Page 3 of 288
*
[PI00425( ALL)05/95]
Table of ContentsIntroduction ....................................................1
Instrumentation ..............................................7
Electronic Sound Systems .........................21
Controls and Features ................................47
Seating and Safety Restraints ..................89
Starting .........................................................125
Driving .........................................................133
Roadside Emergencies ..............................155
Maintenance and Care .............................183
Capacities and Specifications .................237
Reporting Safety Defects
(U.S. Only) ..................................................243
Customer Assistance .................................245
Accessories ..................................................257
Quick Index ................................................265
Index .............................................................275
Service Station Information ....................292
File:01prpip.ex
Update:Wed Jun 19 14:48:25 1996
Page 6 of 288
Introductory Information
3
*
[IN01080(ALL)08/95]
To use theIndex, turn to the back of the book and search in the
alphabetical listing for the word that best describes the
information you need. If the word you chose is not listed, think
of other related words and look them up. We have designed the
Index so that you can find information under a technical term.
%*
[IN01090(ALL)08/95]
Canadian Owners Ð French Version
*
[IN01100(ALL)08/95]
French Owner Guides can be obtained from your dealer or by
writing to Ford Motor Company of Canada, Limited, Service
Publications, P.O. Box 1580, Station B, Mississauga, Ontario L4Y
4G3.
%*
[IN02400(ALL)04/95]
Your Maintenance Schedule and Record
Booklet
*
[IN02500(ALL)03/95]
TheMaintenance Schedule and Recordbooklet lists the services
that are most important for keeping your vehicle in good
condition. A record log is also provided to help you keep track
of all services performed.
%*
[IN02600(ALL)01/95]
About the Warranties
*
[IN02700(ALL)04/95]
Your vehicle is covered by three types of warranties:Basic
Vehicle Warranty,Extended Warrantieson certain parts, and
Emissions Warranties.
%*
[IN03100(ALL)03/95]
Read yourWarranty Information Bookletcarefully to find out
about your vehicle's warranties and your basic rights and
responsibilities.
*
[IN03250(ALL)03/95]
If you lose yourWarranty Information Booklet,you can get a new
one free of charge. Contact any Ford or Lincoln-Mercury dealer,
or refer to the addresses and phone numbers on the first page
of this owner guide.
File:02uninx.ex
Update:Thu Feb 29 08:58:20 1996
Page 23 of 288
19
*
[IS07300(ALL)04/96]
5. Refer toAdding Engine Coolantin the
Maintenance and Carechapter. Add as much
coolant as your engine needs. If the engine
continues to overheat, have the cooling
system serviced.
%*
[IS07500(ALL)03/96]
Speedometer
*
[IS07600(ALL)03/96]
The speedometer tells you how many miles
(kilometers) per hour your vehicle is moving.
%*
[IS07700(ALL)03/96]
Odometer
*
[IS07800(ALL)01/96]
The odometer tells you the total number of miles
(kilometers) your vehicle has been driven.
%*
[IS08000(ALL)01/96]
Trip Odometer
[IS08100(ALL)01/96]
Use the trip odometer to track your mileage.
Simply set the trip odometer to zero by pressing
the reset button.
%*
[IS09000(ALL)03/96]
Tachometer
[IS09100(ALL)01/96]
The tachometer indicates approximate engine
revolutions per minute, and is located on the
right-hand side of the instrument cluster. The
tachometer pointer may move slightly when the
key is placed in the ACC or ON position, with
the engine off. This pointer movement is normal,
and will not affect the accuracy of the
tachometer once the engine is running.
File:03prisp.ex
Update:Thu May 16 09:43:45 1996
Page 107 of 288
104
*
[SS10300(ALL)02/96]
RWARNING
Failure to follow these instructions will
affect the performance of the safety belts
and increase the risk of personal injury.
%
*
[SS10400(ALL)03/96]
Safety Belt Maintenance
*
[SS10500(ALL)02/96]
Check the safety belt systems periodically to
make sure that they work properly and are not
damaged.
%*
[SS10600(ALL)05/96]
All safety belt assemblies, including retractors,
buckles, front seat belt buckle support assemblies
(slide bar) (if equipped), shoulder belt height
adjusters (if equipped), child safety seat tether
bracket assemblies (if equipped), and attaching
hardware, should be inspected after any
collision. Ford recommends that all safety belt
assemblies used in vehicles involved in a
collision be replaced. However, if the collision
was minor and a qualified technician finds that
the belts do not show damage and continue to
operate properly, they do not need to be
replaced. Safety belt assemblies not in use
during a collision should also be inspected and
replaced if either damage or improper operation
is noted.
