station travels, the
weaker it is. The listenable
range of the average FM station
is approximately 40 km (24
miles). This range can be
affected by ªsignal modulation.º
Signal modulation is a process
radio stations use to increase
their strength/volume relative to
other stations.
²Terrain. Hills, mountains and tall
buildings between your vehicle's
antenna and the radio station
signal can cause FM reception
problems. Static can be caused
on AM stations by power lines,
electric fences, traffic lights,
driving under bridges and
com_radio_reception_factors.01
Radio frequency information
27

thunderstorms. Moving away
from an interfering structure
(out of its ªshadowº) returns
your reception to normal.
²Station overload. Weak stations
are sometimes captured by
stronger stations when you pass
a broadcast tower. A stronger
station may temporarily
overtake a weaker station and
play while the weak station
frequency is displayed.
The audio system automatically
switches to single channel
reception if it will improve the
reception of a station normally
received in stereo.
WARRANTIES AND SERVICE
Refer to the ªWarranty Guideº for
audio system warranty information.
If service is necessary, see your
dealer or a qualified technician.
com_warranties_and_service.01
Warranties and service
28

AM/FM select ................................7
Audio power ..................................6
Bass adjust ..................................13
CD select .....................................14
Clock ............................................18
Compact disc changer
care ............................................26
operation ...................................20
troubleshooting .........................25
Compression adjust ....................17
Display .........................................24
Dolbyt
noise reduction .........................17
Electronic sound system ...........2,4
Fast forward function .................15Radio frequency
information ................................27
reception ...................................27
Rewind function ..........................15
Scan function ..............................10
Seek function ................................9
Speaker balance adjust ..............13
Stations
selecting ....................................11
Tape direction select ..................16
Tape select ..................................14
Treble adjust ...............................13
Tune adjust ...................................8
Warranties
radio ...........................................28
Index
29