%
*
[SS10900(ALL)05/96]
Air Bag Supplemental Restraint
System (SRS)
*
[SS11000(ALL)05/96]
Important Air Bag Precautions
*
[SS11100(ALL)05/96]
Your vehicle is equipped with a supplemental
restraint system designed to work with the
safety belts to help protect you and your right
front seat passenger in the event of a collision.
The Air Bag Supplemental Restraint System is
primarily designed to reduce certain upper body
injuries.
File:06prssp.ex
Update:Mon Jun 3 10:07:19 1996
Page 113 of 288
110
*
[SS12200(ALL)05/96]
Determining if System Is Operational
*
[SS12250(ALL)05/96]
The Air Bag Supplemental Restraint System uses
a readiness light and a tone to indicate the
condition of the system. The readiness light is in
the instrument cluster. When you turn the
ignition key to ON, this light will illuminate for
approximately six (6) seconds and then turn off.
This indicates that the system is operating
normally. NOTE: Routine maintenance of the air
bag system is not required.
%*
[SS12300(ALL)05/96]
A problem with the system is indicated by one
or more of the following:
*
[SS12350(ALL)05/96]
q
the readiness light will either flash or stay lit,
*
[SS12400(ALL)05/96]
q
the readiness light will not light immediately
after ignition is turned on,
%*
[SS12450(ALL)05/96]
q
a group of five beeps will be heard. The tone
pattern will repeat periodically until the
problem and light are repaired.
*
[SS12500(ALL)05/96]
If any of these things happen, even
intermittently, have the Air Bag Supplemental
Restraint System serviced at your Ford or
Lincoln-Mercury dealer immediately. Unless
serviced, the system may not function properly
in the event of a collision.
*
[SS12550(ALL)05/96]
Disposal of Air Bags and Air Bag
Equipped Vehicles
*
[SS12600(ALL)05/96]
For disposal of air bags or air bag equipped
vehicles, see your local Ford or Lincoln-Mercury
dealer. Air bags MUST BE disposed of by
qualified personnel.
File:06prssp.ex
Update:Mon Jun 3 10:07:19 1996
Page 177 of 288
174 [ER09990(ALL)04/96]Your vehicle has metric (12 mm) wheel studs
and lug nuts. During wheel removal and
replacement, make certain that you use the same
lug nuts to reinstall the wheel or replace them
with nuts of the same metric size and threading.
*
[ER10000(ALL)01/96]
RWARNING
Installation of an English thread nut on a
metric stud (or vice-versa) will not
properly secure the wheel to the hub.
Damaged studs may result in wheel
separation and possible injury.
*
[ER10200(ALL)03/96]
5. Lower the vehicle by turning the jack handle
counterclockwise.
[ER10300(ALL)01/96]
6. Remove the jack and fully tighten the lug
nuts in the order shown in the illustration
under step 2.
[ER10700(ALL)01/96]
7. Put the tire, jack, and wrench away.
[ER10750(ALL)01/96]
8. Unblock the wheels.
%
*
[ER11000(ALL)02/96]
Jump-Starting Your Vehicle
[ER11100(ALL)01/96]
Your vehicle has a Motorcraft maintenance-free
battery. Your vehicle's battery may die if you
leave the lights on or any electrical equipment
on after you turn the engine off. If this happens,
you may be able to jump-start from a booster
battery to start your vehicle.
*
[ER11150(ALL)02/96]
RWARNING
The gases around the battery can explode
if exposed to flames, sparks, or lit
cigarettes. An explosion could result in
injury or vehicle damage.
File:10prerp.ex
Update:Thu Jun 13 09:57:39 1996
Page 182 of 288
179
*
[ER14100(ALL)03/96]
If you need to replace your battery, seeBattery
in theMaintenance and Carechapter.
%
*
[ER15000(ALL)04/96]
Towing Your Vehicle
*
[ER15100(ALL)03/96]
If you need to have your vehicle towed, contact
a professional towing service or, if you are a
member, your roadside assistance center.
Recommended towing options include wheel lift
towing or flat bed towing.
[ER15200(ALL)01/96]
half page art:0032391-A*
[ER15300(ALL)01/96]
When calling for a tow truck, tell the operator
what kind of vehicle you have. A towing
manual is available from Ford Motor Company
for all authorized tow truck operators. Have
your tow truck driver refer to this manual for
the proper hook-up and towing procedures for
your vehicle.
File:10prerp.ex
Update:Thu Jun 13 09:57:39 1996
Page 185 of 288
183
Maintenance and Care
%*
[MC00300(ALL)01/96]
Service Made Easy
*
[MC00400(ALL)01/96]
Ford has two goals for servicing your vehicle.
*
[MC00500(ALL)01/96]
1. When we can, we design parts that do not
need to be serviced.
*
[MC00600(ALL)01/96]
2. We want to make servicing your vehicle as
easy as possible. To help you:
*
[MC00700(ALL)01/96]
q
We highlight do-it-yourself items in yellow in
the engine compartment so that you can find
them easily.
*
[MC00800(ALL)03/96]
q
When possible, we design parts that can be
replaced without tools.
*
[MC00900(ALL)02/96]
q
We give you a Maintenance Schedule that
makes tracking routine service for your
vehicle easy. The maintenance schedule is
located in theMaintenance Schedulebooklet.
*
[MC00925(ALL)01/96]
This chapter tells you about the basic parts that
you need to check and service regularly.
*
[MC00930(ALL)01/96]
If your vehicle needs professional servicing, your
dealership can provide the parts and service
required. Check yourWarranty Information Booklet
to find out which parts and services are covered.
Also see theCustomer Assistancechapter of this
Owner Guide.
*
[MC01000(ALL)03/96]
Ford Motor Company recommends that you
perform the Owner Maintenance Checks listed in
theMaintenance Schedulebooklet. These services
are important for the proper operation of your
vehicle. In addition to the conditions listed in
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996
Page 186 of 288
184the Owner Maintenance Checklist, be alert for
any unusual noise, vibration, or other indication
that your vehicle may need service. If you do
notice something unusual, see that your vehicle
is serviced promptly.
*
[MC01100(ALL)01/96]
Use only recommended fuels, lubricants, fluids,
and service parts that meet Ford Motor
Company specifications. Motorcraft parts are
designed and built to provide the best
performance in your vehicle. Using these parts
for replacement is your assurance that Ford-built
quality stays in your vehicle.
%*
[MC01150(ALL)05/96]
NOTE: Always dispose of used automotive
fluids in a responsible manner. Follow
your community's standards for
disposing of these types of fluids. Call
your local recycling center to find out
about recycling automotive fluids.
%
*
[MC01600(ALL)01/96]
Precautions When Servicing Your
Vehicle
*
[MC01700(ALL)01/96]
Be especially careful when inspecting or
servicing your vehicle. Here are some general
precautions for your safety:
%*
[MC01800(ALL)01/96]
q
Do not work on a hot engine. The engine
cooling fan may come on unexpectedly.
Always turn the engine off and let it cool.
*
[MC01850(ALL)05/96]
RWARNING
The cooling fan is automatic and may
come on at any time. Always disconnect
the negative terminal of the battery before
working near the fan.
*
[MC01900(ALL)01/96]
q
If you must work with the engine running,
avoid wearing loose clothing or jewelry that
could get caught in moving parts. Take
appropriate precautions with long hair.
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996
Page 192 of 288
190
%*
[MC05600(ALL)01/96]
Engine Oil Recommendations
*
[MC05700(ALL)01/96]
We recommend using Motorcraft oil or an
equivalent oil meeting Ford Specification
WSS-M2C153-F and displaying the American
Petroleum Institute CERTIFICATION MARK on
the front of the container.
*
[MC05800(ALL)01/96]
one third page art:0060021-E
The API Certification Mark
*
[MC05900(ALL)01/96]
Neveruse:
*
[MC06000(ALL)01/96]
q
ªNon-Detergentº oils
*
[MC06100(ALL)02/96]
q
Oils labeled API SA, SB, SC, SD, SE, SF or SG
%*
[MC06200(ALL)01/96]
q
Additional engine oil additives, oil treatments
or engine treatments
%*
[MC06300(ALL)03/96]
Engine oils with anSAE 5W-30viscosity are
PREFERREDfor your vehicle. They provide the
best engine performance, fuel economy and
engine protection for all climates down to-15ÊF
(-25ÊC).
%*
[MC06400(ALL)03/96]
Synthetic engine oils which are CERTIFIED and
of the preferred viscosity may be used in your
engine. The engine oil and oil filter must still be
changed according to the maintenance schedule.
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996
